General Assembly Guidelines
I. Insure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to insure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The main types of hardware used to assemble this product are wood dowels, screws,
bolts and washers.
V. The provided glue is to secure wood dowels in place. When first inserting dowels,
locate the appropriate hole for the dowel, place a small amount of glue in the hole
and insert the dowel. Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together, place a small amount of glue on the end of the dowel before attaching
parts together. Wipe away excess glue immediately.
VI. A Phillips head screwdriver is required for the assembly of this product.
VII. Power tools should not be used to assemble this product.
P.2

Parts List

Insert dowels (A) into slats (7,14,15,17) and crossbar (18) as shown above.
Carefully fit table top pieces (1,2,3) firmly together.

Insert dowels (A) into table top pieces (1,2,3).
Attach slats (6) to slats (7) using dowels as guides.

Attach slats (6,7) to table top pieces (1,2,3) using screws (C).
Attach slats (5) to table top pieces (1,2,3) using screws (C).

Attach corner blocks (13) to slats (5,6) using screws (C).
Attach corner blocks (12) to slats (8,9,10) using screws (C). Repeat this step for second set of slats (8,9,10).

Attach slats (8,9,10) to table top pieces (1,2,3) using screws (C).
Slide slats (11) into place along table top assembly.

Insert dowels (A) into slats (11). Attach table locks (J) to slats (5) using screws (K).
Attach crossbars (19) to crossbar (18) using bolts (D). Tighten bolts (D) with wrench (M).

Attach crossbars (19) to legs (20,21) using screws (B). Attach end caps (22) to crossbars (19) using dowels as
guides.
Align legs (20,21) with slats (8,9,10). Attach legs (20,21) to corner blocks (12) using bolts (E), spring washers (F)
and washers (G). Tighten all bolts (E) with wrench (N).

Attach slats (17) to leaf (4) using screws (C). Repeat this step for second leaf (4).
Attach slats (14,15,16) to leaf (4) using screws (C). Repeat this step for second leaf (4).

Attach corner blocks (13) to slats (14,16,17) using screws (C). Attach table locks (H) and brackets (L) to slat (15)
using screws (K). Repeat this step for second leaf (4).
Align leaves (4) with main table assembly.

Pull slats (11) through leaves (4). Lock leaves (4) to main table assembly using table lock pieces (H,J).
