Walker Edison D42MAR3D User manual

Insert wooden dowel (A) into parts (3,4,5,6,8,10,11) as per diagram.

Secure cam bolt (C) into parts (1,9) with Philips head screwdriver as per diagram.

Using screw (J) attach part (1) to part (8) with Philips head screwdriver as per diagram.

Using cam lock(B) secure parts (3,4,5,6) to part (1) with Philips head screwdriver as per diagram.

Put part (7) as per diagram.

Using screw (H) attach part (14) , screw (L) attach plastic wedge (K) to part (2) with Philips head
screwdriver as per diagram.

Using screw (D) attach part (2) into parts (3,4,5,6) with hex key (E) as per diagram.

Using screw (N) secure plastic wedge (M) to part (7) with Philips head screwdriver as per diagram.

Using screw (J) attach parts (10,11) to part (12) with Philips head screwdriver as per diagram.

Put part (13) as per diagram.

Using cam lock(B) secure part (9) to parts (10,11,13) with Philips head screwdriver as per diagram.

Place sticker (G) cover the holes as per diagram .

Using bolt (F) attach parts (15,18) to parts (16,17) with hex key (E) as per diagram.
Note：Do not fully tighten all the bolts .

Using bolt (F) attach parts (15,16,18) to part(2) with hex key (E) as per diagram.
Note：Fully tighten all the bolts.

Insert the assembled drawers into the unit frame.
