Walker Edison W448D1D User manual

Item # : W448D1 D
Assembly Instructions
 
 .eredison.com

   P.1

Attach door stopper (R) to part (1) using screw (A) with screwdriver. Insert cam bolt (D) to
part (1). Insert wooden dowel (B) to part (2,14).
Insert cam bolt (D) to part (10). Insert wooden dowel (B) to part (3,4).

Insert cam bolt (D) to part (6,7,8,9). Insert wooden dowel (B) into part (6,7,8,9).
Attach part (14) to part (2) with screw (T) with screwdriver. Attach foot part (15) to part (2)
using bolt (H) with hex key (S).

Attach part (10) to part (4), then insert and secure cam lock (C) to part (4) to lock it.
Attach part (8,9) to part (3), then insert and secure cam lock (C) to part (3) to lock it.

Attach part (6,7) to part (3), then insert and secure cam lock (C) to part (3) to lock it.
Attach part (4) to part (2) using bolt (H) with hex key (S).

Attach part (3) to part (2), then insert and secure cam lock (C) to part (2) to lock it.
Slide back panel (11) into grooves as per diagram.

Attach part (1) to part (3,4) then insert and secure cam lock (C) to part (3,4) to lock it.
Attach plastic wedge (F) to part (11) using screw (G) with screwdriver.

Place sticker (E) over holes as per diagram.
Insert shelf support pin (J) into side panel (3,4), then place shelf (12,13) on top of support
pin (J).

Attach hinge (Q) to part (5) using screw (K) with screwdriver.
Attach door plate (P) using screw (K), handle (N) using bolt (M) to part (5) with screwdriver.

Attach part (5) to part (6) to secure hinge (Q) using screw (K) with screwdriver.
