VWR 82007-202 User manual

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
VWR Mini Blot Mixer
INSTRUCTION MANUAL
North American Catalog Number
US Cord(120V): 82007-202
US Cord(230V): 83007-210
European Catalogue Number(s):
Euro Plug: 700-0245
Swiss Plug: 700-0247
UK Plug: 700-0246
Version: 3
Issued: 06 / 20 / 2014

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Legal Address of Manufacturer
United States Europe
VWR International VWR International bvba/sprl
1310 Goshen Parkway Researchpark Hassrode 2020
West Chester, PA 19380 Geldenaaksebaan 464
800-932-5000 3001 Leuven
http://www.vwr.com + 32 16 385011
http://www.be.vwr.com
Country of origin
USA

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Table of Contents
Safety information 4
Package Contents 4
Unpacking 4
Installation 5
Intended Use 5
Symbols and conventions 5
Specifications 6
Description of buttons and switches 6
Operation 7
Troubleshooting 7
General maintenance 7
User replaceable accessories and spare parts 8
Technical Service 8
Warranty 8
Disposal 9
Local VWR offices in Europe 10

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Safety Information
Please follow the guidelines below, and read this manual in its entirety to ensure safe operation of the
unit.
• Hazardous samples should be mixed only in appropriate containment vessels.
• Do not mix flammable or explosive samples!
To avoid electrical shock:
• Do not use the mixer near water sources. Be sure that water doesn’t get on the device, especially
during the cleaning procedures!
Avoiding Damage to the Instrument
• Do not expose the mixer to aggressive vapors (e.g. organic solvents).
Package Contents
Description Quantity
VWR Mini Blot Mixer 1
Small Blot Box 1
Large Blot Box 1
Instruction Manual 1
Warranty Card 1
Unpacking
Before starting the installation, carefully examine the mixer.
• Open the box and carefully remove the padding. Check that the mixer has not been visibly damaged during
transportation. Keep the packing material until you are sure that the mixer works properly.
• Carefully lift the device out of the box.
• Be sure that the following information is included on the serial label located on the bottom of the unit: Serial Number,
Product number, Electrical rating.
• Check that the power cord plug has a pin configuration that matches a wall socket according to the local standard.
Should any kind of damage have occurred during transportation, contact the carrier immediately. The carrier is responsible
for shipping damage.

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Installation
Place the mixer on a horizontal, level and stable surface. Connect the plug end of the cord to a grounded wall socket. Avoid
lines on which powerful electric motors, refrigerators and similar devices are connected. Use the on/off switch to control
power to the mixer.
Use caution when plugging into a grounded wall socket!
Do not touch plug with wet hands!
Do not unplug by pulling on the cord!
Intended use
The VWR Mini Blot Mixer combines the actions of a rocker and a shaker to produce a three dimensional
motion that is gentle enough for fragile gels and blots, yet provides thorough mixing. Designed for processing
blots and staining applications, the pitch and speed of the mixer are optimally set to allow for use of a minimal
amount of solution while preventing the membrane or gel from drying out.The flat rubber mat is ideal for
holding blotting boxes or trays.
For research use only. Not intended for any animal or human therapeutic or diagnostic use.
Symbols and conventions
The following chart is an illustrated glossary of the symbols that may be used in this
manual or on the product.
The electrical warning indicates the presence of a potential hazard which could result
in electrical shock.
CAUTION This symbol refers you to important operating and maintenance (servicing)
instructions within the product Instruction Manual. Failure to heed this information
may present a risk of damage or injury to persons or equipment.
This symbol identifies a Protective Earth (PE) terminal, which is provided for
connection of the supply system’s protective earth (green or green/yellow) conductor.

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Product Specifications
Electrical requirements: 115V model 115V 10% - 50/60Hz, 0.03A
230V model 230V 10% - 50/60Hz, 0.015A
Speed: 115V/230V model 18 rpm / 20 rpm
Motion: 3-Dimensional rocking/rotating
Platform Tilt angle: 5°
Platform Dimensions: 20 x 16.5cm
Dimensions WxLxH: 20 x 16.5 x 17cm
Platform Load Capacity: 0.8kg
Platform Capacity 4 Small Blotting Boxes
2 Large Blotting Boxes
Weight: 0.85kg
Operating conditions: 4C to 65C, up to 85% RH, non-condensing
Description of Buttons and Switches
Main Power Switch

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Operation
Blotting boxes or trays may be placed directly on the rubber mat. When placing boxes, it is important to arrange them
evenly to distribute the weight across the platform.
Always load the platform in a uniform and balanced fashion.
Use the On / Off switch to turn the unit on. The direction of rotation in which the unit starts is random and does not affect
mixing. If desired, the rotational direction can be reversed by holding the unit’s base and very briefly touching the rotating
platform on the bottom at one corner. This technique can also be used to select the quietest direction of rotation.
Troubleshooting
Review the information in the table below to troubleshoot operating problems.
Problem Cause Solution
Mixer does not
start.
Power connection Check power connection
Platform blocked Check for obstructions blocking the motion of
the platform.
Motor Problem Contact VWR Technical service
Platform continually
changes rotation
direction
Platform blocked Check for obstructions blocking the motion of
the platform.
Repair and maintenance of the VWR Mini Blot Mixer
No routine maintenance or lubrication is required.
Keeping the mixer clean will help to maintain it in proper working order
Cleaning
The outside housing can be cleaned with a soft, damp cloth when needed.
Do not use any aggressive or abrasive cleaners (acetone, nitro, polish etc.) This may permanently damage the mixer
finish.
Before cleaning the mixer, always unplug the power cord from the wall socket!

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
User replaceable accessories and spare parts
The small and large blot boxes are available separately
Description Part Number
Small Blot Box, Pack of 10 700-0248
Large Blot Box, Pack of 10 700-0249
Technical service
Web Resources
Visit the VWR’s website at www.vwr.com for:
•Complete technical service contact information
•Access to VWR’s Online Catalogue, and information about accessories and related products
•Additional product information and special offers
Contact us For information or technical assistance contact your local VWR representative or visit.
www.vwr.com.
Warranty
VWR International warrants that this product will be free from defects in material and workmanship for a
period of two (2) years from date of purchase. If a defect is present, VWR will, at its option, repair, replace, or
refund the purchase price of this product at no charge to you, provided it is returned during the warranty
period. This warranty does not apply if the product has been damaged by accident, abuse, misuse, or
misapplication, or from ordinary wear and tear.
For your protection, items being returned must be insured against possible damage or loss. This warranty
shall be limited to the replacement of defective products. IT IS EXPRESSLY AGREED THAT THIS
WARRANTY WILL BE IN LIEU OF ALL WARRANTIES OF FITNESS AND IN LIEU OF THE WARRANTY OF
MERCHANTABILITY.

Lit M00074 VWR Mini Blot Mixer, Version 2, 04/01/2012
Equipment disposal
This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not
be disposed of with unsorted waste.
Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling it over to an
authorized facility for separate collection and recycling. It's also your responsibility to decontaminate the
equipment in case of biological, chemical and/or radiological contamination, so as to protect from health
hazards the persons involved in the disposal and recycling of the equipment.
For more information about where you can drop off your waste of equipment, please contact your local dealer
from whom you originally purchased this equipment.
By doing so, you will help to conserve natural and environmental resources and you will ensure that your
equipment is recycled in a manner that protects human health.
Thank you
