Item#: DW54PEREX
AssemblyInstructions

P.4
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
8x30mm Woodendowel 38 pcs
Philipsheadscrewdriverrequiredforassembly
(notincluded)
A
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
6x35mm Cambolt 40 pcs B
15x11mm Camlock 32 pcs
C
30mm Sticker
8pcs D
6x50mm Screw
40 pcs E
10 pcs F
G
H
J
K
L
M
N
P
Q
15x9.5mm Camlock
R
HardwareList
Gluetube 1 pc
S
T2
Drawerslider sets
*Note:Thispiece comes preassembled for
shippingpurposesand must bedisassembled
tocompletethe deskassembly.
4mm HexKey 1 pc
Screw 12 pcs
Screw 36 pcs
4x32mm
3x12mm
Bolt
6x12mm 20 pcs
4pcs
Europe Hinge
Shelf supportpin 8
Screw 24 pcs 3.5x14mm
2pcs
pcs
4pcs
2pcs
Handle
Connectingiron sheet
Doorstopper

P.5
Step 1
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
T
T
Sliderarm
Sliderbracket
Sliderarm
Sliderbracket
Pick up the slider arm (T) and separate the slide Runner for the following Steps. Extend
the Slide .Runner all the way forward,press the plastic release lever of the slider arm up
and pull the Slide Runner Complete out .

P.6
Step 2
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
x2
T
T
L
L
L
L
L
L
19
18
Using Screw (L) attach part (T) to parts (18,19) with Philips head screwdriver as per diagram.

Insert wooden dowel (A) into parts (7,8,11,12) ,then secure Cam bolt (B) into part (7) and using
Screw (L) attach door stopper (P) to parts (11,12) with Philips head screwdriver as per diagram.

Insert wooden dowel (A) into parts (9,10) ,then secure Cam bolt (B) into part (1) with Philips head
screwdriver as per diagram.

Using Screw (M) secure part (10) to part (1) with Philips head screwdriver as per diagram.

Insert wooden dowel (A) into parts (2,3,4,5) ,then secure Cam bolt (B) into parts (2,3,4,5) with
Philips head screwdriver as per diagram.

Step 7
P.11
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
2 3
45
TT
TT
LLLLLL
LLLLLL
T
L
Using Screw (L) secure part (T) into parts (2,3,4,5) with Philips head screwdriver as per diagram.

Step 8
P.12
21 3
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
C
C
11
3
Using Cam lock (C) secure part (11) into part (3) with Philips head screwdriver as per diagram.

Step 9
P.13
21 3
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
11
2C
C
Using Cam lock (C) secure part (11) into part (2) with Philips head screwdriver as per diagram.

Step 10
P.14
21 3
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
4
12
C
C
Using Cam lock (C) secure part (12) into part (4) with Philips head screwdriver as per diagram.

Step 11
P.15
21 3
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
12
5
C
C
Using Cam lock (C) secure part (12) into part (5) with Philips head screwdriver as per diagram.

Using Cam lock (C) secure part (8) into part (7) with Philips head screwdriver as per diagram.

Step 13
P.17
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
2
7
8
C
C
CC
Using Cam lock (C) secure parts (7,8) into part (2) with Philips head screwdriver as per diagram.

Using Bolt (H) attach Connecting Iron Sheet (J) to parts (3,8) with Hex Key (G) as per diagram.

Step 15
P.19
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
5
8
7
CC
C
C
Using Cam lock (C) secure parts (7,8) into part (5) with Philips head screwdriver as per diagram.

Using Bolt (H) attach Connecting Iron Sheet (J) to parts (4,8) with Hex Key (G) as per diagram.
