Vulcan-Hart GCO2D User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780
ISO9001
Vulcan-Hart Co. MODEL: GCO2D
Half Size Gas Convection Oven
STANDARD FEATURES
■Stainless steel front, sides, top and rear enclosure panel.
■Stainless steel door with double pane window.
■Cool to the touch oven door handle.
■Stainless steel oven door gaskets.
■25,000 BTU/hr. input.
■Electronic spark ignition system.
■Solid state temperature control adjusts from 200° to 500°F.
■60 minute electric timer with time expired buzzer.
■1/2H.P. single speed fan motor.
■Oven cool switch for rapid cool down when door is open.
■Oven interior liners are porcelain on steel.
■Nine position rack guide with five nickel plated racks.
■4" adjustable chrome plated legs.
■Manual shut-off valve and gas pressure regulator. 3/4" gas
connection required.
■Requires 120/60/1 power supply. 8 amps total draw.
Furnished with cord and plug.
■One year limited parts and labor warranty.
OPTIONS AT EXTRA COST
Set of four 163/4" stainless steel legs with adjustable feet
and stack set.
Set of four 163/4" stainless steel legs with casters and
stack set.
34" stainless steel stand with legs and nine position rack
storage capacity.
34" stainless steel stand with casters and nine position rack
storage capacity.
Additional oven racks.
Rack hanger.
Second year extended limited parts and labor warranty.
F-32192 (03-08)
MODEL GCO2D
HALF SIZE GAS CONVECTION OVEN
SPECIFICATIONS:
Half size gas convection oven, Model No. GCO2D, manufac-
tured by Vulcan-Hart. Porcelain enamel on steel oven interior
measures 151/4"w x 21"d x 20"h. Furnished with nine position
nickel plated rack guides and five nickel plated racks
measuring 143/8" x 207/8". Heated by 25,000 BTU/hr. gas burner.
Electronic spark ignition system. Stainless steel front, sides, top
and rear enclosure panel. Insulation applied to the top, rear,
both sides, bottom and door. Stainless steel door with double
pane window. Solid state temperature controls adjustable from
200° to 500°F. 60 minute electrical timer with continuous
sounding buzzer. Single speed 1/2H.P. permanently lubricated
oven blower-motor. Requires 120/60/1 power supply. 8 amps
total draw. Furnished with cord and plug.
Exterior dimensions: 30"w x 281/4"d x 305/8"h on 4" legs.
CSA design certified for use in the U.S. and Canada. NSF listed.
Specify type of gas and finish when ordering. Specify
altitude if above 2,000 ft.
Shown on optional S/S stand with casters

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
MODEL GCO2D
HALF SIZE GAS CONVECTION OVEN
F-32192 (03-08)
IMPORTANT
1. A gas pressure regulator sized for this unit is included. Natural gas 3.5" W.C., propane gas 10.0" W.C.
2. These units are manufactured for installation in accordance with ANSZ223.1 (latest edition), National Fuel Gas Code. Copies
may be obtained from American Gas Association Inc., Accredited Standards Committee Z223, 400 N. Capitol St. NW,
Washington, DC 20001 or the Secretary Standards Council, NFPA, 1 Batterymarch Park, Quincy, MA 02169-7471.
3. This appliance must be installed with a 3" clearance at both sides and the rear adjacent to combustible or noncombustible
construction.
4. This appliance must be installed on 4" legs or a leg stand.
5. This appliance is manufactured for commercial installation only and is not intended for home use.
