Waytronic WT-N11 User manual

-第 1页-
Shenzhen Waytronic Electronics Co., Ltd. WT-N11
WT-N11 V1.00
Motion sensor speaker
1.Product features
Small and exquisite, with excellent sound quality.
4 levels of volume.
Micro USB interface.
Human body induction, the induction distance up to 4 meters.
Standard 32Mbit SPI-flash, available to replace capacity according to customer requirements.
Support to copy the audio files from USB disk
1.1：Interface
On/off button
Micro port
Speaker
Motion sensor
Battery House

-第 2页-
Shenzhen Waytronic Electronics Co., Ltd. WT-N11
2.Electrical parameters：
Power supply
Micro USB 5V/1A
7 x AAA Batteries
Working Current
Sleep standby mode
≤35uA
Playing mode
≤230mA
Audio Format
BIN
Speaker
8Ω/0.5W
Volume level
≥80dB
3.Basic function
3.1：On/off button
Button
Operation
Function
On/off button
Longer press
On/off
Short press
Adjust volume level
Double press
Change sound file
3.2：Change Audio File
1：Put audio file in to a specific upload tool
2：Plug upload tool into micro usb port,audio file will upload automatically (indicated light flash fast when
uploading , indicated light stay on when finish uploading )。

-第 3页-
Shenzhen Waytronic Electronics Co., Ltd. WT-N11
4.Install environment and attentions
1、If environment temperature higher than 33℃，will affect motion sensor working!
2、Do not install product near Air conditional ,Fans etc
5.FAQ
Question
Answer
How to make the battery lift longer
1：lower the volume level
2：External power supply
What is the battery life of 3xAAA batteries
Around one month
6.Accessories
Name
Number
Main device
1
Velcro
2
Indemnification
SHENZHEN WAYTRONIC ELECTRONIC CO.,LTD. reserves the right to modify and use information without prior
notice to customers. New product specifications will be subject to the latest version
