Vynco VMC334 User manual

INSTALLATION INSTRUCTIONS
AUCKLAND
9 Levene Place, Mount Wellington
PO Box 12 249, Penrose, Auckland 1061
New Zealand
P [phone]
VYNCO INDUSTRIES (NZ) LIMITED
CHRISTCHURCH
388 Tuam Street, Phillipstown, Christchurch, 8011
PO Box 9022, Tower Junction, Christchurch 8149
New Zealand
P [phone]
E [email protected]
VYNCO.CO.NZ
VMC334 - 34 WAY THREE PHASE SERIES COMBINED METER BOARDS
INSV0156
SPECIFICATIONS
Rated Operational
Voltage
415V AC maximum,
50Hz
Maximum Current 100A
Rated Insulation Voltage 1000V
Short Circuit Withstand 10kA
DIMENSIONS
Cover Assembly 900 x 402 x 77mm
Base Box Dimensions 853 x 355 x 150mm
Overall Assembled
Dimensions 900 x 402 x 171mm
Total Internal Meter
Mounting Space 310 x 320 x 139mm
Maximum Meter Depth 130mm
SAFETY
This product complies in full with AS/NZS 61439.3.
This product should be installed by a suitably
qualied person in accordance with Australian
and New Zealand wiring rules.
IP40
INSTALLATION PROCEDURE
This product is designed to be installed inside a wall
cavity with a minimum stud size of 90mm and a
minimum plaster board/wall covering of 10mm.
For surface mounting use VMCC surface mount
enclosure in conjunction with this board.
The metal wall enclosure must be earthed. Fold out
tags (x6) on the side walls of the enclosure can be
folded out to set the correct height onto the studs.
Door hinge pins are easily removable and the door
can be reversed so that it swings either left or right.
This product is designed to be used with
New Zealand and Australia’s MEN system.
DO NOT install a link between the neutral bars
and earth bar on circuits dedicated to RCDs.
Please ensure circuits and protective devices
are adequately identied during installation.
WARRANTY
This product is covered by a 1 Year Vynco Warranty -
proof of purchase is required. Please contact Vynco
for details of returns procedure.
NOTE: This product contains NO user serviceable parts.

INSTALLATION INSTRUCTIONS
VYNCO.CO.NZ
EARTH AND NEUTRAL BUSBAR LAYOUT
Material Number of Bars Double Screw Tunnels Single Screw Tunnels
Earth Bar Brass with steel screws 1330
Neutral Bar Brass with steel screws 1414
RCD Neutral Bar Brass with steel screws 513
REMOVING DOOR
STEP 1
Rotate top pin 90°.
STEP 2
Slide pin down to release door. There is no need
to remove pin completely.
STEP 3
Lift and remove door.
STEP 1 STEP 2
STEP 3
FITTING DIAGRAM
To t into wall cavity, fold out tabs to set height of
enclosure onto studs.
FITTING DIAGRAM
VMC334 - 34 WAY COMBINED METER BOARD
