Walker Edison W528D4C User manual

Item # : W528D4C
Assembly Instructions
  
 
Revised 03/2017
Copyright © 2016, by Walker Edison Furniture Co., LLC. All rights reseed. P.1

Attach cam bolts (B) to parts (1). Insert wooden dowels (A) into parts (2).
Insert wooden dowels (A) into parts (5, 6) and (8) as shown in the diagram.

Attach cam bolts (B) and Insert wooden dowels (A) into parts (9,10,11) and (12).
Attach parts (9) and (11) to part (8), then insert and tighten cam locks (C) as shown in the
diagram.

Attach parts (10) and (12) to part (8), then insert and tighten cam locks (C) as shown in the
diagram.
Use the wrench (U) to tighten bolts (N) to connect parts (5) and (6) to part (2).

Use cam bolts (C) to connect parts (9) and (11) to part (2).
Use cam bolts (C) to connect parts (10) and (12) to part (2).

Secure shelf (3) to legs using parts (F) and (G) as shown in the diagram.
Use cam bolts to connect part (1) to the frame assembly as shown in the diagram.

Attach back panels (15) and (16) using screws (D) as shown in the diagram.
Place stickers (M) over cam locks as desired.

Insert shelf supports (E) and place shelves (4) and (7) as shown in the diagram.
Attach door stopper (P) to designated areas by using screws (Q).

Attach hinges (K) to the doors (13,14) by using screws (L).
Attach handles (H) to the doors (13,14) by using screws (J). Attach metal stopper (R) using
screw (S).

Attach hinges (E) by using screws (F) as shown in the diagram.
