Vulcan-Hart GH72 User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
0
8
7
2
A
1
0
0
9
O
S
I
.
o
C
t
r
a
H
-
n
a
c
l
u
V
F-31515 (05-06)
SPECIFICATIONS
Heavy duty even heat top gas range with oven, Vulcan-Hart
Model No. GH72. Stainless steel body and 6" adjustable legs.
11⁄4" diameter front gas manifold. Two polished cast iron hot
top sections measure 17"w x 2313⁄16"d. Ceramic re brick under
hot tops. Four 20,000 BTU/hr. burners, two per hot top section.
One manual gas control valve per section. Pilot igntion system.
Oven interior measures 26"w x 28"d x 14"h. Porcelain enamel on
steel hearth, door and side liners. One oven rack and two rack
positions. 50,000 BTU/hr. heavy cast "Flame Retention" burner
with pilot ignition. Thermostat adjusts from 150° to 500°F.
Controls located in the cool zone.
Exterior dimensions: 34"w x 391⁄8"d x 36" working height on
6" legs.
CSA design certied. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
GH72 Standard Oven
GH72C Convection Oven
STANDARD FEATURES
Stainless steel body and 6" adjustable legs.
11⁄4" diameter front gas manifold.
Two polished cast iron hot top sections measure
17"w x 23 13⁄16"d. Ceramic re brick under hot tops. Four
20,000 BTU/hr. burners, two per hot top section. One man-
ual gas control valve per section. Pilot ignition system.
Oven controls located in the cool zone.
Oven interior measures 26"w x 28"d x 14"h. Porcelain enamel
on steel hearth, door and side liners. One oven rack and two
rack positions. 50,000 BTU/hr. "Flame Retention" burner with
pilot ignition. Thermostat adjusts from 150° to 500°F.
One year limited parts and labor warranty.
OPTIONS
Snorkel TM convection oven in place of standard oven. Add
sux "C" to the model number. Porcelain enamel on steel
interior measures 26 1⁄8"w x 22 3⁄32"d x 14 1⁄8"h. Three oven racks
and ve rack positions. 32,000 BTU/hr. burner with pilot
ignition. Thermostat adjusts from 200° to 500°F. 1⁄4HP blower
motor with 7 foot power cord and plug. 120/60/1, 5 amps.
Stainless steel back nishing panel.
Common front top ledge up to 68" wide. (Not for use on griddle
tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s). (No charge.)
15/8" stainless steel toe base - 31 5⁄8" working height.
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Cooling fan for Snorkel TM convection oven motor. Required
when unit is installed with a back nishing panel or a toe base.
Rear gas connection. (Reference spec sheet F-31525.)
Second year extended limited parts and labor warranty.
Model GH72 shown with single deck high shelf
2
7
H
G
:
L
E
D
O
Mg
n
a
R
s
a
G
y
t
u
D
y
v
a
e
H
p
o
T
t
a
e
H
n
e
v
Ee
MODEL GH72
EVEN HEAT TOP HEAVY DUTY GAS RANGE
GH72S Storage Base
Cabinet storage base in place of standard oven. Add the
suux “S” to the model number.

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specications without notice.
F-31515 (05-06)
MODEL GH72
EVEN HEAT TOP HEAVY DUTY GAS RANGE
ACCESSORIES
17" high stainless steel backguard. (Common backguards
available up to 102" wide.)
23" high stainless steel single deck high shelf. (Common high
shelves available up to 72" wide.)
35" high stainless steel double deck high shelf. (Common high
shelves available up to 72" wide.)
Additional oven rack(s).
Gas pressure regulator (specify size and type of gas).
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
IMPORTANT
1. A gas pressure regulator suitable for battery or single unit
application must be furnished and installed. Natural gas 6.0"
W.C., propane gas 10.0" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing to
the National Fire Protection Association, Batterymarch Park,
Quincy, MA 02269. When writing refer to NFPA No. 96.
3. These units are manufactured for installation in accordance
with ANSZ223.1a (latest edition), National Fuel Gas Code.
Copies may be obtained from the American Gas Association,
1515 Wilson Blvd., Arlington, VA 22209.
4. All models require a 6" (152 mm) clearance at both sides and
rear adjacent to combustible construction.
5. For proper ueing a backguard or high shelf must be installed
with each unit. Please refer to spec sheet F31537 for specic
styles and sizes.
6. This appliance is manufactured for commercial installation
only and is not intended for home use.
TOP VIEW
GH72C
SIDE VIEW
GH72
SIDE VIEW
GH72 & GH72C
FRONT VIEW
1
⁄ 8 " 36"
LESS LEGS
MODEL
GH72
GH72C
GH72S
GAS RATED INPUT BTU/hr.
TOP: 80,000
TOP: 80,000
TOP: 80,000
OVEN: 50,000
OVEN: 32,000
____________
TOTAL: 130,000
TOTAL: 112,000
TOTAL: 80,000
34"39
WIDTH HEIGHT WKG. HEIGHT APPX. SHP. WT.
630 lbs./286 kg
690 lbs./313 kg
UNKNOWN
