Warren Controls 200 Guide

This document covers the installation, operation and maintenance
of Type 200 presented in the “Level Controls and Accessories”,
Product Specification.
The instructions given herein cover generally the operation
and maintenance of subject equipment. Should any
questions arise which may not be answered specically
by these instructions, they should be referred to Warren
Controls Inc. for further detailed information and technical
assistance.Thismanualcannotpossiblycovereverysituation
connected with the operation, adjustment, inspection, test,
overhaul and maintenance of the equipment furnished.
Every eort is made to prepare the text of this manual so
that engineering and design data is transformed into the
most easily understood wording. Warren Controls Inc., in
furnishing this equipment and this manual, must presume
that the operation and maintenance personnel assigned
thereto have sucient technical knowledge and experience
PRODUCT OVERVIEW
to apply sound safety and operational practices which
may not be covered herein. In applications where Warren
Controls Inc. furnished equipment is to be integrated with
a process or other machinery, these instructions should be
thoroughly reviewed to determine the proper integration of
the equipment into the overall plant operational procedures.
Warren Controls does not assume responsibility for
the selection, use, or maintenance of any product.
Responsibility for proper selection, use, and maintenance
of any Warren Controls product remains solely with the
purchaser and end-user
GENERAL INFORMATION
200_IOM_RevC_0618
INSTALLATION, OPERATION
& MAINTENANCE INSTRUCTIONS
TYPE 200
VACUUM BREAKER
TABLE OF CONTENTS
Overview ........................................................ COVER
General Information................................... COVER
Installation ................................................................ 4
Operation .................................................................. 4
Maintenance ............................................................ 4
Seat Inspection & Cleaning Procedures......... 5
Opening Force Test & Adjustment
Procedures................................................................ 6
Overhaul.................................................................... 6
Information Present on
Vacuum Breaker...................................................... 7
Type 200 Vacuum Breaker Specifications 8-10
Type 200 Vacuum Breaker Parts/Overhaul..11
Parts Kits ........................................................... 12-13
Construction Drawing & Dimensions............14
TYPE 200 IOM - VACUUM BREAKER

22600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
!
WARNING!
CHECK VACUUM BREAKER FOR ANY
DAMAGE DUE TO IMPROPER STORAGE
OR TRANSPORTATION. IMMEDIATELY
NOTIFY YOUR SALES ORGANIZATION OF
ANY DAMAGED GOODS UPON RECEIPT.
DO NOT ATTEMPT TO MOVE OR DISTURB
THE VACUUM BREAKER FURTHER SO
PHOTOS MAY BE TAKEN. IF THE SHIPPING
CONTAINER IS NOTICEABLY DAMAGED
REFUSE RECEIPT, AS THE SHIPPING
COMPANY SHOULD BE HELD LIABLE
UNTIL A SHIPPING REPRESENTATIVE IS
AVAILABLE TO TAKE PHOTOS.

3
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
The following is a typical example of a tank filling/deaerator application using properly sized, selected, and maintained Warren
Controls Level Controls. Demand for water reduces the liquid level in the tank. The [A] 377 Float Cage opens the [B] 322L or 326L
Lever Valve to supply intake water to the tank. When the water reaches the desired level the float cage closes the lever valve
to accurately maintain the liquid at the desired level. Deaerators, tanks with steam blankets, produce additional liquid as
the steam condenses. The [C] 313 Overflow Trap traps and relieves this condensate through its internal pilot without
the steam blanket escaping. Overflow can occur if the water entering the tank exceeds its capacity. The 313 Overflow
Trap relieves the overflow through its internal single seated main stage valve. Falling liquid levels and condensing steam
can cause a vacuum that can damage the tank. The [D] Type 200 Vacuum Breaker opens to admit outside air to relieve the
vacuum in the tank. Warren Controls Level Controls are also used on boiler make-up water tanks and many other storage tank
applications.
WARREN CONTROLS
LEVEL CONTROLS AT WORK...

42600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
INSTALLATION – TYPE 200 VACUUM BREAKER
MAINTENANCE – TYPE 200 VACUUM BREAKER
 
have, locate the part number on the factory serial
number label (See Information Present on Type 200
section for location of important information on
vacuum breaker). Then see Type 200 Specifications
section to determine the performance and physical
characteristics of the vacuum breaker).
 
position with its mounting connection downward.
A flanged vessel mounting connection must be a
flat surface to prevent distortion of surfaces when
the connection is tight. A warped vessel mounting
flange may cause a leaky joint or break a cast iron
Type 200 mounting flange.
 -
stallations where vibration exists.
 -
ing are clean inside and free of scale, chips, welding
spatter, and foreign material. Thoroughly blow out
or flush pipe lines.
        
paint.
OPERATION – TYPE 200 VACUUM BREAKER
 When no vacuum is present the vessel pressure acts on the vacuum breaker’s discholder pressing the disc into the seat
sealing the tank’s/ pipeline’s contents inside. When the vessel pressure drops below atmospheric pressure a vacuum forms.
The atmospheric pressure then acts on the discholder to overcome the force of the vacuum breaker’s spring. The seat and
disc separate admitting outside air. TheType 200 Vacuum Breaker opens gradually to admit outside air to relieve the vacuum
in the tank/ pipeline. The Type 200 Vacuum Breaker cannot be preset to open at a particular setpoint.
 
fluid pressure and temperature within the limits of the vacuum breaker (See Information Present on Type 200 sec-
tion for location of important information on vacuum breaker and Type 200 Specifications section for additional
details).
 
return freely to the closed position if pushed away from the valve body.
 
 

5
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
SEAT INSPECTION AND CLEANING PROCEDURE
1 ) Remove line or tank pressure and isolate vacuum breaker. (It is recommended that the vacuum breaker be removed from the piping or
tank for the seat inspection and cleaning procedure. It is recommended that you have an Inspection Kit on hand before beginning the
procedure.)
2) Remove nuts and bolts fastening valve body to adapter body.
3) Remove valve body from adapter body.
4) Remove capscrews from spring chamber.
5) Remove spring chamber from valve body.
6) Remove jamnuts from stem. Be careful, spring is preloaded.
7) Remove spring button.
8) For vacuum breakers with single spring remove spring. For vacuum breakers with dual springs remove outer and inner springs.
9) Remove disc and stem assembly from valve body.
10) Clean gasket surfaces on valve body and adapter body.
11) Inspect the integral seat or seat ring in the valve body. The integral seat or seat ring must be clean and free from deposits, scratches, or
other damage. If deposits are present clean the seat with red (fine) crocus cloth and a general purpose degreasing solvent. Cloths or
pads containing ultra fine silicon carbide such as a Scotch-Brite Ultra Fine Hand Pad or Norton Bear-Tex Clean & Finish Pad are also suitable
for cleaning the seat. Clean the seat with a circumferential motion around its diameter not with a longitudinal motion across its length.
For vacuum breakers with an integral seat, if after polishing the seat, you can still detect deposits, scratches, or other damage with your
fingernail , then replace the vacuum breaker. For vacuum breakers with a replaceable seat ring, if after polishing the seat, you can still
detect deposits, scratches, or other damage with your fingernail, then replace the seat ring. For vacuum breakers with an integral seat,
after cleaning, a light coat of primer may be applied to protect the seat.
12) Install disc and stem assembly in valve body.
13) For vacuum breakers with single spring, install spring over stem and center spring over pilot on valve body. For vacuum breakers with
dual springs, install inner spring over stem. Install outer spring over stem and inner spring. Center outer spring over pilot on valve body.
14) Install spring button on stem. Watch orientation. Center spring(s) over pilot(s) on spring button.
15) Install jamnuts on stem. DO NOT tighten until opening force is adjusted see following page.
16) Install new gasket on adapter body.
17) Install valve body on adapter body.
18) Install bolts through holes in adapter body and valve body. Install nuts on bolts. Tighten nuts and bolts in increments in an alternating
pattern.
19) Complete steps 4 thru 10 of Opening Force Adjustment Procedure.

62600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
SIZE OPENING FORCE
2 2 POUNDS
4 5 POUNDS
6 15 POUNDS
8 15 POUNDS
10 20 POUNDS
12 30 POUNDS
OPENING FORCE TEST PROCEDURE
1) Remove line or tank pressure and isolate vacuum breaker.
(It is recommended that the vacuum breaker be removed from the piping or tank for the test procedure)
2) Remove capscrews from spring chamber.
3) Remove spring chamber from valve body.
4) Apply water to cover top of disc.
5) Refer to table below. Apply opening force to end of stem using dead weights. The seat must open enough that it will not
hold water applied above the disc retainer. The disc must return to contact the seat when the weight is removed.
OPENING FORCE ADJUSTMENT PROCEDURE
1) Remove line or tank pressure and isolate vacuum breaker.
(It is recommended that the vacuum breaker be removed from the piping or tank for the adjustment procedure)
2) Remove capscrews from spring chamber.
3) Remove spring chamber from valve body.
4) Loosen jamnuts on stem until disc is not in contact with seat.
5) Tighten lower jamnut against spring button until disc remains in contact with seat.
6) Apply water to cover top of disc.
7) Set spring opening force. Refer to table in Opening Force Test Procedure. Apply opening force to end of stem using dead
weights. Adjust the positionof the lower jamnut on the stem so the seast opens enough that it will not hold water applied
above the disc retainer; and the disc returns to contact the seat when the weight is removed.
8) Tighten upper jamnut against lower jamnut.
9) Install spring chamber on valve body.
10) Install capscrews through holes in spring chamber. Tighten capscrews to secure spring chamber to valve body.
OVERHAUL
Rebuilding of the vacuum breaker should not be necessary under normal operating conditions. Should the vacuum breaker
become worn or damaged, parts kits are available. See Parts/ Overhaul.

7
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
FACTORY SERIAL
NUMBER LABEL
INFORMATION PRESENT ON TYPE 200
PART NUMBER & SERIAL NUMBER
Information Symbol(s) Location Notes
Part number P/N On spring chamber Factory Serial Number Label attached to spring chamber.
Serial Number SERIAL NO. On spring chamber and
valve body
Factory Serial Number Label attached to spring chamber.


SERVICE
Information Symbol(s) Location Notes
Maximum
pressure rating
Maximum
Pressure
On spring chamber Factory Serial Number Label attached to spring chamber.
Maximum
temp. rating
Maximum
Temperature
On spring chamber Factory Serial Number Label attached to spring chamber.
VALVE ATTRIBUTES
Information Symbol(s) Location Notes
Body material On vacuum
breaker

one piece the body material is iron.

of three sections welded together the body material is steel.

is made of three sections welded together the body material
is stainless steel.
INFORMATION PRESENT ON TYPE 200 VACUUM BREAKER
There is information present on each vacuum breaker ranging in importance from the part number and serial number to the
color of the paint and casting numbers. This information is important for identifying the vacuum breaker, installing it correctly,
and obtaining parts. An example of the current factory serial number label used on Type 200 vacuum breakers is shown
here. The accompanying table identifies the information present and where to find it on the vacuum breaker. There may also
be other casting numbers and foundry marks present that do not provide useful information. Customer specific tagging may
also present. The labels or plates used, and information present, on Warren Controls other product lines or older vacuum
breakers may be different, contact the factory for details.

82600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
Serial number label located here
Sales order (serial)
number stamped here
4” Iron Type 200
Stainless steel stem and non-asbestos
disc assembly, Iron body with seat and
brass guide, and stainless steel spring
assembly shown separately
VACUUM BREAKERS
WITH NON-ASBESTOS DISC
TYPE 200 VACUUM BREAKER SPECIFICATIONS
200
WITH STANDARD TRIM
INTEGRAL SEAT, NONASBESTOS
DISC AND STEEL DISCHOLDER
Body Material Size End Connection Part Number
IRON  125FLG 020009EXX000
 NPT 020009IXX000
4 125FLG 020013EXX000
6 125FLG 020015EXX000
8 125FLG 020017EXX000
10 125FLG 020019EXX007
12 125FLG 020020EXX000
STEEL  150FLG 020009GXX000
4 150FLG 020013GXX000
6 150FLG 020015GXX000
8 150FLG 020017GXX000
10 150FLG 020019GXX000
12 150FLG 020020GXX000
STEEL  300FLG 020009HXX000
4 300FLG 020013HXX000
6 300FLG 020015HXX000
8 300FLG 020017HXX000
10 300FLG 020019HXX000
12 300FLG 020020HXX000

200
WITH NONASBESTOS DISC
AND STAINLESS STEEL TRIM SS
DISCHOLDER AND
SS REPLACEABLE SEAT
Body Material Size End Connection Part Number
IRON 2 125FLG 020009EXX006
2 NPT 020009IXX006
4 125FLG 020013EXX006
6 125FLG 020015EXX006
8 125FLG 020017EXX006
10 125FLG 020019EXX010
12 125FLG 020020EXX006
STEEL 2 150FLG 020009GXX006
4 150FLG 020013GXX006
6 150FLG 020015GXX006
8 150FLG 020017GXX006
10 150FLG 020019GXX006
12 150FLG 020020GXX006
STEEL 2 300FLG 020009HXX006
4 300FLG 020013HXX006
6 300FLG 020015HXX006
8 300FLG 020017HXX006
10 300FLG 020019HXX006
12 300FLG 020020HXX006

9
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
VACUUM BREAKERS WITH TEFLON DISC
TYPE 200 VACUUM BREAKER SPECIFICATIONS
200 WITH INTEGRAL SEAT, TEFLON DISC
AND STEEL DISCHOLDER
Body Material Size End Connection Part Number
IRON  125FLG 020009EXX001
 NPT 020009IXX001
4 125FLG 020013EXX001
6 125FLG 020015EXX001
8 125FLG 020017EXX001
10 125FLG 020019EXX008
12 125FLG 020020EXX001
STEEL  150FLG 020009GXX001
4 150FLG 020013GXX001
6 150FLG 020015GXX001
8 150FLG 020017GXX001
10 150FLG 020019GXX001
12 150FLG 020020GXX001
STEEL  300FLG 020009HXX001
4 300FLG 020013HXX001
6 300FLG 020015HXX001
8 300FLG 020017HXX001
10 300FLG 020019HXX001
12 300FLG 020020HXX001

200
WITH TEFLON DISC AND STAINLESS
STEEL TRIM SS DISCHOLDER AND
SS REPLACEABLE SEAT
Body Material Size End Connection Part Number
IRON 2 125FLG 020009EXX004
2 NPT 020009IXX004
4 125FLG 020013EXX004
6 125FLG 020015EXX004
8 125FLG 020017EXX004
10 125FLG 020019EXX009
12 125FLG 020020EXX004
STEEL 2 150FLG 020009GXX004
4 150FLG 020013GXX004
6 150FLG 020015GXX004
8 150FLG 020017GXX004
10 150FLG 020019GXX004
12 150FLG 020020GXX004
STEEL 2 300FLG 020009HXX004
4 300FLG 020013HXX004
6 300FLG 020015HXX004
8 300FLG 020017HXX004
10 300FLG 020019HXX004
12 300FLG 020020HXX004

10 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
APPLICATION:
Falling liquid levels and condensing steam can cause a vacuum
that can damage a tank. The Type 200 Vacuum Breaker opens
gradually to admit outside air to relieve the vacuum in the
tank. The unit must be installed vertically with its mounting
connection downward.
FEATURES:
Iron, steel, or stainless steel body; Iron, steel, or stainless steel
seat; Non-asbestos or TFE disc;
Size 2” iron with NPT or 125FLG connections,
2” steel and stainless steel with 150 or 300FLG;
4” through 12” iron with 125FLG,
4” through 12” steel and stainless steel with 150 or 300FLG
Air relief capacities to 14,280 CFM
See What’s Available Chart for Features
PRESSURE-TEMPERATURE
RATINGS:
Body: Iron
End Connection: 125THD (NPT) and 125FLG
Disc: Non-asbestos
Maximum Pressure: 50 PSIG
Maximum Temperature: 300F
Body: Steel or Stainless Steel
End Connection: 150FLG
Disc: Non-asbestos
Maximum Pressure: 150 PSIG
Maximum Temperature: 500F
Body: Steel or Stainless Steel
End Connection: 300FLG
Disc: Non-asbestos
Maximum Pressure: 300 PSIG
Maximum Temperature: 500F
The Type 200 cannot be set to open at a particular vacuum.
The vacuum values presented in the table are for reference only.
AIR RELIEF CAPACITIES:
WEIGHTS:
For dimensions see drawing 0200032510.
TYPE 200 VACUUM BREAKER SPECIFICATIONS
STANDARD
OPTION
WHAT’S AVAILABLE 200
Features
Size (IN)
2 4 6 8 10 12
Body/ Seat
125 THD (NPT) IRON/ IRON
125 FLG IRON/ IRON
150 FLG STL/ STL
300 FLG STL/ STL
150 FLG ST STL/ ST STL
300 FLG ST STL/ ST STL
Disc
NON-ASBESTOS
TFE (TO 200 °F)
Disc-
holder
STEEL
ST STEEL
REPLACEABLE SEAT ST STEEL
BIRDSCREEN
LIFT RINGS
VACUUM
INCHES OF
MERCURY
CFM OF FREE AIR ADMITTED
AT 60F SIZE IN 200
2 4 6 8 10 12
0.75 88 352 792 1408 2200 3300
0.80 94 376 846 1504 2350 3525
0.85 106 424 934 1696 2650 3975
1.15 126 504 1128 2016 3150 4725
1.25 148 592 1332 2298 3700 5550
1.65 162 648 1458 2592 4050 6780
2.30 188 752 1692 3008 4700 7050
4.00 226 904 2034 3616 5650 8475
4.45 236 944 2124 3776 5900 8850
6.05 268 1072 2412 4288 6700 10050
6.30 276 1104 2484 4416 6900 10350
8.10 300 1200 2700 4800 7500 11250
8.65 314 1256 2826 5024 7850 11775
11.30 334 1336 3006 5344 8350 12525
12.05 348 1392 3132 5568 8700 13050
16.05 370 1480 3330 5920 9250 13875
16.65 372 1488 3348 5952 9300 13950
18.50 386 1541 3481 6189 9670 14505
19.10 381 1523 3427 6093 9520 14280
VALVE SIZE IN
2 4 6 8 10 12
Weight (lb) 26 68 102 180 230 375

11
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
Damaged or worn parts can decrease performance and shorten the life of the vacuum breaker.
A damaged or worn gasket can cause external leakage and damage to surrounding equipment.
A damaged or worn spring can result in a vacuum breaker that does not close when the vacuum in a tank is relieved allowing the tank’s
contents to escape and damage surrounding equipment, and can also cause damage to the stem.
A damaged or worn stem can result in a vacuum breaker that does not open to relieve a vacuum in a tank or close when the vacuum is
relieved allowing the contents to escape and damage surrounding equipment, and can also cause damage to the stem guide.
A damaged or worn stem guide can result in a vacuum breaker that does not open to relieve a vacuum in a tank or close when the
vacuum is relieved allowing the contents to escape and damage surrounding equipment, and can also cause damage to the stem.
A damaged or worn connecting pin, disc, disc retainer, or disc holder can cause external leakage resulting in the loss of the contents
from the tank and damage to surrounding equipment, and can also cause damage to surrounding parts inside the vacuum breaker.
A damaged or worn integral seat or seat ring can cause external leakage resulting in the loss of the contents from the tank and damage
to surrounding equipment, and can also cause damage to the disc and disc holder.
Two different parts kits are available. An Inspection kit is available to allow a vacuum breaker to be opened to inspect its internal parts. A
rebuild kit is available to allow a vacuum breaker to be overhauled. Please provide serial number to get the correct kit part numbers.
TYPE 200 VACUUM BREAKER PARTS/ OVERHAUL

12 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
INSPECTION KIT FOR TYPE 200 VACUUM BREAKER
SIZE 2 THRU 12 INCH
SEE DWG 0200032510
ITEM QTY DESCRIPTION
12 1 GASKET
REBUILD KIT
FOR TYPE 200 VACUUM BREAKER WITH INTEGRAL SEAT AND SINGLE SPRING
SIZE 2 THRU 12 INCH
SEE DWG 0200032510
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 2 JAMNUT 9 1 CONNECTING PIN
2 1 SPRING BUTTON 10 1 DISC RETAINER
3 1 SPRING 12 1 GASKET
5 1 STEM 14 1 DISC HOLDER
7 1 STEM GUIDE 15 1 DISC
REBUILD KIT
FOR TYPE 200 VACUUM BREAKER WITH INTEGRAL SEAT AND DUAL SPRING
SIZE 10 & 12 INCH EFFECTIVE DATE: 9/26/2008
SEE DWG 0200032510
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 2 JAMNUT 10 1 DISC RETAINER
2 1 SPRING BUTTON 12 1 GASKET
3 1 OUTER SPRING 14 1 DISC HOLDER
5 1 STEM 15 1 DISC
7 1 STEM GUIDE 18 1 INNER SPRING
9 1 CONNECTING PIN
TYPE 200 VACUUM BREAKER PARTS KITS
The inspection kit allows a vacuum breaker to be opened so the condition of its internal parts may
be inspected. The rebuild kits allow a vacuum breaker to be overhauled.
(Provide vacuum breaker serial number to get kit part numbers)

13
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
REBUILD KIT
FORTYPE 200 VACUUM BREAKERWITH REPLACEABLE SEAT AND SINGLE SPRING
SIZE 2 THRU 12 INCH
SEE DWG 0200032510
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 2 JAMNUT 10 1 DISC RETAINER
2 1 SPRING BUTTON 12 1 GASKET
3 1 SPRING 14 1 DISC HOLDER
5 1 STEM 15 1 DISC
7 1 STEM GUIDE 17 1 SEAT RING
9 1 CONNECTING PIN
REBUILD KIT
FOR TYPE 200 VACUUM BREAKER WITH REPLACEABLE SEAT AND DUAL SPRING
SIZE 10 & 12 INCH EFFECTIVE DATE: 9/26/2008
SEE DWG 0200032510
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 2 JAMNUT 10 1 DISC RETAINER
2 1 SPRING BUTTON 12 1 GASKET
3 1 OUTER SPRING 14 1 DISC HOLDER
5 1 STEM 15 1 DISC
7 1 STEM GUIDE 17 1 SEAT RING
9 1 CONNECTING PIN 18 1 INNER SPRING
TYPE 200 VACUUM BREAKER PARTS KITS

14 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
DRAWING 0200032510

15
Level Controls - IOM 200 VACUUM BREAKER 200__IOM_RevC_0618
NOTES


DEPENDABLE, RUGGED, PRECISION CONTROL VALVES AND ACCESSORIES
200_IOM_RevC_0618
