Walther Systemtechnik SMS-17 User manual

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 1 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
Assembly Instructions
Handpen SMS-17
Article number: SMS-17-0.3
SMS-17-0.5
SMS-17-1.0
Figure: Handpen SMS-17 (without suspension bracket)
NOTE
Please read the Assembly Instructions carefully before first using the incomplete device and
strictly adhere to the instructions!
The incomplete device may only be worked with and worked on by persons who are familiar
with the assembly instructions and the current regulations for industrial safety and accident
prevention.
Keep a translated version of the “Original Assembly Instructions“at the incomplete device!
The instructions have to be available anytime!

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 2 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
Content
page
EC DECLARATION OF INCORPORATION ....................................................................................................................... 3
1INTRODUCTION ................................................................................................................................................. 4
1.1 TARGET GROUP OF THE ASSEMBLY INSTRUCTIONS ............................................................................................................ 4
1.2 LIST OF SIGNS AND SYMBOLS ....................................................................................................................................... 4
2SAFETY............................................................................................................................................................... 4
2.1 GENERAL INFORMATION.............................................................................................................................................. 4
2.2 DANGERS DUE TO RESIDUAL ENERGY.............................................................................................................................. 4
2.3 WARRANTY AND LIABILITY........................................................................................................................................... 4
2.4 CORRECT USE............................................................................................................................................................ 5
2.5 INCORRECT USE ......................................................................................................................................................... 5
2.6 QUALIFICATION OF PERSONNEL .................................................................................................................................... 5
3TRANSPORT....................................................................................................................................................... 6
3.1 PACKAGING .............................................................................................................................................................. 6
3.2 TASKS BEFORE TRANSPORT .......................................................................................................................................... 6
4FUNCTIONAL DESCRIPTION ............................................................................................................................... 6
4.1 FUNCTION................................................................................................................................................................ 6
4.2 DESCRIPTION AND OPERATING ELEMENTS ...................................................................................................................... 7
4.3 TECHNICAL DATA........................................................................................................................................................ 7
4.4 TYPE LABEL .............................................................................................................................................................. 7
5INSTALLATION AND INITIAL START-UP................................................................................................................ 8
5.1 MOUNTING AND INSTALLATION .................................................................................................................................... 8
6OPERATION ....................................................................................................................................................... 8
6.1 GENERAL INFORMATION.............................................................................................................................................. 8
6.2 OPERATING INSTRUCTIONS .......................................................................................................................................... 8
6.3 OPERATING ELEMENTS ............................................................................................................................................... 9
6.4 NEEDLE STROKE ADJUSTMENT ...................................................................................................................................... 9
7TAKING OUT OF SERVICE ................................................................................................................................. 10
7.1 SHORT INTERRUPTION .............................................................................................................................................. 10
7.2 LONG-TERM INTERRUPTION ....................................................................................................................................... 10
7.3 FINAL SHUTDOWN OF THE DEVICE ............................................................................................................................... 10
8MAINTENANCE AND REPAIR ............................................................................................................................ 11
8.1 GENERAL INFORMATION............................................................................................................................................ 11
8.2 CLEANING .............................................................................................................................................................. 11
8.3 INSERTING NEW GASKETS .......................................................................................................................................... 11
8.4 NEEDLE-VALVE UNIT ................................................................................................................................................. 11
8.5 SPARE PARTS .......................................................................................................................................................... 12
8.6 CUSTOMER SERVICE /SUPPORT .................................................................................................................................. 12
9TROUBLESHOOTING ........................................................................................................................................ 12
9.1 GENERAL INFORMATION............................................................................................................................................ 12
9.2 MALFUNCTIONS:..................................................................................................................................................... 12
9.3 SPRAY IMAGE/TYPE OF DEFECT ..................................................................................................................................13
10 APPENDIX........................................................................................................................................................ 14
10.1 SPARE PARTS DRAWING SMS-17 ........................................................................................................................... 14
10.1.1 Spare parts list SMS-17......................................................................................................................... 15
10.2 ARTICLE NUMBERS FOR AIR CAPS (FLAT SPRAY), NOZZLES AND NOZZLE NEEDLES ............................................................... 16
10.3 WEAR-AND-TEAR PARTS ...................................................................................................................................... 16

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 3 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
EC Declaration of Incorporation
in accordance with EU Machinery Directive 2006/42/EU, dated 17 May 2006, Appendix II B
We herewith confirm that the below mentioned incomplete device meets the basic requirements for safety
and health as stated in EU Machinery Directive 2006/42/EU for its design and construction as well as for the
configuration released by us on the market. This machine component will not be operated before it has been
determined that the incomplete system where the machine component will be installed also meets the
requirements of the Directive (2006/42/EG).
Manufacturer Walther Systemtechnik GmbH
Hockenheimer Straße 3
D- 76726 Germersheim
Description Handpen SMS-17, article-No. SMS-17-0.3
SMS-17-0.5
SMS-17-1.0
We also declare the conformity with other, product-relevant directives/guidelines:
Mach. Direct. 2006/42/EU App. I, Clause: 1.1.2, 1.1.3, 1.1.5, 1.1.6, 1.3.2, 1.3.3,
1.3.4, 1.5.8, 1.5.9
Applied harmonized standards, in particular:
DIN EN ISO 12100 Safety of Machinery –General Design Principles –
Risk Assessment and Risk Reduction (ISO
12100:2010)
In addition, we also confirm that the special documentation according to Appendix VII Part B has
been prepared.
The manufacturer, respectively his authorized representative obligates himself to submit this documentation
to the market surveillance authorities, if requested.
This EC Declaration of Incorporation becomes invalid if the incomplete device will be altered or changed
without consent of Walther Systemtechnik GmbH.
Authorized representative for Technical Documentation:
Stefan Hirl, Hockenheimer Straße 3, D- 76726 Germersheim
Germersheim, 30 October 2015
(place, date) (Stefan Hirl, management)

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 4 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
1 Introduction
1.1 Target Group of the Assembly Instructions
Operating personal
Maintenance personal
1.2 List of Signs and Symbols
The assembly instructions warn users of operations which may put their health at risk. The warnings are
indicated by combinations of text and symbols as follows:
DANGER
Describes a potentially dangerous situation.
Death, grievous bodily harm or severe material damage WILL occur if the respective
measures of precaution have not been taken
WARNING
Describes a potentially dangerous situation.
Death, grievous bodily harm or severe material damage MAY occur if the respective
measures of precaution have not been taken
CAUTION
Describes a potentially dangerous situation.
Slight injuries CAN occur if the respective measures of precaution have not been
taken. This signal word is also used to describe possible property damages.
IMPORTANT
Indicates tips for usage and other particularly useful information.
No dangerous situation.
2 Safety
2.1 General information
The construction of this device is according to the latest technology and is absolutely reliable. The individual
components as well as the complete device are continuously checked by our quality management.
2.2 Dangers due to residual energy
Please instruct the operating personnel on the respective measures to be taken against the occurrence of
mechanical, hydraulic, pneumatic and electric / electronic residual energies.
2.3 Warranty and Liability
According to the conditions laid down by the German Engineering Federation (VDMA), Walther Systemtech-
nik GmbH has a guarantee of 12 months under normal European operating conditions on its own parts
(spare parts are excluded); or according to the conditions of the manufacturer.
This guarantee can only be granted by Walther Systemtechnik GmbH, if:
the user has thorough knowledge of the content of the assembly instructions;
the user follows the instructions and notes contained in the assembly instructions;
the user does not rebuild or make changes on parts of the device without prior consent of WST Sys-
temtechnik GmbH.

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 5 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
2.4 Correct use
This device is a needle valve suitable for the processing of sprayable media in continuous as well as inter-
mittent use. It is not suitable for spraying aggressive fluids such as acids, alkaline solutions, cleaning agents,
chemicals, etc. In case of doubt, please contact the manufacturer.
2.5 Incorrect use
Operating the device with insufficient knowledge about the operation, maintenance and care of the
device.
Making changes, extensions or alterations on the device that may hamper its safety without the prior
consent of Walther Systemtechnik GmbH.
Operating the device with defective safety installations or not properly attached or malfunctioning
safety devices.
Using unsuitable materials.
Handling the device while energized.
2.6 Qualification of Personnel
Only trained and instructed personnel may conduct work on the equipment.
The responsibilities of the personnel for assembly work, operation, repair work or maintenance work must be
clearly assigned to individuals!
Persons in training may work with the equipment only under supervision of an experienced person.
Personnel
Task
Instructed
Personnel
Personnel with Technical
Qualification
Specialist
Supervisor
Packing, Transport
X
-
-
-
Commissioning
X
X
-
Operation
X
-
Troubleshooting, general
X
X
-
Troubleshooting
mechanical
-
X
-
-
Troubleshooting electrical
-
-
X
-
Setting up
-
X
-
-
Maintenance
-
X
-
-
Repair
-
X
X
-
Taking out of service,
Storage
-
X
X
-

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 6 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
3 Transport
3.1 Packaging
The type of packaging depends on the individual mode of shipping. If not separately contracted, the
packaging is in accordance with the rules and regulations of Walther Systemtechnik GmbH. This rule is in
accordance with the Federal Association for Packaging HPE.
3.2 Tasks before Transport
The following has to be done before transport:
Disconnect all power lines.
The actual transport of the incomplete device and its individual parts requires special care in order to prevent
damages from external forceful impact or careless on- and off-loading. Depending on the mode of
transportation, suitable transport and load securing has to be selected. The incomplete device will be aligned
and leveled by appropriate fastening elements.
4 Functional description
The SMS-17 Handpen is controlled via a mechanical manual lever. The medium is supplied from a pressure
tank or via a feed pump. The separately controlled spraying air atomizes the material into a spray jet.
Depending on the air cap used, this valve sprays in flat- or round spray
4.1 Function
CAUTION
Use of other media can result in malfunctions, property damage, or destruction of the
machine
The SMS-17 Handpen is particularly designed for a very fine application of low-viscosity media such as
colors or release agents in plastic moulds. Depending on the viscosity of the medium, the application pattern
can be adjusted individually via nozzle dimension, atomizing air pressure and material pressure. The supply
of atomizing air, control air, and material takes place via two hoses. The SMS-17 Handpen is a high-precision
tool. Always keep clean and observe minimum instructions to maintain a long life of the valve.

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 7 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
4.2 Description and Operating Elements
4.3 Technical data
Article number
SMS-17
General data
Dimensions (length x width x )[mm]
128 x 32 x 20
(length depending on nozzle
and hose connection)
Weight [g]
approx. 120
Energy supply
Atomizing air pressure [bar]
0,5-6
Material pressure [bar]
max. 15 bar
Connection thread
Atomizing air [mm]
4
Material [mm]
M4x0,5
In the basic version the spray dosing pen is not equipped with an air cap. The air cap must be selected
additionally. The WALTHER spray dosing pen is delivered with prefabricated connection hoses (length 0.5
m). The material hose is equipped with a 6mm adapter and the connection for atomizing and control air is
equipped with a 4 mm PU hose.
4.4 Type label
The type designation is etched in on the valve body.
The serial number is also inscribed in this area.
Compressed air connection
„SL-Control Air“
Material Connection
Valve Body
Spray Head
Manual release

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 8 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
5 Installation and initial start-up
The valves can be used in any position. The distance to the surface where the medium will be applied
depends on the required application width.
5.1 Mounting and Installation
IMPORTANT
We recommend superposing a maintenance unit to the control air.
6 Operation
6.1 General information
This device may only be operated if the safety-related equipment is permanently effective and not suspend-
ed during operation or altered in its intended effectivity
6.2 Operating instructions
CAUTION
Never point the jet at people. The wearing of eye protection is strongly recommended.
The spraying process can create noise depending on the air and fluid pressures used.
Ear protection should be worn, if required.
WARNING
Danger caused by flammable, harmful fluid. Always follow the safety instructions on the
container or the safety data sheet for the fluid.
It is harmless to leave fluid in the valve during longer standstills if system stays under pressure (no
connection to outside air).
Compressed air connection
„SL-Control Air“
Material Connection „M“

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 9 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
6.3 Operating Elements
6.4 Needle stroke adjustment
The material amount can be set with the locking screw (19) as follows:
turn to the right: decreasing material amount
turn to the left : increasing material amount
IMPORTANT
Accident prevention directions will be strictly followed when applying high material
pressures. Please strictly follow the following instructions when planning and
constructing application systems!
Manual Release

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 10 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
7 Taking out of service
7.1 Short interruption
After short interruptions (15 min and more), the valve should be blown free prior to use.
NOTE
Please refer to the operating notes!
7.2 Long-term interruption
Please observe the procedure stated below when taking the device out of service for longer periods of time:
Make sure that no pressure is left in the system.
Take off air cap (2) and nozzle (5) and clean with a soft cloth and the special dilution. Please make
sure not to leave any cloth particles on the nozzle tip.
NOTE
Please refer to the maintenance notes!
7.3 Final shutdown of the device
Please observe the following procedure when finally shutting down the device:
Clean handpene with special dilution.
NOTE
Please refer to the maintenance notes!

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 11 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
8 Maintenance and repair
8.1 General information
CAUTION
Before starting any maintenance or repair work, ensure that all air-operated tools are
depressurized and disconnected from the air supply.
Before opening the spray valve it must be disconnected from the air and fluid supply.
Otherwise, ejected components can cause injuries
The SMS-17 Handpens are high precision tools. Always keep clean and observe minimum instructions to
maintain a long life of the valve. We recommend lubricating moveable parts regularly and greasing threads,
especially the nozzle threads, when replacing or cleaning the nozzle. Always use clean and filtered material
only. The control air must also be clean and should be slightly oiled, if necessary. Maintenance also depends
on the individual operating conditions and the type of media used
8.2 Cleaning
IMPORTANT
Only use soft brushes for outside cleaning of the nozzle tips. Never use metal tools
with sharp edges.
Only use soft brushes for outside cleaning of the nozzle tips. Never use metal tools with sharp edges.
Wash equipment thoroughly after use to remove residues and dirt; especially, if needle, sealing bush or noz-
zle are to be exchanged.
8.3 Inserting new gaskets
IMPORTANT
When inserting O-rings and gaskets, do not use any sharp or pointed metallic imple-
ments. Especially the gasket is a very precise and sensitive component that is not able
to stand impacts.
8.4 Needle-valve unit
When assembling the needle-valve unit make sure the two needle nuts (16) are mounted and countered
according to the below drawing.

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 12 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
8.5 Spare Parts
IMPORTANT
Only use original spare parts from the manufacturer!
Wrong or defective spare parts from other manufacturers can damage the device. If
other than original spare parts of the manufacturer will be used, all obligations from the
manufacturer or his sales partners, such as guarantees, service contracts etc will be
forfeited without further notice.
8.6 Customer service / support
Walther Systemtechnik GmbH
Hockenheimer Straße 3
D-76726 Germersheim
Germany
phone ++49(0)7274-7022-0
fax ++49(0)7274-7022-91
e-mail [e-mail]
internet www.walther-2000.de
9 Troubleshooting
9.1 General information
IMPORTANT
First check all supply lines for connectivity and serviceability
In case of serious problems that cannot be resolved, please contact the Walther Systemtechnik GmbH
customer service.
9.2 Malfunctions:
Fault
Possible Cause
Action
Nozzle needle does
not open
Not enough control air supplied
Check if enough control air available (3 -
6 bar).
Leakages
Check if O-Rings are defective.
Needle is sticky within the needle sealing
(12 / 13).
Disassemble and clean.
Needle stroke is set too low.
Check if needle stroke is correctly set.

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 13 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
9.3 Spray Image/ Type of defect
SPRAY IMAGE
PROBLEM
CAUSE
ACTION
Normal Spray Image (Flat jet)
Normal Spray Image (Round jet)
Spray image shaped
too much
upwards and
downwards
Soiled
air cap
Soiled
nozzle
Clean nozzles
Spray image too much
left-sided or right-sided
Soiled
air cap
Soiled
nozzle
Clean nozzles
Heavy application in the
middle of the spray image
Too much material
Material too thick
Reduce
material supply
Dilute material
Split
spray image
Too little material
Pressure flat jet too
high
Increase
material supply
Increase pressure
for round jet

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 14 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
10 Appendix
10.1 Spare parts drawing SMS-17

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 15 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
10.1.1 Spare parts list SMS-17
Pos.
Art.-No.
Pieces
Description
1
97410142
1
Retainer ring, 14 x 4.5 mm
2
97310679
1
Air cap, round spray KLS, 0.2-1.0 mm, 11 x 4.5 mm
2.1
*
1
Air cap, flat spray KLS, 0.2-1.0 mm, 11 x 6.5 mm
3
97320782
1
Air cap fixture, ø15 x 16, M12 x 0.75
4
97640052
2
O-ring 10 x 1 / Viton®
5
*
1
Nozzle, KLS, NIRO steel, 8 x 25.8 mm, SW7
6
97320657
1
Cylindrical pin DIN 6325 2 x12
7
97190032
1
Lever, 7 x 4 x 62 mm, nickel-plated
8
97511393
1
Main body SMS-17 / SV, ø20 x 100 mm, anodized
9
97640062
1
Needle seal, Teflon®, 5.7 x 5 mm
10
97810002
1
Needle gland nut M7 x 0.75 x 3.5 mm
11
97640036
1
O-ring 4,7 x 1.42 / Viton®
12
97640317
1
O-ring 7 x 1.5 / Viton®
13
97380095
1
Air valve, ø10.7 x 52
14
97820020
1
Pressure spring 1.1 x 22 mm
15
*
1
Nozzle needle, KLS, ø2 x 85 mm
16
97410026
2
Needle nut, SW3 x 3, M2
17
97820102
1
Pressure spring 0.7 x 19 mm
18
97610001
1
Valve locking screw 6 x 7.5 mm, M5
19
97810191
1
Locking screw, M12 x 0.75, ø12 x 5 mm
20
97221009
1
Screwing, complete, SW 8 x 19 mm, M4 x 0.5
97910429
1
Suspension bracket (optionally available)
* These article numbers can be found on the following page.
IMPORTANT
Always indicate the inscribed serial numbers when ordering spare parts!

Rev. 1.0
Assembly Instructions - Handpen SMS-17
Page 16 of 16
Walther Systemtechnik GmbH –D 76726 Germersheim
Telefon: [phone] Telefax: [phone]
http://www.walther-2000.de –[e-mail]
10.2 Article numbers for air caps (flat spray), nozzles and nozzle needles
2.1
Air cap, flat spray KLS nozzle Ø .2 –1.0 mm (Ø 11 x
6.5 mm)
Article-No.
Description
97310689
Air cap with spray angle 90°
97310690
Air cap with spray angle 60°
97310691
Air cap with spray angle 45°
2.1
Marking air cap, Ø 11x4,5mm
Article-No.
Description
97310732
Marking air cap 0,3 - 0,5 mm
5
Nozzle, KLS, NIRO steel, 8 x 2.8 mm, SW7
Article-No.
Description
97211942
Nozzle, 0.3 mm
97211952
Nozzle, 0.5 mm
97211954
Nozzle, 1.0 mm
5
Marking Nozzle, NIRO steel, 8x26,5mm
Article-No.
Description
97212158
Marking nozzle 0,3mm
97212160
Marking nozzle 0,5mm
15
Nozzle needle without piston, KLS Ø 2 x 85 mm
Article-No.
Description
97112260
Nozzle needle, 0.2/0.3 mm
97112277
Nozzle needle, 0.5 mm
97112278
Nozzle needle, 0.8/1.0 mm
15
Marking Nozzle needle, Ø 2 x 85 mm
Article-No.
Description
97112534
Marking nozzle needle 0,3mm
97112535
Marking nozzle needle 0,5mm
10.3 Wear-and-Tear Parts
Wear-and-tear set complete for SMS-17 1
Consisting of:
# Pos. 4 (O-ring)
# Pos. 9 (Needle seal)
# Pos. 10 (Needle gland)
# Pos. 11 (O-ring)
# Pos. 12 (O-ring)
Article-No.
Description
979504.010
Wear-and-tear kit for SMS-17, VITON
1This wear-and tear kit is recommended for a complete overhaul of the device.
