Wabtec Ricon Faiveley FoldOver FR2E Series User manual

Service Manual
05/20/20 32DFRE02.C 2020 RICON CORPORATION
All Rights Reserved
U.S and Foreign Patents Pending
Printed in the United States of America
FoldOver ®
Electric FR2E-Series
Low-Floor Vehicle Access Ramp
for Transit Buses

i
TABLE OF CONTENTS
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
This Ricon service manual is only for use by Ricon dealers or
qualified service technicians, and is not intended for use by non-
professionals. The manual provides essential instructions and
reference information, which supports qualified technicians in the
correct installation and maintenance of Ricon products.
Ricon dealers or qualified service technicians have the training
and knowledge to perform maintenance work properly and safely.
For the location of a Ricon dealer or qualified service technician in
your area, call Ricon Product Support at 1-800-322-2884 or visit
our website at http://ricondealer.wabtec.com.
Customer Name:
Installing Dealer:
Date Installed:
Serial Number:

ii
TABLE OF CONTENTS MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
REVISION RECORD
RE
V
PAGES DESCRIPTION OF CHANGE ECO
32DFRE02.
C
Cvr Update to compan
y
lo
g
o
9239
All Revised all title bars/footers
1-3 Update to company logo
4-1 Text update
4-7 Update to Figure 4-2.4
4-9, 4-10 Update to Figure 4-2 Parts List
4-15 Update to Figure 4-4 Parts List
4-16 Update to Table 2-4
4-17 Update to Table 2-5

iii
TABLE OF CONTENTS
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
Chapter Page
I. FOLDOVER ELECTRIC FR2E-SERIES RAMP INTRODUCTION ......................................... 1-1
A. RAMP FEATURES .......................................................................................................................... 1-1
1. INTERLOCK SUPPORT ............................................................................................................................ 1-1
2. AUDIBLE ALERT ....................................................................................................................................... 1-1
3. RAMP CONTROL PANEL ......................................................................................................................... 1-1
B. RICON PRODUCT SUPPORT ........................................................................................................ 1-2
C. RICON TWO-YEAR LIMITED WARRANTY ................................................................................... 1-3
D. SHIPPING INFORMATION ............................................................................................................. 1-4
E. CUSTOMER ORIENTATION ........................................................................................................... 1-5
II. FOLDOVER ELECTRIC FR2E-SERIES RAMP INSTALLATION .......................................... 2-1
A. INSTALLATION GUIDELINE .......................................................................................................... 2-1
1. LOCATING MOUNTING BRACKETS ON BUS FRAME ........................................................................... 2-1
2. INSTALLING RAMP IN FLOOR ................................................................................................................. 2-1
3. INSTALLING VEHICLE WIRING HARNESS ............................................................................................. 2-3
B. FOLDOVER RAMP ADJUSTMENTS ............................................................................................. 2-3
1. CHAIN ASSEMBLY REPLACEMENT........................................................................................................ 2-3
2. FINAL INPSECTION .................................................................................................................................. 2-4
III. FOLDOVER ELECTRIC FR2E-SERIES RAMP MAINTENANCE .......................................... 3-1
A. GENERAL SAFETY PRECAUTIONS ............................................................................................. 3-1
B. DAILY INSPECTION ....................................................................................................................... 3-2
C. MAINTENANCE SCHEDULE .......................................................................................................... 3-2
D. RAMP COMPONENT INFORMATION ............................................................................................ 3-3
1. MOTOR DRIVE SYSTEM .......................................................................................................................... 3-3
2. TRAY POSITION SWITCHES ASSEMBLY ............................................................................................... 3-3
3. ELECTRONIC CONTROLLER .................................................................................................................. 3-3
4. INTERLOCK OUTPUT STATUS ................................................................................................................ 3-4
5. CIRCUIT BREAKERS AND FUSES .......................................................................................................... 3-4
6. ELECTRICAL DIAGRAMS ......................................................................................................................... 3-4
E. ELECTRICAL DIAGRAMS .............................................................................................................. 3-7
IV. FOLDOVER ELECTRIC FR2E-SERIES RAMP SPARE PARTS ........................................... 4-1
Appendix: Ramp Specifications ..................................................................................................... 4-16

iv
TABLE OF CONTENTS MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
This page intentionally left blank.

1 - 1
I
N
TRODU
C
TIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
I. FOLDOVER® ELECTRIC FR2E-SERIES RAMP INTRODUCTION
his manual applies to the Ricon FoldOver® Electric FR2E-Series Low-Floor Vehicle Access Ramp when installed
in transit vehicles. The chapters in this service manual contain product description, maintenance instructions, and
a spare parts list. The descriptions in this chapter apply to the Ricon FoldOver® Electric FR2E-Series Low-Floor
Vehicle Access Ramp when installed in transit vehicles utilizing 12VDC or 24VDC applications. The FoldOver
electric ramp is installed in low-floor transit vehicles to accommodate persons with disabilities using mobility-aid equip-
ment or who cannot easily climb steps. The electro-mechanically powered ramp folds into the vehicle vestibule flooring
when not in use.
All Electric FR2E-Series ramps have a 1,000 lbs. (453 kg) load limit. Passengers must use the ramp one at a time; do
not overload ramp. Be certain that persons with mobility-aid equipment fit between the left- and right-side ramp barri-
ers without any interference before allowing use of ramp.
FIGURE 1-1: RICON FOLDOVER FR2E ELECTRIC LONG AND SHORT RAMP
A. RAMP FEATURES
1. INTERLOCK SUPPORT
The ramp electronics can interface with the vehicle interlock circuitry to prevent vehicle departure when ramp
is deployed. The electric ramp interlock circuitry senses the position of the ramp (stowed or deployed) and
makes this information available by the controller and through the 55-pin amp harness connector. A vehicle
interlock circuit typically requires that the following conditions be met before operating power is supplied to
electric ramp:
 Park vehicle and set parking brake.
 Place transmission in neutral.
 Open vehicle door adjacent to electric ramp.
2. AUDIBLE ALERT
NOTE: This feature is optional and may not have been connected during ramp
installation.
The ramp supports an audible alert device that sounds while the ramp
is in motion.
3. RAMP CONTROL PANEL
Refer to Figure 1-2. Ricon typically does not provide a control panel.
However, the ramp can be operated with one similar to that shown (the
actual panel appearance will vary between transit authorities and vehi-
cles). The control panel is normally installed in the driver area. It should
have a power ON/OFF switch, a power on indicator light, and a spring-
loaded, three-position ramp control switch (center-off). The electric ramp
receives power from the vehicle when the interlock conditions are met and
the power on/off switch is ON. The control panel can then be used to
transmit deploy or stow signals to the electric ramp.
T
FIGURE 1-2: TYPICAL
CONTROL PANEL

1 - 2
I
N
TRODU
C
TIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
B. RICON PRODUCT SUPPORT
If you have questions about this manual, or you need additional copies, please contact Ricon Product Support at
the locations listed. Also, refer to the Ricon website at: http://ricondealer.wabtec.com
Ricon Corporation
1135 Aviation Place
San Fernando, CA 91340
Telephone: ................................ [phone]
................................. [phone]
(in US but outside 818 area code)
John Condon
National Sales Manager
Telephone: ................................
Email: [email protected]
209-603-5189
Mike O’Neill
Eastern Area Sales Manager
Telephone: ................................
Email: [email protected]
847-224-5087
Justin Millikin
Central Area Sales Manager
Telephone: ................................
Email: [email protected]
916-206-7456
Vapor Ricon Europe Ltd.
Meadow Lane
Loughborough, Leicestershire
LE 1HS, United Kingdom
Telephone: ................................ (+044) 1509 635 920
C. RICON TWO-YEAR LIMITED WARRANTY
The following warranty provides two years of limited coverage for the Ricon FoldOver® Electric FR2E-
Series Low-Floor Vehicle Access Ramp when installed in Transit Vehicles.

1 - 3
I
N
TRODU
C
TIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
RICON FOLDOVER® ELECTRIC FR2E-SERIES
LOW FLOOR VEHICLE ACCESS RAMP FOR TRANSIT BUSES
TWO-YEAR LIMITED WARRANTY
Ricon Corporation (Ricon) warrants to the original purchaser of this product that Ricon will repair or replace,
at its option, any parts that fail because of defective material or workmanship as follows:
 Repair or replace parts for a period of two years starting from the date ramp is put into service. Obtain a
complete list of parts covered by this warranty from Ricon Product Support.
 Labor costs for specified parts replaced under this warranty for a period of two years from the date put into
service. A Ricon rate schedule determines parts covered and labor allowed.
This Warranty Does Not Cover:
 Malfunction or damage of product parts caused by accident, misuse, lack of proper maintenance, neglect,
improper adjustment, modification, alteration, mechanical condition of vehicle, road hazards, overloading,
failure to follow operating instructions, or acts of nature (i.e., weather, lightning, flood).
NOTE: Ricon recommends this product be inspected by a Ricon dealer or qualified service technician at least
once every six months, or sooner if necessary. Perform required maintenance at this time.
WARNING!
THIS PRODUCT HAS BEEN DESIGNED AND MANUFACTURED TO EXACT
SPECIFICATIONS. ANY MODIFICATION OF THIS PRODUCT CAN BE
HAZARDOUS.
This Warranty is Void If:
 The product is not installed and maintained by a Ricon dealer or qualified service technician.
 The product is modified, in any respect from its original design, without written authorization from Ricon.
Ricon disclaims liability for any personal injury or property damage that results from opera-
tion or use of a Ricon product that is modified from the original Ricon design. No person or
company is authorized to change the design of this Ricon product without written authori-
zation from Ricon.
Ricon obligation under this warranty is exclusively limited to the repair or exchange of parts
that fail within the applicable warranty period.
Ricon assumes no responsibility for expenses or damages, including incidental or conse-
quential damages. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply.
Important: The warranty registration card must be completed and returned to Ricon within
20 days after product installation to validate this warranty. The warranty is not transfera-
ble.
The warranty gives specific legal rights. There may be other rights that vary in each state.

1 - 4
I
N
TRODU
C
TIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
D. SHIPPING INFORMATION
• When the product is received, unpack the product and check for freight damage. Claims for any damage should be
made to the carrier immediately.
• Be sure the ramp assembly contains all items listed on the included bill of material. Please report any missing items
immediately to Ricon Product Support. Save bill of material for later reference. Return the completed warranty and
owner registration cards to Ricon within 20 days to validate warranty.
NOTE: The Sales or Service personnel must review the Warranty and this Operator Manual with the user to be certain
that they understand how to safely operate the product. Instruct the user to follow the operating instructions
without exception.

1 - 5
I
N
TRODU
C
TIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
E. CUSTOMER ORIENTATION
1. Figure 1-3 shows major components of the Ricon FoldOver® Electric FR2E-Series ramp. A description of
each component is provided in Table 1-1. Refer to Chapter IV “Parts Diagrams and Lists” for more details.
RSM0067200
14
1
3
4
55
8
8
8
15
11
12
13
9
10
16
18
7
6
7
6
17
2
17
19
FIGURE 1-3: ELECTRIC FR2E-SERIES RAMP MAJOR COMPONENTS

1 - 6
I
N
TRODU
C
TIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
TABLE 1-1: FOLDOVER® ELECTRIC FR2E-SERIES RAMP MAJOR COMPONENTS
ITEM DESCRIPTION
Item Description
Front, Rear, Left
and Ri
g
h
t
Reference point from outside the vehicle looking inward.
1
A
d
j
ustable Coupler - Use for ad
j
ustment and ali
g
nment of chain sprocket.
2 Chain – Transfers the motion from the drive shaft to the CAM shaft which actuates the micro-
switches that identif
y
the position of the ramp tra
y
.
3 Controller – Translates electrical commands from bus control panel into signals that control
ramp electro-mechanical components. Monitors ramp position and drives counter.
4 Counter
–
Counts each c
y
cle.
5 Couplings – (Left & Right) Transmits rotary motion and attaches the drive motor shaft assem-
blies to the dual
g
earboxes.
6 Drive Arms
–
Ramp linka
g
e arms attach to outboard end of driveshafts.
7 Driven Arms
–
Ramp linka
g
e arms attach to ramp.
8 Flange Kit – Perimeter trim pieces that are installed after the ramp has been installed in vehi-
cle.
9 Floor Plate (Access Cover) – Portion of ramp that passenger traverses over to enter and exit
vehicle which also provides access to electro-mechanical ramp components.
10 Front Cover
–
Front ed
g
e of ramp that opens and closes when platform is deplo
y
ed or stowed.
11 Harness
–
Inte
g
rates conduits, rela
y
s, etc.
12 Hatch Handle
–
Use to assist in manual deplo
y
or stow ramp.
13 Motor Drive System – Electro-mechanical motor-gearbox combination used to operate the
ramp.
14 Non-Slip Surface – Flooring over which passengers
traverse.
15 Platform Assembl
y
–
A
rea where passen
g
ers traverse over to enter and exit vehicle.
16 Positive Connection Block
–
Connection throu
g
h which the ramp receives power from vehicle.
17 * Ramp Tra
y
Barrier
–
Left and Ri
g
ht side barrier of platform.
18 Spider Couplin
g
Drive Shaft
–
Transmits motor torque to drive arms.
19 Tray Position Switches Assy – Contains CAMs and micro-switches which identify the position
of the ramp tr
y
b
y
the position of the CAMs
 Note: Short ramp tray shown.

2 - 1
INSTALLATIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
II. FOLDOVER® ELECTRIC FR2E-SERIES RAMP INSTALLATION
A. INSTALLATION GUIDELINES
Careful installation of the Ricon FoldOver® Electric FR2E-Series Low-Floor Vehicle Access Ramp contributes to
proper and safe operation. Use the electrical wiring diagram in Chapter III, Figure 3-4 to supplement this sec-
tion.
1. LOCATING MOUNTING BRACKETS ON BUS FRAME
Use a rigid fixture that substitutes for the ramp assembly when positioning ramp mounting brackets on the
bus frame. If the ramp assembly is used to position the mounting brackets, verify that it is correctly located
relative to the vehicle floor, etc. Accurate positioning of the brackets prevents twisting or warping of ramp
frame when installing and tightening the mounting hardware. A warped frame may cause the ramp motion
to be erratic. Set the height of the ramp flooring surface flush to the surrounding floor structure to prevent a
tripping hazard.
2. INSTALLING ELECTRIC FR2E-SERIES LOW-FLOOR VEHICLE ACCESS RAMP IN FLOOR
The location of the ramp depends on its path of motion. The ramp must be positioned so it can move un-
obstructed through its required range of travel.
a. Trim away floor material to allow ramp assembly to drop into floor opening.
NOTE: Do Not install ramp trim (flange kit) until ramp is installed in bus. The ramp trim overlaps the perimeter
gap between the sides of the enclosure and bus structure. The typical gap between the sides of the
enclosure and the bus structure is 1/8 inch. Use shims to fill gap.
RSM0068200
EYE BOLTS
EYE BOLTS
FRONT
REAR
RIGHT
LEFT
FIGURE 2-1: RAMP LIFTING EYE BOLTS
TAKE EXTREME CARE WHEN POSITIONING RAMP INTO BUS. BE SURE TO FOLLOW
PROPER OPERATION AND SAFETY INSTRUCTIONS WHEN USING LIFTING DEVICE.
b. Refer to Figure 2-1. Attach lifting device hooks to pre-installed eye bolts.
WARNING!

2 - 2
INSTALLATIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
c. Use lifting device to place ramp into bus.
d. Refer to Figure 2-2. Lower ramp onto bus floor. Ensure that rear ramp flange rests on bus floor.
RSM0068400
BUS FLOOR
REAR FLANGE
FRONT REAR
FIGURE 2-2: RAMP INSTALLATION (SHORT RAMP SHOWN)
NOTE: Ramp should sit securely and level on bus structure. If ramp does not sit level on bus structure, install
appropriate shim spacers accordingly.
FOLLOW SEQUENCE FOR SECURING RAMP ONTO BUS STRUCTURE. DEVIATION FROM
THE INSTALLATION SEQUENCE CAN CAUSE RAMP WARPAGE.
e. Install and tighten hardware to secure ramp enclosure within bus structure.
NOTE: Installation of ramp into bus may vary by manufacturer and configuration of ramp.
f. Refer to Figure 2-3. Install left and right trim pieces with attaching hardware provided.
g. Install rear trim piece with attaching hardware provided.
RSM0068300
SCREWS
(15 PL)
TRIM (LH)
TRIM (RH)
TRIM (REAR)
FRONT
REAR
RIGHT
LEFT
FIGURE 2-3: RAMP TRIM INSTALLATION
CAUTION!

2 - 3
INSTALLATIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
3. INSTALLING VEHICLE WIRING HARNESS
Route wiring harness from vehicle ramp controls to rear of ramp. Use the supplied electrical installation kit
to connect vehicle control wiring to the ramp interface connector (Ricon P/N 51034). See Table 2-1 for 12-
pin Deutsch connector pin and signal descriptions.
a. Disconnect vehicle battery.
CAUTION
Be sure that harness does not interfere with any moving
parts, or binds against any parts, or is pinched in any way.
b. Install Main Circuit Breaker Kit (P/N 36267). Avoid installing near a heat source.
c. Refer to Chapter III Electrical Diagram, Figure 3-4. Route and install black ground cable (P/N 43929) to
ground connection and red power cable (P/N 43928) to positive connection block.
d. Route and install ramp interface harness (supplied by bus manufacturer) to ramp interface connection.
e. Cycle ramp a few times to ensure ramp is working properly.
Table 2-1: CONNECTOR SIGNAL DESCRIPTION
5 Pin 12 Pin Wire Description
A 1 White Interlock (Output) – No signal when ramp not stowed, Ground when ramp stowed.
B 2 Red Stow Attempt (Input) – 12V/24V to controller to engage stow functions.
C 3 Orange Interlock (Output) – 12V/24V when ramp not stowed. 0V when ramp stowed.
D 4 Black Deploy Attempt (Input) – 12V/24V to controller to engage deploy functions.
E 5 Brown Heater Mat (Optional) – 12V/24V to heater mat (Grounded internally).
B. FOLDOVER FR2E ELECTRIC RAMP COMPONENT REPLACEMENT AND ADJUSTMENTS
Removal of ramp assembly from vehicle and onto a workbench or work stand is necessary for access to enclo-
sure components. Moving the ramp assembly to a workbench or work stand may require two people.
Follow all safety requirements before proceeding with any of the following procedures.
1. CHAIN ASSEMBLY REPLACEMENT
In the event that the chain assembly may require replacement, follow the removal and installation proce-
dures. The chain assembly is located on the inside of the enclosure. The ramp tray will not require removal
to access the chain assembly.
a. Deploy wheelchair ramp to ground level.
b. Remove Floor Cover to access enclosure components.
c. Refer to Figure 2-4. Loosen adjustment screws of Tray Position Switch Assembly.
d. Mark the position of the chain relative to the timing sprocket of the left had crank shaft.

2 - 4
INSTALLATIO
N
MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
RSM0068500
MASTER CHAIN LINK
CHAIN
TRAY POSITION ASSY
SWITCHES
SPIDER COUPLING
ADJUSTMENT
SCREWS
FIGURE 2-4: CHAIN REMOVAL
e. Refer to Figure 2-4. Remove and retain master chain link.
f. Replace and install new chain then install master chain link.
g. Adjust tension of chain by adjusting position of Tray Position Switch Assembly.
h. Tighten two screws to secure Tray Position Switch Assembly.
i. Test the chain assembly by deploying and stowing ramp 2-3 cycles.
2. FINAL INSPECTION
a. Visually inspect ramp for loose or missing hardware and fittings, and confirm that pockets are free of
debris.
b. Verify that slanted plated cover is secure and closed on ramp.
c. Verify that non-skid flooring is clean, functional, and securely fastened.
d. Verify that manual operation strap is undamaged.

3 - 1
MAINTENANCE
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
III. FOLDOVER® ELECTRIC FR2E-SERIES RAMP MAINTENANCE
he maintenance information in this chapter applies to the Ricon FoldOver® Electric FR2E-Series Low-Floor
Vehicle Access Ramp when installed in transit vehicles. The information consists of safety precautions, a
maintenance schedule, component information, and diagrams for the electrical system. This chapter is intended
to supplement related sections of the vehicle manufacturer Owner Manual and Quick-Start Guide.
A. GENERAL SAFETY PRECAUTIONS
WARNING!
THIS ELECTRIC RAMP IS DRIVEN WITH AN ELECTRIC MOTOR DRIVE SYSTEM.
USE EXTREME CAUTION WHEN DOING MAINTENANCE AND REPAIRS. DO NOT
DISCONNECT ELECTRICAL CABLES OR FITTINGS WHEN RAMP IS IN MOTION OR
WHEN POWER IS APPLIED TO THE ELECTRIC RAMP.
Follow these safety precautions during service of the Ricon FoldOver Electric ramp:
• Under no circumstances is maintenance, repair, or adjustment of the FoldOver electric ramp to be
performed without the presence of an individual capable of giving aid.
• Give immediate attention to all injuries, and administer first-aid or seek medical attention as necessary.
• Protective eye shields and clothing should be worn during maintenance, repair, and adjustment of the
FoldOver electric ramp.
• The user must be cautious when operating the ramp. Be certain that hands, feet, legs, and clothing are
not in the path of ramp movement.
• Batteries contain acid that can burn. Wear protective clothing and eye protection at all times. If acid
comes in contact with skin, immediately flush affected area with water and wash with soap. Do not place
anything electrically conductive on top of battery. Do not smoke or use an open flame near battery.
• Work in a properly ventilated area.
• Read and understand all instructions before attempting to operate the FoldOver electric ramp.
• Inspect the ramp before use for unsafe conditions, unusual noises, or erratic movements. Do not use
ramp if any of these are present, and arrange to have a Ricon dealer or qualified service technician
inspect ramp.
• Keep others clear of the ramp while it is operating.
• Ricon strongly recommends that the vehicle be parked on level ground when using ramp. Using the
ramp when vehicle is sloped may result in a ramp angle that is too steep for safe use. In addition, the
sloped vehicle may not allow the ramp to make complete contact with the ground.
• The FoldOver electric ramp and other system components require periodic maintenance. Ricon
recommends a thorough vehicle inspection by a Ricon dealer or qualified service technician at least once
every six months. To maximize safety, the ramp and related components should be maintained at their
highest level of performance.
• Read and comply with warning labels attached to ramp.
T

3 - 2
MAINTENANCE MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
B. DAILY INSPECTION
Check ramp daily, following the Daily Inspection outlined in Table 3-1. Meet all inspection criteria before allowing pas-
sengers on ramp.
TABLE 3-1: DAILY INSPECTION
INSPECTION POINT CHECK
Ramp controller  Power ON/OFF switch operates correctly.
 Power On indicator illuminates when Power ON/OFF switch is ON.
 DEPLOY and STOW switches operate correctly.
 No unusual noises or erratic movements when ramp is deploying or stowing.
Ramp and
surrounding area
Vestibule area is free of loose objects and trim pockets are free of debris.
Ramp non-slip
surfaces
 Surface is clean and free of slippery or sticky substances that could compro-
mise user safety.
 Surface is intact and secure, and loose edges, if present, cannot create a
stumbling hazard.
END OF TABLE
C. MAINTENANCE SCHEDULE
Regular maintenance and inspection of the Ricon FoldOver® Electric FR2E-Series Low-Floor Vehicle Access Ramp
provides optimum performance and reduces the need for repairs. Maintain the ramp as directed in Table 3-2. Perform
ramp maintenance more frequently during heavy use (more than 20 cycles per day).
CAUTION!
~ This Ricon Product Is Complex ~
Required warranty period maintenance and repairs must be done at a Ricon dealer or
qualified service facility. Improper maintenance, use of non-Ricon replacement parts, or
product modification will void warranty and can result in unsafe operating conditions. We
recommend that a Ricon dealer or qualified service facility continue maintenance inspections
when warranty ends.
TABLE 3-2: MAINTENANCE SCHEDULE
INSPECTION POINT ACTION
– 6,000 MILE INSPECTION –
Electrical System Check all electrical cables and fittings; tighten or replace as necessary.
Cover Fasteners Check all threaded fasteners for looseness, and retighten as necessary.
Non-slip surface Visually check for damage to surface, and for loose or missing non-slip material.
Ramp Interior Visually check ramp interior area and remove accumulated dirt and debris.
Setscrews Check for loose or missing setscrews at these locations:
 Driveshaft couplers (2 x 4 ea)
 Sensor target (1 ea)
 Pillow blocks (2 x 2 ea)
Tighten, or replace, as necessary.
Decals Visually check for illegibility or damage, replace as necessary.

3 - 3
MAINTENANCE
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
TABLE 3-2: MAINTENANCE SCHEDULE
INSPECTION POINT ACTION
– 12,000 MILE INSPECTION –
Wiring harnesses Check wiring insulation for heavy abrasions, and connectors for looseness. Replace as necessary.
Fasteners Check all threaded fasteners for tightness and retighten as necessary.
Non-slip
surfaces
Check non-slip surface for excessive wear or damage (rips, tears, peeling, etc.), and re-
place as necessary.
– 24,000 MILE INSPECTION –
Self Aligning Assembly Grease or oil to lubricate parts is NOT recommended. Keep components clean and free
of debris. Refer to installation section for self aligining assembly replacement.
END OF TABLE
D. RAMP COMPONENT INFORMATION
Ricon FoldOver® Electric FR2E-Series Low-Floor Vehicle Access Ramp uses electrical power from the host vehicle to
deploy and stow the ramp. Vehicle electrical power is converted to mechanical force, which is used to move the ramp.
Electrical components are described below. Please refer to Figures 3-4 for electrical diagram.
1. ELECTRIC MOTOR DRIVE SYSTEM
The ramp employs an electro-mechanical motor drive system (contained within the ramp enclosure). Settings are
programmed in the motor drive system and is preset at Ricon.
The motor drive system converts electrical power into mechanical force through the crank shafts when either the
DEPLOY or STOW micro-switches are activated and controlled by an electronic controller. Ricon recommends op-
erating the ramp while the vehicle engine is running in order to minimize current drain on the vehicle battery.
2. TRAY POSITION SWITCH ASSEMBLY
A factory adjusted tray position switch assembly identifies the DEPLOY or STOW position of the ramp tray as the
electro-mechanical drive system transfers motion from the crank shaft, through the chain, onto the CAM shaft. The
CAMs attached on the rotating CAM shaft activate the micro-switches which relay signals to the electronic controller
that controls the functions of the ramp.
3. ELECTRONIC CONTROLLER
The electronic controller interprets input/output signals from the micro-switches and controls ramp functions by re-
laying signals to/from the control box. It contains integrated circuits (ICs), relays, fuses, and associated parts. The
ICs cannot be accessed externally. The 55-pin ramp connector receives 12V/24V to power the controller and sends
12V/24V through the control box that controls power to the motor drive system.
Refer to Figure 3-1 for connector and controller connection. Controller only requires one 55-pin connector connec-
tion.

3 - 4
MAINTENANCE MAY 2020
32
D
FR
E
02.
C
FR2E-SERIES SERVICE MANUAL
RSM0030600
CONTROLLER
55-PIN CONNECTOR
FIGURE 3-1: CONTROLLER
NOTE: Voltage levels are 24 to 28 VDC in this application.
4. INTERLOCK OUTPUT STATUS
The FoldOver Electric ramps has two ramp positions that are monitored by the controller. This position is fully
stowed to deployed position. The ramp must be in the fully stowed area before the electrical interlock output signal
will turn on (24VDC). This is done to reduce the possibility of a passenger tripping on the front edge of the ramp
when it is not stowed completely as well as preventing the bus from operating or moving when ramp is deployed.
Refer to Table 3-3. The status of the interlock output (GND or 12VDC/24VDC) occur when the ramp is either
STOWED or DEPLOYED. Note that the interlock output has both a normal and an inverted output. This table ap-
plies to the normal output.
TABLE 3-3: INTERLOCK OUTPUT STATUS
POSITION INTERLOCK OUTPUT
STOWED GND
DEPLOYED 12VDC/24VDC
End of Table
5. CIRCUIT BREAKERS AND FUSES
The bus builder installs a 50-amp circuit breaker for 12V or 24V applications to protect ramp control circuits. Refer
to Table 3-4 for harness fuses.
6. ELECTRICAL DIAGRAMS
Refer to Figure 3-2 for a description of plug and receptacle designations used on schematic.

3 - 5
MAINTENANCE
MAY 2020
32
D
FR
E
02.
C
FR2E
-
SERIES SERVICE MANUAL
55-PIN AMP
CONNECTOR
FUSE
(AMPERAGE
INDICATED)
DIODE
DUETSCH
CONNECTOR
12-PIN DUETSCH
CONNECTOR
WIRE CROSSINGS
NOT
CONNECTED
CONNECTED
BATTERY
(POWER SOURCE)
COMMON
RSM0068900
FIGURE 3-2: SCHEMATIC SYMBOLS
TABLE 3-4: HARNESS FUSES
FUSE RATING CIRCUIT
F1 5 AMP Lift Enable (Ramp Switch)
F2 15 AMP 12V/24V High Voltage (Motor Power)
END OF TABLE
