Watts AERCO ADMS Series User manual

User Guide & Instruction Manual
ADMS
Smart Water Tempering System
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use information can result
in death, serious personal injury, property damage, or damage to the
equipment. Visit aerco.com with any questions.
Keep this Manual for future reference.
WARNING
!

Technical Support
(Mon-Fri, 8am-5pm EST)
1-800-526-0288
aerco.com

LIMITED WARRANTY / LIMITATION OF REMEDY:
What is covered? AERCO warrants to the original purchaser only, that the product it manufactured
when used as intended and instructed, is free from defects in materials or workmanship for five year
warranty from date of shipment to the original purchaser.
What is not covered? This Limited Warranty does not cover or is voided by (a) any product,
components or parts not manufactured by AERCO, (b) faulty or improper installation or unsuitable
installation environment, (c) failure to follow instructions or warnings, (d) problems caused by
unauthorized attachments, modification, repairs or parts, (e) negligence or vandalism, (f) problems due to
foreign material, adverse or improper water conditions, chemicals, contamination, improper pH, water
treatment activities or products, mineral deposits, or decomposition by galvanic action, (g) shipping
defects or damage, (h) normal wear and tear, (i) any abuse, misuse, unintended use, failure to maintain
or inspect, (j) any circumstances over which AERCO has no control.
IN NO EVENT SHALL AERCO BE LIABLE TO BUYER OR THIRD PARTIES FOR ANY GENERAL,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED
TO, PROPERTY DAMAGE, PERSONAL INJURIES, LOST PROFITS, LOSS OF SAVINGS OR
REVENUE, LOSS OF THE USE OF THE PRODUCT OR ANY ASSOCIATED PRODUCTS, COST OF
REPAIR, COST OF ANY SUBSTITUTE PRODUCTS OR SERVICES, DELAY DAMAGES, LABOR
CHARGES, FINES/ PENALTIES, ECONOMIC OR NON-ECONOMIC LOSSES, ARISING DIRECTLY
OR INDIRECTLY FROM THE SALE/PURCHASE, OWNERSHIP, INSTALLATION, OR USE OF
THE PRODUCT, WHETHER BASED ON BREACH OF WARRANTY, BREACH OF CONTRACT,
NEGLIGENCE, STRICT LIABILITY, OR ANY OTHER LEGAL THEORY.
What will AERCO do? THE SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY
OR ANY IMPLIED WARRANTIES, is: Within a reasonable period of time after receiving a timely
and bona fide claim, AERCO will at its sole option (a) repair the product, or (b) replace the product (or
component) with a same or similar product. A replaced product is warranted for 90 days from the date of
return shipment, or for the balance of the original Limited Warranty period, whichever is longer. IN NO
EVENT SHALL AERCO LIABILITY EXCEED AN AMOUNT EQUAL TO THE SALES PRICE OF THE
PRODUCT.
To obtain warranty service: Contact AERCO at 1-800-526-0288 with description of the problem and
proof of the date of original purchase. Cost of shipping and insuring returned product must be paid by
purchaser. AERCO is not responsible for any loss of damage to the product incurred during shipping.
Disclaimer of other warranties: THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
DISCLAIMED.

COMPUTER SYSTEM, NETWORK AND DATA DISCLAIMER:
ADMS receives stores and displays data concerning your water distribution system, performs functions
based upon owner/user data input and selections, and can be remotely programmed and utilized with
specified and compatible building automation systems.
AS SUCH, AERCO MAKES NO EXPRESS OF IMPLIED WARRANTY, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING COMPATIBILITY WITH
OTHER TECHNOLOGIES, HARDWARE, SOFTWARE, NETWORK OR SYSTEMS, THE ACCURACY OR
COMPLETENESS OF ANY DATA, THE SECURITY OF ANY COMPUTER NETWORK OR SYSTEM, OR ANY
RESULTS TO BE ACHIEVED FROM THE ADMS OR ANY COMPUTER NETWORK OR SYSTEM. AERCO
HAS NO RESPONSIBILITY OR LIABILITY ARISING FROM: THE UNAUTHORIZED USE OF THE ADMS;
THE CONNECTION TO OR INTEGRATION WITH A USER'S OR ANY OTHER COMPUTER NETWORK
OR SYSTEM; ANY HARDWARE OR SOFTWARE NOT SUPPLIED BY AERCO; ANY DATA THAT IS
INCORRECT, CORRUPT OR CORRUPTED, LOST, STOLEN OR PIRATED; ANY FAILURE TO SECURE THE
ADMS OR THE USER'S OR ANY OTHER COMPUTER NETWORK OR SYSTEM; ANY "CRASHING" OR
TEMPORARY/PERMANENT INOPERABILITY OF ADMS OR ANY COMPUTER NETWORK OR SYSTEM;
ANY UNAUTHORIZED USES, USERS, OR INTRUDERS OF THE ADMS OR ANY COMPUTER NETWORK
OR SYSTEM; ANY INTENTIONAL OR UNINTENTIONAL VIRUSES OR CORRUPTION OF ANY KIND OF THE
ADMS OR ANY COMPUTER NETWORK OR SYSTEM; OR ANY THIRD PARTY ACTION SUCH AS HACKING
OR UNAUTHORIZED ACCESS OR USE OF THE ADMS OR ANY COMPUTER NETWORK OR SYSTEM.

Table of Contents
Introduction .............................................2
Safety Information ........................................3
Understanding Safety Information ...........................3
Radio Frequency Warnings & Hazards ........................ 3
ADMS Description & Specifications .........................4
Description of Controls & Functions .........................9
Set up and Programming ................................. 20
Sanitization ............................................31
AERCO ADMS BAS Integration Manual ......................37
Troubleshooting ......................................... 52
Scheduled Testing, Inspection and Maintenance ...............63
OMM-0126-0A Page 1 of 71

Attention Owners and Users
Thank you for purchasing the AERCO ADMS. This equipment will provide safe and productive opera-
tion as long as it is installed, set up, used, and serviced in accordance with the instructions in this
Manual and is properly maintained. Owners and users of this equipment have the responsibility
to make certain that this equipment is used properly and safely. To avoid the possibility of death,
serious personal injury, property damage, or damage to the equipment, owners should not permit
anyone to touch this equipment unless they are over 18 years of age, are adequately trained and
supervised, and have read and understand this Manual. Owners should ensure that no unauthorized
personnel come in contact with this equipment.
READ THIS MANUAL carefully,
learn how to install, set up, use,
service and maintain this equip-
ment correctly, and strictly follow
all safety information and instruc-
tions contained in this Manual and on the
equipment, as well as any requirements of
local, state, and federal law. Failure to do so
could result in death, serious personal injury,
property damage, or damage to the equipment.
This Manual should be considered a perma-
nent part of the ADMS and be kept available
for easy reference by any user.
If this equipment, or any of its parts, becomes
damaged or needs repair, stop using the equip-
ment and contact an experienced service indi-
vidual immediately. If the product labels or this
Manual are misplaced, damaged or illegible,
or if you require additional copies, please visit
aerco.com.
Please remember that this Manual and the
product labels do not replace the need to be
alert, to properly train and supervise users, and
to use common sense when using this equip-
ment.
If you are ever uncertain about a particular
task or the proper method of operating this
equipment, ask your supervisor, consult this
Manual, visit aerco.com, or contact your local
sales representative.
Product Identification
Please record your product's identification and purchase information which will help in the event you
have questions or need any service.
Model: Date of purchase:
Seller name / address:
OMM-0126-0A Page 2 of 71

Understanding Safety Information
This safety-alert symbol is
shown alone or used with a sig-
nal word (DANGER, WARNING,
or CAUTION), a pictorial and/
or a safety message to identify
hazards and alert you to the
potential for death or serious
personal injury.
Identifies hazards which, if not
avoided, will result in death or
serious injury.
Identifies hazards which, if not
avoided, could result in death or
serious injury.
Identifies hazards which, if not
avoided, could result in minor or
moderate injury.
Identifies practices, actions, or
failure to act which could result
in property damage or damage
to the equipment.
• Read the Manual and all product
labels and follow all safety and other
information.
• Learn how to properly and safely use
the equipment BEFORE installing,
set up, using, or servicing.
• Keep the Manual available for easy
access and future reference.
• Replace missing, damaged, or illegible
Manual and product labels.
• Replacement Manuals available at
aerco.com
This pictorial alerts you to the
need to read the manual.
This pictorial alerts you to
scalding, burn and hot water
hazards.
This pictorial alerts you to burn
and hot surfaces hazards.
This pictorial alerts you to elec-
tricity, electrocution, and shock
hazards.
This pictorial alerts you to the
need to perform appropriate
Lock Out/ Tag Out procedures.
WARNING
!
CAUTION
!
NOTICE
DANGER
!
!
WARNING
!
TO AVOID DEATH,
SERIOUS PERSONAL
INJURY, PROPERTY
DAMAGE, OR DAMAGE
TO THE EQUIPMENT:
Reading & Understanding the Manual
Important Safety Information
OMM-0126-0A Page 3 of 71

The ADMS is electronic water mixing system providing user-directed control and monitoring of water
distribution systems. ADMS includes an electronic Control Module featuring a color touchscreen digital
display to select desired outlet water temperature, an electronically actuated valve that mixes hot water
with cold water, temperature sensors (plus a quick response temperature sensor), pressure sensors,
check valves, and a recirculation pump to maintain the recirculation loop temperature (reducing wait
time for tempered water to reach point-of-use fixtures, saving water and energy). The ADMS monitors
hot supply inlet temperature, hot supply pressure, mixed outlet temperature, mixed outlet pressure,
mixed outlet flow rate (optional), return temperature, and return pressure, to help maintain the desired
outlet water temperature. ADMS also features a user programmable high temperature Sanitization mode
to help limit water-borne bacteria as part of a user-directed and controlled thermal eradication protocol.
The ADMS Control Module supports building automation systems (BAS) communication with BACnet®
IP, BACnet®MSTP, and Modbus®protocols, allowing remote programming and data viewing.
Installation and adjustment of the ADMS are the responsibility of the owner and installer and must be
done by qualified personnel in accordance with the manufacturer’s instructions, and complying with all
governmental requirements, building and construction codes and standards. It is recommended to install
ADMS as part of an ASSE compliant water distribution system, including mixing valves and/or tempera-
ture limiting devices at all point-of-use fixtures (faucets, sinks, tubs, showers, etc.) that are approved
to ASSE 1016, 1069, 1070 and 1071. The owner and user of the ADMS is responsible for selecting and
installing the product in an appropriate water distribution system, proper sizing, maintaining proper
water quality/condition, and deciding what temperature is safe and appropriate for the water distribution
users and facility.
ADMS Description and Specifications
OMM-0126-0A Page 4 of 71

ADMS Description and Specifications
The ADMS components are
shown below:
Dimensions
18.90
[480.1]
31.28
[794.5]
50.00
[1270.0]
56.32
[1430.5]
3.08
[78.2]
3.24
[82.2]
7.47
[189.6]
10.65
[270.5]
8.25
[209.6]
4.91
[124.8]
LFIS150 IS SHEET LINE ART
56.00
[1422.4]
61.73
[1568.0]
3.25
[82.6]
2.48
[63.0]
19.93 [506.2]
33.28 [845.3]
8.23
[209.0]
11.80
[299.8]
8.13
[206.4]
5.12
[130.0]
LFIS200 IS SHEET LINE ART
ADMS150 ADMS200
Dimensions are shown ±1/2''
Dimensions in parentheses are in mm
P1
T1
T4
T2
P2
T3P4 P3
FT1
Control Unit
Mixed Outlet
Temp & Pressure
Sensors
Hot Temp
& Pressure
Sensors
Electronically
Actuated Valve
Recirc Temp &
Pressure Sensors
Cold Temp &
Pressure Sensors
Recirculation
Pump
Hot
Water
Inlet
Cold
Water
Inlet
Return
Mixed Water
Outlet
To
Water
Heater
OMM-0126-0A Page 5 of 71

Flow Capacity at 50-50 mixed ratio
Pressure Drop Across Valve
Model Min.
System
Draw*
CV
5psi
(34 kPa)
10psi
(69 kPa)
20psi
(138 kPa)
30psi
(207 kPa)
45psi
(310 kPa)
50psi
(345 kPa)
ADMS150 0.50 26.88 60 gpm
227 lpm
85 gpm
322 lpm
120 gpm
454 lpm
147 gpm
556 lpm
180gpm
681 lpm
190 gpm
719 lpm
ADMS200 0.50 42.70 96 gpm
363 lpm
135 gpm
511 lpm
191 gpm
723 lpm
234 gpm
886 lpm
286 gpm
1083 lpm
302 gpm
1143 lpm
ADMS150D 0.50 53.57 120 gpm
454 lpm
170 gpm
644 lpm
240 gpm
908 lpm
294 gpm
1113 lpm
360 gpm
1363 lpm
380 gpm
1439 lpm
ADMS200D 0.50 85.27 192 gpm
727 lpm
270 gpm
1022 lpm
382 gpm
1446 lpm
468 gpm
1772 lpm
572 gpm
2165 lpm
604 gpm
2286 lpm
ADMS200T 0.50 127.90 288 gpm
1090 lmp
405 gpm
1533 lpm
573 gpm
2169 lpm
702 gpm
2657 lpm
858 gpm
3248 lpm
906 gpm
3430 lpm
ADMS Description and Specifications
Specifications
Maximum Operating Pressure ...................................................... 200psi (1379 kPa)
Maximum Hot Water Temperature ........................................................ 200°F (93°C)
Minimum Hot Water Supply Temp.** ........................... 2°F (1°C) Above Set Point
Hot Water Inlet Temperature Range .................................... 120 – 180°F (49-82°C)
Cold Water Inlet Temperature Range ......................................... 39 – 80°F (4-27°C)
Minimum Flow*** ........................................................................... 0.5 gpm (1.89 lpm)
Outlet Water Temperature Adjustment Range**** ............. 80 – 180°F (27-82°C)
Listing/Compliance .............................. ASSE1017®, cUPC®, NSF®, CSA 24/UL873
* The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight.
** With Equal Pressure
*** Minimum flow when ADMS is installed at or near hot water source recirculating tempered water with a
properly sized continuously operating recirculating pump.
**** Low limit cannot be less than the cold water temperature. For best operation, hot water should be at
least 5°F (3°C) above desired set point.
Technical Specifications
Input Power....................................115 V ±10%, 60 Hz, 30 VA, 1180 VA fully loaded
Pump relay ............................................ 115/230 V: 10/8 FLA, 50/48 LRA Motor Load
Alert relay:...................................................30 V (ac/dc) max. 2 A, resistive, Class 2
5 V capacity:..............................................10 mA maximum each, resistive, Class 2
20 V capacity:............................................20 mA maximum each, resistive, Class 2
Actuator load:...........................................................................................................20 VA
Meets Class B: ...........................................................................ICES and FCC Part 15
Capacity
*With a properly sized pump
^ Listed without re-circulation line & pump
!User is responsible for determining safe and appropriate
temperatures and pressures for system users, guests and facility.
OMM-0126-0A Page 6 of 71

Installation
Failure to follow all installation requirements risks possible death, personal injury,
property damage, and failure of the ADMS to perform as intended.
• Installation of ADMS MUST be performed by qualified technicians, including licensed electricians
and plumbers, following all manufacturer’s instructions, complying with all local, state, federal and
other governmental requirements, and with all building and construction codes and standards.
• Use ONLY with a potable water distribution system free of debris, foreign materials, corrosive
chemicals or substances, and other adverse conditions.
• ADMS is recommended for use as part of an ASSE compliant water distribution system, including
mixing valves and/or temperature limiting devices at all point-of-use fixtures (faucets, sinks, tubs,
showers, etc.).
• ADMS MUST be installed in a dry area not susceptible to freezing.
• Keep work area clean, well-lighted, free of clutter and distractions, and accessible only by
authorized personnel and workers.
• ADMS Control Module and touchscreen display must be located in accessible and well-lighted area
for use, servicing, repair or replacement by authorized personnel.
• ADMS Control Module is electrically powered. ALWAYS take proper precautions to recognize,
evaluate, and control electricity hazards during installation, programming, use and service/
maintenance.
WARNING
!
NOTICE
Installation of ADMS is performed by the owner using qualified and licensed trades such as plumbers
and electricians, following all local, state, federal and other governmental requirements, and all building
and construction codes and standards. Step-by-step installation instructions depend upon the applica-
tion and the configuration of the building’s water distribution system.
All installations require thorough flushing of all piping BEFORE installation, and testing for and eliminat-
ing all leaks before and after installation.
Check valves are recommended to prevent cross-flow.
OMM-0126-0A Page 7 of 71

Mixed Outlet
Pressure Sensor (P1)
Recirc Pressure
Sensor (P2)
Cold Pressure
Sensor (P3)
Hot Pressure
Sensor (P4)
-
+
GOptional Modbus®
BAS Connection
R
C
12 4
RCCom
0-10
ActFB
53
Mtr
678911121310
FT1 Cs F2 +5V
Not Used
Gnd
1514
20 VF1
(dc)Sup
Ret V
4-20
BACnet 26 27 28 29 30 31 32 33 34 35 36 37 38
CsCs CsT1+5V+5V+5V+5V P4P3
T2 T3
P1 P2
2523 2422
ComCom ComCom
21 39 40
Cs
T4
18 19
Gnd
RS-485
20
+
16 17
Alert
Relay
L
G
N
Recirculation
Pump
115 V (ac)
Power Supply
43 44 45 46
NN
L
Power
Pmp
Recirc Return
Flow Sensor (F2)
Mixed Outlet
Flow Sensor (F1)
Mixed Outlet Temperature
Sensor (T1)
Mixed Outlet Fast
Temperature Sensor
Recirc Return Temperature
Sensor (T2)
Cold Supply Temperature
Sensor (T3)
Hot Supply Temperature
Sensor (T4)
Actuator
Motor
Optional BACnet®IP
Connection
Alert Relay
1
8
2
RJ45
F1 Gnd +5 V
Sup V
Control Unit Connections (interior)
OMM-0126-0A Page 8 of 71

Control Module and Digital Display
Description of Controls and Functions
The following sections generally outline and describe the controls and functions of the ADMS Control
Module you will experience when using the digital display. See “Set Up and Programming” section of
this Manual for use instructions.
The intelligence running the ADMS is contained within a Control Module. The color and touch screen
digital display allows the user to view temperatures, pressures, flow rates throughout the system, and
to configure the controls. The following sections describe and explain the user interface to assist in
navigating and configuring the control.
After power up, the “Attention!” screen (shown below) will appear. You have 60 seconds to begin
system navigation.
The Control will begin mixing operation after 60 seconds. The "Attention" message will appear again
after 10 seconds of inactivity until the 60 seconds time has elapsed.
NOTICE
WARNING
!
Always read the Manual and all product labels
and follow all safety and other information. If
you are ever uncertain about a particular task or
the proper method of operating this equipment,
ask your supervisor, consult this Manual, or visit
aerco.com
Start Up Screen
OMM-0126-0A Page 9 of 71

Description of Controls and Functions
By touching the screen the user can access the "Home" screen, shown below.
Home Screen
Item Description Units
Mixed Outlet Setpoint Temperature setpoint °F or °C
Mixed Outlet Temp Temperature measured at the mixing valve outlet °F or °C
Hot Supply Temp Temperature measured at the hot inlet °F or °C
Cold Supply Temp Temperature measured at the cold inlet °F or °C
Recirc Return Temp Temperature measured at the recirculation pump inlet °F or °C
Mixed Outlet Pressure Pressure measured at the mixing valve outlet psi or KPa
Hot Pressure Pressure measured at the mixing valve hot inlet psi or KPa
Cold Pressure Pressure measured at the mixing valve hot inlet psi or KPa
Recirc Pressure Pressure measured at the recirculation pump inlet psi or KPa
Load Flow*
Difference between the mixed and recirc flow rates (F1 and F2) gpm or m
3
/h or lpm
Mixed Outlet Flow* Flow rate measured at the mixed outlet (F1) gpm or m3/h or lpm
Recirc Flow* Flow rate measured on the recirculation return piping (F2) gpm or m3/h or lpm
Valve Position Control Voltage supplied to the mixing valve V
Mix Percent Mixed percent hot to total flow, i.e. (Tmixed-Tcold)/(Thot-
Tcold) %
*Available on models with optional flow monitoring package
Field 1 Label
Field 1 Select
Field 2 Select
Field 2 Label
Field 1 Value
Field 2 Value
Programming
Menu Access
Pump Status Field
As shown in the screen shot above, there are two fields viewable within the “Home” screen. For
instance, the. Label (item) and Value for Field 1 and Field 2 shown in the Home screen view above are:
Field 1 - “Mixed Outlet Set point” and value of “140°F.”
Field 2 - “Mixed Outlet Temp” and value of “140°F.”
The Label (item) displayed in the fields can be changed by touching the “Field Select” icon to the
right of each field value. The Labels (items) available for viewing on the Home screen by touching the
“Field Select” icon are shown in the table below:
Mixed Outlet Setpoint
140 °F
140 °F
Mixed Outlet Temp
PRGM Recirc Pump OFF
OMM-0126-0A Page 10 of 71

Description of Controls and Functions
Programming Menu
Unlock Function
Also shown on the Home screen is the Pump Status Field (showing if pump is ON or OFF), and the
icon to access the Programming menu.
Touching the icon takes the user to the “Programming” Menu containing six function icons –
“Unlock,” “Setup,” “Monitor,” “Sanitize,” “Home” and “Toolbox” - as shown below:
On the “Programming” Menu the and icons are the only active icons until the control is
unlocked. See “Unlock the System” in the “Set up and Programming” section of this Manual.
Touching the icon takes the user back to the Home Screen.
Touching the icon takes the user to the “Unlock” function screen shown below:
UNLOCK SETUP MONITOR
SANITIZE HOME TOOLBOX
Programming
Unlock
Back Clear Enter ?
1
6
2
7
3
8
4
9
5
0
OMM-0126-0A Page 11 of 71

To set and enter a passcode and unlock the system, follow instructions in the “Set Up and
Programming” section of this Manual.
The Set up Function allows the user to access three menus:
■“System”
■“Network”
■“BAS”
The icon on the Unlock function screen is deactivated until the user enters the correct passcode.
The icon will take you back to the Programming Menu.
The icon will show additional information if available.
After entering the correct passcode, the “Setup“, “Monitor”, “Sanitize” and “Toolbox” functions can be
accessed from the “Programming” Menu screen.
The following Sections generally outline and describe these functions.
Touching the icon on the “Programming” Menu will allow access to the Setup function:
Setup Function
Description of Controls and Functions
NOTICE
System Network BAS
Setup
Back ?
OMM-0126-0A Page 12 of 71

Description of Controls and Functions
System Menu
Item Field Range Default Additional Info
BAS Setpoint Max
80 to Mixed Out
Maximum - 10F
(max value = 180°F)
140°F
Limit to the remote temperature adjustment (BAS)
for added security and safety. If BAS is set to
'None' this field will not display.
Mixed Out Setpoint
80 to Mixed Out
Maximum - 10F
(max value = 180°F)
140°F Mixed Outlet setpoint.
High Temp Alert Mixed Out Setpoint
+10F to 190°F 150°F
A mixed outlet temperature over this amount will
create an error condition and issue a reset for the
control.
Pump Operation OFF <> ON <> AUTO AUTO
DHW Recirculation pump control mode. AUTO-
temperature differential and dead head protection.
ON-Pump is always on. OFF-Pump is always off.
Pump Head 0.0 to 50.0 psi 8.5 psi
If the head measured across the pump is greater
than this value, the pump will turn/remain off since
it can not generate any flow at these operating
conditions (Dead Head Protection)
Pump Min On/Off Time 0 to 60 min 1 min The minimum time the pump runs or remains off.
Return Target 80°F to 180°F 130°F The target temperature about which the pump relay
will operate.
Return Differential 1°F to 20°F 10°F The differential used to determine the pump on and
pump off temperatures.
The System Menu selections are generally described in the table below:
BAS Setpoint Max 140 °F
Mixed Out Setpoint 140 °F
Pump Operation Auto
Pump Min On/Off Time 1 min
High Temp Alert 150 °F
Pump Head 0.0 psi
Return Target 130 °F
Return Differential
Back Up Down
System
Enter
?
10 °F
OMM-0126-0A Page 13 of 71

Description of Controls and Functions
Network Menu
The Network Menu selections are generally described in the table below:
Item Field Range Default When Displayed Description Additional Info
IP Configuration Manual<> Auto Auto Always
IP Address: 0.0.0.0
Netmask: 0.0.0.0
Gateway: 0.0.0.0
IP Address 0.0.0.1 to
255.255.255.255 192.168.0.1 IP Configuration=Manual
Use keypad entry
0 thru 9
key in IP Address
Buttons on screen
are OK, DEL,
TAB,<–, -->, ?
Subnet Mask 0.0.0.1 to
255.255.255.255 255.255.255.0 IP Configuration=Manual
Use keypad entry
0 thru 9
key in Subnet IP
Address
Buttons on screen
are OK, DEL,
TAB,<–, -->, ?
Gateway
Address
0.0.0.1 to
255.255.255.255 192.168.0.1 IP Configuration=Manual
Use keypad entry
0 thru 9
key in Gateway IP
Address
Buttons on screen
are OK, DEL,
TAB,<–, -->, ?
MAC Address aa:bb:ee:ff:11:22 Unique to
each device Always MAC Address:
00:04:a3:62:59:8e
IP Configuration Manual
IP Address --->
Gateway Address --->
Subnet Mask --->
MAC Address --->
Back Up Down
Network
Enter ?
IP Configuration Auto
MAC Address --->
Back Up Down
Network
Enter ?
OMM-0126-0A Page 14 of 71

Description of Controls and Functions
BAS Menu
The BAS Menu selections are generally described in the table below:
Item Field Range Default When
Displayed Description Additional Info
BAS Type
NONE <>
BAC-IP <>
BAC-MSTP <>
MODBUS
NONE Always Building Automation
Type:
None = control runs in stand alone.
BAC-IP = control is connected to a
BACnet/IP system.
BAC-MSTP = control is connected to
a BACnet/MS-TP system.
MODBUS = control is connected to a
Modbus system.
BACnet
DEVICE ID 0 to 4194303 1BAS Type = BAC-IP or
BAC-MSTP
Buttons on screen are
OK, DEL,<–, --> ? BACnet device ID
BACnet Port 1 to 65535 47808 BAS Type = BAC-IP
Use keypad entry 0
thru 9
BACnet Portkey in BACnet PORT
Buttons on screen are
OK, DEL,<–, -->, ?
Register
Foreign Dev OFF<>ON OFF BAS Type = BAC-IP
Is a BACnet Device that has an IP
subnet address different from those
comprising the BACnet/IP network.
BBMD TIME OFF, 30 to 65535 OFF
BAS Type = BACnet Time-to-live (Seconds)
BACnet Broadcast Management. A
specified time, extending that time
by periodic (automatic) renewal
requests.
Register Foreign Dev
≠ OFF
Use keypad entry 0
thru 9
key in BBMD TIME
Buttons on screen are
OK, DEL,<–, -->, ?
BBMD IP 0.0.0.1 to
255.255.255.255 127.127.127.127
BAS Type = BACnet Use keypad entry0
thru 9
BACnet Foreign device internet
Protocol address. A numerical label
assigned to the foreign device.
Register Foreign Dev≠
OFF key in IP Address
Buttons on screen are
OK, DEL,<–, --> ?
BBMD PORT 0 to 65535 47808
BAS Type = BACnet Use keypad entry 0
thru 9
BACnet Broadcat Management Port.
Register Foreign Dev≠
OFF key in BBMD PORT
Buttons on screen are
OK, DEL,<–, --> ?
BAC-MSTP
Address 0 to 127 1BAS Type = BAC-
MSTP
Buttons on screen are
OK, DEL,<–, --> ?
Set the MSTP address. Each MSTP
device must have a unique address.
BACnet Baud
Rate
9600, 19K2, 38K4,
57K6, 76K8,
115K2
9600 BAS Type = BAC-
MSTP Slider, OK,<–, --> ? BACnet MS/TP baud rate
Modbus
Address 1 to 247 1BAS Type = MODBUS Radio buttons, OK, ?
Modbus Address:
1 to 247
Modbus Data
Type RTU <> ASCII RTU BAS Type = MODBUS Slider, OK,<–, --> ?
Modbus Data Type
RTU or ASCII
Modbus baud
Rate
1200, 4800, 9600,
14K4, 19K2,
28K8, 38K4,
57K6, 76K, 115K2
9600 BAS Type = MODBUS Slider, OK,<–, --> ? Modbus baud rate
Modbus Parity None <> Odd <>
Even Even Slider, OK,<–, --> ? Modbus Parity type.
OMM-0126-0A Page 15 of 71

Description of Controls and Functions
Monitor Function
The Monitor Function allows access to the following fields:
Touching the icon on the “Programming” Menu will allow access to the Monitor Function:
Item Field Range When is it
Displayed Description Additional Info
Current Error Always The highest priority error code.
Mixed Outlet
High -22 to 266°F Always The highest measured mixed outlet
temperature since last cleared.
Mixed Outlet
Low -22 to 266°F Always The lowest measured mixed outlet
temperature since last cleared.
Recirc Pump 0-65535 hrs Always Accumulated run time hours of
pump since last cleared.
Hot Inlet High -22 to 266°F Always The highest measured hot inlet tem-
perature since last cleared.
Hot Inlet Low -22 to 266°F Always The lowest measured hot inlet tem-
perature since last cleared.
Pressure High 0-65535 psi Always
psi or kPa The highest measured DHW outlet
pressure since last cleared.
Resolution in tenths
Pressure Low 0-65535 psi Always psi or kPa The lowest measured DHW outlet
pressure since last cleared.
Resolution in tenths
Energy 0-65535 Therms
or GJ
Optional F1 and F2 Flow
Sensors present
The accumulated energy usage
since last cleared.
System Supply Sensor
present
System Return Sensor
present
Flow High 0-65535 gpm Optional F1 and F2 Flow
Sensors present
gpm or m³/h The largest load flow measured
since last cleared.
Resolution in tenths
Reset All ON<>OFF Always Clear all monitored values to zero.
--- gpm
Mixed Outlet High 109 °F
Energy Used 0 MBtu
Hot Inlet High 158 °F
Mixed Outlet Low 91 °F
Recirc Pump 0 hr
Hot Inlet Low 130 °F
Load Flow High
Current Error ---
Back Up Down
System Monitor
Enter
?
OMM-0126-0A Page 16 of 71
