WebDT SA2000 Assembly instructions

ENGLISH
BASIC OPERATION GUIDE
SA2000
Signage Appliance
THE SA2000
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 http://www.dtresearch.com I http://signage.dtri.com
Copyright©2008, DT Research, Inc. All Rights Reserved. DT Research and WebDT are registered trademarks of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the
SA2000, a WebDT Signage
Appliance by DT Research.
The WebDT Signage Appliance
facilitates the creation of a unique and powerful communication medium that offers
unparalleled opportunities to capture an audience’s attention at key decision-making locations.
The SA2000 enables efcient deployment for digital signage, with reliable hardware features
and an innovative server-based software suite. The Microsoft® Windows® XP Embedded-based
SA2000 offers remote management of the devices and the displayed content with the WebDT
Device Manager and WebDT Content Manager software. The SA2000 together with the WebDT
software suite, offers an efcient solution for delivering and managing messages that target
audiences in the right place, at the right time.
Package Contents
W
1. ebDT Signage Appliance SA2000
S
2. oftware and User Guide (including
WebDT Content Manager, WebDT
Device Manager and user guides
on Software Disk)
V
3. ESA-compliant Mounting Bracket
A
4. C/DC Power Adapter
Basic Operation Guide5.
NOTE: The actual package contents may
vary depending on the conguration
acquired.
SPECIFICATIONS
Processor AMD Sempron™ 1.6GHz/ 2GHz,
or AMD Turion™ 2.1GHz Dual-Core processor
Memory (Storage) 4GB, 8GB, 16GB Flash, or 120GB HDD
Memory (RAM) 1GB or 2GB
Operating Systems Microsoft® Windows® XP Embedded
Display Resolution Up to 1920 x 1080
Control Buttons 1 front Power button
Input/Output Ports
1 VGA port, 1 HDMI port, 3 Audio jacks, 2 USB
ports, RJ45 for Ethernet, 1 DC–in jack, 1 S-video
input, 1 Composite Video-in, 1 RS232 COM port,
1 dipole antenna (optional)
Networking 10/100Mb BaseT LAN/ WiFi 802.11 a/b/g
Enclosure Metal enclosure
Dimensions (H x W x D) 1.96 x 5.5 x 6.5 (in)
50 x 140 x 165 (mm)
Base Weight 2.3lbs (1050g )
AC/DC Adapter Input: 100 – 240V AC
Output: 18.5V DC
Power North America, EU, UK, China
Regulatory FCC Class B, CE, C-tick, RoHS compliant
Operating Temperature 0° – 40°C
Humidity 0% – 90% non–condensing
* Note: Specications subject to change without notice
Content Manager
Device Manager
1
2 3 4

THE SA2000
ENGLISH 23ENGLISH
VESA Mounting Bracket Installation Guide for SA2000
The WebDT Signage Appliance package includes a VESA-compliant mounting bracket (1)
which mounts the SA2000 (2) onto a VESA-compatible monitor or display.
NOTE: The VESA Mounting Bracket is compatible with most displays and monitors that support
the VESA standard.
Step1:
- Locate the existing mounting holes on the monitor.
- Line the bracket holes up with the holes on the back of the
monitor, as shown to the right.
- Place the screws to hold the mounting bracket in place
and tighten the screws (do not over-tighten).
Step2:
- Remove the two M3 screws (3) originally on the SA2000
signage appliance.
- Place the SA2000 (2) on the bracket rail with the interface
ports side facing downwards so that the two mounting
holes on the appliance are aligned with the existing holes
on the rail (see picture).
Step 3:
- Apply and tighten the screws into their original locations
and make sure that the bracket and the SA2000 are
properly secured.
Powering ON and OFF
The SA2000 is programmed to Power On automatically when power is rst applied or
re-established. There is also a Power Button, located on the front of the SA2000. To turn the
SA2000 on, push and release the Power Button on the front bezel. The adjacent power LED will
be lit (blue), and the corresponding interface will be shown on the display monitor.
To turn off the device, use the software to shutdown interface provided, or unplug the
appliance.
In the event of system lockup, unplug or re-plug the power cable. Also, the Power Button may
be used to perform a reset on the device. To do that, push and hold the Power Button for at
least 4 seconds. The system will shut down and all unsaved work may be lost. Pushing on the
Power Button again will restart the device.
Server Installation
Please refer to the corresponding User Guides for software installation instructions.
Appliance Registration
After turning on the SA2000 for the rst time, a screen
prompt is displayed for registering the player. If the screen
prompt is not shown, please follow the instructions below:
Press and hold “Control + Shift + Space” to exit the1.
WCM Player software.
Navigate to Start | Programs | DT Research | WCM2.
Player
Select Register Player Again. The Player Registration3.
screen should appear. Fill in all elds to register. The
required information is marked.
Click OK to register and connect to the WebDT Signage4.
Appliance Publish Server.
THE SA2000 Signage Appliance
<1>
<2>
<3>
Memory and Storage
Depending on the base software conguration, the user may need only the internal ash
memory of the SA2000 for user’s installed software and storage. The user may also supplement
storage space with USB-based peripherals such as ash disks, disk drives, etc.
Options
The SA2000 WebDT Signage Appliance is designed to work with a range of custom and off-the-
shelf options to enhance its applicability for various deployments.
* Internal mini-PCI wireless LAN (WLAN) adapters with dipole antenna
Rear ViewFront View
ABC D EFH
GIJ
Ethernet port
HDMI port
VGA port
RS232 COM port
DC in
F
H
G
I
J
A
B
C
D
E
Audio jacks
Composite Video Input
S-video input
Power button
USB 2.0 (2)
