Vytronix MFW1600 User manual

MFW1600 4-IN-1 WET & DRY VACUUM,
CARPET WASHER & BLOWER
INSTRUCTION MANUAL
w w w . v y t r o n i x . c o m

-BLANK PAGE -

Contents
1.Hose inlet
2.Solution pump on/off switch
3.Power cord
4.Top cover
5.Tank locking clip
6.Top handle
7.Vacuum power on/off switch
8.Tank
9.Base/wheel assembly
10.Float frame
11.HEPA filer
12.Floater bottom
13.Solution tank
14.Solution tank cover
15.Hose main connector
16.Hose
17.Front solution tube adapter
18.Rear solution tube adapter
19.Solution tube
20.Aluminum extension tubes
21.Solution/water floor brush
22.Floor brush
23.Water squeegee (optional)
24. 2 in 1 nozzle
25.Crevice tool (optional)
26.Disposable high filtration dust bag

Product introduction
The product is for domestic use only, its functions include wet vacuum, dry vacuum, carpet washer/cleaner
and a rear blower function. It can be operated easily and safely. The product has a float chamber to avoid
water/solution. The detachable solution tank is fully detachable for ease of emptying/cleaning.
Safety advice
•Please read the manual carefully before operating and select suitable accessories for different
cleaning purposes.
•Don’t leave the appliance on while unattended.
•For indoor, domestic use only.
•The appliance is not suitable for use by children.
•Only supplied accessories should be used.
•Always consult the manufacturer before attempting to carry out any repairs on the appliance
beyond normal maintenance.
•Check the suction hose if any blockage before operation.
•In the event of any blockage or malfunction, switch the appliance off immediately and unplug.
•Please make sure the all filter components are correctly fitted prior to use.
Cleaning –Carpet cleaner version
•Remove the dust bag.
•Use on flat surface.
•Stop the appliance immediately if any water or solution bubbles spray out. Check the levels in the
collection tank. Clean the water tank and float assembly if required.
•Solution tank capacity is 3.5L.
•A full solution tank will provide approx 20-25 minutes.

Operation
1. Release tank clip, take out the top cover and remove the dust bag.
2. Hold the top handle, take off the float chamber frame as per direction instruction, check the float
chamber frame, filter, float assembly, HEPA filter and check whether all are in the correct position.

3. Assemble the floater frame according to direction instruction. Put the top onto the water tank, fix the
tank clip.
4. Insert the main hose adapter, rotate according to direction instruction and fix firmly. Then fix the front
solution nozzle in anticlockwise.

5. Connect the two parts of the aluminum tube together with the solution nozzles.
6. Connect the solution/water floor brush/solution nozzle with the aluminum tube/solution nozzle.
7. Release solution tank clip and remove the tank. Fill with clean, cold or warm but not hot water and
solution of desired –if using solution, read the instructions on the bottle before use.

8. Park the solution tank onto the vacuum bottom.

9. Plug in and power on the vacuum first, then switch on solution pump.
10. When vacuuming, check if solution pump working, solution speed, floater protection, water/solution
bubble level (no exceeding the MAX line)

11. Full solution tank can last 20-25 minutes working. Check often the solution level as per the tank scale.
Power off the pump for 30 seconds before switching off the vacuum.
12. After vacuuming, take out the solution nozzles and solution tank for cleaning.
