Wahl Lithium Ion Triple Play 9880 User manual

1
Lithium Ion Triple Play
Trimmer Kit Lithium Ion Triple Play
9880

2
Lithium Ion Triple Play
Please read all instructions carefully to familiarize yourself with the
Wahl Lithium Ion Triple Play before using.
Save these instructions for further reference.
For any further assistance or information call customer services on
T: 01227 744330
or visit
W: www.wahl.co.uk
E: [email protected]
INDEX
IMPORTANT SAFEGUARDS Page 3
USING YOUR TRIMMER Page 4
USING GUIDE COMBS Page 7
CLEANING AND MAINTENANCE Page 9
WIRING Page 11
PRODUCT REGISTRATION Page 12
GUARANTEE Page 14

3
Lithium Ion Triple Play
IMPORTANT SAFEGUARDS
When using this electrical appliance, especially when children
are present, basic safety precautions should always be
observed including the following.
TO REDUCE THE RISK OF FIRE AND INJURY
1. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
2. Switch off the appliance except when charging, and unplug from
outlet when not in use, before putting on or taking off
attachments and also before cleaning the appliance.
3. Never use your appliance without paying attention! Always
unplug the unit when not in use, even for a moment.
5. Do not operate the appliance with a broken cord or plug, or if the
appliance malfunctions, or is dropped or damaged in anyway.
6. Any servicing or repair must be performed by an authorized
service representative.
7. Do not use outdoors or in damp areas.
8. Do not let the cord hang over the edge of the work surface or let
it touch any hot surfaces.
9. The use of attachments that are not supplied by the manufacturer
may cause fire, electric shock or injury and damage to the
appliance.
10.To protect against risk of electrical shock, never immerse the unit
or let it come into contact with water or any other liquids. Do not
use the unit with wet hands. If the appliance should become wet,
damp or fall in water, remove plug from mains socket
immediately. Do not put your hands in the water.
11.Never carry the unit by its power cord.
12.Use this appliance only for its intended purpose.

4
Lithium Ion Triple Play
RECHARGING YOUR TRIMMER
1. This trimmer is conveniently designed for household use. It should be
allowed to charge 1 hour before first use.
2. Remove the trimmer, transformer and accessories from the packing
material.
3. Connect the transformer to the trimmer, BE SURE THE TRIMMER IS IN
THE OFF – 0 POSITION WHEN CHARGING.
4. Plug the transformer into any convenient electrical outlet at the correct
voltage.
5. When trimmer is low in power, it should be connected to the
transformer and plugged into an outlet to assure maximum power is
available when it is next used. This transformer is designed to
completely charge the battery without over charging. Do not use the
trimmer while it is charging.
6. The battery will take approximately 60 minutes to charge. The lithium
Ion trimmer also has quick charge capability.
WARNING: Only use the transformer supplied with the trimmer
TROUBLESHOOTING
If your trimmer does not seem to take charge, check the following before
returning it for repair.
1. Check outlet to make sure it is working by plugging in another
appliance.
2. Be sure the trimmer is properly connected to the transformer, all
connections are secure and the switch on the trimmer is turned OFF – 0
3. If you electricity is connected to a master power switch, we suggest the
trimmer be disconnected from the charger anytime the master switch is
off. Leaving the unit plugged into a dead outlet or unplugged charger
will drain the battery.
4. If the trimmer does not run and is completely charged, turn the unit
ON – I and pinch or push the blades manually. (Oil may have dried out
between the blades, so they may be temporarily stuck together).
USING YOUR TRIMMER
SPECIAL FEATURES
Rotary Shaver Head Attachment.
Your shaver has been designed with several advanced features to help
you get perfect results every time you groom. Your shaver head detaches
and can be replaced by several other grooming tools to achieve your no
compromise look.

5
Lithium Ion Triple Play
• Toremoveshaverhead,pulltheheadinadownwardfashionandaway
from the switch.
• Tore-attach,Locatesmalltabandhookontoback,thenrockforward
until it snaps down. Before using, make sure the head is fully attached
with no gaps between the shaver head and shaver body.
• Openshaveheadlidtoremoveorcleanunwantedhairfromchambers.
 Simplypulluptherazorfoillidasshown.Tore-attachit,alignpegsfrom
razor lid with guide holes on shaver base attachment.
A detachable blade system enables you to quickly change from a shaver
to a precision trimmer to trim moustache, goatee or anywhere. To remove
attachment, simply pull top edge of blade away from body unit. To attach,
align back tab of attachment head to cavity on the inner edge of trimmer
unit and push down on top of the blade.
Should blades become dull or damaged or if you want additional
attachment heads for your trimmer, you may purchase them from Wahl
UK.
6 POSITION COMB
A 6 position trimming guide makes achieving a consistent trim easy every
time. The guide can be removed (providing a seventh cutting position) and
re-attachedwithoutchangingthepresetcuttinglength,soonceyouhave
found the perfect length, there’s no guesswork in achieving it every trim.
The trimming guide is a two piece assembly, consisting of a base and a
comb. It should not be disassembled. To attach the guide, simply slide it
on at a slight angle and press the release tab down to secure in position.
To remove the guide, gently push up on the release tab and slide the
assembly away from the trimmer. Adjust the trimming length by pressing
on the thumb lever and moving the comb forward or backward to the
desired setting
ROTATING HEAD
The trimming head rotates 180 degrees, providing two trimming positions.
This allows you to achieve the optimum ergonomic relationship between
the hand, the trimmer and the face. Rotate the head to the desired position
as follows. With the switch in the OFF – 0 position, depress the lock button
and rotate the head clockwise or counter clockwise 180 degrees.
WARNING: Do not rotate head during use with shaver attachment.

6
Lithium Ion Triple Play
ROTARY SHAVER USE
For new rotary shave use
• Useyournewshaverexclusivelyfor3weekstofullyenjoythe 
closeness of a Wahl shave.
• Atrstyoumaynotgetascloseashaveasyouexpect,oryourface
may even become slightly irritated. This is normal since your beard and
skin will need time to adjust. Invest 3 weeks and you’ll soon enjoy the
full joy of your razor.
How to shave with an electronic razor
• Shavingwithacleandryfacegivesthebestresults.
1. Turn razor ON with the on/off button. Shave against the direction of the
beard growth using both straight and circular movements.
2. Stretch your skin taut with your free hand so blades can more clearly
cut whiskers. Gently press razor to skin so the floating heads can follow
the contour of the face.
WARNING: Do not press to hard as hair does not feed so well, too much
pressure can pinch the skin into the blades.
3. Turn razor OFF with the On/Off switch
NECKLINES AND SIDEBURNS USING TRIMMER HEAD
Detach shaver head had previously described. Attach trimmer blade,
slowly move trimmer downward on desired areas to neatly trim and shape.
TRIMMING AND EDGING YOUR FACIAL HAIR
The following are suggested trimming steps and trimmer positions, you
may find different procedures work better for you.
1. Comb your beard in the direction that it grows to help reveal stray hairs
that may be longer than others.
2. Attach the 6 positions trimming guide to trim and taper your beard.
Begin with guide set at a long trimming length. Trim toward your chin
in smooth, overlapping strokes following the lay of the beard. If you
trim against the way your beard naturally lays, the trimmer will cut the
hair much shorter and the result may be patchy.

7
Lithium Ion Triple Play
Adjust the trimming to progressively shorter settings until you reach
the desired length of beard. You may wish to set the trimming guide
attachment to cut closer near the ear and down under the chin. When
the trimming guide is removed, it will remain at the last length setting
until you change it.
Always be sure the trimming guide is locked solidly into the desired
position before you start to trim.
3. To cut the outline of your beard, remove the trimming guide. Starting
under your chin and working back toward your jawbone and ears, cut
the outer perimeter underneath the jawbone. Continue the line all the
way up to the ears and hairline.
4. Accentuate your beard line by using the trimmer in a downward motion.
Start at the line you’ve created and, working from the chin back toward
the ears, trim the area right under your beard line.
5. Define the upper part of your beard using the same technique.
6. For a neater finished look, replace attachment blade to the detail
attachment. Use this blade for fine, detail trimming anywhere it is
needed, such as the sideburns near the ears, goatees e.t.c.
USING GUIDE COMBS
To attach the guide combs, hold the comb with the teeth up. Snap guide
comb attachment firmly to the bottom of the trimmer blade.
TRIMMING WITH GUIDE COMBS
The stubble guide has 1 bar, the medium cut attachment has 2 bars and the
long cut attachment has 3 bars. These attachments are ideal for blending,
tapering and defining beards, as well as for achieving a close trim stubble
look around the face. To use the attachments, go with the hair direction. To
achieve closer looks, go against the hair direction.
TRIMMING NOSE HAIR
Make sure the nasal passages are clean. Slowly move the detailer in and
out of each nostril, no more than ¼ inches deep.
TRIMMING EAR HAIR
Make sure the outer areas of the ears do not contain any wax. Hold the ear
flat with one hand and carefully insert detailer no more than ¼ inches into
the outer ear.

8
Lithium Ion Triple Play
WARNING: Do not insert the detailer or any other foreign object into the
inner ear.
For hair growing on the outside of the ear, simply move the detailer slowly
along the edges of the ear.
TRIMMING EYEBROWS WITH COMB
Snap on the eyebrow guide comb on detailer. Slowly move the detailer to
neatly trim stray hairs. Do not press hard against brow as it may remove
too much hair. You may also use your trimmer blade with the #2 or #3
guide comb. Move the trimmer with the direction of the hair flow (from the
bridge of your nose to the temple). Be sure to mind your eyelashes as you
trim.
TRIMMING ARM & LEG HAIR USING TRIMMER HEAD
Simply glide the trimmer over your arm or leg until desired hair length is
achieved. The first time you trim the hair, start by using a longer setting on
the guide comb on the guide comb on the trimmer, then use progressively
shorter settings if a shorter length is preferred.
TRIMMING CHEST & STOMACH USING TRIMMER HEAD
Glide the trimmer over your torso region, in an upward motion until desired
hair length is achieved. For tight, scratch free trimming use the #1 guide
comb.
TRIMMING PRIVATE AREAS WITH THE TRIMMER & DETAILER HEAD
1. Volume reduction using trimmer head. Attach guide comb and select
a long trimming length. Begin trimming, starting at the top and working
down. Use progressively closer settings to get the look and length you
prefer.
2. For hard to reach or tight areas, use the detailer head. Always pull skin
taut. Then slowly move the detailer through the area to trim until desired
look is accomplished.
3. Shave your private areas by gently shaving in the desired area and
always keep the skin taut.

9
Lithium Ion Triple Play
CLEANING AND MAINTENANCE
CLEANING ROTARY SHAVER (ATTACHMENT HEAD ONLY)
• Regularcleaningguaranteesbettershavingresults.
• Neverclean,removeorreplaceattachmentheadassemblywhilemotor
is on.
• Donotapplypressuretobladefoils.Donottouchrazorheadswithhard
objects as this may dent or damage precision made slotted blade foils.
• Donotuserazorifbladefoilsaredamagedorbroken.
• Therotaryshavermaybeopeneduptodischargewhiskers.
WARNING: Do not immerse razor unit in water.
• OnlygettheshaverlidwetandNOTtheshavebase.Watermaygetinto
the base and become trapped. Only brush or blow out the base if
whiskers remain.
• Thequickestandeasiestwaytocleantherazorheadsistorinsethem
after each use or at least once a week with water. Water from the tap
should be on a cold setting.
1. Always switch razor OFF, unplug and remove power cord before
cleaning.
2. Before cleaning under tap water, first remove the rotary shaver
attachment from body as described earlier.
3. Pop open top razor foil from attachment head.
4. Clean inside and outside the razor heads and chamber by running under
cold water.
5. Leave razor head assembly open to air dry before next use.
IMPORTANT: Do not wipe or dry the shaving heads with a towel or tissue.
This could damage the shaving heads.
6. If the shaving assembly comes detached from the shaver base, align
pegs from razor lid with guide holes on the shaver base attachment.
7. You may also clean the hair chamber without water by using the
supplied cleaning brush.

10
Lithium Ion Triple Play
OILING BLADES
For best results, put one or two drops of Wahl Clipper oil on the trimmer
blades before and after each use. Motor bearings are permanently
lubricated-donotattempttooil.
When oiling your trimmer, turn the trimmer ON – I, hold the unit with the
blades facing down and squeeze one or two drops of oil onto the blades.
Wipe the excess oil with a soft cloth.
IMPORTANT: Do not over Oil!
BLADE CARE
Trimmerbladesareprecision-hardenedgroundandtappedcuttingteeth.
Blades should be handled carefully and never bumped or used to cut dirty
abrasive material. Never rinse the blades with water, or the blades may
rust. Clean with the included cleaning brush.
CLEANING/STORAGE
Before storing your trimmer, use the cleaning brush to whisk any loose
hairs from the unit and the blades. Store the unit in such a manner so that
the blades are protected from damage. When the trimmer is not in use, the
trimmer blade guard should be in place. Store rotary shave with included
head cover.

11
Lithium Ion Triple Play
IMPORTANT WIRING INSTRUCTIONS
WARNING: If the supply cord is damaged it must be replaced by the
manufacturers service agent or a similarly qualified person in order to
avoid a hazard.
This product must only be used with the transformer supplied. Should a
replacement be required contact Wahl on 01227 740666

12
Lithium Ion Triple Play
PRODUCT REGISTRATION
Wahl are constantly developing and launching new products in the UK.
We would like to understand your product needs and expectations and we
value any comments you may have. As part of Wahl Customer Care, we
are offering you the chance to be kept up to date with the latest product
launches, innovations and special offers.
Please take a minute to register your product online at www.wahl.co.uk.

13
Lithium Ion Triple Play
WASTE ELECTRICAL & ELECTRONIC EQUIPMENT DIRECTIVE 2002/96/EC
(WEEE)
At the end of this products life it should not be disposed of
with general household waste.
Care should be taken to dispose of in a suitable manner in
accordance with your Local Authority regulation.

14
Lithium Ion Triple Play
GUARANTEE
This product is guaranteed against defects in material and workmanship for
a period of 5 years from the date of original purchase or receipt as a gift.
Should this product become defective during the guarantee period, return
it to the store of purchase together with your proof of purchase for repair
or replacement
Alternatively within the guarantee period you can return the product
to Wahl (UK) Ltd who will repair any such defect or elect to replace the
product or any part of it, without charge, provided that there is proof of
purchase. Should a replacement be offered this will not extend the original
guarantee period.
The guarantee becomes invalid in the case of misuse, alteration or repair
by unauthorised persons.
This guarantee does not include blades, cables, shaver heads, foils and
cutters etc., which are consumable parts.
This product is designed for domestic use only and use within a
professional environment will invalidate the guarantee.
This guarantee in no way affects your rights under statutory law in the
United Kingdom.

15
Lithium Ion Triple Play
NOTES

16
Lithium Ion Triple Play
Wahl (UK) Ltd
Herne Bay Trade Park
Herne Bay
Kent
CT6 8JZ
www.wahl.co.uk
Customer Service T: 01227 744330
FormNo.94596-900
Rev005-12
