WAC Lighting QMP-G1RN User manual

11/22/06 Rev 1
INSTRUCTIONS: Quick Connect Canopies
Models: QMP-M1RN and QMP-G1RN
CAUTION:
Read all instructions.
Do not conceal or extend exposed conductors through a building wall.
Do not install this system in wet locations.
For low voltage exposed insulated conductor systems required by 30.1© do not install any part of this
system less than 7 feet (2.2m) above the floor.
To reduce the risk of fire and burns, do not install this lighting system where the exposed bare conductors
can be shorted or contact any conductive materials.
To reduce the risk of fire and overheating, make sure all connections are tight.
Do not install any luminaire closer than 6 inches ( 15.25 cm) from any curtain, or similar combustible
materials.
Turn off electrical power before modifying the lighting system in any way.
SAVE THESE INSTRUCTIONS
Overview: Canopies are designed to fit all W.A.C
quick connect fixtures. They may also be used on
other manufacturers brand of quick connect
(consult factory for compatibility). Uses a 50 watt
max fixture or pendant.
Canopies come with a self-contained electronic
transformer that may be dimmed with an
electronic low volt dimmer switch.
1. Loosen the three canopy screws and
separate the canopy from the base plate.
2. Remove a knock out from the base plate.
3. Support canopy and guide the black and
white wires and from the transformer through
the knock out in the base plate and into the
Junction box.
4. Connect ground wire from junction box to the
green grounding wire from the base plate.
5. Connect corresponding line volt wires from
the junction box to transformer wires, with
wire nuts (supplied). Tuck excess wire into
the junction box.
6. Attach the base plate to the junction box
using the slotted holes.
7. Raise the canopy to the base plate, and
tighten the three screws loosened earlier.
Junction Box
Base Plate
Ground wire
Canopy
Quick Connect
fitting
Finishing ring
Shown with QF-194
Fixture (not included)
