Wassermann SG-1 User manual

Suction unit
SG-1/1
Single Workbench Suction Unit
USER MANUAL

Dear customer,
Thank you for choosing a product from the Wassermann range Wassermann Dental-
Maschinen incorporates the highest standards of quality and the latest technology
In order to enjoy maximum performance and years of trouble-free operation, please read
this user manual carefully before you connect this device and start work, and operate the
device according to the recommended guidelines The operation safety and the
functionality of this device can only be guaranteed if you follow both the general safety
guidelines and the applying laws to prevent accidents as well as the precautions given in
this user manual We are not liable for any damages which occur due to inappropriate
usage or faulty operation of this device
Make sure that anyone using this device has read and understood this user
manual
Keep this user manual in a safe place where it can be referred to as required at
any time
The unit complies with the relevant EU guidelines
The unit is subject to the EU guidelines 2012/19/EU (WEEE Directive)
Company address:
Wassermann Dental-Maschinen GmbH
Rudorffweg 15-17
21031 Hamburg, Germany
Phone : [phone]/ -24 Fax : [phone]
export@wassermann-dental com
www wassermann hamburg
Erstellt: 10 07 17/ msc Version: 1 Auftrag: 140995/090

Contents
1 Features 4
2 Safety Symbols used in this Manual 4
3 Safety Guidelines 5
4 Responsibility for Operation or Damage 5
5 Application 6
6 Before Starting 6
6 1 Transport 6
6 2 Installation 7
6 3 Storage 7
7 Installation/ Start-up 7
8 Operation 8
8 1 General Operating Instructions 8
9 Troubleshooting 8
10 Care and Maintenance 8
10 1 Cleaning 8
10 2 Maintenance 9
10 2 1 Changing the Filter 9
10 3 Repairs 9
10 4 Spare Parts 9
10 5 Service Hotline [phone]/ -24 9
10 6 Scope of Delivery/ Accessories 10
10 7 Warranty 10
11 Technical Data 10
12 Disposing of the Unit 11
12 1 Information on Disposal for Countries within the EU 11
13 EU Declaration of Conformity 12

1 Features
•Single workbench suction unit according to the low pressure principles
•Multifunctional deployment – from polishing trough to fine blasting units
•Maximum flexibility via extremely compact construction design
•Incl plug for elaboration machines or polishing motors
•Virtually noiseless operation, no cooling down of the hands
•Suitable for continuous operation
•Low wear-and-tear and nearly maintenance-free
•Comprehensive range of special accessories available, recommended special
accessories: automatic switcher AS-100 for the automatic hooking up suction units
2 Safety Symbols used in this Manual
arning!
This is a warning of risk situations and dangers
Failure to observe this warning could be life-threatening These warnings has to
be observed
Information!
This symbol draws your attention to specific features that has to be observed
4

3 Safety Guidelines
Configuring and operating this equipment requires precise knowledge and observance
of the instructions in this user manual The equipment is designed only for its intended
application
ARNING:
Servicing and repairs should be carried out only by authorised specialists
Disconnect the power plug before starting any maintenance work
Make sure that the equipment is connected to the correct power source
4 Responsibility for Operation or Damage
The responsibility for operating the device lies exclusively with the owner or user if said
device is incorrectly serviced, maintained or altered by persons not employed by an
authorised dealer or if the device is used in a manner contrary to its specified purpose
The unit has to be maintained and operated in accordance with this user manual
Wassermann Dental-Maschinen GmbH is not responsible for damage arising from the
nonobservance of these instructions
Warranty and responsibility provisions contained in the sales and supply conditions of
Wassermann Dental-Maschinen GmbH are not extended by these instructions
5

5 Application
The SG 1/1 suction unit can be installed in various locations such as a dental-laboratory
workbench or a polishing trough Its suction action combines a maximum quantity of air
and a low air speed and is dedicated to extracting suspended dust particles, which could
enter the lungs The advantages are virtually silent operation of the fan motor and an
overall low noise level, thanks to the slow flow speed of the air drawn in This slow air
speed means that your hands do not get cold, even after a long time working at the suction
inlet
The SG 1/1 also features an additional socket, allowing you to connect one other device,
which then starts to operate as soon as the suction is turned on
Only use the device for this type of application
6 Before Starting
6.1 Transport
Before transporting the unit, ensure that it has been unplugged from the power socket
Make sure that it is packed correctly in order to avoid accidental damage
Be sure to check for any transport damage when unpacking the goods Note down
any damage if found
6

6.2 Installation
Open the box, remove the packing materials, and carefully lift out the device and
accessories Check the included accessories
The device has to stand horizontally on a steady and even surface
Install the device in a place where it will not block the working area and the
functionality (take the dimensions into account) Make sure that there are about
10 cm of free space on each side to guarantee air circulation (heat dissipation)
Do not install the unit outdoors or in places without proper ventilation
Before start-up, be sure the device reaches room temperature
6.3 Storage
The unit location is very important when it comes to workplace safety, even if it is only to
be set up there for a short period The room should be dry, well ventilated and vibration-
free An even temperature and wooden supports also help The unit should not be stored
or set up outdoors If the unit is to be stored for an extended period, protect it from
moisture and dust
7 Installation/ Start-up
Before starting the unit, connect up the following:
1 Take the cable from the filter under the cover
2 Plug the unit into the mains
Finally, insert the power plug into the socket, making sure that the mains and the unit
operate on the same voltage
7

8 Operation
8.1 General Operating Instructions
All instructions for using the unit, whether in verbal or written form, are based on our own
experience and experimentation and can only be regarded as guidelines
Use the rocker switch on the cable to switch the unit on and off
9 Troubleshooting
Contact your dental depot or our service department
10 Care and Maintenance
10.1 Cleaning
Disconnect the power plug before starting any maintenance work
The identification plate has always to be kept in easily legible condition and has
not to be removed
Remove external dirt from time to time with some form of cold cleaner
Use only cold cleaners to avoid damaging the paintwork or removing the lettering
The equipment should be cleaned at regular intervals to ensure trouble-free
operation
It requires only normal cleaning (sponge, damp cloth, mild detergent) and no further
chemical additives
8

10.2 Maintenance
10.2.1 Changing the Filter
This equipment uses a one-way, micro fine filter bag, which must be replaced once it is full
of dust
To do so, open the catches right and left, remove the cover, take out the filter bag and
then remove the packaging from the replacement bag Insert the new filter and close the
cover
You will need to change the filter regularly to ensure trouble-free dust removal It needs
replacing at the latest when the suction becomes laboured or the fine dust filter changes
colour
10.3 Repairs
Servicing or repairs to the unit has only to be carried out by qualified technicians
Only original spare parts are to be used Responsibility for the product is voided
if unauthorised persons alter it or if inappropriate components are installed
10.4 Spare Parts
If necessary please contact our service hotline phone
10.5 Service Hotline [phone]/ -24
9

10.6 Scope of Delivery/ Accessories
Included parts Item no.
Supply line with switchable shock proof plug 140022
Micro fine dust filterbag - - -
Accessories/Spare parts Item no.
Spare filterbag for micro finedust (dust class M), 1 set=4 pieces 611010
Spare filterbag for plaster (class 1 / class 2), 1 set=4 pieces 611018
10.7 arranty
The warranty period for our equipment is 12 months If faults occur within the
warranty period, contact your dental depot or get in touch directly with our service
department
Your equipment should only be operated in perfect condition If faults occur which
could harm operators or third parties, the unit should not be used until it has been
fixed
This warranty does not cover damage caused by improper use, external mechanical
causes, transport damage or interference with the unit by unauthorized persons
11 Technical Data
SG-1/1 Item no.: 140995
Voltage* 220–240 V / 50/60 Hz
Power consumption 0 75 A
Plug socket power consumption max 8 A
Output 170 W
W x H x D 260 x 400 x 330 mm
Weight 9 9 kg
Sound level 59 dB(A)
Suction capacity 500 m3/h (free-blowing)
*Other voltages on request
The noise level of the unit amounts to ≤ 70 dB (A)
Technical changes reserved
10

12 Disposing of the Unit
The unit has to be disposed by an authorized recycling operation The selected company
has to be informed of all possibly health-hazardous residues in the unit
12.1 Information on Disposal for Countries within the EU
To conserve and protect the environment, prevent environmental pollution and
improve the recycling of raw materials, the European Commission adopted a
directive that requires the manufacturer to accept the return of electrical
and electronic units for proper disposal or recycling
Within the European Union units with this symbol should not therefore be disposed of
in unsorted domestic waste
For more information regarding proper disposal please apply at your local authoritie
11

13 EU Declaration of Conformity
in accordance with 2014/35/EU (Low Voltage Directive) and 2014/30/EU (Electromagnetic
Compatibility Directive) and 2006/42/EC (Machinery Directive) and 2011/65/EU (RoHS
Directive)
Manufacturer: W A S S E R M A N N
Dental-Maschinen GmbH
Rudorffweg 15-17
21031 Hamburg
Germany
Product description: Suction Unit for
dental
applications
Model: SG 1/1 Suction Unit 140995
Applicable
standards:
DIN EN 61010-1
DIN EN 61000-6-3
DIN EN 61000-6-1
DIN 45635-1
DIN EN 60335-1
Hiermit wird bestätigt, dass die oben bezeichnete Maschine den genannten EU-Richtlinien
entspricht Diese Erklärung wird ungültig, falls die Maschine ohne unsere Zustimmung
verändert wird
This is to confirm that the above mentioned machine complies with the described EU
guidelines This declaration becomes invalid if the machine is modified without our
approval
Cette machine est conforme aux normes en vigueur d´Union européenne Cet avis est
nul et non avenant si cette machine est modifiée sans notre accord
Esta máquina, anteriormente mencionada, cumple con los limites requeridos por el
reglamento UE Ahora bien, esta declaración quedará invalidada en caso de realizar
modificaciones al aparato sin nuestra aprobación
Hiermee wordt bevestigd dat bovengenoemde machine voldoet aan de voorgeschreven
EU normen Deze verklaring verliest geldigheid als er zonder onze uitdrukkelijke
toestemming wijzigen aan de machine worden aangebracht
Place, date: Hamburg, 2017-07-10 Company stamp:
Signature: ________________________
Wilfried Wassermann
(Managing Director)
12
