Owner’s Manual
Electric Drill Utility Pump
WA63UP Drill Pump
WA62UP
Drill Pump with Kit
General Safety . . . . . . . . . . . . . . . . . . . . 2
Specications. . . . . . . . . . . . . . . . . . . . . 3
Assembly . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly/Maintenance . . . . . . . . . . . . . 5
Troubleshooting/Warranty . . . . . . . . . . . 6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . .7
TABLE OF CONTENTS
2
ALWAYS USE EXTREME CAUTION
maintaining this product!
Important Safety Instructions
Carefully read and follow all safety
instructions in this manual and on pump.
SAVE THESE INSTRUCTIONS – This manual
contains important instructions that should be
followed during installation, operation, and
maintenance of the product.
Save this manual for future reference.
Safety Labels
This is the safety alert symbol. When you
see this symbol on your pump or in this manual,
look for one of the following signal words and be
alert to the potential for personal injury!
Indicates a hazard which, if
not avoided, will result in death or serious injury.
Indicates a hazard which,
if not avoided, could result in death or serious
injury.
Indicates a hazard which, if
not avoided, could result in minor or moderate
injury.
NOTICE indicates practices not related to
personal injury.
Keep safety labels in good condition. Replace
missing or damaged safety labels.
General Safety
Risk of burns. Do not
touch an operating motor. Motors are de-
signed to operate at high temperatures. To
avoid burns when servicing pump, allow it to
cool for 20 minutes after shut-down before
handling.
Do not allow pump or any system compo-
nent to freeze. To do so will void warranty.
Pump water only with this pump.
Periodically inspect pump and system com-
ponents.
Wear safety glasses at all times when work-
ing on pumps.
Risk of explosion. Pump
body may explode if used as a booster
pump.
NOTE: Not recommended to use for drinking
water
GENERAL SAFETY
STOP Before you start
3
Warranty
WHAT IS COVERED
Thi s pump i s guar anteed for 90days from d ate ofpurchase. It will pump clean water and motor oil.
WHAT IS NOT COVERED
Pumping anything other than clean water and motor oil, and if damaged due to misuse from primarilybeing run without water or oil in the
pump (running the pump dry).
Contact the Cu stomer Service Team at1-844-883-1872 or visit www.HomeDepot.com.
Pre-Assembly
PRODUCT SPECIFICATIONS
Maximum Head at 1,200 RPM 45 ft.
Maximum Head at 800 RPM 32 ft.
Rate of Flow at 1,200 RPM 90 GPH
Rate of Flow at 800 RPM 60 GPH
Priming Self-priming up to 8 ft. vertical ly
Lubrication Pressure-lubricated bearings, shaft, and seal
PLANNING OPERATION
Carefully unpack and inspecteach part. Compare parts with the Package Contents list. If any part appears missing or damaged, do not
operate this product. Contact the Customer Service Team.
TOOLS REQUIRED
Drill Garden h ose
Warranty
WHAT IS COVERED
Thi s pump i s guar anteed for 90days from d ate ofpurchase. It will pump clean water and motor oil.
WHAT IS NOT COVERED
Pumping anything other than clean water and motor oil, and if damaged due to misuse from primarilybeing run without water or oil in the
pump (running the pump dry).
Contact the Cu stomer Service Team at1-844-883-1872 or visit www.HomeDepot.com.
Pre-Assembly
PRODUCT SPECIFICATIONS
Maximum Head at 1,200 RPM 45 ft.
Maximum Head at 800 RPM 32 ft.
Rate of Flow at 1,200 RPM 90 GPH
Rate of Flow at 800 RPM 60 GPH
Priming Self-priming up to 8 ft. vertical ly
Lubrication Pressure-lubricated bearings, shaft, and seal
PLANNING OPERATION
Carefully unpack and inspecteach part. Compare parts with the Package Contents list. If any part appears missing or damaged, do not
operate this product. Contact the Customer Service Team.
TOOLS REQUIRED
Drill Garden h ose
SPECIFICATIONS
Maximum Head at 1,200 RPM 45 ft.
Maximum Head at 800 RPM 32 ft.
Rate of Flow at 1,200 RPM 90 GPH
Rate of Flow at 800 RPM 60 GPH
Priming Self-priming up to 8 ft. vertically
Lubrication Pressure-lubricated bearings, shaft and seal
PART DESCRIPTION REPLACEMENT PART NO. QUANTITY
A Oil tube, 30 “ x 1/4” O.D. EF60DRILL003 1
B 3” Adapter tube (3/8” O.D. & 1/4” I.D.) EF60DRILL005 1
C Pump EF60DRILL001 1
D 3’ x 1/2” Garden hose with brass female tting EF60DRILL006 1
TOOLS REQUIRED
Drill Garden Hose
TOOLS REQUIRED
Carefully unpack and inspect each part. Pull oil tube completely out of garden hose. Compare parts with the
Package Contents list. If any part appears missing or damaged, do not operate this product. Contact the
Customer Service Team.
CONTENTS
A
B
C
D
A
B
C
IN
OUT
D
NOTE: If using a garden hose on the suc-
tion side of pump, then the hose must be
sti walled and be kept as short as pos-
sible. If not, then there is a risk of the hose
collapsing and blocking suction. There
can be no leaks in the suction line or the
pump will not prime.
4
C
B
A
1
D
ASSEMBLY
1
Preparing to pump motor oil using
adapter and tube 2
Preparing to pump clean water using
garden hose connected to pump
• Remove the dipstick from the engine/motor
from which you plan to remove motor oil.
• Cut at a 60 degree angle one end of tube (A).
• Lubricate the pump impeller by placing several
drops of mineral or vegetable oil on the
impeller at inlet port (1).
• Place the adapter tube (B) into the inlet port (1)
of the pump (C) as far as it will go in.
• Insert the end of the tube (A) with the
60 degree cut into the motor dipstick hole.
• Attach the garden hose (D) to port (2).
• Attach drill pump with tubes and hose to drill.
• Connect drill motor power cord to a 3-wire
grounded plug.
• Inspect the washer in the inlet hose to
make sure it is in good condition and installed
in the hose.
• Lubricate the pump impeller by placing several
drops of mineral or vegetable oil on the
impeller at inlet port (1).
• Connect hose (D) to the port and suction hose
to intlet port on pump (C) outlet.
• Attach the drill pump with hoses to the drill.
• Connect the drill motor power cord to a 3-wire
grounded plug.
Ensure drill is not connected
to electrical service as you begin this process.
Ensure drill is not connected
to electrical service as you begin this process.
Keep the inlet hose as short
as possible
The combined height of the
inlet and outlet hose should be no higher than 8
ft. above the water source and/or not more than
25 ft. horizontally from the water source.
To minimize the pump rotating
on the drill, rmly grip the drill pump and hold it
as you start the drill.
To minimize the pump rotating
on the drill, rmly grip the drill pump and hold it
as you start the drill.
Ensure motor oil is drawn into
the drill pump within 15-20 seconds to avoid
damaging the pump. If it does not, check to en-
sure the tube (A) is rmly inserted in the adapter
(B) and that the adapter (B) is rmly installed in
pump (C), ensure the tube is not crimped and
that the tube is fully inserted in the dipstick hole.
NOTE: Motor oil should be removed when at
room temperature.
Ensure water is drawn into the
drill pump within 15-20 seconds to avoid damag-
ing the pump. If it does not, check to ensure the
hose connections are rmly installed to the pump
(C) and that the adapter (B) is rmly installed in
pump (C), ensure none of the hoses are crimped
and that the suction hose is fully inserted in the
water source.
NOTE: Water should be removed when it is at
room temperature.
If water has suspended solids,
a strainer should be installed on hose (D )that is
in the water. A piece of door screen tied to end
of hose that is in the water would help keep any
solids out of the hose.
A B
C
D
D
1
C
12
2
1 C
ASSEMBLY AND MAINTENANCE
5
1
Preparing to pump motor oil using
adapter and tube 2
Preparing to pump clean water using
garden hose connected to pump
Risk of electrical shock, per-
sonal injury or death. Never touch or handle
driven pump with wet hands or when standing on
a wet surface or in water.
Be sure the drill is always
electrically grounded to an acceptable electrical
ground.
NOTE: Keep the suction line as short as possible
and lled with water.
NOTE: Never operate the impeller dry.
Operating it dry for as little as 30 seconds can
ruin the pump. The impeller must be oiled to
reduce friction or wear.
NOTE: Never operate the pump dry for prolonged
periods of time, as this will damage the pump.
NOTE: Use a strainer on the end of the inlet
hose, when pumping liquids with small solids to
extend pump life.
NOTE: Oil becomes thick in cold weather. Oil
must be kept thin for the pump to work properly.
NOTE: Electric drills are not intended to be oper-
ated unattended or continuously. Doing either of
these can cause the pump and drill to fail.
NOTE: Any air leaks in the suction line will pre-
vent the pump from priming.
• Use the unit within the liquid temperature
range of 40°F to 120°F.
• Inspect hoses thoroughly before each use,
making surethat all connections are tight and
that the hoses are all in good condition.
• Be sure that the inlet line (1) is airtight and
submerged in uid. The inlet (1) and dicharge
(2) lines should be free of kinks and other ow
restrictions.
• Wet the impeller located inside the pump with
pumped uid and/or cooking mineral oil
before starting the pump. This inproves the
priming process.
• Start the drill pump. Self-priming should
occur within 30 seconds. The pump will self-
prime up to an 8 ft. vertical lift. Be sure
that the liquid enters the pump within 15 to
20 seconds. If not, refer to the assembly
instructions and also the Troublshooting
section.
• If pump fails to prime, ensure that there are no
air leaks or obstructions in suction line.
• Lubricate the impeller with cooking oil or mineral oil.
• Always ush with clear water after using.
• Keep the suction line as short as possible and prime the line (ll with liquid) when possible before
starting the pump.
• Do not use suction hose that can collapse due to vacuum pressure.
NORMAL USE OF THE PUMP CAUSES WEAR. TO EXTEED PUMP LIFE:
2
IN
OUT
1
TROUBLE SHOOTING
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
The pump will not prime Air is leaking into the inlet hose Replace the washer in the hose
or connection. tting or replace the hose.
The inlet hose is clogged. Clean or replace the hose.
The hose collapsed due to inlet Notch the end of the inlet line
line suction on a at surface. where it meets the at surface, use
suction rated hose
The impeller, body and end cover Replace the pump.
are worn from pumping abrasives.
The impeller blades are missing Replace the pump.
or charred from dry running.
Air leak in at the seal or o-ring. Replace the pump.
The shaft turns but the impeller Replace the pump.
does not turn.
Drill speed is too slow. Increase drill speed
There is a low ow rate. The drill is running too slowly. Increase the drill speed or use
another 1/4” drill or larger.
There is restriction in the inlet Clean or replace the hoses. Check
or discharge hoses. hoses to eliminate any sharp
bends or kinks in the lines. Use
The hose diameter is too small. larger diameter hose of high quality.
Liquid is leaking where The lip seal is damaged. Replace the pump.
the shaft enters the
pump body.
6
LIMITED WARRANTY
This pump is warranted to be free from defects in material and workmanship and to perform within applicable
specications for a period of 90 days. Obligation under this warranty is limited to repairing or replacing any part thereof,
which shall within two years be returned to us with transportation charges prepaid, and proved to be defective.
The above limited warranty takes the place of all other warranties, express or implied and correction of such defects by
replacement or repair shall constitute a fulllment of all obligations under the terms of the warranty, which specically
EXCLUDES any incidental damages caused by or associated with this product or its use. The warranty does not cover
any unit which has been damaged either in transit or by misuse, accident or negligence. No warranty or representative not
contained herein shall be binding.
1899 Cottage Street
Ashland, Ohio 44805
Telephone: 1-844-394-2604

This manual suits for next models

1

Other WaterAce Water Pump manuals

WaterAce RTS5 1/2 HP User manual

WaterAce

WaterAce RTS5 1/2 HP User manual

WaterAce R100U User manual

WaterAce

WaterAce R100U User manual

WaterAce R106 User manual

WaterAce

WaterAce R106 User manual

WaterAce R7PBS User manual

WaterAce

WaterAce R7PBS User manual

WaterAce R25SP-01 User manual

WaterAce

WaterAce R25SP-01 User manual

WaterAce RBSP User manual

WaterAce

WaterAce RBSP User manual

WaterAce R7L User manual

WaterAce

WaterAce R7L User manual

WaterAce R200A User manual

WaterAce

WaterAce R200A User manual

WaterAce R520C-T7-01 User manual

WaterAce

WaterAce R520C-T7-01 User manual

WaterAce RCPH User manual

WaterAce

WaterAce RCPH User manual

WaterAce WA61DUP User manual

WaterAce

WaterAce WA61DUP User manual

WaterAce R7L User manual

WaterAce

WaterAce R7L User manual

WaterAce R520C-T7 User manual

WaterAce

WaterAce R520C-T7 User manual

WaterAce R5PILT User manual

WaterAce

WaterAce R5PILT User manual

WaterAce R4W User manual

WaterAce

WaterAce R4W User manual

WaterAce RSDP User manual

WaterAce

WaterAce RSDP User manual

WaterAce WACS Series User manual

WaterAce

WaterAce WACS Series User manual

WaterAce R6S User manual

WaterAce

WaterAce R6S User manual

WaterAce R3PGI User manual

WaterAce

WaterAce R3PGI User manual

WaterAce WAUP Series User manual

WaterAce

WaterAce WAUP Series User manual

WaterAce R33SU-01 User manual

WaterAce

WaterAce R33SU-01 User manual

WaterAce WABUP User manual

WaterAce

WaterAce WABUP User manual

WaterAce WA50RSWW User manual

WaterAce

WaterAce WA50RSWW User manual

WaterAce R5V User manual

WaterAce

WaterAce R5V User manual

Popular Water Pump manuals by other brands

Pentair Berkeley BVM Series Installation, Operation & Parts Manual

Pentair

Pentair Berkeley BVM Series Installation, Operation & Parts Manual

Elemental Solutions EHP204 manual

Elemental Solutions

Elemental Solutions EHP204 manual

Dutypoint ScubaTANK WX Operation and maintenance manual

Dutypoint

Dutypoint ScubaTANK WX Operation and maintenance manual

Graco Triton 308 Instructions-parts list

Graco

Graco Triton 308 Instructions-parts list

Defort DSP-402N user manual

Defort

Defort DSP-402N user manual

Raider Pro RDP-WP27 user manual

Raider

Raider Pro RDP-WP27 user manual

Grundfos JP Booster PS Series Installation and operating instructions

Grundfos

Grundfos JP Booster PS Series Installation and operating instructions

Ingersoll-Rand ARO PX20P A Series Operator's manual

Ingersoll-Rand

Ingersoll-Rand ARO PX20P A Series Operator's manual

Labtech VP30 user manual

Labtech

Labtech VP30 user manual

RIDGID Kollmann KJ-2200 user manual

RIDGID

RIDGID Kollmann KJ-2200 user manual

DAB CP-G Series Instruction for installation and maintenance

DAB

DAB CP-G Series Instruction for installation and maintenance

Compat Ella Instructions for use

Compat

Compat Ella Instructions for use

Kessel Aqualift F XL Duo Installation and operating instructions

Kessel

Kessel Aqualift F XL Duo Installation and operating instructions

Flux FP 430 Ex S-41/38 FOOD Original attachment

Flux

Flux FP 430 Ex S-41/38 FOOD Original attachment

Tuthill FILL-RITE 700V Series Owners installation, operation, and safety manual

Tuthill

Tuthill FILL-RITE 700V Series Owners installation, operation, and safety manual

Pentair Onga JS Series manual

Pentair

Pentair Onga JS Series manual

SIA SIA-24-L100-CR-V-150113-HIEC manual

SIA

SIA SIA-24-L100-CR-V-150113-HIEC manual

Crane BARNES PRESSURE SYSTEMS omni GRIND plus ULTRA GRIND OGP2022AUE... installation manual

Crane

Crane BARNES PRESSURE SYSTEMS omni GRIND plus ULTRA GRIND OGP2022AUE... installation manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
