Warmington Evoque 1300 Operating and maintenance manual

27 August 2021
Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
All Dimension are in mm……….Copyright
1
Warmington Evoque 1300
Maintenance and
Operating Instructions
How to light and maintain your Evoque Open Wood fire
Please keep these instructions for future reference
Manufactured by Warmington Industries, 47 Sir William Ave, East Tamaki, Auckland.
PO Box 58 652, Botany 2163
Telehpone: 09 273 2997 Fax: [phone] www.warmington.co.nz
Email: [e-mail]

27 August 2021
Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
All Dimension are in mm……….Copyright
2
FOR CORRECT OPERATION OF YOUR OPEN WOOD FIRE
These are guidelines only as each installation has it’s own unique aspects.
Using the handle, open the screen (see Dia 1.) and place a generous amount of crumpled newspaper on top of
the grate. Place a dozen or so, pieces of finely split kindling on top and behind the paper. You can place fire-
lighters under the newspaper to help sustain the fire, if you wish.
Light the paper and/or firelighters from both ends and the
middle. As soon as the kindling has ‘caught’ and is burning
briskly, add smallish pieces of wood to the fire. When the
fire is established, put on larger pieces in a criss-cross
pattern.
You may notice a faint smell on the first light of the fire. This
is the paint coat curing and this smell will soon disappear.
Screen up
and open:
damper opens
automatically
Dia 1.
You can continue to operate the fire safely with the screen
in the up position, or if the fire is left unattended you can
lower the screen to guard against any possible embers
sparking out of the fireplace.
This will automatically close the flue damper and slow the
rate of combustion.
IMPORTANT: You must always use the supplied grate
and safely load the fire with the correct amount of firewood
(maximum 5kg). This open fire has been tested to 2918
and you run the risk of overfiring if the fire is overloaded
and the warranty may also be voided if these instructions
are not followed.
Screen down
and closed:
damper closes
automatically
Dia 2.
Important Note:
Do not load the fire with more than
5kg of softwood. Do not use the
fire without the supplied grate.
Description GRATE
Grate Depth V410
Grate Width W605
Grate Height X195
GRATE

27 August 2021
Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
All Dimension are in mm……….Copyright
3
You can control the fire with the damper settings. The preset control handle is located on the top of the firebox, above the
screen. The control allows you to preset the minimum opening of the damper, when the screen is closed.
This adjusts the burn rate, as it restricts the flow of combustion air to the fire.
Presetting and changing the setting of the damper control
1. Push the preset control handle in order to disengage it from its catches.
2. Keeping it pushed in, slide up or down in order to obtain the desired setting:
• Preset control upwards = trap more open increased draught.
• Preset control downwards = trap more closed decreased draught.
3. Once you have obtained the desired position, release the control.
4. When using the appliance for the first few times, it will be necessary to set the damper trap according to the
natural draught of your chimney. This is unique to each individual install.

27 August 2021
Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
All Dimension are in mm……….Copyright
4
BAFFLE POSITION
CHAIN AND SPROCKET ACCESS CHANNEL
Location of the sprocket and chain
access panel.
This must be accessible for
servicing, maintenance and
lubrication on both sides.
Ensure that the Warmington and flue system is swept annually
or more frequently if required. To sweep flue and firebox:
Cover front of fire with sheets, or keep screen closed during.
Remove cowl from top of chimney.
Sweep from the top, down the flue.
Remove all soot and ash.
Ensure cowl and bird protection is clean and replaced.
Visually inspect fireplace and flue system.

27 August 2021
Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
All Dimension are in mm……….Copyright
5
GENERAL NOTES: ASNZS 2918: 2001
NOTES:
• Correct installation and operation must be maintained to comply with Warmington warranty.
• The appliance and flue system must be installed in accordance with ASNZS2918:2001 and the appropriate
building codes.
• The fire must be serviced and the flue system and fireplace is to be swept annually, or more frequently if
required.
WARNINGS:
• WARNING: ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRIT-
ING BY THE TESTING AUTHORITY IS CONSIDERED AS BREACHING AS/NZS 4013.
• WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE
FIRE.
• WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHEN IT IS OPERATING.
• WARNING: DO NOT STORE FUEL WITHIN HEATER INSTALLATION CLEARANCES.
• CAUTION: THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN
ACCORDANCE WITH THESE INSTRUCTIONS
• CAUTION: THE USE OF SOME TYPES OF PRESERVATIVE-TREATED WOOD AS A FUEL CAN BE
HAZARDOUS.
Industries 1994 LTD
PO Box 58652, Botany 2163, Auckland
www.warmington.co.nz
Important Note:
Do not load the fire with more than
5kg of softwood. Do not use the
fire without the grate.
