Walton 01MOW4803-V3 Instruction manual

01MOW4803-V3
Overlap mower store
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
**Protim Aquatan T5 (621)**
Protim Aquatan* T5 is a coloured, water-based concentrate which is diluted with water to make a solution
for application to unseasoned timber. Protim Aquatan T5 treated wood is not protected against wood
destroying insects or wood decaying fungi. Further preservative treatment is required to protect against
these organisms.
Contains: Boric Acid, Sodium Hydroxide 32% solution, aqueous mixture of sodium dioctyl sulphosuccinate &
alcohols: 2,4,6-Trichlorophenol.
Hazard Statements:
H315: Causes skin irritation.
H319: Causes serious eye irritation.
H412: Harmful to aquatic life.
Wear gloves when handling freshly treated wood.
Avoid breathing dust when cutting treated or untreated wood.
Dispose of o-cuts responsibly – do not burn.
IF SKIN IRRITATION OCCURS: Get medical advice/attention.
IF IN EYES: Rinse cautiously with water for several minuets. Remove contact lenses, and continue rinsing. If
the irritation persists: Get medical advice/attention.
DO NOT INGEST.
Please retain product label and instructions for future reference
P 1
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to protect
the product during transit and for upto 3 months against mould. To validate your
guarantee and ensure longevity of the product, it is ESSENTIAL the building is treated
with a wood preserver within the rst three months of assembly and thereafter in
accordance with the manufactures recommendations. Care must be taken to ensure
the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions, The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for you specic product code

1
Front Panel Left Gable
2
Right Gable
3
Plain Panel Floor Roof Door
QTY 2
4 5 6 7
8Door Strip - 7x45x1264mm QTY 2
9Lrg Fascia - 7x60x1429mm
10 Sml Fascia - 7x60x945mm
11
Butt Hinge QTY 4
12
Turn Button QTY 2
12
Hasp & Staple
50mm Screw x21
Felt Tacks x48
30mm Screw x50
30mm Black Screw x8
Nail Bag
Pre Assembly
Before beginning assembly remove the transportation
blocks from the bottom of each panel.
5
Step 1
Place the oor onto a rm and
level base.
Ensure the base has suitable
drainage & is free from areas
where standing water can
collect.
Step 2
Place the back panel and the right
gable onto the oor and secure
at the corner with 3x50mm screws.
Fix to the oor using 5x50mm screws,
ensure to screw through the framing
into the oor bearers.
8x50mm Screws
Pre drill
hole
50mm
screw
a
b
P 2
01MOW4803-V3
Overall Dimensions:
Length = 1429mm
Width = 950mm
Height = 1419mm
Base Dimensions:
Length = 1395mm
Width = 910mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
a
a
b
b
bb
b
4
3

Step 3
Place the left gable onto the oor
and secure at the corner with
3x50mm screws.
Fix to the oor using 2x50mm screws,
ensure to screw through the framing
into the oor bearers.
5x50mm Screws
Pre drill
hole
50mm
screw
a
b
Step 3
Fix the front panel inbetween the gables,
securing into place with 4x50mm screws
from the inside of the building.
*Ensure to align the framing with the edge
of each gable.
4x50mm Screws
Pre drill
hole
50mm
screw
8
8
Step 4
Attach the door strips to either side of the
building.
*Ensure the strip sits fush to edge of the
framing and there is NO overhang inside
the building.
6x30mm Screws
11
Step 5
Fit 2x butt hinges to each door with
3x30mm screws per hinge.
Align each door into the door gap
and secure into place with 3x30mm
screws per hinge.
*Ensure the doors open and close
freely without any obstructions.
24x30mm Screws
P 3
Please retain product label and instructions for future reference
a
b
2
b
a
a
1
Pre drill
hole
30mm
screw
Pre drill
hole
30mm
screw

Felt
tacks
HANDLE
WITH CARE
12
3
4
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
P 4
Please retain product label and instructions for future reference
6
Step 6
Place the roof sheet on top of the building
and x into place with 10x30mm screws.
10x30mm Screws
Pre drill
hole
30mm
screw
Step 7
Measure and cut the felt to size and lay onto
the roof.
*Ensure there is approximately 50mm of
overhang around the building.
Fix the felt down using 48x felt tacks at 100mm
intervals.
48x Felt Tacks
Felt size: 1530mm
910
10
Step 8
Attach the lrg and sml fascias to the
front and sides of the building, xing
into place using 9x30mm screws.
9x30mm Screws
Pre drill
hole
30mm
screw
12 12
13
a
b
Step 9
Secure the 2 turn buttons to
the front panel using 2x30mm
black screws.
*Ensure these turn buttons close over
each door.
Fit the hasp and staple onto the
doors centrally with 5x30mm
black screws, making sure to
screw into the door framing.
7x30mm Black Screws
30mm
screw
Pre drill
hole
a
b

It is ESSENTIAL that you apply wood treat-
ment immediately after the building has
been assembled.
P 5
Please retain product label and instructions for future reference
