Watson-Marlow 501CC, 621CC and 701 ATEX User Manual
PB0448:m-501-621-701atex-en-01 1
1 Declaration of conformity 3
2 Introduction 6
3 Pump description 7
4 Warranty 8
5 Information for returning pumps 9
6 Safety notes 9
7 Pump specification 12
8 Potential pump hazards 13
9 Installation 14
9.1 Do’s and do not’s 15
10 Start-up 17
10.1 Check list for installation in explosive environments 17
11 Troubleshooting 17
12 Maintenance 18
12.1 AC motor maintenance 18
12.2 Gearbox maintenance 18
12.3 Pneumatic (air) motor maintenance 18
12.4 Pumphead maintenance 18
13 ATEX marking 19
13.1 Key 19
14 Replacements 19
15 Patient-connected use—warning 19
16 Disclaimers 20
17 Dimensions 21
17.1 501CC Dimensions 21
17.2 621CC Dimensions 26
17.3 701CC Dimensions 30

2 PB0448:m-501-621-701atex-en-01
18 Materials of construction 34
18.1 Watson-Marlow manufactured parts 34
Original instructions
The original instructions for this manual have been written in English. Other language versions of this
manual are a translation of the original instructions

1 Declaration of conformity
Watson-Marlow Limited
Falmouth
Cornwall
TR11 4RU
England
1. 500 Series, ATEX compliant,configured peristaltic pumps.
2. Manufacturer:
Watson Marlow Ltd
Bickland Water Road
Falmouth
TR11 4RU
UK
3. This declaration of conformity is issued underthe sole responsibility of the manufacturer.
4. 501D (F,V,FX,VX,P variants ATEX closed coupled pumps, configured with 501RL(A, 2A, GA.2GA, CA, 2CA, CGA,
2CGA), 505l(A, XA, GA), 313(DA, BA, XA, XBA, D2A, D2AK, B2A, X2A, XB2A) or 314(DA, BA, XA, XBA, D2A, B2A,
X2A, XB2A) families of ATEX compliant pumpheads.
5. The object of the declaration described above isin conformity with the relevant Union harmonisation legislation:
ATEX Directive 2014/34/EU
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EC
ROHS Directive 2011/65/EU
ATEX Rating:
II 2G Ex h IIB T4 Gb X
This declaration applies to the pump when using the Watson-Marlow tubing stated within the pumphead manual and in
accordance with the operating instructions provided in the manual. The use of any other tubing material in the pump
would invalidate this declaration.
6. Harmonised standards used:
BS EN ISO 80079-36:2016
BS EN ISO 80079-37:2016
7. Notified body,SGS Fimko Oy (CE0598), P.O Box 30 FI-00211, Helsinki, Finland, holds a copy of the technical
reference file “ATEX-WM”, containing full details of the conformity assessment procedure.
Signed for and behalf of:
Watson Marlow Ltd
Falmouth, 31 October 2019
Simon Nicholson, Managing Director, Watson-Marlow Limited
Watson-Marlow Fluid Technology Group Telephone [phone]
A Spirax-Sarco Engineering plc company
EU declaration of conformity
PB0448:m-501-621-701atex-en-01 3

4 PB0448:m-501-621-701atex-en-01
Watson-Marlow Limited
Falmouth
Cornwall
TR11 4RU
England
1. 600 Series, ATEX compliant, configured peristaltic pumps.
2. Manufacturer:
Watson Marlow Ltd
Bickland Water Road
Falmouth
TR11 4RU
UK
3. This declaration of conformity is issued under the sole responsibility of the manufacturer.
4. The following models and versions of the 621D (F, V, FX, VX, P variants) ATEX close-coupled pumps, configured with
620RA, 620REA, 620RE4A families of ATEXcompliant pumpheads
5. The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
ATEX Directive 2014/34/EU
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EC
ROHS Directive 2011/65/EU
ATEX Rating:
II 2G Ex h IIB T4 Gb X
This declaration applies to the pump when using the Watson-Marlow tubing stated within the pumphead manual and in
accordance with the operating instructions provided in the manual. The use of any other tubing material in the pump
would invalidate this declaration.
6. Harmonised standards used:
EN 80079-36:2016
EN 80079-37:2016
7. Notified body, SGS Fimko Oy (CE0598), P.O Box 30 FI-00211, Helsinki, Finland, holds a copy of the technical
reference file “ATEX-WM”, containing full details of the conformity assessment procedure.
Signed for and behalf of:
Watson Marlow Ltd
Falmouth, 31 October 2019
Simon Nicholson, Managing Director, Watson-Marlow Limited
Watson-Marlow Fluid Technology Group Telephone [phone]
A Spirax-Sarco Engineering plc company
EU declaration of conformity

Watson-Marlow Limited
Falmouth
Cornwall
TR11 4RU
England
1. 700 Series, ATEX compliant,configured peristaltic pumps.
2. Manufacturer:
Watson Marlow Ltd
Bickland Water Road
Falmouth
TR11 4RU
UK
3. This declaration of conformity is issued underthe sole responsibility of the manufacturer.
4. The following models and versions of the 701D (B, FB,VB & PB variant), configured with 701RA, 701REA, 701RXA,
701REXA or 701RGA families of ATEX complaint pumpheads.
5. The object of the declaration described above isin conformity with the relevant Union harmonisation legislation:
ATEX Directive 2014/34/EU
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EC
ROHS Directive 2011/65/EU
ATEX Rating:
II 2G Ex h IIB T4 Gb X
This declaration applies to the pump when using the Watson-Marlow tubing stated within the pumphead manual and in
accordance with the operating instructions provided in the manual. The use of any other tubing material in the pump
would invalidate this declaration.
6. Harmonised standards used:
EN 80079-36:2016
EN 80079-37:2016
7. Notified body, SGS Fimko Oy (CE0598), P.O Box 30 FI-00211, Helsinki, Finland, holds a copy of the technical
reference file “ATEX-WM”, containing full details of the conformity assessment procedure.
Signed for and behalf of:
Watson Marlow Ltd
Falmouth, 31 October 2019
Simon Nicholson, Managing Director, Watson-Marlow Limited
Watson-Marlow Fluid Technology Group Telephone [phone]
A Spirax-Sarco Engineering plc company
EU declaration of conformity
PB0448:m-501-621-701atex-en-01 5

6 PB0448:m-501-621-701atex-en-01
2 Introduction
Directive 2014/34/EU, commonly known as the ATEX directive, carries obligations to the person who
places equipment on the market, in the EU territory, for use in potentially explosive environments.
All of Watson-Marlow’s ATEX pumps have been rated as II 2G Ex h IIB T4 Gb X under the definitions of
2014/34/EU:
lEquipment group II
lEquipment category 2
lEnvironment G
lMechanical protection concepts EX h
lGas group IIB
lTemperature class T4
lEquipment protection level Gb
lSpecial operating restrictions X (see pumphead manual)
"Equipment category 2 comprises equipment designed to be capable of functioning in conformity with
the operational parameters established by the manufacturer and of ensuring a high level of protection.
Equipment in this category is intended for use in areas in which explosive atmospheres caused by gases,
vapours, mists or air/dust mixtures are likely to occur occasionally. The means of protection relating to
equipment in this category ensure the requisite level of protection, even in the event of frequently
occurring disturbances or equipment faults which normally have to be taken into account."
Watson-Marlow pumps must not be used in the underground parts of mines, and in surface
installations of such mines, likely to become endangered by firedamp and/or combustible
dust.
As stated in the Directive, where two or more items of ATEX equipment are combined, the complete
assembly shall carry the same rating as the lowest ranking individual piece of equipment.
All Watson-Marlow ATEX pumps covered by this manual are intended for use in gas based environments
only.
If you are unsure about the meaning of this ATEXrating see section 13 "ATEX marking" on page19 or
contact your Watson-Marlow representative for advice. Watson-Marlow representatives can advise which
rating and approvals products carry, but cannot evaluate nor recommend which product may be
suitable for use in an end users hazardous installation. Only the end user or their qualified representative
can confirm the ATEX rating of the equipment meets the requirements of their installation.
DANGER! - EXPLOSIONHAZARD
Incorrectly selected ATEX equipment can cause fire or explosion.

3 Pump description
ATEX Industrial Close Coupled Pump units incorporating standard ATEX motors and Watson-Marlow
ATEX pumpheads. Single pumphead versions available as standard with a selection of fixed output
speeds.
For customer specific applications, further options can be configured such as drive speed, pumphead or
drive orientations, and coatings or finishes.
Alternative drive options may also be requested such as pneumatic motors, duplex pumpheads and
mechanical variators. For more information please contact your local Watson-Marlow representative.
PB0448:m-501-621-701atex-en-01 7

8 PB0448:m-501-621-701atex-en-01
4 Warranty
Watson-Marlow Ltd ("Watson-Marlow") warrants this product to be free from defects in materials and workmanship for
two years (one year for air motors) from the date of shipment, under normal use and service.
Watson-Marlow's sole responsibility and the customer's exclusive remedy for any claim arising out of the purchase of
any product from Watson-Marlow is, at Watson-Marlow's option: repair, replacement or credit, where applicable.
Unless otherwise agreed in writing, the foregoing warranty is limited to the country in which the product is sold.
No employee, agent or representative of Watson-Marlow has the authority to bind Watson- Marlow to any warranty
other than the foregoing unless in writing and signed by a director of Watson-Marlow. Watson- Marlow makes no
warranty of the fitness of its products for a particular purpose.
In no event:
i. shall the cost of the customer's exclusive remedy exceed the purchase price of the product;
ii. shall Watson-Marlow be liable for any special, indirect, incidental, consequential, or exemplary damages,
however arising, even if Watson-Marlow has been advised of the possibility of such damages.
Watson-Marlow shall not be liable for any loss, damage, or expense directly or indirectly related to or arising out of the
use of its products, including damage or injury caused to other products, machinery, buildings, or property. Watson-
Marlow shall not be liable for consequential damages, including without limitation, lost profits, loss of time,
inconvenience, loss of product pumped, and loss of production.
This warranty does not obligate Watson-Marlow to bear any costs of removal, installation, transportation, or other
charges which may arise in connection with a warranty claim.
Watson-Marlow shall not be responsible for shipping damage of returned items.
Conditions
oProducts must be returned by pre-arrangement to Watson-Marlow, or a Watson-Marlow approved service centre.
oAll repairs or modifications must have been made by Watson-Marlow Ltd, or a Watson- Marlow approved service
centre or with the express permission in writing of Watson-Marlow, signed by a manager or director of Watson-
Marlow.
oAny remote control or system connections must be made in accordance to Watson-Marlow recommendations.
oAll PROFIBUS systems must be installed or certified by a PROFIBUS approved installation engineer.
Exceptions
lConsumable items including tubing and pumping elements are excluded.
lPumphead rollers are excluded.
lRepairs or service necessitated by normal wear and tear or by lack of reasonable and proper maintenance are
excluded.
lProducts which, in the judgement of Watson- Marlow, have been abused, misused, or subject to malicious or
accidental damage or neglect are excluded.
lFailure caused by electrical surge is excluded.
lFailure caused by incorrect or sub-standard system wiring is excluded.
lDamage by chemical attack is excluded.
lAncillaries such as leak detectors are excluded.
lFailure caused by UV light or direct sunlight.
lAny attempt to disassemble a Watson-Marlow product will invalidate the product warranty.
Watson-Marlow reserves the right to amend these terms and conditions at any time.

5 Information for returning pumps
Before returning products, they must be thoroughly cleaned/decontaminated. The declaration
confirming this should be completed and returned to us in advance of the item being shipped.
You are required to complete and return a decontamination declaration stating all fluids that have been
in contact with the equipment being returned to us.
On receipt of the declaration, we will issue a Returns Authorisation Number. We reserve the right to
quarantine or refuse any equipment that is not displaying a Returns Authorisation Number.
Please complete a separate decontamination declaration for each product and use the correct form that
denotes the location you wish to return the equipment to.
A copy of the appropriate decontamination declaration can be downloaded from the Watson-Marlow
website at www.wmftg.com/decon
If you have any queries then please contact your local Watson- Marlow representative for further
assistance at www.wmftg.com/contact.
6 Safety notes
Refer to pumphead safety manual for safe operation of the pumphead.
313 ATEX pumpheads PB0353
501RL ATEXpumpheads PB0346
505 ATEX pumpheads PB0379
620 ATEX pumpheads PB0347
701 ATEX pumpheads PB0348
This safety information should be used in conjunction with the rest of this operating manual.
In the interests of safety, this pump and pumphead should only be used by competent, suitably trained
personnel after they have read and understood the manual and considered any hazard involved. If the
pump is used in a manner not specified by Watson-Marlow Ltd, the protection provided by the pump
may be impaired. Any person who is involved in the installation or maintenance of this equipment
should be fully competent to carry out the work. In the UK this person should also be familiar with the
Health and Safety at Work Act 1974.
This symbol, used on the pump and in the manual, means: Caution,
refer to accompanying documents.
This symbol, used on the pump and in the manual, means: Do not
allow fingers to contact moving parts.
PB0448:m-501-621-701atex-en-01 9

10 PB0448:m-501-621-701atex-en-01
This symbol, used on the pump and in the manual, means: Caution,
hot surface.
This symbol, used on the pump and in the manual, means: Caution,
risk of electric shock.
This symbol, used on the pump and in the manual, means: Personal
Protective Equipment (PPE) must be worn.
This symbol, used on the pump and in the manual, means: Recycle
this product under the terms of the EU Waste Electrical and Electronic
Equipment (WEEE) Directive.
Fundamental work with regard to lifting, transportation, installation,
starting-up, maintenance and repair should be performed by qualified
personnel only. The unit must be isolated from mains power while
work is being carried out. The motor must be secured against
accidental start-up.
Some pumps weigh more than 18kg (the exact weight depends on the
model and pumphead - see on the pump). Lifting should be performed
according to standard Health and Safety guidelines.
This pump must be used only for its intended purpose.
The pump must be accessible at all times to facilitate operation and maintenance. Access points must not
be obstructed or blocked. Do not fit any devices to the drive unit other than those tested and approved
by Watson-Marlow. Doing so could lead to injury to persons or damage to property for which no liability
can be accepted.
If hazardous fluids are to be pumped, safety procedures specific to
the particular fluid and application must be put in place to protect
against injury to persons.

Ensure the chemicals to be pumped are compatible with the
pumphead, lubricant (where applicable), tubing, pipework and
fittings to be used with the pump. Please refer to the chemical
compatibility guide which can be found at: www.wmftg.com/chemical.
If you need to use the pump with any other chemical please contact
Watson-Marlow to confirm compatibility.
Explosion hazard. Failure to comply may cause severe or even fatal
injuries.
All work, e.g. transportation, storage, installation, connection,
commissioning, servicing and maintenance must be performed in a
non-explosive atmosphere.
Always check to ensure that an ATEXpump assembly is suitably rated
for the hazardous zone area in which it is to be used, including ATEX,
Ex and any other hazardous area legislation for the country in which it
is being installed. Exd motors should only be installed by Exd qualified
personnel.
Primary operator protection from rotating parts of the pump is
provided by the pumphead guard. Note that pumphead guards differ,
depending on the type of pumphead.
There are moving parts inside the pumphead. Before opening the
pumphead guard, ensure that the following safety directions are
followed:
1. Ensure that any motor drive connected to the pumphead is
isolated from any electrical or compressed air supply.
2. Ensure that there is no pressure in the pipeline
3. If a tube failure has occurred, ensure that any fluid in the
pumphead has been allowed to drain to a suitable vessel,
container or drain
4. Ensure the pumphead is isolated from the fluid supply
5. Ensure that appropriate Personal Protective Equipment (PPE) is
worn
PB0448:m-501-621-701atex-en-01 11

12 PB0448:m-501-621-701atex-en-01
7 Pump specification
ATEX rating II 2G Ex h IIB T4 Gb X
Operating temperature 5C to 40C (41F to 104F)
Storage temperature -40C to 70C (-40F to 158F)
Humidity (non-condensing) 35% to 80%
Supply voltage See motor specification label
Power consumption See motor specification label
IP See motor specification label
dB rating < 70dB (A) @ 1m
dB rating (700 series) < 85dB (A) @ 1m
Control ratio See pump specification label
Note: Where specifications are listed in more than one operating manual, the lowest specification must
be adhered to.
For further information please contact your Watson-Marlow representative.

8 Potential pump hazards
As part of the requirements of ATEX Directive 2014/34/EU all potential hazards, including expected
malfunctions, have been identified and subjected to a risk assessment. In order to prevent these ignition
sources becoming hazardous, a number of changes have been implemented. In addition to
engineering modifications, the changes include comments in these instructions in order to specify
correct usage in hazardous locations.
Recognised ignition sources of the pumphead
Surface temperatures of rollers and spindles
Tube burst and subsequent spilling of pumped fluid
Mechanical failure of rotor hub
Exothermic chemical reaction
Electrostatic discharge
Bearing failure
Spring failure
For the motor and gearbox please refer to the manufacturer’s instructions as supplied.
PB0448:m-501-621-701atex-en-01 13

14 PB0448:m-501-621-701atex-en-01
9 Installation
Preliminary checks
DANGER! - EXPLOSIONHAZARD
Failure to inspect the pumphead unit for damage or check the ATEX
labelling data may cause a fire or explosion.
Check the label on the pump to ensure that the pump type and the ATEX labelling conform to the
planning of the plant or machine.
Check that all components are present. Inspect components for damage in transit. If anything is missing
or damaged, contact your Watson-Marlow representative immediately.
Mechanical installation
Fundamental work with regard to lifting, transportation, installation,
starting-up, maintenance and repair should be performed by qualified
personnel only. The unit must be isolated from mains power while
work is being carried out. The motor must be secured against
accidental start-up.
Some pumps weigh more than 18kg (the exact weight depends on the
model and pumphead - see on the pump). Lifting should be performed
according to standard Health and Safety guidelines.
Explosion hazard. Failure to comply may cause severe or even fatal
injuries.
All work, e.g. transportation, storage, installation, connection,
commissioning, servicing and maintenance must be performed in a
non-explosive atmosphere.
Site the pump on a flat, horizontal, vibration-proof surface allowing a free flow of air around it. Ensure
there is 0.5m of straight tubing before the pumphead inlet and after the pumphead outlets.
If the pump is not supplied attached to a baseplate then the unit must be bolted down to a suitable
substrate via the bolting holes identified in the motor and gearbox manuals.
Refer to the manufacturers instructions for the motor and gearbox for further installation instructions.

All Watson-Marlow ATEX rated pumpheads include provision for the prevention and dissipation of
electrostatic charge. In order to dissipate electrostatic charge effectively there must be sufficient electrical
contact between the pumphead and the suitably earthed drive.
It is imperative that the 500, 600 and 700 series ATEX pumps are earthed. The pumphead
guard, track, gearbox and motor and baseplate (where applicable) already have earth
straps installed. The user must ensure that these earth straps are connected to a suitable
earth point on installation.
It is possible to check the effectiveness of any earth connection by measuring its electrical resistance. To
ensure reliable dissipation of static, the maximum resistance from the earth point
identified above to earth should not exceed 1 MOhm.
Peristaltic tubing is insulating and so its use should be limited to the length adjacent to the pumphead.
Earthed, conductive pipework should be used elsewhere in the system.
AC motor/Air motor
Please refer to the manufacturer’s instructions as supplied with the ATEX certified motor.
9.1 Do’s and do not’s
Do not build a pump into a tight location without adequate airflow around the pump.
Do keep delivery and suction tubes as short and direct as possible and follow the straightest route. Use
bends of large radius: at least four times the tubing diameter. Ensure that connecting pipework and
fittings are suitably rated to handle the predicted pipeline pressure. Avoid pipe reducers and lengths of
smaller bore tubing than the pumphead section, particularly in pipelines on the suction side. Any valves
in the pipeline (not usually needed) must not restrict the flow. Any valves in the flow line must be open
when the pump is running.
Do use suction and delivery pipes equal to or larger than the bore of the tube in the pumphead. When
pumping viscous fluids use pipe runs with a bore several times larger than the pump tube.
Do ensure that your system fluid supply and discharge pipework is suitable for the hazardous
environment in which the pump is operating and doesn't allow for the accumulation of electrostatic
charge.
Do site the pump at or just below the level of the fluid to be pumped if possible. This will ensure flooded
suction and maximum pumping efficiency.
Do keep the pumphead track and all moving parts clean and free from contamination and debris.
Do run at slow speed when pumping viscous fluids. Flooded suction will enhance pumping
performance in all cases, particularly for materials of a viscous nature.
Do limit peristaltic tubing to the length adjacent to the pumphead because peristaltic tubing is insulating.
Electrostatic testing has been used to determine which Watson- Marlow tubing is suitable for use in
hazardous environments. Refer to pumphead manual for more information. Earthed, conductive
pipework should be used elsewhere in the system.
When using Marprene or Bioprene continuous tubing, do re-tension the tube after the first 30
minutes of running.
PB0448:m-501-621-701atex-en-01 15

16 PB0448:m-501-621-701atex-en-01
Tube selection: The chemical compatibility lists published in Watson-Marlow publications are guides. If
in doubt about the compatibility of a tube material and the duty fluid, request a Watson-Marlow tube
sample card for immersion trials.

10 Start-up
If the unit has been supplied integrated with a air filter, lubricator and regulator then please refer to the
manufacturers instructions as supplied, in conjunction with the recommendations in the air motor
operating manual.
Please refer to the pumphead instructions to ensure correct loading and operation of the pumphead.
Prior to start-up ensure that the tubing material used is listed in the "Special conditions of use for safe
operation - Tube materials suitable for use with this equipment" section of the pumphead manual.
The unit will self prime, minimise the time to prime the pump as dry running will reduce the life of the
tube.
10.1 Check list for installation in explosive environments
Complete the following check list prior to starting installation in an explosive environment. All actions
must be completed in accordance with Directive 2014/34/EU.
lCheck ATEX pump and motor labelling and configuration. Ensure that they conform to actual
installation (see section 13 "ATEX marking" on page19).
lCheck the ambient temperature of the site and the ability to maintain proper ambient temperature.
(see section 7 "Pump specification" on page12).
lCheck the site to make sure that the motor will be adequately ventilated and that there is no external
heat input (e.g. couplings). The cooling air may not exceed 104ºF/40ºC.
lCheck that the pump is not damaged.
lCheck the installation has been carried out correctly in accordance with pumphead, gearbox and
motor manufacturers instructions.
11 Troubleshooting
Should the pump fail to operate, make the following checks to determine whether or not servicing is
required.
lRefer to the motor manufacturer's manual to ensure correct connection of the electrical or air
supply.
lCheck that the pump is not stalled by incorrect fitting of tubing.
Any deviation from normal operating conditions (increased power
consumption, temperature, vibrations, noise) or warning signals by
monitoring equipment suggest malfunction. Inform the responsible
maintenance personnel at once to prevent the trouble from worsening.
If in doubt disconnect the pump immediately.
PB0448:m-501-621-701atex-en-01 17

18 PB0448:m-501-621-701atex-en-01
12 Maintenance
The pump should be cleaned regularly to avoid the accumulation of dust, this will prevent build up of
electrostatic charge due to the presence of dust. This product is not certified for use in ATEX dust
environments.
Visually inspect the earth straps monthly to ensure mechanical integrity. Electrical conductivity of the
earth system must be verified six monthly.
On the 701 series ATEX products, the shaft coupling should be examined every six months for signs of
wear to the spider. If the spider is worn then it should be replaced. Please refer to the shaft coupling
manufacturers instructions.
Monthly visual inspection must be undertaken to determine if the product has been damaged due to
(but not limited to) adverse operating conditions caused by worn components, loose bolts or
environmental conditions.
12.1 AC motor maintenance
Please refer to the manufacturer’s instructions as supplied with the ATEX certified motor.
12.2 Gearbox maintenance
Please refer to the manufacturer’s instructions as supplied with the ATEX gearbox.
12.3 Pneumatic (air) motor maintenance
Please refer to the manufacturer’s instructions as supplied with the ATEX certified pneumatic motor.
12.4 Pumphead maintenance
Please refer to the ATEX pumphead manual as supplied seperately for the relevant pumphead.

13 ATEX marking
The pumps have been marked with the following labels:
Serial No: 123456-987654
050.8652.L20
501Df/Rl2A Atex Eexd
223rpm IP55 0.18kW Ptcs
230/400V 50/60Hz 3Ph
Issue No.: 6
13.1 Key
II Equipment Group II for above ground areas (surface)
2G Equipment Category 2G (Gas) - Zone 1
Ex h Ignition protection labelling for mechanical devices
IIB Group IIB – typical gas: Ethylene
T4 Temperature classification (Gas) ≤ 135°C
Gb Group II (Gas); protection Level: High
X Special conditions of use for safe operation - See pumphead manual
14 Replacements
Spares and replacements should be ordered through Watson-Marlow pumps or through an official
representative. Only Watson-Marlow spares and replacements should be used in order to guarantee
continued compliance with the ATEX directive.
Watson- Marlow’s policy is to provide spare parts for all products for a minimum of 7 years from
discontinuation. The ability to implement this policy is not entirely within Watson-Marlow’s control and
cannot be guaranteed, but every effort will be made to honour this policy.
Please contact your local Watson-Marlow representative for assistance.
15 Patient-connected use—warning
Warning, These products are not designed for use in, and should not be used for patient connected
applications.
PB0448:m-501-621-701atex-en-01 19

20 PB0448:m-501-621-701atex-en-01
16 Disclaimers
The information contained in this document is believed to be correct but Watson-Marlow Limited accepts
no liability for any errors it contains and reserves the right to alter specifications without notice. It is the
users responsibility to ensure product suitability for use within their application. Watson- Marlow,
LoadSure, Qdos, ReNu, LaserTraceability, Pumpsil, PureWeld XL, Bioprene, Marprene are registered
trademarks of Watson-Marlow Limited. Tri-Clamp is a registered trademark of Alfa Laval Corporate AB.
GORE and STA-PURE are registered trademarks of W.L. Gore and Associates.
