Model Numbers Covered in this Specification
PC[1]8140E PASTA COOKER (10.5 kW).
PC[1]8140E-7 PASTA COOKER (7.0 kW).
NOTE: [1]: - - Standard Back Models.
L - Low Back Models.
General
A commercial heavy duty, electric, high performance Pasta Cooker designed for cooking in a
commercial high production output site. The boiling medium is contained within a heavy gauge
stainless steel tank, heated by a 3 coil heavy duty element within the tank.
This Pasta Cooker features an Over Temperature Safety Cut Out System.
An open tank design and pivoting element system to make cleaning a simple and easy task.
Optional Accessories
This appliance can be fitted with the following optional accessories, (refer to the 'Replacement Parts
List' for details).
• Plinth Kit.
• Basket 320 x 165 mm.
Electrical Supply Requirements
Electrical Connection
Electrical supply connection point is located 56 mm from the right hand side, 529 mm from the rear of
the appliance and 489 mm from the floor.
When connecting a this electric appliance to the mains supply, ensure that the following is carried
out:-
•
The supply cord shall not be lighter than ordinary tough rubber sheathed (oil
resistant) cord. e.g. H05 RN-F with sufficient current carrying capacity cable sizes.
•
The branch supply line shall be overload protected.
•
The point of connection shall be as close as practicable to the appliance and shall
have a
n isolating switch accessible during manual operation of the appliance.
• The supply cord shall be protected against any mechanical or thermal damage.
Refer to the appropriate wiring standards for the size of cable that is to be supplied to an appliance
for the current drawn on that line.
Water Supply Requirements
A cold water supply must be connected to the water inlet connection (R 1/2" BSP), located 49mm from
the LH side, 556 mm from rear and 139 mm from the floor. This should be plumbed in, in accordance
with National / Local Codes covering installation.
Maximum water supply pressure 550 kPa (80 psi).
Tank capacity - 40 ltrs of water.
Specifications
WARNING:
THIS APPLIANCE MUST BE EARTHED. IFTHE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY A
SUITABLY QUALIFIED PERSON IN ORDER TO AVOID AHAZARD.
Standard Ex-Factory Model Convertible to:
PC8140E 10.5 kW 3P+N+E, L1=L2=L3 = 15A @ 240V 1P+N+E, 44A @ 240V
PC8140E-7 7.0 kW 1P+N+E, 30A @ 240V 3P+N+E, L1=L2=L3 = 10A @ 240V
