Vytronix BCS01 User manual

BCS01 Cordless 3 in 1 Vacuum
INSTRUCTION MANUAL
w w w . v y t r o n i x . c o m

Power / maintenance lights
Dust container release button
Dust container
Battery indicator

26V
22.2V
120W
and harder to
reach areas
3 - 4 hours
Up to 35 minutes

3
Do not submerge any part of the appliance in water.
dust container and filter in place.
the charger or
battery are damaged.
for prolonged periods of
time when not in use. Always unplug before servicing.
charger

Not suitable for use on liquids or wet surfaces

Install the dust container by inserting the clip into the main body,
then twisting into place. It will “click” to secure.
for
appliance

NOTE: In the event of a maintenance issue with
the product such as a jammed brush roll one of
the three BLUE indicator lights will flash on and
off until the issue is resolved, in this case turn
the cleaner off until the issue is rectified.
Mount the unit to the wall bracket and attach
the charger to the mains. Plug the cable into
the power inlet located on the side of the
battery which is fitted into the main body.
When charging the energy indicator light will
be illuminated RED. Once fully charged this
indiindicator light will change to GREEN. Indicator
lights may turn off when fully charged.
Once fully charged, turn the charger off at
the mains.

for a third time.
Unclip the dust container from the main body.
Cleaning the dust container
The vacuum must be fully charged before using for the first time.

Twist the lid of the dust container anit-clockwise to open.
Remove the dust container from the main body.

Remove the sponge inlet filter from the top of the dust container.

1. Slide the brush roll securing catch “ A “ away from the brush as
indicated in the illustration below.
2. Remove the brush roll from the brush housing.

3. Carefully clean and remove any hairs and fibres from the brush roll.
Wipe clean only, do not use any soap or harsh cleaning agents.
4. If brush roll becomes damp during cleaning, allow to dry naturally
before replacing the brush roll back into the housing.
5. Slide securing catch “ A “ back into original position to secure
the brush roll.

filter, air duct, extension tube, floor head and accessories.
Empty the dust container and clean or replace the filter.
The appliance will not power on.

Don’t forget to register your warranty at www.vytronix.com
using product code brandnew-vytronix-bcs01
REGISTRATION
