W6 N 8000 Exklusive User manual

Sewing machine W6 N 8000 Exklusive
Instruction manual
1

Product name W6 N 8000 Exklusive sewing machine
Publisher W6 Wertarbeit Projektierungs- und andelsgesellschaft mb
Bredenbecker Straße 13 / D-30974 Wennigsen
Email: [email protected]
www.w6-wertarbeit.de
This document is protected by copyright. All rights reserved.
The document may not, in whole or in part, be copied,
reproduced, translated or reduced to an electronic medium of
machine-readable form without the explicit permission of W6
Wertarbeit Projektierungs- und andelsgesellschaft mb .
Preamble Thank you very much for buying a W6 product.
We have included a comprehensive manual, so that you can
easily learn how to operate the machine. It will help you to get
to know your machine quickly. Please register your machine on
the website at www.w6-wertarbeit.de by selecting Service /
Guarantee Registration. W6 WERTARBEIT also offers the
following options on its website for free. Please access our
website using www.w6-wertarbeit.de and under Service / elp
select:
•Criteria for the optimal threading of a W6 N 8000 Exklusive
(4-min. video).
•A tutorial video specifically for the W6 N 8000 Exklusive.
•Maintenance, tips and tricks for the W6 N 8000 Exklusive.
•A visual selection of stitches and their use, and much more.
The W6 sewing ideas on the W6 website support you with
creative sewing projects. Please take a look at the website.
Please read the manual and the safety notes carefully, before
operating the machine.
W6 tip This manual is revised from time to time. You can find the latest
version under Service / elp / Your machine type / Downloads.
Subscribe to our W6 newsletter. We keep you up-to-date and
you can take part in our special weekly
promotions.
Enjoy your new sewing machine.
W6 WERTARBEIT
The company head office is based in a deconsecrated church
in Germany.

ontents
Inhaltsverzeichnis
1 Safety notes...............................................................................................6
1.1 Notes for operational safety................................................................6
1.2 Instructions for use.............................................................................6
1.3 After sewing........................................................................................7
1.4 Tips for a long service life...................................................................7
1.5 What we expect from you...................................................................8
2 Assembling the machine...........................................................................9
2.1 Unpacking...........................................................................................9
2.2 Setting up..........................................................................................10
2.3 Connecting the machine...................................................................10
2.4 Unplugging the power plug...............................................................12
2.5 Information on the embroidery unit...................................................13
3 Getting to know the machine...................................................................15
3.1 Front view.........................................................................................16
3.2 View of the presser foot, automatic needle threader and needle plate
................................................................................................................17
3.3 Top view............................................................................................18
3.4 Rear view..........................................................................................20
3.5 Extension table.................................................................................20
3.6 Removing the extension table..........................................................21
3.7 Connecting the machine...................................................................22
3.8 Foot controller...................................................................................23
4 Accessories.............................................................................................24
5 Operating elements.................................................................................29
5.1 Start / Stop button.............................................................................30
5.2 Reverse button.................................................................................30
5.3 Needle Up / Down / Slow Sewing button..........................................31
5.4 Thread Cutter button.........................................................................31
5.5 Speed control....................................................................................31
5.6 Presser foot lifter...............................................................................32
5.7 Drop feed lever.................................................................................32
5.8 Thread tension dial...........................................................................33
5.9 Start screen......................................................................................33
5.10 Using the elp button.....................................................................35
3

5.11 Utility stitch selection.......................................................................36
5.12 Selecting other utility stitches.........................................................37
5.13 Stitch Settings screen.....................................................................38
5.14 Stitch Settings screen (mirror / stretch)..........................................41
5.15 Stitch Settings screen (thread tension)..........................................42
6 Changing the presser foot and presser foot holder................................43
6.1 Changing the presser foot................................................................43
6.2 Changing the presser foot holder.....................................................44
7 Selecting the needle................................................................................45
7.1 Checking the needle.........................................................................45
7.2 Inserting a needle.............................................................................46
7.3 Needle and thread table...................................................................47
8 Inserting the bobbin.................................................................................50
8.1 Why use W6 bobbins?......................................................................50
8.2 Removing the bobbin........................................................................50
8.3 Winding the bobbin...........................................................................51
8.4 Inserting a plastic bobbin in the hook race.......................................53
8.5 Using the upper thread to pull up the lower thread..........................55
9 What do I do with the upper thread?.......................................................57
9.1 Threading the upper thread..............................................................57
9.2 Using the needle threader................................................................60
9.3 Using the upper thread to pull up the lower thread..........................62
10 Sewing a test seam...............................................................................64
10.1 Sewing a test seam using straight stitch as an example...............64
10.2 Backtacking options........................................................................67
10.2.1 Sewing in reverse....................................................................67
10.2.2 Automatic tie-off, Automatic tie-off and cut..............................68
11 Using a pattern......................................................................................70
11.1 Overview of patterns.......................................................................71
11.2 Using a pattern................................................................................71
11.2.1 Straight stitches........................................................................78
11.2.2 Stretch straight stitch.......................................................................81
11.2.3 Triple pierced seat seam.................................................................82
11.2.4 Quilting stitches........................................................................83
11.2.5 Zigzag stitch.............................................................................84
11.2.6 Flat stitch..................................................................................85
11.2.7 Stretch zigzag stitch.................................................................86
11.2.8 Overcasting / overlock..............................................................88
11.2.9 Scalloped hem..........................................................................92
4

11.2.10 Stretch, non-stretch blind stitch..............................................93
11.2.11 Sewing buttonholes................................................................95
11.2.12 Automatic bar tack................................................................104
11.2.13 Patches / Patchwork............................................................107
11.2.14 Antique and nostalgia stitches.............................................109
11.2.15 Dekorative stitches...............................................................110
11.2.16 Satin stitch............................................................................112
11.2.17 Sewing in zippers.................................................................114
11.2.18 Sewing with the twin needle.................................................119
11.2.19 Sewing on buttons................................................................122
11.2.20 Sewing decorative stitches and letters.................................125
11.2.21 Darning / Freehand embroidery...........................................145
11.2.22 Appliqués / Appliqué.............................................................149
11.2.23 Quilting bar...........................................................................151
11.2.24 Walking foot..........................................................................152
11.2.25 Narrow hems........................................................................155
11.2.26 Sewing on cords...................................................................157
12 Maintenance........................................................................................159
12.1 Inspection at W6...........................................................................159
12.2 Maintenance to be carried out by the customer...........................160
12.2.1 Checking the needle plate.....................................................160
12.2.2 Checking the needle / Why using W6 needles is important? 160
12.2.3 Cleaning the hook, hook race and feed dogs........................161
12.2.4 Checking the hook system for damage.................................163
12.2.5 Checking the hook race for damage......................................164
12.3 Disposal........................................................................................165
13 Error messages...................................................................................166
14 Technical data.....................................................................................169
14.1 Key data........................................................................................169
14.2 Technical data...............................................................................169
EU Declaration of Conformity..............................................................170
15 Service information..............................................................................171
5

Notes for operational safety
Safety notes
1Safety notes
This section contains information on how to use the manual:
•Notes for operational safety (Section 1.1)
•Instructions for use (Section 1.2)
•After sewing (Section 1.3)
•Tips for a long service life (Section 1.4)
•What we expect from you (Section 1.5)
1.1 Notes for operational safety
The machine has been carefully designed and is safe.
Nevertheless, hazards may arise from the machine.
•If the machine is not used as intended.
•If the machine is used for an improper application.
•If the machine is operated under impermissible conditions.
For this reason, please take note of the instructions in the following
sections so that you can work safely and enjoyably.
1.2 Instructions for use
Please take note of the following points when handling the machine:
•When unpacking, make sure that you choose a secure surface to unpack
the machine safely.
•Keep animals and objects away from the area around the sewing
machine.
•Always operate the machine on a sturdy, clean and level surface.
•Keep children away from the machine.
•Always keep animals and objects away from the area around the foot
controller.
•Replace defective or damaged machine parts immediately. Only use
original parts!
•Change the needles regularly. Worn or damaged needles pose a hazard.
•Spare parts and tools must comply with the technical requirements laid
down by the manufacturer! This is only always guaranteed with original
spare parts.
•Perform maintenance work in the manner described in this manual.
•Observe the deadlines for recurring maintenance work.
•Only rectify faults when the machine is switched off. Unplug the power
plug too.
•Never change, dismantle or bypass safety devices.
6

After sewing
Safety notes
•Never deactivate safety equipment.
•Never make structural changes to the machine.
•Never operate the machine outdoors where it is exposed to the elements.
•In the event of a malfunction, switch the machine off immediately.
•W6 WERTARBEIT offers frequent sewers an annual inspection, at the
owner’s expense. Normal use indicates that an inspection should be
performed every two to four years.
1.3 After sewing
Observe the following points after use:
•Clean the machine and remove any small pieces of thread, lint or dust.
•Switch the machine off.
•Always unplug the power plug.
•Position the machine so it cannot fall.
•Always keep the machine out of the reach of children and animals.
•Change the needles regularly. Worn or damaged needles pose a hazard.
1.4 Tips for a long service life
To ensure a long service life, please take note of the following:
•Do not expose the machine to direct sunlight, moisture or high levels of
humidity.
•Clean your machine regularly. Perform these tasks thoroughly and at least
once a year. In the event of increased use, more frequently.
•When cleaning the machine, only use dry or damp cloths.
•Never use benzine, thinners or other chemical cleaning agents for
cleaning.
•Do not expose the machine to strong vibrations.
•Based on its design, the machine is not intended for commercial use.
•ave it inspected by a W6 workshop (this may result in additional costs).
•Frequent sewers should send the machine in for an annual inspection
while an inspection every 2 to 4 years should be sufficient for normal use.
You can conveniently book an inspection online on the W6 Wertarbeit
website under Service / Sewing Machine Inspection at a fixed price (incl.
wage costs, spare parts and shipping costs).
7

What we expect from you
Safety notes
1.5 What we expect from you
Specific knowledge and skills are required when working with this machine.
•You should be confident when working with the machine.
•You must have read and understood the safety notes and this manual.
•Always have a clear head when working with the machine.
•Never work with the machine when under the influence of alcohol or
drugs.
•Take note of the package insert when taking medication.
•If you are pregnant, let someone help you when assembling and moving
the machine.
•Do not dismantle the machine but leave this to a trained specialist.
•You are personally suited to operate the sewing machine.
•In case of doubt, always contact our Service Department. To do so,
contact W6 WERTARBEIT directly by email: [email protected].
•Only allow an authorised workshop to work on electrical components.
W6 WERTARBEIT also offers the following options on its website for free. Please
access our website using www.w6-wertarbeit.de and under ELP select:
•Criteria for the optimal threading of a W6 N 8000 Exklusive video.
•A tutorial video specifically for the W6 N 8000 Exklusive.
•Tips and tricks for the W6 N 8000 Exklusive.
•A visual selection of stitches and their use, and much more.
8

Unpacking
Assembling the machine
2Assembling the machine
This section contains information on how to set up the machine:
•Unpacking (Section 2.1)
•Setting up (Section 2.2)
•Connecting the machine (Section 2.3)
•Unplugging the power plug (Section 2.4)
•Information on the embroidery unit (Section 2.5)
2.1 Unpacking
You are responsible for shipping the machine for inspection or repair to a W6
specialist workshop. To avoid any damage, please send the machine in its
original packaging. We therefore recommend that the packaging material,
including polystyrene, be stored.
In this case, ensure that all packaging material is stored out of the reach of
children.
DANGER There is a risk of suffocation
On delivery, the machine is packed in a plastic bag. There is a risk of
suffocation for children who play with it.
➔Cut up the plastic bags.
➔Make sure that children do not play with the packaging material.
AUTION The machine is supplied with a needle installed
There is a risk of being pricked by the needle.
➔Take care of the needle when unpacking.
Carry out the following steps:
1. Unpack the machine on a suitable surface.
2. Cut up all plastic bags supplied with the machine.
3. Store the packaging material in a secure place out of the reach of children.
!Should you wish to dispose of it, do not simply throw the packaging
Material away but send it for recycling.
» The machine is unpacked.
9

Setting up
Assembling the machine
2.2 Setting up
When setting up, please pay attention to the following points:
•The supporting surface must be sturdy, non-slip and of adequate size.
•There is adequate lighting for work.
•Your seat ensures a convenient and ergonomically sound posture when
working.
•It is placed out of the reach of children and animals.
•It is not exposed to direct sunlight.
•It is not exposed to high levels of humidity or moisture.
•It is not placed next to radiators or other heat sources.
2.3 Connecting the machine
Prerequisite:
•The power cable is not damaged.
•There are no heavy objects on the cable.
•The cable is not exposed to high temperatures.
•The mains voltage is 230 volts.
DANGER Danger to life posed by electric shock
The sewing machine operates at low voltage. Improper connection poses the risk
of an electric shock.
➔Only use an easily accessible power socket as a power source.
➔Do not operate several devices from one power socket. There is a risk of
overloading.
➔Do not pull the plug out of the socket with wet hands.
➔Do not plug the plug into the socket with wet hands.
➔Do not pull the plug out of the socket by the power cable.
10

onnecting the machine
Assembling the machine
Carry out the following steps:
1. Place the machine on a sturdy, non-slip and adequately sized table.
2. Plug the power plug into the sewing machine socket.
3. Plug the power plug into the power socket.
4. Plug the foot controller plug into the sewing machine socket.
11

Unplugging the power plug
Assembling the machine
5. Set the on / off switch to the “I” (ON) position.
➔The machine is switched on.
➔The lighting is switched on.
?The machine does not sew?
The machine is not connected correctly.
➔Switch the machine off again.
➔Check all plug connections.
6. Slowly press the foot controller to start sewing.
! The further the foot controller is pressed, the faster the machine
sews.
7. Release the foot controller when you want to stop sewing.
8. Set the on / off switch to the “0” (OFF) position to switch the machine off.
» The machine is connected.
2.4 Unplugging the power plug
In the following situations you should switch the machine off at the on / off
switch and pull the plug out of the socket:
•If the machine is left unattended.
•If you are replacing the needle or bobbin.
•If you are removing the covers.
•If a power failure occurs during use.
•During thunderstorms.
12

Information on the embroidery unit
Assembling the machine
2.5 Information on the embroidery unit
This sewing machine becomes a full-fledged embroidery machine in no time at
all. The embroidery unit is available from the W6 online shop.
You can create many different embroideries using the embroidery unit, such as
large sections of embroideries as well as letter embroidery (available patterns
vary depending on the model). With the W6 embroidery software, you can also
easily create any customised embroidery you fancy.
A basic W6 embroidery software is included in the embroidery unit price. Data is
transferred from the embroidery software to the embroidery unit using a USB
stick.
1) Switch off the sewing machine’s power plug to connect the embroidery unit
and lower the feed dogs by pushing the drop feed lever to the left (see
Section 5.7).
2) Plug the embroidery unit’s connecting cable plug into the sewing machine
socket.
13

Information on the embroidery unit
Assembling the machine
3) Switch the sewing machine on after attaching the embroidery unit. The
thread tension is shown on the sewing machine’s LCD display when using
the embroidery unit. You can adjust the thread tension using the buttons on
the control panel. If necessary, reduce the thread tension by just one
point.
You can carry out the following on the sewing machine:
•Start / stop
•Thread cutter
•Needle stop up / down / slow sewing
•Speed control
•Winding
When you connect the embroidery unit, the needle stop position is set to up. For
more details on use, refer to the instruction manual that came with the
embroidery unit. After embroidering, raise the feed dogs again by pushing the
drop feed lever to the right and turning the hand wheel five times (towards you).
PLEASE NOTE Accident prevention.
Switch off the sewing machine’s power plug to connect the embroidery unit.
14

Front view
Getting to know the machine
3Getting to know the machine
This section will familiarise you with the machine parts and what they are called:
•Front view (Section 3.1)
•View of the presser foot, automatic needle threader and needle plate
(Section 3.2)
•View / top view (Section 3.3)
•Rear view (Section 3.4)
•Extension table (Section 3.5)
•Removing the extension table (Section 3.6)
•Connecting the machine (Section 3.7)
•Foot controller (Section 3.8)
15

Front view
Getting to know the machine
3.1 Front view
No. Designation
01 Needle Up / Down / Slow Sewing button
(See notes, Section 5.3)
02 Thread Cutter button
03 Speed control
04 Top cover
05 LCD display
06 Control panel
07 and wheel
08 Adjustable foot pressure dial
09 Light cover (not visible)
10 Reverse button
11 Start / Stop button (for sewing without foot controller)
12 Extension table
13 Knee lever connection to insert the knee lever
16

Rear view
Getting to know the machine
3.2 View of the presser foot, automatic needle threader and
needle plate
No. Designation
14 Manual thread cutter
15 ole for magnifier
16 Lowerable buttonhole lever
17 Lowerable needle threader lever
18 Needle threader
19 Presser foot holder
20 Presser foot
21 Feed dogs
22 Needle clamp screw
23 Thread guide needle support
24 Needle
25 Locking button for presser foot
26 Needle plate
27 Bobbin cover release button
28 Bobbin cover
17

Top view
Getting to know the machine
Guide lines on the needle plate indicate the distance from the centre needle
position. To stick to the seam allowance width, guide the fabric edge along this
guide line.
3.3 Top view
Lift the top of the head cover to open the top cover.
No. Designation
29 Inside the top cover*
30 Pattern table
31 Bobbin guide
32 Thread guide
33 Thread guide
34 Thread take-up lever (inside)
35 Thread tension regulator (inside)
36 Spool cap (small)
37 orizontal spool pin
38 Felt washer
39 Bobbin guide
40 Thread cutter
41 Bobbin winder stop
42 Bobbin winder spindle
43 Extra spool pin
18

Top view
Getting to know the machine
Machine parts
No. Designation
44 andle
45 Manual thread cutter
46 Presser foot lifter
47 Connection for embroidery unit
48 Power switch (On / Off)
49 Power cable connection socket
50 Foot controller socket
51 Foot controller
52 Power cable
19

Rear view
Getting to know the machine
3.4 Rear view
No. Designation
53 Drop feed lever (The drop feed lever
can only be accessed when the extension table has been removed.)
3.5 Extension table
Extension table
Opening the accessory compartment
Grab the front / rear compartment and pull it out.
a: Front compartment
b: Rear compartment
20
