OPERATION MANUAL
Model No. WST-PEX006
HDMI 4K@60Hz & IR over Single Cat.6 US Wall plate Extender Kit
with PoC & Loop out & Audio Extraction, 70m
Safety Instruction

Copyright ©2020 Wavesplitter AV Technology |Wavesplitter .com
TEL：[phone] MAIL：[e-mail]
OPERATION MANUAL
Introduction
The WST-PEX006 Extender Kit is a simple to use plug and play solution which lets the user extend HDMI signals up to 70m using a single
Cat.6 UTP cable (not included). The Transmitter wall plate meets USA standard installation requirements.
The Extender supports HDMI 2.0 18G specification that allows the transmission of 4K Ultra HD resolutions. It also supports High-Dynamic
Range which enable video content to be seen with enhanced brightness, greater contrast of black and white and a much wider colour
gamut. This Extender is a perfect solution for an immersive home cinema experience.
The Extender features an HDMI loop-through output on the Transmitter wall plate which allows for simultaneous viewing using local and
remote displays. The built-in EDID dip switch enables the user to control the acceptance of EDID from local or remote display, ensuring
maximum compatibility with different HDMI displays and projector formats. Bi-Directional PoC allows for both power and data signals over
a Cat.6 cable in a point-to-point configuration, this provides flexibility as only one power supply is required for both the Transmitter and the
Receiver. This is ideal when power outlets are limited in the installation environment.
The Extender also has separate optical and 3.5mm audio ports to extract audio from HDMI signals for non-HDMI amplifiers or soundbars,
making it ideal for supporting video with immersive multichannel audio.
Featuring IR pass-through, the source equipment can be seamlessly controlled from the remote display side of the installation using
compatible infrared remote controls.
Key Features
Supports resolutions up to 3840x2160@60Hz 4:4:4 8bit, with support for HDR10
Each set includes one Transmitter wall plate with loop out and one Receiver
Supports Dual Way PoC
Extension distance up to 70m for 4K@60Hz / 1080P@60Hz
Supports Local EDID or Remote EDID Copy or Built-In EDID (4K@60Hz 4:4:4)
HDCP1.x / 2.2 compliant
The Transmitter wall plate is designed to be mounted on a one-gang junction box
HDMI audio pass-through supports 7.1CH and audio sampling rate supports 192kHz
Toslink (Optical) digital audio port supports 5.1CH and audio sampling rate supports 96kHz / 3.5mm analog audio port supports 2.0CH and
audio sampling rate supports 96kHz
Supports Dolby®, TrueHD, DTS-HD®, & Master Audio™, multi-channel, & stereo etc.
Supports IR pass-through
Package Contents
US Wall Plate 1-Gang Transmitter x 1 | Receiver x 1 | 12V/1A Multi-Country Power Adapter x 1 | IR Emitter x 1 | IR Receiver x 1 |
Ear Mounts x 2 | Screws Pack x 1

Copyright ©2020 Wavesplitter AV Technology |Wavesplitter .com
TEL：[phone] MAIL：[e-mail]
OPERATION MANUAL
Panel Description
Note:
1. The Transmitter has AUTO and COPY EDID function (3PIN EDID switch).
AUTO EDID including 4K@60Hz
Copy EDID including to copy the LOCAL or REMOTE TV
2. LINK Indicator: When Display connected, the indicator works
3. LIVE Indicator: When Power connected, the indicator works
Connecting and operating
Wall Mounting

Copyright ©2020 Wavesplitter AV Technology |Wavesplitter .com
TEL：[phone] MAIL：[e-mail]
OPERATION MANUAL
Hardware Installation
1. Connect 1 source such as a Blu-Ray Player, game console, STB, etc. to the HDMI input on the transmitter．
2. Connect 1 display such as an HDTV or HD Projector to the Loop HDMI output on the transmitter.
3. Connect 1 display such as an HDTV or HD Projector to the HDMI output on the receiver．
4. Connect a single Category 6 or above up to (70m) to both transmitter and receiver.
5. Plug in the IR-RX cable and IR-TX cable to the IR jack port located on the Receiver and transmitter banal.
6. Power on the transmitter firstly, then power on the source and sink.
Applications

Copyright ©2020 Wavesplitter AV Technology |Wavesplitter .com
TEL：[phone] MAIL：[e-mail]
OPERATION MANUAL
Specifications
Transmitter
InputsHDMI Type-A (Female) x 1
OutputsHDMI Loop out Type-A (Female) x 1
|
RJ45 (Female) x 1
|
IR-Out slot x 1
USB Micro USB port: for firmware upgrading
Power 2PIN Phoenix port, supports PoC
Receiver
InputsRJ45 (Female) x 1
|
IR-In slot x 1
OutputsHDMI Type-A (Female) x 1
Audio HDMI Audio by pass supports 7.1 CH and audio sampling rate supports 192kHz
Toslink digital audio port supports 5.1 CH and audio sampling rate supports 96kHz
3.5mm analog audio port supports 2.0 CH and audio sampling rate supports 96kHz
USB Micro USB port: for firmware upgrading
Power 5.5 / 2.1 mm with screw Slot, supports PoC
Transmission
HDMI CompliantHDMI2.0b
HDCP Compliant 2.2 / 1.4
Output Signal HDMI
Output Resolution (Max.) 3840x2160@60Hz
Audio Format Dolby
®
、TrueHD、DTS-HD
®
、Master Audio™、multi-channel, stereo etc
IR Frequency 38-56kHz
Power
Power Supply 12V/1A DC (Select one side for power-on)
Max. Power Consumption 4.8W
Environment
Operating Temperature -5˚C～40˚C
Storage Temperature -20˚C～60˚C
Product Structure
Main Material TX: Aluminum
|
RX: Iron
Size W x D X H TX : 69.6 x 114.8 x 42.4 mm
|
RX : 75.8 x 72.2 x 18mm
Weight TX : 144g
|
RX : 152.6g
Country of Origin China
Certification
Safety & Emission CE / FCC / RoHS / REACH
