Wassermann Dental-Maschinen SIDOMIX User manual

Mixing and dosing unit
SIDOMIX
USER MANUAL

Dear customer,
Thank you for choosing a product fro the Wasser ann range. Wasser ann dental
equip ent incorporates the highest standards of quality and the latest technology.
In order to enjoy axi u perfor ance and years of trouble-free operation, please read
this instruction anual carefully before you connect this device and start work, and
operate the device according to the reco ended guidelines. The operation safety and
the functionality of this device can only be guaranteed if you follow both the general safety
guidelines and the applying laws to prevent accidents as well as the precautions given in
this instruction anual. We are not liable for any da ages which occur due to
inappropriate usage or faulty operation of this device.
Make sure that anyone using this device has read and understood this instruction
anual.
Keep this instruction manual in a safe place where it can be referred to as required
at any time.
Company address:
Wasser ann Dental-Maschinen G bH
Rudorffweg 15-17
D-21031 Ha burg, Ger any
Tel. : +49 (0)40 / 730 926 – 0 Fax.: +49 (0)40 / 730 37 24
E- ail: info@wasser ann-dental.co
URL: http//www.wasser ann-dental.co
Erstellt: 20.12.2007 / s Version: 1 Auftrag: 172984
.

Index
1 Features .......................................................................................................................... 4
2 Safety guidelines ............................................................................................................. 4
2.1 Safety sy bols used in this anual .......................................................................... 4
2.2 Safety guidelines ....................................................................................................... 5
3 Application ....................................................................................................................... 5
4 Before starting ................................................................................................................. 6
4.1 Transport................................................................................................................... 6
4.2 Installation.................................................................................................................. 6
4.3 Storage...................................................................................................................... 6
5 Start-up / Installation ....................................................................................................... 7
6 Operation ......................................................................................................................... 9
7 Troubleshooting ............................................................................................................. 10
8 Care and aintenance .................................................................................................. 11
8.1 Cleaning................................................................................................................... 11
8.2 Servicing.................................................................................................................. 11
8.3 Warranty ................................................................................................................. 11
8.4 Spare parts.............................................................................................................. 11
8.5 Scope of delivery / Accessories .............................................................................. 12
8.6 Repairs.................................................................................................................... 12
9 Technical data ............................................................................................................... 13
10 EC Confor ity Certificate ............................................................................................ 14

1 Features
Mixing and dosing of addition-vulcanazing 1:1 two-co ponent silicones. For even dosage
of both co ponents, both ust have si ilar viscosity.
dvantages:
• Mixing head with separate output openings – ixing of A and B co ponents while
ounting or dis ounting the ixing cannula is i possible
• Auto atic production of ho ogene silicone aterial without any loss or bubbles at the
press of a button
• Saves aterial and ti e by filling ore than one bowl at the sa e ti e with just a single
ixing cannula
• Forced ixing by a disposable ixing cannula, pink with bayonet ount
• Containers with quick couplings ounted directly on the device
• Quick coupling for ounting of 1 kg and 6 kg (optional adapter set ) or 25 kg (optional
pad stand and adapter set with connection hoses required).
• The included 2x2 litre aterial containers feature a quick coupling and can be used
i ediately.
• Food switch available as option
2 Safety guidelines
2.1 Safety symbols used in this manual
Warning!
This is a warning of risk situations and dangers.
Failure to observe this warning could be life-threatening. These warnings ust
be observed.
Information!
This sy bol draws your attention to specific features that ust be observed.
4

2.2 Safety guidelines
Always keep the two silicone co ponents separated – never ix up the
connections! The ixing of co ponents would cause the silicone within the
device to harden, aking extensive repairs of the device in the Ha burg plant
necessary.
Drill a ventilation hole using a drill or si ilar tool at the upper side edge of the 1
litre bottle or 6 kg or 25 kg can. Do not tighten the caps of the 2 litre aterial
containers, but just fit the loosely to ensure proper ventilation.
After hardening and before further usage, fit a new ixing cannula.
W RNING: Never use with a hardened mixing cannula!
Note that while using bulk containers, the cans ust be positioned at a height
higher than the device. Optional pad stands are available on request.
Leave about 2-3 c ini al filling inside the containers to avoid air to get into
the syste and the need for de anding bleeding of the device.
3 pplication
Mixing and dosing of addition-vulcanazing 1:1 two co ponent silicones. For even dosage
of both co ponents, both ust have si ilar viscosity.
Only use the device for this type of application.
5

4 Before starting
4.1 Transport
Before transporting the unit, ensure that it has been unplugged fro the power socket.
Make sure that it is packed correctly in order to avoid accidental da age.
Be sure to check for any transport da age when unpacking the goods. Note down
any da age if found.
4.2 Installation
Open the box, re ove the packing aterials, and carefully lift out the device and
accessories. Check the included accessories.
Install the device on a stable, level surface.
Do not install the SIDOMIX outdoors or in places without proper ventilation.
Before start-up, be sure the device reaches roo te perature.
Install the device in a place where it will not block the working area and the
functionality (take the di ensions into account).
4.3 Storage
If the unit is to be stored for an extended period, protect it fro oisture and dust.
6

5 Start-up / Installation
Connect the power cord.
Re ove the closing plugs fro the connections and dosage head.
When using 2 litre aterial containers (included):
Fill the aterial container with the relevant co ponent.
Warning: Insert the container filled with coloured silicone compound –
component B – into the colour marked entry at the back of the device. Do not
mix up! If you ix up the closings even for a short ti e, the device ust be
disasse bled and cleaned.
Very important: Do not tighten the caps of the aterial containers, but just fit the
loosely to ensure proper ventilation.
When using 1 kg bottles:
Re ove the closings of the bottles filled with two co ponent silicone and screw the
above entioned etal quick closings (accessories) onto the bottles.
Warning: Screw the colour marked quick closings onto the bottles filled with
coloured silicone compound – component B. Do not mix up! If you ix up the
closings even for a short ti e, the device ust be disasse bled and cleaned.
Insert the bottles with quick closings into the entry on the back of the device (the
bottles will be upside down).
Very important: Drill a ventilation hole using a drill or si ilar tool at the upper side
edge of the bottles to ensure proper ventilation.
When using 6 kg bulks:
Re ove the closings fro the cans filled with two co ponent silicone and screw
the adaptor set onto the cans.
Warning: Screw the colour marked adapter onto the can filled with coloured
silicone compound – component B. Do not mix up! If you ix up the closings
even for a short ti e, the device ust be disasse bled and cleaned.
Insert the can with quick closings into the entry on the back of the device (the can
will be upside down).
Very important: Drill a ventilation hole using a drill or si ilar tool at the upper side
edge of the can to ensure proper ventilation.
7

When using 25 kg bulks:
Note that while using bulk containers, the cans ust be positioned at a height
higher than the device. Optional pad stands are available on request.
Re ove the closings fro the cans filled with two co ponent silicone and screw
connection hoses onto the cans.
Warning: Screw the colour marked connection hose onto the can filled with
coloured silicone compound – Component B - screw on. Do not mix up! If you
ix up the closings even for a short ti e, the device ust be disasse bled and
cleaned.
Place the can, e.g. on the optional pad stand, to ake sure that it will be placed
higher than the dosage device (can will be upside down) and insert the connection
hoses with quick closings into the entry on the back of the device.
Very important: Drill a ventilation hole using a drill or si ilar tool at the upper side
edge of the can to ensure proper ventilation.
Replacing bottles/cans:
Re ove the quick coupling/bottle adaptor fro the device by pulling up the lock. Screw the
quick coupling/bottle adaptor onto the new bottle/can and connect as explained above.
Take special care to never confuse the bottles or connection hoses A+B – not even
for a short ti e – since the silicone within the connections and pipes hardens
instantly! The cleaning procedure is very de anding and ay only be perfor ed by
authorised repair co panies.
Note that while using bulk containers, the cans ust be positioned at a height higher than
the device. Optional pad stands are available on request.
Never use with a hardened mixing cannula!
8

6 Operation
Switch on the device; the toggle switch lights green.
To clean the pipes and dosage pu p, perfor the following upon first start-up as
well as when replacing the bottles: Position a container under the ixing head
without the ixing cannula, press the red button and hold it until both co ponents
run evenly and without bubbles fro the ixing cannula adaptors.
Mount the ixing cannula by turning it 90° on the ixing cannula adaptor (clean
the adaptor before if necessary). Place the bowl or the odel to be used for
doubling the syste under the ixing cannula. Press the red button: 1:1 ixed
silicone runs out of the ixing cannula.
We reco end collecting a s all a ount of the ixture initially output and just
letting the substance output subsequently run into the for . You can fill ore for s
without changing the ixing cannula as long as the period between the single
dosage operations lies within the dripping ti e of the used silicone (about 4 in.).
The dosage achine 1:1 dispenses ixed silicone as long as you press the red
button.
After use, leave the ixing cannula attached to the device and allow the re aining
silicone to vulcanise. This closes the openings of both co ponents sufficiently.
A new ixing cannula ust to be fitted after hardening and before further usage.
W RNING: Never use with a hardened mixing cannula!
Very important:
Do not continue operation if one or both containers are e pty; otherwise the
pipes will convey air (observe the ini u liquid level of the containers: ~ 2-3
c !).
9

7 Troubleshooting
Problem Cause Remedy
No silicone output. Hardened aterial
within the old
cannula.
Mount a new ixing cannula.
No silicone output. Mixing head clogged. Clean ixing head carefully.
Warning: Silicone co ponents ust not get
in contact with each other!
No silicone output. A and B co ponent
was ixed up;
silicone within the
device syste has
hardened.
The device needs to be disasse bled and
cleaned by a qualified technician.
No silicone output. Mini u liquid level
of the silicone
containers was
reached; syste has
sucked in air.
Add silicone co pound and wait about 20
in. until silicone fills the pipes. Position a
container under the ixing head without the
ixing cannula, press the red button and hold
it until both co ponents run out even and
without bubbles fro the ixing cannula
adaptors. Clean the ixing head and connect
a new ixing cannula if necessary.
Silicone output
without 1:1 ratio.
Silicone co ponents
do not have si ilar
viscosity.
We reco end using Wasser ann doubling
silicones WaSil soft and WaSil.
Silicone output
without 1:1 ratio.
Gears within the
pu p are not evenly
worn.
The device needs to be inspected by a
qualified technician.
If the above recommendations do not solve the problem, contact your dental
depot or our service department.
10

8 Care and maintenance
8.1 Cleaning
Disconnect the power plug before starting any aintenance work.
The identification plate ust always be kept in easily legible condition and ust
not be re oved.
Always keep the ixing cannula adaptor and the quick closings clean.
8.2 Servicing
The SIDOMIX does not require any servicing. Just ake sure that the device is kept clean.
8.3 Warranty
The warranty period for our equip ent is 12 onths. If faults occur within the
warranty period, contact your dental depot or get in touch directly with our Service
depart ent.
Your equip ent should only be operated in perfect condition. If faults occur which
could har operators or third parties, the unit should not be used until it has been
fixed.
This warranty does not cover da age caused by i proper use, external
echanical causes, transport da age or interference with the unit by unauthorized
persons.
Wasser ann Dental-Maschinen G bH does not accept any liability when using
silicone co pounds produced by other anufacturers. Doubling silicones ay vary
in viscosity and abrasiveness of both co ponents; therefore not all co ercially
available doubling co pounds ay be suitable for usage with this dosage device.
8.4 Spare parts
If necessary please contact our service hotline phone:
0049 (0)40 / 730 92 6-0
11

8.5 Scope of delivery / ccessories
Included parts: Part no.
Material container set with quick coupling, 2x2 litres 172640
Mixing cannula, pink 100 pieces 622022
ccessories: Part no.
Mixing cannula, pink 100 pieces 622022
Foot switch 174175
Retrofitting set for foot switch 172630
Material container set with quick coupling, 2x2 litres 172640
Pad stand s all for WaSil / WaSil soft 2 x 6 kg bulk 172631
Pad stand large for WaSil / WaSil soft 2 x 25 kg bulk 172632
Connection hoses co plete, 2 pieces 172633
Adaptor set for WaSil / WaSil soft 2 x 1 kg bulk 172634
Adaptor set for WaSil / WaSil soft 2 x 6 kg bulk 172636
8.6 Repairs
Servicing or repairs to the unit ust only be carried out by qualified technicians.
Only original spare parts are to be used. Responsibility for the product is voided
if unauthorised persons alter it or if inappropriate co ponents are installed.
12

9 Technical data
Mixing and dosing unit SIDOMIX, 1:1 – ite no. 172984
Di ensions: width: 290 , height: 310 , depth: 450
Weight: 11.5 kg
Voltage*: 220-240 V / 50/60 Hz – 115 V / 50/60 Hz
Output: 260 Watt
Power consu ption: 1.6 A
*Other voltages upon enquiry.
The noise level of the unit a ounts to ≤ 70 dB(A).
The technical data are subject to change without prior notice.
13

10 EC Conformity Certificate
in accordance with 2006/95/EG (low-voltage guidelines) and 2004/108/EG (EMV
guidelines) and 98/37/EG ( achinery guidelines)
Manufacturer: W A S S E R M A N N
Dental-Maschinen G bH
Rudorffweg 15 - 17
D-21031 Ha burg
Product description: Mixing and dosing
unit, 1:1, for
dental
applications
Model: SIDOMIX Ite -no. 172984
Aapplicable
standards:
DIN EN 61010-1:2004
DIN EN 61000-6-3:2005
DIN EN 61000-6-1:2002
DIN 45635-1:1984
DIN EN 60335-1:2007
Hier it wird bestätigt, dass die oben bezeichnete Maschine den genannten EG-Richtlinien
entspricht. Diese Erklärung wird ungültig, falls die Maschine ohne unsere Zusti ung
verändert wird.
This is to confir that the above entioned achine co plies with the described EC
rules. This declaration beco es invalid if the achine is odified without our approval.
Cette achine est confor e aux nor es en vigueur de la Co unité Européene. Cet
avis est nul et non avenant si cette achine est odifiée sans notre accord.
Esta áquina, anterior ente encionada, cu ple con los li ites requeridos por el
regla ento EC. Ahora bien, esta declaración quedará invalidada en caso de realizar
odificaciones al aparato sin nuestra aprobación.
Hier ee wordt bevestigd dat bovengenoe de achine voldoet aan de voorgeschreven
EU nor en. Deze verklaring verliest geldigheid als er zonder onze uitdrukkelijke
toeste ing wijzigen aan de achine worden aangebracht.
Place, date: Ha burg, 20.07.2007 Co pany sta p:
Signature : ________________________
Wilfried Wasser ann
(Managing Director)
14

Notes:
15
