Vytronix RBC02 User manual

BAGGED VACUUM CLEANER
USER GUIDE
Model : RBC02
RBC08/0510

IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution should always be followed, including the following:
READ ALL INSTRUCTIONS
BEFORE USING (THIS APPLIANCE)
WARNING-To reduce the risk of fire, electric shock, or injury:
1. Do not leave vacuum cleaner when plugged in. Unplug from outlet when no use and before servicing.
2. To reduce the risk of electric shock, do not use outdoors or on wet surfaces
3. Use only as described in this manual. Use only Vytronix recommended attachments.
4. Do not use with damaged cord or plug. If vacuum cleaner is not working as it should, has been
dropped, damaged, left outdoors or dropped into water, please contact Vytronix.
5. Do not pull or carry by the cord, use the cord as a handle, close door on the cord, or pull the cord
around sharp edges or corners. Do not run the vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
6. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
7. Do not handle plug or vacuum cleaner with wet hands.
8. Do not put any object into openings. Do not use with any opening blocked. Keep free of dust, lint, hair
and anything that may reduce airflow.
9. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
10. Turn all controls off before unplugging.
11. Take extra care when using the vacuum on the stairs.
12. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they
may be present.
13. Hold plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.
14. Unplug before connecting the hose
15. Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
16. Do not use without dust bag and filter in place.
17. If the supply cord is damaged, it must be replaced by Vytronix in order to avoid a hazard.
18. This appliance is not intended for use by persons such as children or those with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instructions concerning the use of the appliance by a person responsible for their
safety.
19. Children should be supervised to ensure that they do not play with the appliance.
SAVE THESE INSTRUCTIONS!
Don't forget to register for your 12 month guarantee at www.vytronix.com using product code: brandnew-
vytronix-rbc02
1

COMPONENTS AND EQUIPMENT
1. Floor nozzle
2. Extension tube
3. Accessories holder
4. Suction control slider
5. Suction hose
6. Cord rewind button
7. ON/OFF button
8. Carrying handle
9. Suction hose connection
10. Crevice Nozzle
11. Upholstery nozzle
12. Dust bag full indicator
Don't forget to register for your 12 month guarantee at www.vytronix.com using product code: brandnew-
vytronix-rbc02
2

ACCIDENT PREVENTION
Switch off the vacuum cleaner immediately if the air intakes, the floor brushes or the telescopes tube
becomes blocked. Before starting the vacuum cleaner up again remove the substance causing the blockage:
1. Never use the vacuum cleaner in the immediate vicinity of fires or radiators or any other appliance
emitting heat. Do not suck up hot objects such as cigarette ends or ashes.
2. Only place the plug in the socket when your hands are dry.
3. Please remove large or sharp objects from the floor before using the vacuum cleaner to avoid any
possible damage to it.
4. Do not pull by the mains cable when pulling out the plug.
Don't forget to register for your 12 month guarantee at www.vytronix.com using product code: brandnew-
vytronix-rbc02
3

PREPARING THE VACUUM CLEANER
Before starting
1. Open the dust bag cover and check that the dust bag is in
place.
2. When you close the lid, ensure that the hole in the dust bag is
lined up with the opening on the top cover of the vacuum.
If during use, you discover dirt / debris inside the bag chamber, check the bag is fitted
correctly.
3. Fit the hose on the vacuum cleaner by inserting the rotating hose
connection into the vacuum cleaner until you hear a click. To
remove the hose, press the button at the side of the hose
connection and pull it out.
Assembling the telescopic extension tube and accessories
1. Fit the telescopic tube onto the other end of the hose.
2. Fit the floor brush onto the extension tube.
Floor Nozzle
The floor nozzle has two settings. When cleaning
hard surfaces (parquet flooring, flooring tiles, etc.),
the nozzle brushes should be extended. When cleaning
carpets and mats, the brushes should be retracted into
the nozzle. Press the brush change button to switch between
the two settings.
Crevice nozzle
For radiators, corners, skirting, etc.
Furniture nozzle
For furniture, curtains, drapes, etc.
Don't forget to register for your 12 month guarantee at www.vytronix.com using product code: brandnew-
vytronix-rbc02
4

USING THE VACUUM CLEANER
1: Before using the vacuum, first pull out a sufficient length of mains cable and plug into the mains socket.
The yellow mark on the electric flex cable is the maximum length that must not be exceeded.
To switch on the device, press the foot pedal button on the casing with your foot or hand.
2: To rewind the power cable, press the button
Hold the cable with one hand and guide the cable to ensure that it does not whip causing damage.
Caution:
Never operate the vacuum cleaner without the dust bag or motor filter fitted, otherwise the device
could be damaged.
REPLACING THE DUST BAG
Replace the dust bag as soon as the ³EDJIXOO´indicator becomes fully illuminated.
1. Switch off the vacuum and unplug from the mains power supply.
2. Remove the hose from the top cover of the vacuum and open the dust bag cover.
3. Carefully pull the cardboard holder to remove the dust bag and then dispose of full bag.
4. Insert a new dust bag by lining up the cardboard holder with the plastic tracks and sliding straight
down.
5. Adjust the corners of the bag to fill the bag compartment.
6. Close the dust bag cover and check that the hole in the bag lines up with the opening on the top
cover.
7. Reattach the hose and mains power and continue cleaning.
Don't forget to register for your 12 month guarantee at www.vytronix.com using product code: brandnew-
vytronix-rbc02
5

Cleaning the motor filter
1. The motor filter can be found in the dust bag container.
It protects the motor from dust and should be cleaned
at least twice a year, when it is dirty, or if suction force is
reduced.
2. Pull the filter holder up out of the vacuum cleaner
3. open the filter holder and remove the filter. Rinse the filter in
tepid water and allow it to dry for 24hours. Do not use a hair
dryer or similar to dry the filter
4. Return the filter to the holder and replace the filter holder in
the vacuum cleaner.
IMPORTANT! Never use the vacuum cleaner without a motor filter.
TROUBLE SHOOTING AND IMPORTANT INFORMATION
This Vacuum Cleaner is fitted with an internal safety thermal cut out.
The Vacuum Cleaner will switch off automatically when it overheats.
The Vacuum Cleaner may overheat if the filters are clogged, the hose is blocked or the dust bag is full.
If the Vacuum Cleaner cuts out, empty the dust bag, remove any blockages and clean the filter out
before using again.
The Vacuum Cleaner will be functional again 30-60 minutes after cooling down.
TRANSPORT AND STORAGE
1. You can lift and carry the vacuum cleaner using the carrying handle. Never pull or lift the vacuum cleaner
by the cord.
2. Before putting the vacuum away, rewind the cord. Switch off the socket, unplug, and press the cord
rewind button until the cord is fully rewound.
3. To save space, the vacuum can be stored upright on its end cover. The telescopic tube can be hung on
the vacuum cleaner by inserting the parking fixture into the vertical parking holder.
WARRANTY AND SPARES
To register you free one year Vytronix warranty visit www.vytronix.com/vytronix-product-registration
Your product code for registration is: brandnew-vytronix-rbc02
To purchase spares for your vacuum, please visit www.vytronix.com/spares
Motor
Filter
Don't forget to register for your 12 month guarantee at www.vytronix.com using product code: brandnew-
vytronix-rbc02
6
If you have any queries or require assistance with using your
product, including set up, troubleshooting or registration
please email our customer services team on
[email protected]

SAFE DISPOSAL
This marking indicates that this product should not be disposed with other household waste
throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To arrange safe disposal of your used device, please use the return and collection
systems or contact the retailer where the product was purchased.
