W. Tombling HQ1500P User manual

GENERAL SAFETY INFORMATION
This heater is intended for industrial use.
The heater is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless under the supervision or instruction of a person responsible for their safety.
Children should be supervised at all times to ensure that they do not play with the
heater.
SAFETY PRECAUTIONS
1. This heater gets very hot during use, position it where accidental
contact is unlikely. We recommend the use of a fire guard where
children or animals are present.
2. DO NOT COVER THE HEATER.
3. Use only on a firm horizontal dry surface.
4. Do not point the heater directly at any flammable objects, materials or
surfaces.
5. Do not use within 3 meters of combustible materials
6. This heater is designed for indoor use and should not be used
outdoors, near or immersed in water.
7. Ensure the mains cable is behind the heater during use, and protect it
from contact with sharp objects, chemicals, and hot surfaces.
8. Replace damaged power leads immediately
9. Always turn the heater off and allow it to cool before moving it.
10. Always unplug and allow the heater to cool for at least 1 hour before
removing any cover or guard, cleaning, carrying out maintenance, or
replacing the lamp.
11. Do not use with a timer or any other device which switches the heater
on automatically.
12. Do not leave the heater turned on while unattended.
13. Do not use the heater where hazardous or flammable vapours may be
present as defined in BS5345.
PROTECTION FROM ELECTRIC SHOCK
To reduce the risk of electric shock, we recommend the heater is connected to the
electricity supply via by a residual current device (RCD).
HQ1500P 230V
HQ1500P-LV 110V
1500W TRIPOD MOUNTED
INFRARED HEATER
W. Tombling Ltd
Wembley House
Dozens Bank
West Pinchbeck
Spalding
Lincolnshire
PE11 3ND
United Kingdom
Tel [phone]
Fax [phone]
Web www.tombling.com
W. TOMBLING LTD
IMPORTANT SAFETY INSTRUCTIONS
Before assembling and using this heater, please read these instructions
carefully and follow all recommendations regarding installation and use.
Failure to do so could result in fire, electric shock, or serious personal injury.
KEEP THIS BOOKLET FOR FUTURE REFERENCE

Check the rating label on the heater, before
connecting it to the electricity supply.
The HQ1500P must only be connected to a 220 - 240V electricity supply
and is fitted with a standard 13A UK plug (BS1363)
The HQ1500P-LV must only be connected to a 110 - 120V electricity
supply and is fitted with a yellow 16A 3 pin industrial plug (BS EN60309)
ASSEMBLY
The HQ1500P(LV) is supplied in three parts, the heater head, on-off switch,bracket and
cable, and a tripod stand.
Step 1
The switch and bracket should be attached to the heater head using the bolt supplied,
ensuring the spacer provided is fitted between the two fixing posts of the heater. Make
sure the star washer is fitted under the head of the bolt, then fully tighten to secure.
Step 2
When assembled, the complete heater head and switch bracket can be attached to the top
of the tripod, using the small hand-wheel fixing screw provided.
Step 3
The height of the tripod can be adjusted by loosening and tightening the securing rings on
the tripod.
WIRING
WARNING: THE HEATER MUST BE EARTHED.
The HQ1500P(LV) is supplied prewired with either a 13A UK plug for the 230V model
(HQ1500P), or a 3 pin 16A BS EN60309 plug for the 110V model (HQ1500P-LV).
If the fitted plug is unsuitable for your socket outlet then the plug should be removed and
disposed of safely. If a new plug is to be fitted please observe the wiring code below. The
plug should only be replaced by a competent person.
Upon completion the heater MUST be tested for electrical safety (PAT) before use.
The wires in the mains lead are coloured in accordance with the following code-
Green and Yellow - Earth Blue - Neutral Brown - Live
LAMP REPLACMENT
Remove the plug from the electricity supply and allow the heater to cool.
Remove the first two screws from one end of the end reflector, this will release the
guard and expose one of the lamp terminal end posts.
Next remove the end reflector from the opposite end of the cassette, exposing the
other lamp terminal. Release the nuts on the exposed terminal end posts just enough
to allow the fork terminals of the lamp leads to be pushed under the washer and nut
provided.
Carefully remove the lamp from its packing, holding it by the porcelain end caps,
taking care not to handle the quartz glass.
If you accdentally touch the glass with your fingers, clean it with methelylated
spirits or isopropal alcohol. Failure to do so will result in premature failure of
the lamp.
Carefully insert the end caps of the lamp under the spring retaining clips of the
heater. The fork terminals on each end of the lamp should now be inserted under the
washer/nuts of the lamp end posts and tightened to make a good connection. The
lamp leads should then be tucked away around the space at each end of the heater.
Finally replace the end reflectors and grill to complete the assembly.
For spare or replacement quartz heater lamps please quote:-
Model Lamp Part No. Description
HQ1500P 64241530 220-240V 1500w ruby lamp
HQ1500P-LV 64121530 110-120v 1500w ruby lamp
Do not attempt to convert the heater from one voltage to the other, by
changing the bulb. The internal connections and cabling are different.
DISPOSAL AT THE END OF THE HEATERS USEFUL LIFE
This product conforms to EU Directive 2002/96/EC.
This appliance bears the symbol of the crossed waste bin. This
indicates that, at the end of its useful life, it must not be disposed
of as domestic waste, but must be taken to a collection center for
waste electrical and electronic equipment.
It is the user's responsibility to dispose of this appliance through
the appropriate channels at the end of its useful life. Failure to do
so may incur the penalties established by laws governing waste
disposal.
