Watts PWSYS-WH-SOFT-TA series User manual

Installation, Operation
and Maintenance Manual
Series PWSYS-WH-SOFT-TA
IOM-WQ-PWSYS-WH-SOFT-TA
Table of Contents
Job Specifications Sheet .................................2
General and Commercial Installation Checklist . . . . . . . . . . . . . . . . . 3
General and Commercial Installation Checklist. . . . . . . . . . . . . . . . . . 5
Regeneration Cycle Program Setting Procedure . . . . . . . . . . . . . . . . 8
Time Brine Refill and Meter Setting Procedure . . . . . . . . . . . . . . . . . . 9
9100 Electro Mechanical Timer Assembly . . . . . . . . . . . . . . . . . . . . 11
9100 Power Head......................................13
9100 Control Valve Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9000/9100/9500 Second Tank Assembly . . . . . . . . . . . . . . . . . . . . 17
9100 Meter Assembly ...................................18
9100 Bypass Valve .....................................20
2310 Safety Brine Valve..................................21
Water Conditioner Flow Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Troubleshooting .......................................26
Mechanical Timer Valve Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9100 Control Dimensions ................................29
Meter Flow Data .......................................30
Injector Flow Data ......................................31
PURE WATER
Model 9000/9100/9500
Service Manual
IMPORTANT: Fill in pertinent information on page 3 for future reference.
Note: Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before or after
the system.

2
Job Specifications Sheet
Job Number ________________________________________________
Model Number ______________________________________________
Water Test ___________________________________________ ______
Capacity Of Unit ________________________ Max. _____________ Per Regeneration
Brine Tank Size _____________________________________________
Salt Setting Per Regeneration _________________________________
Control Valve Specifications
1. Type of Timer
A. 82 minute available regeneration time, 1/15 RPM
B. 164 minute available regeneration time, 1/30 RPM
2. Type of Meter
Mechanical Valves (gallon settings)
Meter Standard Range
3/4" 125–2,125
1" 310–5,270
3. Timer Gallon Setting _________________________________ gal.
4. Regeneration Program Setting
A. Backwash ______________________________________ min.
B. Brine and Slow Rinse _____________________________ min.
C. Rapid Rinse ____________________________________ min.
D. Brine Tank Refill _________________________________ min.
5. Drain Line Flow Control _____________________________ gpm
6. Brine Refill Rate ____________________________________ gpm
7. Injector Size ____________________________________________

3
Model 9000/9100/9500
4
General and Commercial Installation Checklist
Water Pressure
A minimum of 25 lbs of water pressure is required for regeneration valve to operate effectively.
Electrical Facilities
An uninterrupted alternating current (A/C) supply is required. Make sure:
• Voltage supply is compatible with unit before installation.
• Current supply is always hot and cannot be turned off with another switch.
Existing Plumbing
Condition of existing plumbing should be free from lime and iron buildup. Replace piping that has heavy lime
and/or iron build-up. If piping is clogged with iron, install a separate iron filter unit ahead of the water softener.
Location of Softener and Drain
Locate the softener close to a clean working drain and connect according to local plumbing codes.
Bypass Valves
Always provide for the installation of a bypass valve if unit is not equipped with one.
CAUTION
• Do not exceed water pressure of 125 psi.
• Do not exceed 110°F water temperature.
• Do not subject unit to freezing conditions.
!
Caution:
• Do not exceed water pressure of 125psi.
• Do not exceed 110°F water temperature.
• Do not subject unit to freezing conditions.
!
Caution:
• Do not use with water that is microbiologically
unsafe or of unknown quality.
• Test the water periodically to verify that the
system is performing satisfactorily.

4
Equipment Configuration
Figure 1
:
9100
inlet
outlet
bypass valve
adapter clips main control valve
tank two adapter
tank two tank one
yokes water meter
9100

5
General and Commercial
Installation Checklist
1. Place the softener tanks where you want to install the unit.
NOTE: Be sure the tanks are level and on a firm base.
2. During cold weather it is recommended that the installer warm
the valve to room temperature before operating.
3. Perform all plumbing according to local plumbing codes.
— Use a 1/2" minimum pipe size for the drain.
— Use a 3/4" drain line for backwash flow rates that exceed 7
gpm or length that exceeds 20' (6 m).
4. Both tanks must be the same height and diameter and filled with
equal amounts of media.*
5. The distributor tube must be flush with the top of each tank. Cut
if necessary. Use only non-aerosol silicone lubricant.*
6. Lubricate the distributor O-ring seal and tank O-ring seal. Place
the main control valve on one tank and the tank adapter on the
second tank.*
NOTE: If required, solder copper tubing for tank intercon-
nection before assembling on the main control valve and
tank adapter. Maintain a minimum of 1" distance between
tanks on final assembly.
7. Solder joints near the drain must be done before connecting
the Drain Line Flow Control fitting (DLFC). Leave at least 6" (152
mm) between the DLFC and solder joints when soldering pipes
that are connected on the DLFC. Failure to do this could cause
interior damage to DLFC.
8. Use only Teflon® tape on the drain fitting.
9. Be sure the floor under the salt storage tank is clean, level, and
strong enough to support the system..
10. Place approximately 1" (25 mm) of water above the grid plate. If
a grid is not utilized, fill to the top of the air check in the salt tank.
Do not add salt to the brine tank at this time.
11. Place the system in Bypass.
— Turn on the main water supply.
— Open a cold soft water tap nearby and let water run a few
minutes or until the system is free of foreign material (usually
solder) resulting from the installation.
12. Place the bypass In Service position and let water flow into the
mineral tank.
Electrical
13. Make all electrical connections according to codes. Plug the
valve into an approved power source. Do not insert meter cable
into the meter yet.
14. Tank one has control valve and tank two has adapter. See Figure
1, page 4.
15. Look on the right side of the control valve, it has indicators
showing which position the control valve is in during Regenera-
tion and which tank is In Service.
— Figure 3, page 6 shows the valve In Service position with tank
one supplying conditioned water and tank two on standby.
NOTE: Make sure the meter cable is not inserted in the me-
ter dome. Swing the timer out to expose the program wheel.
To swing timer out, grab onto the lower right corner of timer
face and pull outward. See Figure 5, page 7.
* Tanks 12" in diameter and smaller are factory loaded with me-
dia. Checking media amounts, distributor tube length, lubricat-
ing the distributor pilot O-rings, and lubricating the tank seal
O-rings on these sized systems is not necessary.
Teflon® is a registered trademark of E.I. Dupont de Nemours & Company.

6
Model 9000/9100/9500
7
16. Cycle timer into backwash position. Turn manual knob so that the micro switch rides on the first set of pins.
— In this position the tanks switch (lower piston) and the control valve moves to the backwash position (upper
piston).
— Wait until the positioning of upper and lower pistons stops before advancing the timer further.
If advanced
too fast
the control will not home into the In Service position (it will not advance to any other position). To
correct this, rotate the manual knob back to In Service and start again into backwash.
NOTE: Once valve positions itself into the backwash cycle, the homing circuit locks in.
17. With all the air backwashed, slowly cycle the timer to the brine position; rapid rinse; and brine tank refill. Wait
for the control drive motor to position itself in each cycle and stop, before advancing on to the next position.
18. Once back in the In Service position, cycle the control valve again into the backwash position. The tanks
switch again, and air head backwashes out of the other tank. Cycle the control back to the In Service position.
Leave the timer in the open position. DO NOT insert meter cable yet.
Figure 3 : Control Valve Position Indicators
Figure 4 : Timer
tank one
tank two
brine fill
stand-by
backwash
rapid rinse
brine rinse
16. Cycle timer into backwash position. Turn manual knob so that
the micro switch rides on the first set of pins.
— In this position the tank's switch (lower piston) and the control
valve moves to the backwash position (upper piston).
— Wait until the positioning of upper and lower pistons stops
before advancing the timer further. If advanced too fast the
control will not home into the In Service position (it will not
advance to any other position). To correct this, rotate the
manual knob back to In Service and start again into back-
wash.
NOTE: Once valve positions itself into the backwash cycle,
the homing circuit locks in. Then unplug the system. Allow
the system to remain in the backwash position until air no
longer flows from the drain line.
17. Plug the unit back in with all the air backwashed, slowly cycle
the timer to the brine position; rapid rinse; and brine tank refill.
Wait for the control drive motor to position itself in each cycle
and stop, before advancing on to the next position.
18. Once back in the In Service position, cycle the control valve
again into the backwash position. The tanks switch again, and
air head backwashes out of the other tank. Once the system
reaches the backwash position unplug it again. Allow the system
to remain in the backwash position until all air is purged from the
system. When all air is gone no air will come out of the drain line.
Then plug the unit back in.
Proceed to regeneration cycle program setting procedure. Cycle
the control back to the In Service position. Leave the timer in
the open position. DO NOT insert meter cable yet.

7
Model 9000/9100/9500
8
NOTE: Two motors are available:
1/15 RPM has 82 minute Regeneration Time.
1/30 RPM has 164 minute Regeneration Time. See
Figure 5 .
Figure 5 : Program Wheel
pin
storage

8
Model 9000/9100/9500
9
Regeneration Cycle Program Setting Procedure
Setting the Regeneration Cycle Program
The Regeneration cycle program on the water conditioner is preset at the factory. However, portions of the cycle or
program time may be lengthened or shortened for local conditions or system design.
1. Expose cycle program wheel by grasping timer in lower right hand corner and pulling. This releases snap
retainer and swings timer to the left
NOTE: Meter cable must be removed from meter dome before opening timer.
2. Remove the program wheel by grasping program wheel and squeezing protruding lugs towards center. Lift
program wheel off timer.
— Switch arms may require movement to facilitate removal.
3. Return timer to closed position by engaging snap retainer in back plate.
— Make certain all electrical wires locate above snap retainer post.
Changing Length of the Backwash Time
The program wheel in Figure 5 is In Service position. Looking at the numbered side of the program wheel, the
group of pins starting at zero determines the length of time the unit backwashes.
Example: If there are six pins in this section, the time of backwash is 12 minutes (2 minutes per pin). To
change the length of backwash time, add or remove pins as required.
— The number of pins multiplied by two equals minutes of backwash.
Changing Length of Brine and Rinse Time
The group of holes between the last pin in the backwash section and the second group of pins determines the
length of time that a unit will brine and rinse (2 minutes per hole).
To change the length of brine and rinse time, add or remove pins in the rapid rinse group of pins to increase or
decrease the number of holes in the brine and rinse section.
— The number of holes multiplied by two equals minutes of brine and rinse.
Changing Length Of Rapid Rinse
The second group of pins on the program wheel determines the length of time the water conditioner rapid rinses (2
minutes per pin). To change the length of rapid rinse time, add or remove pins at the higher numbered end of this
section as required.
— The number of pins multiplied by two equals minutes of rapid rinse.
NOTE: Program wheels with 0–82 minute cycle times, use one minute per pin or hole to set Regeneration
times. The layout of pins and holes on the program wheel follow the same procedure as on this page.
Changing Length of Brine Tank Refill Time
The second group of holes on the program wheel determines the length of time the water conditioner refills the
brine tank (2 minutes per hole).
To change the length of refill time, move the two pins at the end of the second group of holes as required.
The Regeneration cycle is complete when the two pin set at end of the brine tank refill section trips the outer
micro-switch. The program wheel, however, continues to rotate until the inner micro-switch drops into the notch on
the program wheel.

9
Model 9000/9100/9500
10
Time Brine Refill and Meter Setting Procedure
Programming
1. The control valve is set at the factory for backwash; brine and slow rinse; rapid rinse and brine tank fill times.
Change any of these times by repositioning the pins and holes or adding more pins.
NOTE: Two speed timer motors are available
1/15 RPM has 82 minute Regeneration Time and each pin or hole equals one minute.
1/30 RPM has 164 minute Regeneration Time and each pin or hole equals two minutes.
2. The control valve has a separate brine tank fill cycle.
— Calculate the desired salt setting using the brine line flow control rate of refill (in gpm) multiplied by the
timer setting. Then, using one gallon of fresh water dissolving approximately 3 lbs salt, calculate the refill
time.
Example: A desired 30 lbs salt setting:
The unit has a 1.0 gpm refill rate so a 10 gallon fill is required.
10 gallons x 3 lbs/gals = 30 lbs salt
Set the timer refill section at 10 minutes.
10 minutes x 1.0 gpm = 10 gallon fill
NOTE: There must always be two pins at the end of a refill time to stop the fill cycle.
With the Regeneration times set, place timer back to its original position, making sure the lower right
hand corner snaps back into the backplate and the meter cable slides through the backplate and does
not bind.
3. Setting the gallon wheel.
Knowing the amount of resin in each tank and the salt setting per Regeneration, calculate the gallons
available, using the following capacities as a guide:
NOTE: Based on tank size:
More resin increases capacity, less resin decreases capacity.
More salt increases capacity, less salt decreases capacity.
Example:
DO NOT SET THIS FIGURE - GO TO STEP 4
— Because the control valve regenerates with soft water from the other tank, subtract the water used for
Regeneration. Take each Regeneration cycle and calculate the water used.
(capacity per ft3 x ft3 of resin per tank) = gallons available
compensated hardness of H2O
tank diameter = 16"
compensated hardness = 35 grains per gal (tested sample)
ft3resin (based on flow rate) = 4
lbs of salt = 8
capacity per ft3= 24,000
(24,000 x 4 ft3 of resin per tank) = 2740 gallons available before regeneration
35 grains

10
Model 9000/9100/9500
11
Example: Unit is set for a 16" diameter tank with 4 ft3 of resin and salted at 8 lbs. per ft3, 7 gpm backwash,
#3 injector, 1.0 gpm brine refill, and 60 psi and timer set for
10 min. backwash, 60 min. brine and
rinse, 10 min. rapid rinse, 10 min. brine tank fill.
With the 2740 gallons available calculated in Step 3, subtract the Regeneration water used from the
total water available.
4. Set meter wheel at approximately 2530 gallons. Lift the inner dial of the meter program wheel so that you can
rotate it freely. Position the white dot opposite the 2530 gallon setting.
NOTE: There is a slight delay between the time the meter zeros out and the cycle starts. Units using the:
1/15 RPM motor, 82 minute Regeneration Time has a 9
minute delay
1/30 RPM motor, 180 minute Regeneration Time has an 18 minute delay .
This delay period is not critical on residential equipment. However, take this factor into consideration
for commercial applications by subtracting continuous flows for 9 minutes or 18 minutes from water
available.
5. Insert meter cable into meter.
6. Check bypass.
7. Plug in unit.
Backwash 10 minutes x 7.0 gpm = 70.0 gallons
Brine and Rinse 60 minutes x 1.0 gpm = 60.0 gallons
Rapid Rinse 10 minutes x 7.0 gpm = 70.0 gallons
Brine Tank Fill 10 minutes x 1.0 gpm = 10.0 gallons
Total Regeneration Water = 210.0 gallons
2740 gallons available - 210 gallons used = 2530 gallons
(in Regeneration, Step 4)

11
Model 9000/9100/9500
22
9000/9100/9500 Electro Mechanical Timer Assembly
Figure 21
9100 Electro Mechanical Timer Assembly

12
Item QuantIty Part number DescrIPtIon
1 1 13870-03 timer housing assembly.
2 1 17870 label, capacity gallons
3 1 15465 label, Caution
4 1 16930 label, Instruction
5 1 15227 actuator plate
6 1 10300 screw, hex washer #8
7 1 17513 spring clip
8 1 15407 washer, plain #4
9 1 15228 spring
10 1 16270-10 gallon wheel assembly 3/4" standard range meter
16270-50 gallon wheel assembly 3/4" extended range meter
16270-30 gallon wheel assembly 1" standard range meter
16270-40 gallon wheel assembly 1" extended range meter
11 1 13806 program wheel retainer
12 1 13748 screw, flathead #6-20
13 2 11999 button decal
14 1 15223 cycle actuator gear
15 1 13886-01 knob
16 4 13296 screw, hex washer #6-20
17 1 17724 drive pinion
18 1 17723 drive pinion clutch
19 1 14276 spring, meter clutch
20 1 14253 retainer
21 3 14087 insulator
22 1 15314 switch
23 1 15320 switch
24 2 11413 screw, pan head #4-40
25 1 13018 idler shaft
26 1 18563 spring, idler shaft
27 1 13017 idler gear
28 1 13164 drive gear
29 1 13887 motor mounting plate
30 1 18743 motor, 120V 60 Hz.-1/30 RPM
18824 motor, 220V 50 Hz.-1/30 RPM
19170 motor, 120V 60 Hz.-1/15 RPM
18825 motor, 220V 50 Hz.-1/15 RPM
31 2 13278 screw, #6-32
32 1 14265 spring clip
33 1 15055 main drive gear
34 1 19210-02 program wheel, 90 minute
19210-05 program wheel, 180 minute
35 23 15493 roll pin
36 1 15203 harness
37 2 12681 wire nut
38 1 60320-02 auxiliary timer switch kit (not shown)
9100 Electro Mechanical Timer Assembly

13
Model 9000/9100/9500
24
9000/9100/9500 Power Head
Figure 22
9100 Electro Power Head

14
Item QuantIty Part number DescrIPtIon
1 2 18728 nut, clip #8-32
2 1 11838 power cord, 6' U.S. 120V
11839 power cord, 12' U.S.120V
11545-01 power cord, 5' European 220V
14678 power cord, 6' U.S. 220V
19303-01 power cord, Australian 8' 220V
19674 transformer, U.S., 110V to 24V
25651 transformer, European, 220V to 24V
3 1 15202 wire harness, mechanical
14822 wire harness auxiliary drive switch
4 1 15134 drive gear assembly, lower
5 1 15135 drive gear assembly
6 1 14896 geneva wheel
7 2 40422 wire connector
8 2 19367 cover screw
9 1 15175 position decal
10 2 14917 retaining ring
11 1 15199 ground plate
12 1 14430 screw, hex washer #6
13 2 19160 screw, motor mounting
14 1 18737 drive motor, 24V, 50/60 Hz (red wires)
1 18738 drive motor, 120V, 60 Hz (black wires)
1 18739 drive motor, 220V, 50 Hz (yellow wires)
15 1 15131 backplate, mechanical and SE
16 2 15172 screw, flat head #4-40
17 2 10340 washer, lock #4
18 10218 micro switch (homing)
19 1 10339 nut, micro switch
20 1 15331 screw, valve mounting
21 2 15133 drive gear assembly, upper
22 1 13547 strain relief
23 1 15810 retaining ring, drive gear
24 1 15132 triple cam (9000/9100)
25 1 15638 cable guide (9000/9100)
26 2 15372 washer, thrust
27 1 15216 meter cable, 15.25", 1" meter, mechanical
15425 meter cable, 13.25", 3/4" meter, mechanical
28 2 15692 spacer
29 1 16433 micro switch (program)
30 1 10302 insulator
31 2 15173 screw
Not Shown
32 1 60232-110 cover, black
1 60232-112 cover, black - left window
33 1 60320-09 optional auxiliary drive switch (9000/9100)
9100 Power Head

15
Model 9000/9100/9500
28
9100 Control Valve Assembly
Figure 24
9100 Control Valve Assembly

16
Model 9000/9100/9500
29
9100 Control Valve Assembly
Item Quantity Part Number Description
1 1 40688 valve body assembly
2 4 15137 screw, hex washer #10-24 x 3/8”
3 1 14906 end plate
4 1 14928 end plug
5 1 19054 O-ring, 124
6 1 18303 O-ring, 336
7 1 40538 retainer, 32mm
8 1 60400 piston top assembly
9 1 60125 seal and spacer kit, top
1 60125-20 seal and spacer kit, top (559PE)
10 1 60421 seal and spacer kit, bottom
1 60421-20 seal and spacer kit, bottom (559PE)
11 1 60401 piston assembly, bottom
12 1 60385-XXXX injector assembly
(see following chart for dash numbers)
injector number DLFC number BLFC number
red #0 00 Blank 0 Blank 0
white #1 01 1.2 1 0.25 1
blue #2 02 1.5 2 0.50 2
yellow #3 03 2.0 3 1.00 3
green #4 04 2.4 4
3.0 5
3.5 6
4.0 7
5.0 8
7.0 9
12A 1 60022-12 brine line flow control assembly, 0.125 gpm
60022-25 brine line flow control assembly, 0.250 gpm
60022-50 brine line flow control assembly, 0.500 gpm
60022-100 brine line flow control assembly, 1.00 gpm
12B 1 60350 brine valve assembly
13 1 61419 distributor adapter kit, 1.05"
Not Shown
14 12763 seal and space stuffer tool
15 13061 spacer puller tool
16 13759 DLFC retainer tool
9100 Control Valve Assembly

17
Figure 29
9100 Second Tank Assembly
12
3
Item QuantIty Part number DescrIPtIon
1 1 60425-12 plastic tube assembly, 9100, up to 12" tanks
60425-16 plastic tube assembly, 9100, up to 16" tanks
2 1 14865 second tank adapter assembly, 9100
3 1 61419 distributors adapter kit, 9100, 1.05"
9100 Second Tank Assembly

18
Figure 31
9000/9100/9500 Meter Assemblies
9100 Meter Assembly

19
Item QuantIty Part number DescrIPtIon
1 1 60086 3/4" meter assembly, standard range
60087 3/4" meter assembly, extended range
1A 1 14038 meter cap assembly, standard range
1C 15150 meter cap assembly, extended range
1D 1 15218 meter cap assembly, brass standard range
15218NP meter cap assembly, brass nickel-plated
standard range
1E 15237 meter cap assembly, brass extended range
15237NP meter cap assembly, brass nickel-plated
extended range
2 1 13509 impeller
13509-01 impeller, hot water
4 1 60389 1" meter assembly, standard range
60389NP 1" meter assembly, standard range
60390 1" meter assembly, extended range
60390NP 1" meter assembly, extended range, nickel-
plated
60612 1" meter assembly, standard range, hot water
4A 1 15078 1" adapter coupling
Not Shown
7 60460 meter checker kit, standard range
8 60461 meter checker kit, extended range
9100 Meter Assembly

20
Model 9000/9100/9500
36
9000/9100 Bypass Valve
Figure 34
Item Quantity Part Number Description
1 1 60040SS 3/4" bypass valve NPT
60040-10 3/4" bypass valve BSP
60041SS 1" bypass valve NPT
60041-10 1" bypass valve BSP
2 1 60049 plastic bypass valve
Not Shown
3 40157 plastic bypass T-handle wrench
9100 Bypass Valve
