User's Manual
Item no. 9796
R
WAGAN Corp. Limited Warranty Registration Form
All WAGAN Corporation products are warranted to the original purchaser of this product.
Warranty Duration: This product is warranted to the original purchaser for a period of one (1)
Year from the original purchase date, to be free of defects in material and workmanship. WAGAN
Corporation disclaims any liability for consequential damages. In no event will WAGAN
Corporation be responsible for any amount of damages beyond the amount paid for the product
at retail. In the even of a defective item, please ship the item, prepaid, with a complete
explanation of the problem, your name, address and daytime phone number. WAGAN
Corporation will, at its option, replaces or repair the defective part. This warranty is void if the
product has been damaged by accident, in shipment, unreasonable use, misuse, neglect,
improper service, commercial use, repairs by unauthorized personnel or other causes not arising
out of defects in materials or workmanship. This warranty is effective only if the product is
purchased and operated in the USA and does not extend to any units which have been used in
violation of written instructions furnished.
Warranty Disclaimers: This warranty is in-lieu of all warranties expressed or implied and no
representative or person is authorized to assume any other liability in connection with the sale of
our products. There shall be no claims for defects or failure of performance or product failure
under any theory of tort, contract or commercial law including, but not limited to negligence,
gross negligence, strict liability, breach of warranty and breach of contract.
Warranty Performance: During the above one (1) Year warranty period, a product with a defect
will be replaced with a comparable model when the product is returned to WAGAN Corporation
with an original store receipt. The replacement product will be in warranty for the balance of the
one (1) Year warranty period.
Please activate my limited warranty for WAGAN Corp.
Enclosed copy of original sales receipt.
Name
Mail Address
City
State, Zip Code
Item Purchased Easy Quick Jumper
Stores Name
Date of Purchase
Signature Date
All WAGAN Corporation Products must be registered within (30) days of purchased to activate this warranty.
Mail the complete registration form, along with a copy of the original receipt to:
Attn: Customer Service
WAGAN Corporation
3589 Yale Way
Fremont, CA 94538
c 2004 WAGAN Corp.
Easy Quick Jumper

Easy Quick Jumper by Wagan Tech
USER’S MANUAL — Please read before using this equipment.
________________________________________________________________________________________________________________________________________________________________
www.wagan.com
© 2004 Wagan Corporation.
All Rights Reserved.
Wagan and Wagan.com are trademarks used by Wagan Corporation.
Thank you for purchasing the Easy Quick Jumper by Wagan Tech. With normal
care and proper treatment it will provide years of reliable service. Please read all
operating instructions carefully before use.
FEATURES
•Safe, easy and effective.
•Starts a car in 10 minutes.
•Simply connect between the 12V cigarette lighter sockets of two vehicles
without the need to open the hoods.
•LED lights illustrate the charging process.
•Designed for 12V vehicles only.
•This system will only function with cigarette lighter sockets with positive
center posts.
•Safer than jumper cables.
•Extra long 20 ft. power cord.
SPECIFICATIONS
•Rating: 12V 6A DC
•20 ft. cord
OPERATING INSTRUCTIONS
1. Make sure the lamps, stereo, air conditioner, and all power using
equipment are turned off.
2. Connect the plug with longer blue power cord to the “run-down” vehicle’s
cigarette lighter socket.
3. Connect the shorter black power cord to the operating vehicle’s plug.
4. Start the engine of the operating vehicle; the red “charging” LED should
turn on.
5. About 10 minutes later when the red LED turns green, start the engine of
the “run-down” vehicle.
6. Once the engine of the vehicle with the “run-down” battery starts, remove
the plugs from the cigarette lighter sockets on both vehicles and stow the
Easy Quick Jumper for future use.
7. Allow the engine on the just-started vehicle to warm up to operating
temperature before driving.
8. If the engine of the vehicle being jumped doesn’t start after the second
attempt, the battery may have been depleted. Under such conditions a
battery replacement would be needed.
TROUBLESHOOTING
1. Remove and reinsert the black plug into the cigarette lighter socket.
2. Restart the engine of the operating vehicle and allow the vehicle to continue to
run.
3. Remove and reinsert the blue plug into the vehicle with the “run-down” battery.
4. Switch the ignition lock of this vehicle to the “Accessory” position.
5. This system will only function with cigarette lighter sockets with positive center
posts.
6. Wait for 10 minutes or more and try again.
7. Be sure that all accessories on both vehicles are turned off.
8. Remove and reinsert both black and blue plugs.
9. No recharging system will help a battery that is shorted internally or
malfunctioning. Under such conditions please replace the battery.
Problems: Possible Cause:
The black power cord plug is not fully inserted
into the cigarette lighter socket of the operating
vehicle.
The engine of the operating vehicle is not
running.
The green LED power indicator
going to the operating vehicle
does not illuminate when the
plug with the shorter cord is
inserted into the cigarette lighter
socket. The “run-down” vehicle’s cigarette lighter
socket has a negative center post.
The blue power cord plug has not been properly
inserted into the vehicle with the “run-down”
battery.
The ignition lock of the vehicle with the “run-
down” battery is not in the “accessory” position.
The green “power” LED
illuminates, but the red
“charging” LED panel does not
illuminate in sequence.
The “run-down” vehicle’s cigarette lighter
socket has a negative center post.
The battery in this vehicle is fully discharged or
shorted internally.
There is not sufficient electric power in the
“run-down” battery to start the engine.
The vehicle with the “run-down”
battery will not start after 10
minutes.
System plugs are NOT properly inserted in the
cigarette lighter sockets.
