Warmlite WL46020G Mounting instructions

LOG EFFECT
STOVE FIRE
MODEL WL46020/WL46020G
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.warmlite.co
This product is only suitable for well insulated spaces or occasional use.

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: Log Eect Stove Fire
Model: WL46020/WL46020G
Rated Voltage: 220 - 240V ~
Frequency: 50/60Hz
Power consumption: 1800W – 2000W
LED Bulbs: 5 x 1W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.warmlite.co
WARNING:
This Appliance MUST be Earthed
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neautral
(Blue)
Live
(Brown)

4
CUSTOMER SUPPORT TEAM: [phone]
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using
the appliance immediately
and seek advice from the
manufacturer or its service
agent or a similarly qualied
person.
• DO NOT let the cord hang
over the edge of a table or
counter or let it come into
contact with any hot surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• DO NOT use this product
for anything other than its
intended use.

5
www.warmlite.co
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT use the appliance
outdoors.
• Always ensure that the
heater is placed on a rm
level surface. Ensure that the
heater is not positioned close
to curtains, furniture or any
combustible materials as this
could create a re hazard.
• The heater must not be
located immediately below a
mains socket outlet.
• DO NOT cover the heater as
this may lead to a re risk.
• DO NOT obstruct any of
the openings of the heater
especially the heat outlet at
the bottom of the heater.
• DO NOT insert any object
through any openings on the
heater.
• DO NOT use the heater
in areas where ammable
liquids are stored or where
ammable fumes may be
present.
• DO NOT operate the heater
on a timer or leave on
overnight.
• When not being used, please
unplug the heater from the
mains socket.
• Keep the mains lead away
from the hot body of the
heater and ensure that it is
not pulled tight between the
socket and the heater.
• DO NOT use the heater in the
immediate surroundings of a
bath, a shower, a swimming
pool or similar indoor
locations.
• Always unplug the heater
and allow it to cool before
moving it from one location to
another.
• DO NOT attempt to dismantle
or repair any part of the
heater. This should only be
done by a qualied service
agent.
• This product is only suitable
for well-insulated spaces and
occasional use.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE DO NOT COVER

6
CUSTOMER SUPPORT TEAM: [phone]
WHAT’S IN THE BOX
Instruction Manual
Log Eect Stove Fire
Remote Control
4 X Legs
12 X Screws
1. Glowing Eect Glass Pane
2. Door Handle
3. Hot Air Vent
4. Legs
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Attach the legs as per the instructions opposite. Note: The actual product may dier from the
illustrations.
3. Keep the front of the appliance through which the heat is radiated at least one meter away from
furniture, curtains and other ammable objects at all times.
4. Ensure there is a grounded socket nearby (back of the appliance).
5. Never use an extension lead. The main cable must remain at the back of the appliance and
must not be in contact with any hot elements.
6. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
2
3
4
1

7
www.warmlite.co
INSTRUCTIONS FOR ATTACHING LEGS
TO MAIN UNIT.
1. Turn the product on its side to start
attaching the legs.
2. Place a leg on each corner and use 3
screws for each leg.
3. Tighten the screws clockwise until each
leg is rmly secured.
4. Turn the unit back up to standing position
making sure it is stable.
5. Place the unit in the required location and
plug it in.
CONTROLS
Power Button - Turns the heater
ON/OFF. The heating element will
stop working once the power is
o. The power can be controlled
by pressing the power button on
the control panel or the supplied
remote.
Heat Setting - Use this button
to select between Low (1000W)
and High (2000W) heat settings.
The heat setting button can also
be used to turn o the heat.
Flame Brightness – Adjusts the
brightness of the ame.
Timer - Press this button to select
the length of time you want the
heater to be on. The timing
sequence is as follows:
(0.5h/1.0h/2.0h/3.0h/4.0h/5.0h/6
0h/7.0h/8.0h)
Note: The maximum time the heater can be on
is 8 hours.
USING YOUR APPLIANCE
1. Plug the heater into the mains socket and
press the button on the rear of the
appliance or on the remote control to turn
it on.
2. On the control panel or remote, press the
button to adjust the brightness of the
ame or to turn it o.
3. Press the button on the remote or on
the heater to toggle between two heat
settings: Low or High.
4. To set the timer, press the timer button on
the control pad or remote control to select
a time between 30 minutes to 8 hours.
Please refer to the timing sequence in the
Controls section.
5. To turn the heater o, press the button
and unplug the heater from the mains
socket.
OVERHEAT SAFETY FEATURE
This heater is equipped with an overheat safety
feature. When the heater’s internal components
reach a certain temperature that could cause
it to overheat and possibly cause a re, the
heater will automatically shut o.

8
CUSTOMER SUPPORT TEAM: [phone]
CLEANING AND CARE
• Before cleaning always switch o the re
and remove the plug from the electrical
socket.
• Ensure that the unit is cool enough to
work on.
• Wipe the appliance with a dry cloth to
remove dust and debris.
• The outer shell may be cleaned with a
soft, damp cloth. You may use a mild
detergent if necessary. After cleaning, dry
the unit with a soft cloth.
• CAUTION! DO NOT let liquid enter the
heater. This may cause damage or
deterioration to the heater’s surface.
• WARNING! DO NOT immerse the heater
in water or any other liquid.
• Never use abrasive powders or solvents.
• If the heater shows any signs of wear or
damage disconnect immediately from the
mains supply,and have it checked by a
suitably qualied person. DO NOT attempt
to use the heater if it appears worn or
damaged.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

9
www.warmlite.co
Model Identifier(s): WL46020/WL46020G
Item Symbol Valve Unit Item Unit
Heat Output Type of heat input for electric storage, local space
heaters only (select one)
Nominal heat
output Pnom 1,8 –2,0 kW Manual heat charge with integrated thermostat N/A
Minimum heat
output (indicative) Pmin 1,0 kW Manual heat charge control with room and/or outdoor temperature feedback N/A
Maximum
continuous heat
output
Pmax, c 2.0 kW Electronic heat charge control with room
and/or outdoor temperature feedback N/A
Auxiliary electricity
consumption Fan assisted heat output N/A
At nominal heat
output elmax N/A kW Type of heat output/room temperature control (select one)
At minimum heat
output elmin N/A kW Single stage heat output and no room temperature control No
In standby mode eISB N/A kW Two or more manual stages, no room
temperature control No
With mechanic thermostat room temperature
control No
With electronic room temperature control Yes
Electronic room temperature control plus day
timer No
Electronic room temperature control plus
week timer No
Other control options (multiple selections possible)
Room temperature control with presence
detection No
Room temperature control with open
window detection No
With distance control option No
With adaptive start control No
With working time limitation Yes
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL

10
CUSTOMER SUPPORT TEAM: [phone]
NOTES

11
www.warmlite.co
NOTES

0120.V6
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.warmlite.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
