Vulcan-Hart VC66GC ML-136495 User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780
ISO9001
Vulcan-Hart Co.
F-32438 (03-08)
MODEL: VC66G Double Deck, Deep Depth Gas Convection Ovens
VC66G SERIES
DOUBLE DECK, DEEP DEPTH
GAS CONVECTION OVENS
SPECIFICATIONS:
Double section, deep depth gas convection oven, Vulcan-Hart
Model No. (VC66GD) (VC66GC). Stainless steel front, sides, top
and legs. Independently operated stainless steel doors with
double pane windows. Non-sag insulation applied to the top,
rear, sides, bottom and doors. Porcelain enamel on steel oven
interiors measures 29"w x 261/8"d x 20"h. Two interior oven lights
per section. Five nickel plated oven racks per section measure
281/4" x 241/2". Eleven position nickel plated rack guides with
positive rack stops. One 44,000 BTU/hr. burner per section.
88,000 BTU/hr. total input. Electronic spark igniters. Furnished
with a two speed 1/2H.P. oven blower-motor per section. Oven
cool switch for rapid cool down. 120 volt, 60 Hz, 1 ph power supply
required. 6' cord and plug. 9 amps total draw.
Exterior dimensions: 40"w x 461/4"d x 70"h on 8" legs. Depth
measurement includes door handles.
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VC66GD Solid state temperature controls adjust from 150°
to 500°F. 60 minute timer with audible alarm.
VC66GC Computer controls with digital time and temperature
readouts. 99-hour timer with audible alarm. Roast
and Hold cycle. Six preset menu selections.
Shelf I.D. programming.
STANDARD FEATURES
■Stainless steel front, sides, top and legs.
■Independently operated stainless steel doors with double
pane windows.
■44,000 BTU/hr. burner per section. 88,000 BTU/hr. total input.
■Electronic spark igniters.
■1/2H.P. two speed oven blower-motor. 120/60/1 with 6' cord
and plug. 9 amps per section. 18 amps total draw.
■Oven cool switch for rapid cool down.
■Porcelain enamel on steel oven interiors.
■Five nickel plated oven racks with eleven rack positions per
section.
■3/4" rear gas connection with combination gas pressure
regulator and safety solenoid system.
■One year limited parts and labor warranty.
OPTIONS
Five hour timer in place of 60 minute timer (Model VC66GD).
Roast & Hold control (Model VC66GD).
Casters.
Stainless steel rear enclosure.
Second year extended limited parts and labor warranty.
ACCESSORIES
Extra oven rack(s).
Rack hanger(s).
Stainless steel drip pan.
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
Down draft flue diverter for direct vent connection.
Model VC66GD

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32438 (03-08)
VC66G SERIES
DOUBLE DECK, DEEP DEPTH
GAS CONVECTION OVENS
DEPTH APPROX.
(INCLUDES BTU/HR. TOTAL SHP. WT.
MODEL NO. WIDTH HANDLES) HEIGHT PER OVEN BTU/HR. ELECTRICAL LBS. KG
VC66G 40" 461/4" 70" 44,000 88,000 120/60/1 1000 454
IMPORTANT
1. A combination gas pressure regulator and safety solenoid
system is included in this unit. Natural gas is 3.5" W.C.,
Propane gas is 10.0" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing to
the National Fire Protection Association, Batterymarch Park,
Quincy, MA 02289. When writing, refer to NFPA No. 96.
3. These units are manufactured for installation in accordance
with ANSZ223.1 (latest edition), National Fuel Gas Code.
Copies may be obtained from American Gas Association Inc.,
Accredited Standards Committee Z223, 400 N. Capitol St.
NW, Washington, DC 20001 or the Secretary Standards
Council, NFPA, 1 Batterymarch Park, Quincy, MA 02169-
7471.
4. Clearances: Combustible Non-combustible
Rear 2" 2"
Right Side 4" 4"
Left Side 1" 0"
5. This appliance is manufactured for commercial installation
only and is not intended for home use.
