Wahl ZX805 User manual

1
Table blender
with grinder
ZX805
SAFETY FIRST:
Never touch the blades while the appliance is plugged in
Always read your instructions before using for the rst time

2
Please read all instructions carefully to familiarise yourself with the
Wahl Table blender and grinder before using.
THIS TABLE BLENDER & GRINDER IS INTENDED FOR HOUSEHOLD
USE ONLY.
Save these instructions for further reference
For any further assistance or information call customer services on
T: 01227 740066
or visit
W: www.wahl.co.uk
E: customer[email protected]
CONTENTS
DESCRIPTION OF PARTS Page 3
IMPORTANT SAFEGUARDS Page 4
BEFORE USE Page 8
HOW TO USE Page 9
CLEANING & STORAGE Page 11
GUARANTEE Page 13
PRODUCT REGISTRATION Page 13
WIRING Page 15

3
Lid
Plastic Jug
Measuring Cup
Blade/
Blade Housing
Mainbody
Grinder
Bowl
Blade/
Blade Housing
Dial
Description of parts

4
Wahl kitchen innovations
Innovative products since 1919
Please read this instruction manual carefully and familiarise yourself
with your new Table Blender with Grinder before using for the rst
time. Please retain these instructions for future reference.
IMPORTANT SAFEGUARDS
When using this electrical appliance, especially when children
are present, basic safety precautions should always be observed
including the following.
TO REDUCE THE RISK OF FIRE AND INJURY
1. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental

5
Wahl kitchen innovations
Innovative products since 1919
capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
2.Never touch or allow contact with moving parts while in motion.
keep hands, hair clothing and other utensils away from the
moving parts during operation to prevent accident, injury or
damage to the appliance.
3.Switch off the appliance and unplug from outlet when not in use,
before putting on or taking off attachments and also before
cleaning the appliance.

6
Wahl kitchen innovations
Innovative products since 1919
4.Never use your appliance without paying attention! Always unplug
the unit when not in use or left unattended.
5.Do not operate the appliance with a broken cord or plug, or if the
appliance malfunctions, or is dropped or damaged in anyway.
6.Any servicing or repair must be performed by an authorized
service representative.
7.Do not use outdoors or in damp areas.
8.Do not let the cord hang over the edge of the work surface or let it
touch any hot surfaces.
9.Only use the attachments supplied with this product. The use of
attachments that are not supplied by the manufacturer may cause
re, electric shock or injury and damage to the appliance.

7
Wahl kitchen innovations
Innovative products since 1919
10. To protect against risk of electrical shock, never immerse the unit
or let it come into contact with water or any other liquids. Do not
use the unit with wet hands. If the appliance should become wet,
damp or fall in water, remove plug from mains socket
immediately. Do not put your hands in the water.
11. Never carry the unit by its power cord.
12. Use this appliance only for its intended purpose.
13. Never use this appliance to blend anything other than foods.
14. Always cool hot liquids before blending.
15. The blades are extremely sharp, handle with care.
16. Always switch off the unit before pulling out the mains plug.
17. Do not remove individual housing components.
18. Only use the unit with the lid tightly closed.

8
Wahl kitchen innovations
Innovative products since 1919
BEFORE USE
1. Remove all packaging and clean the jug, measuring cup and lid thoroughly before using for the rst time.
Only clean the main unit with a damp cloth. Never immerse the unit in water or place under running water.
See cleaning & storage section page 11 & 12 for full cleaning instructions.
WARNING: Never touch the blades while the appliance is plugged in, the blades are sharp.
extreme care should be taken when handling.
2. Do not plug in the appliance before assembling.
3. Place the appliance on a at surface.
4. Place the jug on to the motor unit lining up the markings on the jug and mainbody and lock into place by
turning clockwise.
5. Put the lid on top of the jug and push it down. Insert the measuring cup into the cover and turn until it locks
into place.
6. Make sure the appliance is turned off before plugging in.

9
Wahl kitchen innovations
Innovative products since 1919
HOW TO USE
1. Before plugging in ensure that the mains voltage matches that shown on the rating label.
2. This unit has a safety design, it will not work if the jug is not installed onto the main body properly.
3. Turn the control dial to position 0 in order to make sure the unit is turned off.
4. Place ingredients into the jug, do not exceed the maximum 1.5L capacity. Do not operate without any ingredients.
5. Put the lid on top of the jug ensuring it is tted correctly.
IMPORTANT: Do not open the lid while the blender is working.
6. Turn the control dial clockwise to your desired speed, or use the pulse function by turning the dial anti-clockwise.
Control settings
P - Pulse. The pulse setting will operate at the highest speed, and will only operate when you are holding the switch,
as soon as you release the switch the appliance will stop. This is suitable for ice and for when you only want to roughly
blend ingredients and you require control so that you don’t end up with a really ne mixture.
1 - Low Speed. Will blend continuously on low speed until you return
the switch to the off position.
2 - High Speed. Will blend continuously on high speed until you return
the switch to the off position.
0 - Off. Will turn off the unit.
7. Turn the dial to the “0/OFF” position when you have nished. Wait for the blender
to completely stop.

10
Wahl kitchen innovations
Innovative products since 1919
8. Always ensure the appliance is unplugged after use.
9. Do not operate the appliance continuously for more than 1 minute. Always allow the appliance to cool down to room
temperature before continuing.
10. If blending warm liquids remove the measuring cap and start at low speed increasing to high speed if required. The
pulse setting is not recommended for warm liquids. Do not blend warm liquids over the 1L level, and always take care
to avoid contact with any steam or liquids.
WARNING: ALWAYS COOL HOT LIQUIDS BEFORE BLENDING.
NOTE: It is recommended to cut the meat, vegetables or other food into smaller pieces before putting them in the jug.
Large quantities of food should be processed in small batches, do not overload.
USING THE GRINDING ATTACHMENT
1. Make sure the unit is unplugged and turned off before installation of the grinder attachment.
2. The grinder can be used for nuts, dried fruit, bread crumbs etc.
3. Turn grinder upside down and carefully unscrew the blade housing. Carefully remove the blade housing.
4. Fill the grinder with desired ingredients. Do not ll more than half full.
5. Screw the blade housing tightly on to the bowl.
NOTE: If it is not tightly screwed together the motor will not work due to a safety mechanism.

11
Wahl kitchen innovations
Innovative products since 1919
6. Turn the grinder the right way up and lock into place on the motor unit by turning clock wise.
7. Plug the appliance in and select desired speed setting.
8. When the ingredients have been grounded/chopped to the desired consistency, unplug the appliance, and
remove the grinding unit from the appliance.
WARNING: ALWAYS UNPLUG AND REMOVE THE COMPLETE GRINDING UNIT. DO NOT UNSCREW THE
BOWL ON THE UNIT. AS THIS WILL CAUSE THE INGREDIENTS TO SPILL OUT AND EXPOSE THE BLADE UNIT.
9. Turn the grinder upside down and carefully unscrew the blade housing. Carefully remove the housing and empty the
ingredients into a bowl etc.
CLEANING AND STORAGE
GRINDER ATTACHMENT
1. Ensure the appliance is turned off and unplugged before cleaning.
2. In addition to the following you must refer to the safety precautions.
3. Turn grinder upside down and carefully unscrew the blade housing. Carefully remove the housing. Clean with hot
water and a little mild cleaning agent taking great care as the blades are very sharp.
4. Ensure the bowl and blades are clean, rinse and dry well before re-using.
5. Never use aggressive cleaning agents.
WARNING: DO NOT TOUCH THE SHARP BLADES, WHEN CLEANING PLEASE WIPE WITH A CLOTH TO
AVOID ACCIDENTAL INJURY.

12
Wahl kitchen innovations
Innovative products since 1919
CLEANING AND STORAGE
BLENDER AND JUG
1. In addition to the following you must refer to the safety precautions.
2. Do not clean motor main body, power cord and plug with water.
3. Clean the main body with a soft, damp cloth and some mild cleaning agent.
4. Fill the jug half-full with warm water and a little cleaning agent. Let the unit run on speed 2 until the jug is clean.
5. Ensure the jug and blades are clean, rinse and dry well before re-using. Caution! The blades inside of the jug are very
Sharp.
6. Never use aggressive cleaning agents.
WARNING: ALWAYS UNPLUG THE MAIN HOUSING AND REMOVE THE COMPLETE JUG ASSEMBLY
BEFORE ATTEMPTING TO UNSCREW THE BLADE HOUSING.
NEVER PLACE OR STORE THE BLADE HOUSING ON THE MAIN UNIT WHILST REMOVED FROM THE JUG.
REMOVABLE BLADE HOUSING
To make cleaning of the blades easier the blade housing can be removed. Please ensure that you read the following
instructions carefully.
1. Ensure the appliance is turned off and unplugged.
2. Remove the jug assembly from the base. Turn upside down, and twist the blade housing clockwise as indicated by the
arrows.
3. Carefully remove the blade housing and wash with mild cleaning agent, taking great care as the blades are sharp.
4. Dry all parts carefully.

13
Wahl kitchen innovations
Innovative products since 1919
TO REASSEMBLE
1. Carefully twist the blade housing anti clockwise back into place as indicated by the arrows ensuring that it is
securely tightened.
PRODUCT REGISTRATION
Wahl are constantly developing and launching new products in the UK. We would like to understand your product needs
and expectations and we value any comments you may have. As part of Wahl Customer Care, we are offering you the
chance to be kept up to date with the latest product launches, innovations and special offers.
Please take a minute to register your product online at www.wahl.co.uk.
GUARANTEE
This product is guaranteed against defects in material and workmanship for a period of twenty four months from the date of
original purchase or receipt as a gift.
The guarantee becomes invalid in the case of misuse or repair by unauthorised persons.
Should this product become defective during the warranty period, return it to the store of purchase together with your proof
of purchase for repair or replacement without any charges to you.
This guarantee in no way affects your rights under statutory law in the United Kingdom.

14
Wahl kitchen innovations
Innovative products since 1919
WASTE ELECTRICAL & ELECTRONIC
EQUIPMENT DIRECTIVE 2002/96/EC
(WEEE)
At the end of this products life it should not be
disposed of with general household waste.
Care should be taken to dispose of in a
suitable manner in accordance with your
Local Authority regulation.

15
Wahl kitchen innovations
Innovative products since 1919
WIRING
WARNING: If the supply cord is damaged it must be
replaced by the manufacturers service agent or a
similarly qualied person in order to avoid a hazard.
The wires in the mains lead of this Table Blender are
coloured in accordance to the following code:
Blue Neutral (N) Brown live (L)
This appliance is tted with a 3 pin plug which has a
13amp fuse tted.
If the plug supplied is not suitable for your socket or
becomes damaged, it should be cut off and disposed
of, and a suitable plug tted as detailed below.
As the colours of the wires in the mains lead of this
Table Blender with Grinder may not correspond with
the colour markings identifying the terminals in your
plug, proceed as follows.
The wire which is coloured BLUE must be connected
to the terminal in the plug which is marked with the
letter ‘N’ or coloured BLACK or BLUE.
The wire which is coloured BROWN must be
connected to the terminal in the plug which is marked
with the letter ‘L’ or coloured RED or BROWN.
DO NOT connect either wire to the terminal in the
plug which is marked with the letter ‘E’ or has the Earth
symbol, or coloured GREEN or GREEN/YELLOW.

12
WAHL (UK) LIMITED
HERNE BAY TRADE PARK, SEA STREET
HERNE BAY, KENT, CT6 8JZ.
CUSTOMER CARE TEL: [phone]
www.wahl.co.uk
Form No. ZB166
Rev1 - 06/14
Table blender
with grinder
ZX805
