WatchNet AVC-DS1 User manual

WatchNET Video Door Station
AVC-DS1

Page 2of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
Revision History ............................................................................................................................................ 3
Chapter 1 Introduction ................................................................................................................................. 3
1.1 Summary ......................................................................................................................................... 3
1.2 Features .......................................................................................................................................... 3
1.3 Panel Description ............................................................................................................................ 5
Chapter 2 Configuration................................................................................................................................ 5
2.1 Web login ........................................................................................................................................ 5
2.2 Login Using Web Browser ............................................................................................................... 6
2.3 Status .............................................................................................................................................. 7
2.3.1 Basic................................................................................................................................. 7
2.4 Intercom.......................................................................................................................................... 8
2.4.1 Basic................................................................................................................................. 8
2.4.2 Advanced......................................................................................................................... 9
2.4.3 LED Setting..................................................................................................................... 10
2.4.4 Relay & Input ................................................................................................................. 11
2.4.5 Live Stream ....................................................................................................................12
2.4.6 RTSP............................................................................................................................... 13
2.4.7 ONVIF............................................................................................................................. 14
2.4.8 Action.............................................................................................................................15
2.5 Account .........................................................................................................................................16
2.5.1 Basic............................................................................................................................... 16
2.5.2 Advanced....................................................................................................................... 17
2.6 Network ........................................................................................................................................ 20
2.6.1 Basic............................................................................................................................... 20
2.6.2 Advanced....................................................................................................................... 21
2.7 Phone ............................................................................................................................................22
2.7.1 Time/Lang...................................................................................................................... 22
2.7.2 Call Feature....................................................................................................................23
2.7.3 Voice ..............................................................................................................................24
2.7.4 Multicast........................................................................................................................25
2.7.5 Call Log...........................................................................................................................26
2.8 Upgrade......................................................................................................................................... 27
2.8.1 Basic............................................................................................................................... 27
2.8.2 Advanced....................................................................................................................... 28
2.9 Security - Basic .............................................................................................................................. 30

Page 3of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
Revision History
Revision
Date
Author
Description of Changes
1.0
06/22/2017
Peter Punzalan
Manual Created.
Chapter 1 Introduction
1.1 Summary
WathcNET’s Video Door Phone (AVCDS1) is a commercial grade full metal body intercom that is
weather proof and easy to install. SIP technology enables easy communication with any EPBX or SIP
telephone, once registered with SIP server the door phone can call landline or mobile phone for
video and audio communication
1.2 Features
Highlights
Vandal resistant body with a flush button
Wide angle camera (90 Degrees)
POE (IEEE802.3af, Power Over Ethernet)
Two-way audio communication over IP network with echo cancelation feature
Complies with SIP standard for easy integration in each SIP PBX
Physical & Power

Page 4of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
Body Material –All Aluminum
Camera –2.1MP, automatic lighting
Button –1 call button
Output Relay –2 output relays for door entry
POE –802.3af Power Over Ethernet
Power Consumption –12W
G-Sensor for tamper alarm
Water proof & Dust Proof –IP65
Installation –Wall mounted
Dimension –190mm x 110mm x 33mm or 7.48” x 4.33” x 1.33”
SIP Endpoint
SIP –SIP v1(RFC2543), SIP v2(RFC3261)
Audio Codecs –G.711a, G.711μ, G.722, G.729
Video Codec –H.264
Speech Quality –7kHz Audio
Echo Cancellation
Voice Activation Detection
Comfort Noise Generator
Video
Resolution –Up to 1080p
Maximum Image Transfer Rate –1080p –30fps
High intensity White LEDs for picture lighting during dark hours with internal light sensor
Compatible to 3rd Party Video Components, i.e. NVRs
Door Entry Feature
Relays controlled individually by DTMF tones
Camera Permanently operational
White Balance –Auto
Auto-night mode with LED illumination
Minimum illumination –0.1LUX
Networking
1x10x100 Mbps Ethernet port
Protocols supports –IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP,
DHCP, ARP
Application Scenario
Office Door Phone with on-site or hosted IP-PBX
Remote site entry over Internet
Logistics & Transportation: Airports or Parking Lots
Villa Intercom with door access control

Page 5of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
1.3 Panel Description
Infrared LED
Photosensitive Sensor
Camera
Speaker
Call Button
Status LED
MIC
Chapter 2 Configuration
2.1 Web Login
Obtaining IP Address –the DS1 is set to DHCP by default, make sure the SIP Door Station is plugin to the
network, to get the IP address simply press and hold the call button for about 5 seconds and a voice
prompt will tell you the IP address of the door station.
Note: Make sure to wait for LED status to turn blue.

Page 6of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.2 Login using Web browser
Open web browser and enter the IP address of the door station into the address bar and type in the
username and password.
User name: admin
Password: admin

Page 7of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.3 Status
2.3.1 Basic –Display’s information about the product, network and account information.

Page 8of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.4 Intercom
2.4.1 Basic –Basic configuration for the intercom such as push button number, no answer feature etc.
Basic
Select Account –Allows you to select to which account applies the settings
No Answer Call –To enable or disable no answer feature
Push Button –to input the number to call when making a call
Push Button –input the number to call when button is pressed
No Answer Call 1 –when the number on push button did not answer, it will dial this instead

Page 9of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
No Answer Call 2 –if the number on “No Answer Call 1” did not answer it will redirected to this
number.
Push Button Action –if configured the door station will record any changes on the surrounding
environment and send the message or picture to the configured receiver
Web Call –to dial out or answer the call from a website
Max Call Time –configure a maximum time during a call
Max Dial Time
Dial In Time –if other phone calls the door station and if ring tone is over the dial in time
without answer the call will be terminated
Dial Out Time –if the door station dial the number and ringtone is over the dial out time
without answer the door station will continue to call on no answer call number.
Push to Hang Up –enable or disable push to hang up feature
2.4.2 Advanced
Photoresistor –Photo resistor is used to sense the light intensity on door station and will enable the LED
automatically, the lower the setting the lower the sensitivity.

Page 10 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
Tamper Alarm –to enable or disable tamper alarm, if the gravity sensor changes the phone will trigger
the alarm, the smaller the threshold the faster the door station will trigger
2.4.3 LED Setting
LED Status
State –supports 5 states, Normal, Offline, Calling, Talking and Receiving.
Color Off –default settings is OFF
Color On –it supports 3 color; Red, Green and Blue
Blink Mode –to configure a different frequency settings
LED Control –to remotely configure the LED using URL
HTTP Format: http://PhoneIP/fcgi/do?action=LedAction&State=1&Color=1&Mode=2500 Status: 1=Idle
;2=Off Line ; 3=Calling ; 4=Talking ; 5=Receiving ; Color: 1=Green ; 2=Blue ; 3=Red; Mode:0=Always
on;1=Always Off 500/1000/1500/2000/25000/3000

Page 11 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.4.4 Relay & Input
Relay –configuration settings about the lock relays
Relay ID –door stations supports 2 relay
Relay Type –to configure the correct type if connecting a relay on the door station.
Relay Delay –to configure the amount of time a relay to stays open

Page 12 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
DTMF Option –to configure the DTMF code, support 1, 2, 3 or 4 numbers.
DTMF –to configure the code to unlock the relay or door
Multiple DTMF –if DTFM Option is set to either 2, 3 or 4 you can input the codes here
Status –status will change depending on the relay state
Web Relay –door station supports remote unlock relay via web
Type –to enable or disable this function
IP Address –input the web relay IP address
User name –input the username if needed
Password –input the password if needed
Open Relay via HTTP
Switch –to enable or disable this feature
Username –input username if needed
Password - input password if needed
Input –to configure the input such as door sensor or contacts
Input Service –to enable or disable the input
Action to execute –to select how to receive the alert
Http URL –if HTTP is selected alarm message will be sent Http message
Call Timer –the interval between calls
Door Status –shows the status whenever the door is opened
Light Status –this status will change depending on the sensor, once the sensor is triggered the
status will show a warning, by default is normal
2.4.5 Live Stream –display the real-time video from the door station

Page 13 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.4.6 RTSP
RTSP Basic –to enable or disable RTSP feature on the door station
RTSP Stream –to enable or disable the RTSP audio and video, also to select RTSP video codec
H.264 Video Parameters –is a video stream compression standard, this provides an approximately
identical level of video stream quality but a half bit rate.
MPEG4 Video Parameters –one of the video network image compression standards, it supports
maximum compression ratio- 4000:1, it is an important and common video function with great
communication application integration ability and less core program space.
MJPEG Video Parameters –is also called as Motion Joint Photographic Experts Group, it is a video
encoding format in which each image is compressed separately by JPEG. MJPEG compression can
produce high quality video image and has a flexible configuration in video definition and compressed
frames.

Page 14 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.4.7 ONVIF
Basic Setting
ONVIF Mode –to configure the mode of the door station
User Name –to modify the username for login
Password –to modify the password for login

Page 15 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.4.8 Action
Email Notification
Sender Name –input the sender’s email address
Recipient’s Email Address – input the receiver’s email address
SMTP Server Address –input the correct SMTP server
SMTP User name –input the sender’s username
SMTP Password –input the sender’s password
Email Subject –input the subject for the email
Email Content –to input the content of the email notification
Email Test –to test if notification can be sent or all information above is correct
FTP Notification
FTP Server –input the FTP Server
FTP User Name –input the FTP`s username

Page 16 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
FTP Password –input the FTP`s password
FTP Test –to test the information above is correct or not
SIP Call Notification –If the SIP Call feature is enabled, enter the number to call and the name on the
number to call out
2.5 Account
2.5.1 Basic
SIP Account
Status –display the status if SIP registered successfully or not
Account –choose which account to register the SIP

Page 17 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
Account Active –to enable or disable the SIP account
Display Label –input the SIP label information
Display Name –input the SIP name information
Register Name –input the SIP registration name
User Name –input username for the SIP account
Password –input the password for the SIP account
SIP Server 1
Server IP –input the SIP`s Server IP
Registration Period –registration expiration after registering the sip, and door station will re-
register again after
SIP Server 2 –This option is for secondary SIP server just in case the first server fails it registers to this
SIP Server
Outbound Proxy Server –to configure the outbound proxy server settings, and outbound proxy server is
used to receive all initiating request messages and route them to the designated SIP server
Note: if configured, all SIP request message from the door station will be sent to outbound proxy
immediately.
NAT –to enable or disable the NAT feature
Stun Server Address –a solution to solve a NAT issues.

Page 18 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.5.2 Advanced

Page 19 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
SIP Account –select which account to display or modify the advanced setting
Codecs –to display or configure which audio codecs to use
Video Codec
Codec Name –enable or disable the H.264 codec
Codec Resolution –to select the resolution
Codec Bitrate –to select the Bitrate
Codec Payload –range from 90-119
DTMF
Type –supports Inband, Info RFC2833 or other combination
How to Notify DTMF –only available if DTMF type is set to “Info”
DTMD Payload –to configure the payload type for DTMF
Note: default settings is “RFC2833” which is the standard, Inband type uses frequency to indicate DTMF
tone which is mostly used to be compatible with traditional telephone server. Info type is used for SIP
info message to indicate DTMF message.
Call
Max Local SIP Port –to configure the maximum local SIP port for designated account
Min Local SIP Port –to configure the minimum local SIP port for designated account
Caller ID Header –to configure which caller ID format to show for display on phone UI.
Auto Answer –if enable, the door station will answer the incoming call automatically
Anonymous Call –if enabled, the door station will send user=phone within SIP message
Anonymous Call Rejection –if enabled, all incoming anonymous call will be rejected
Missed Call Log –to display the miss call log
Prevent SIP Hacking –to prevent SIP from being hacked
Session Timer
Active –to enable or disable session timer feature. If enabled the ongoing call will be
disconnected automatically once the session expires, unless it’s been refresh by UAC or UAS
Session Expire –to configure the session expire time
Session Refresher –to configure who should be responsible for refreshing the session
Note: UAC means User Agent Client or stands for IP phone, UAS means User Agent Server or stands for
SIP server
Encryption –If voice Encryption is enabled all audio signal will be encrypted for more security
NAT
UDP Keep Alive Message –if enabled, door station will send UDP keep-alive message
periodically to router to keep NAT port alive
UDP Alive Message Interval –keep alive message interval
Rport –if enabled, it will add remote port into outgoing SIP message for designated account
User Agent –One can customize user agent field in the SIP message, if user agent is set to a specific
value user could see the information from PCAP. If user agent is not set by default, user could see the
company name, model and firmware version from PCAP

Page 20 of 30 351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: [phone] TOLL FREE: 1-866-331-3341 • FAX: [phone]
www.watchnetinc.com / [e-mail]
2.6 Network
2.6.1 Basic –to configure the network of the door station, by default it is set to DHCP
