VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
C.S.I. Section 11420
A2780
ISO9001
Vulcan-Hart Co.
F-32205 (03-08)
MODEL: ECO22D Double Deck Half Size Electric Convection Oven
STANDARD FEATURES
■Stainless steel front, sides, top and rear enclosure panel.
■Stainless steel doors with double pane window.
■Cool to the touch oven door handles.
■Stainless steel oven door gaskets.
■11 KW total input (5.5 KW per section).
■Solid state temperature controls adjust from 200° to 500°F.
■60 minute electric timers with time expired buzzer.
■1/3H.P. two speed fan motor per deck.
■Oven cool switch for rapid cool down when door is open.
■Oven interior liners are porcelain on steel.
■Nine position rack guides with five nickel plated racks
per section.
■163/4" adjustable stainless steel legs.
■Requires 208/240 volt, 60 Hz, 1 or 3 phase power supply.
■One year limited parts and labor warranty.
OPTIONS
163/4" adjustable stainless steel legs with casters.
Additional oven racks.
Rack hanger(s).
Second year extended limited parts and labor warranty.
MODEL ECO22D
DOUBLE DECK HALF SIZE ELECTRIC
CONVECTION OVEN
SPECIFICATIONS:
Double deck half size electric convection oven, Model No.
ECO22D, Manufactured by Vulcan Hart. Each porcelain enamel
on steel oven interior measures 151/4"w x 21"d x 20"h.
Furnished with nine position nickel plated rack guides and five
nickel plated racks measuring 143/8" x 207/8" per section.
Heated by enclosed tubular heating elements rated at 5.5 KW
per section. 11 KW total input. Stainless steel front, sides, top
and rear enclosure panel. Insulation applied to the top, rear,
both sides, bottom and door. Stainless steel doors with double
pane window. Solid state temperature controls adjustable
from 200° to 500°F. 60 minute electrical timers with continu-
ous sounding buzzer. Two speed 1/3H.P. permanently
lubricated oven blower motors. Requires 208/240 volt, 60 Hz,
1 or 3 phase power supply.
Exterior dimensions: 30"w x 281/4"d x 683/8"h on 163/4" legs.
NSF listed. U L listed. U L listed to Canadian safety standards.
Model ECO22D
Shown on optional casters
