Walker Edison W44CMCR2D User manual

P.1
AssemblyInstructions
Item# : W44CMCR2D
Revised 17/05/2019 (E)
Copyright 2019 by Walker Edison Furniture Co., LLC. All rightsreserved.
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com
Walker Edison
TM

.2
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
General Assembly Guidelines
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
21
III. Two people are recommended for ease in the assembly of this product.
IV. The three main types of hardware used to assemble this product are: wood
dowels, screws and bolts.
V. The provided glue is to secure wood dowels in place. When first inserting dowels,
locate the appropriate hole for the dowel, place a small amount of glue in the hole
and insert the dowel. Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together, place a small amount of glue on the end of the dowel before attaching
parts together. Wipe away excess glue immediately.
VI. A hillips head screwdriver is required for the assembly of this product.
VII. ower tools should not be used to assemble this product.
. Concealed hinges are three-way adjustable.
Horizontal
by screw adjustment
In-and-Out
by loosening the hinge-arm
mounting screw or via cam
adjustment
Vertical
Via slots in the mounting
plate or via cam adjustment
Door
Side panels Side panels Side panels
Door Door
VIII. Drill may be needed for securing product to wall.

P.3
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
PartsList
1
2
3
46
5
7
9
10
8
11
12
14
13
15
16
17
18
18

HardwareList
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
A
Philipshead screwdriverrequired forassembly
(not included)
P.4
20 pcs Wooden dowel8x30mm
Copyright ©2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
B18 pcs Cambolt6x35mm
C12 pcs Camlock15x11mm
D32 pcs Sticker30mm
E22 pcs Screw6x50mm
F 1 pc HexKeyM4
G
H
14 pcs 6x12mm
J
K
L
M
2
Bolt
N
4
P
pcs
Knob
pcs
Bolt4x22mm
4
24
pcs
West hinge
pcs
Screw3x14mm
8pcs Shelf support pin8x5x16mm
7pcs Plastic wedge
Screw4x12mm
Screw4x25mm
Plastic strap
Nut
Q
R
S
T
U
V
1pc Glue tube
1pc
1pc
1pc
1pc
6pcs Camlock15x9mm
15 pcs Wooden dowel6x30mm

Step 1
.5
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
A
A
B
BB
B
B
B
B
B
B
B
B
B
B
1
2
Insert cam bolt (B) and wooden dowel (A) to parts (1,2) with Philips head screwdriver
as per diagram .

Step 2
.6
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
A
A
A
A
B
B
B
B
12
14
Insert cam bolt (B) and wooden dowel (A) to parts (12,14) with Philips head screwdriver
as per diagram .

Step 3
P.7
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
R
R
A
R
RA
A
A
A
A
7
9
15
Insert wooden dowel (A,R) to parts (7,9,15) as per diagram

Step 4
.8
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
R
R
R
R
R
R
R
8
10
Insert wooden dowel (R) and connect with parts (8,10) as per diagram.

Step 5
P.9
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
E
F
2
7
15
Using screw (E) secure part (2) to part (7,15) with hex key (F) as per diagram.

Step 6
.10
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
21 3
C
C
2
12
Using cam lock (C) secure part (2) to part (12) with Philips head screwdriver as per diagram.

Step 7
.11
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
21 3
C
C
2
14
Using cam lock (C) secure part (2) to part (14) with Philips head screwdriver as per diagram.

Step 8
P.12
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
CC
C
C
C
C
1
7
12
14
Place part (1) cover parts (7,12,14),then using cam lock secure them with Philips head
screwdriver as per diagram .

Step 9
P.13
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
C
C
Q
Q
1
2
9
15
Using cam lock (Q) secure part (15) to part (1) , then using cam lock (C) secure part (9) to part
(2) with Philips head screwdriver as per diagram.

Step 10
P.14
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
Q
Q
Q
2
810
Using cam lock (Q) secure parts (8,10) to part (2) with Philips head screwdriver as per diagram.

Step 11
P.15
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
E
F
3
8
9
10
12
14
Using screw (E) secure part (3) to parts (8,10,12,14) with hex key (F) as per diagram.

Step 12
P.16
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
E
F
2
3
11
Using screw (E) secure part (11) to parts (2,3) with hex key (F) as per diagram.

Step 13
P.17
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
EF
2
3
13
Using screw (E) secure part (13) to parts (2,3) with hex key (F) as per diagram.

Step 14
.18
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
FG
G
G
G
GG
G
G
H
H
H
H
H
H
H
H
F
F
4
5
6
Using bolt (G) secure plastic wedge (H) to parts (4,5,6) with hex key (F) as per diagram.

Step 15
.19
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
FG
H
4
5
Using bolt (G) secure plastic wedge (H) to part (4) to part (5) with hex key (F) as per diagram.

Step 16
.20
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
F
G
H
6
5
Using bolt (G) secure plastic wedge (H) to parts (4,5,6) with hex key (F) as per diagram.
