Weber Summit E 470 User manual

YOU MUST READ THIS OWNER’S GUIDE
BEFORE OPERATING YOUR GAS GRILL.
mDANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury,
death, or damage to property.
mWARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
mWARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
56211 02/28/11 LP
US - ENGLISH
#56211
mWARNING: Do not ignite this appliance
without first reading the BURNER
IGNITION sections of this manual.
470
Guía del Propietario del Asador de Gas Licuado de Propano - Pg. 37
Guide de L’Utilisateur du Grill à Gaz PL - Pg. 73
GAS GRILL
LP Gas Grill Owner’s Guide
ESNA

2
mDANGER
Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or
death, or in a fire or an explosion causing damage to property.
mWARNINGS
mDo not store a spare or disconnected liquid propane
cylinder under or near this barbecue.
mImproper assembly may be dangerous. Please follow the
assembly instructions carefully.
mAfter a period of storage, and/or nonuse, the Weber®gas
barbecue should be checked for gas leaks and burner
obstructions before use. See instructions in this manual for
correct procedures.
mDo not operate the Weber®gas barbecue if there is a gas
leak present.
mDo not use a flame to check for gas leaks.
mCombustible materials should never be within 24 inches (61
cm) of the back or sides of your Weber®gas barbecue.
mDo not put a barbecue cover or anything flammable on, or in
the storage area under the barbecue.
mYour Weber®gas barbecue should never be used by
children. Accessible parts of the barbecue may be very hot.
Keep young children away while it is in use.
mYou should exercise reasonable care when operating your
Weber®gas barbecue. It will be hot during cooking or
cleaning and should never be left unattended, or moved
while in operation.
mShould the burners go out while in operation, turn all
gas valves off. Open the lid and wait five minutes before
attempting to relight, using the igniting instructions.
mDo not use charcoal or lava rock in your Weber®gas
barbecue.
mNever lean over open grill or place hands or fingers on the
front edge of the cookbox.
mShould a grease fire occur, turn off all burners and leave lid
closed until fire is out.
mDo not enlarge valve orifices or burner ports when cleaning
the valves or burners.
mThe Weber®gas barbecue should be thoroughly cleaned on
a regular basis.
mLiquid propane gas is not natural gas. The conversion or
attempted use of natural gas in a liquid propane unit or
liquid propane gas in a natural gas unit is dangerous and
will void your warranty.
mDo not attempt to disconnect any gas fitting while your
barbecue is in operation.
mUse heat-resistant barbecue mitts or gloves when operating
barbecue.
mKeep any electrical supply cord and the fuel supply hose
away from any heated surfaces.
mCombustion byproducts produced when using this product
contain chemicals known to the state of California to cause
cancer, birth defects, or other reproductive harm.
mDo not use this barbecue unless all parts are in place. The
unit must be properly assembled according to the assembly
instructions.
mDo not build this model of grill in any built-in or slide-in
construction. Ignoring this Warning could cause a fire or
an explosion that can damage property and cause serious
bodily injury or death.
mProposition 65 Warning: Handling the brass material on
this product exposes you to lead, a chemical known to the
state of California to cause cancer, birth defects or other
reproductive harm.
(Wash hands after handling this product.) ◆
LIQUID PROPANE GAS UNITS ONLY:
mUse the pressure regulator and hose assembly that is
supplied with your Weber®gas barbecue.
mDo not attempt to disconnect the gas regulator and hose
assembly or any gas fitting while your barbecue is in
operation.
mA dented or rusty liquid propane cylinder may be hazardous
and should be checked by your liquid propane supplier. Do
not use a liquid propane cylinder with a damaged valve.
mAlthough your liquid propane cylinder may appear to be
empty, gas may still be present, and the cylinder should be
transported and stored accordingly.
mIf you see, smell or hear the hiss of escaping gas from the
liquid propane cylinder:
1. Move away from liquid propane cylinder.
2. Do not attempt to correct the problem yourself.
3. Call your fire department. ◆
WARNINGS

WWW.WEbER.com®3
TAbLE oF coNTENTS
WARNINGS ..........................................2
TAbLE oF coNTENTS .................................3
EXPLoDED VIEW .....................................4
EXPLoDED VIEW LIST ................................5
WARRANTY .........................................6
GENERAL INSTRUcTIoNS .............................7
CANADIAN INSTALLATION ..........................................7
OPERATING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
STORAGE AND/OR NONUSE........................................7
GAS INSTRUcTIoNS ..................................8
SAFE HANDLING TIPS FOR LIQUID PROPANE GAS CYLINDERS ..........8
IMPORTANT LP CYLINDER INFORMATION ............................9
LEAK CHECK PREPARATION........................................9
CHECK FOR GAS LEAKS.......................................... 11
REFILLING THE LIQUID PROPANE CYLINDER.........................13
LIGHT FEATURES ...................................13
WEBER®GRILL OUT™ HANDLE LIGHT ..............................13
LIGHTED CONTROL KNOBS .......................................13
bEFoRE USING THE GRILL ...........................14
FUEL LEVEL .................................................... 14
SLIDE OUT GREASE TRAY AND DISPOSABLE DRIP PAN................14
HOSE INSPECTION .............................................. 14
SNAP IGNITIoN oPERATIoN ..........................15
mAIN bURNER IGNITIoN & USAGE .....................16
MAIN BURNER IGNITION ..........................................16
TO EXTINGUISH .................................................16
MAIN BURNER MANUAL IGNITION .................................17
TO EXTINGUISH .................................................17
GRILLING TIPS & HELPFUL HINTS .....................18
PREHEATING ................................................... 18
COVERED COOKING ............................................. 18
DRIPPINGS AND GREASE .........................................18
FLAVORIZER®SYSTEM ...........................................18
SEAR STATION®.................................................18
cooKING mETHoDS .................................19
DIRECT COOKING ...............................................19
INDIRECT COOKING .............................................19
SIDE bURNER IGNITIoN & USAGE .....................20
SIDE BURNER IGNITION ..........................................20
TO EXTINGUISH .................................................20
SIDE BURNER MANUAL IGNITION ..................................21
TO EXTINGUISH .................................................21
SEAR STATIoN® IGNITIoN & USAGE ....................22
SEAR STATION®BURNER IGNITION .................................22
TO EXTINGUISH .................................................22
SEAR STATION®BURNER MANUAL IGNITION ........................23
TO EXTINGUISH .................................................23
USING THE SEAR STATION®.......................................23
SmoKER bURNER IGNITIoN & USAGE ..................24
SMOKER BURNER IGNITION.......................................24
TO EXTINGUISH .................................................24
SMOKER BURNER MANUAL IGNITION...............................25
TO EXTINGUISH .................................................25
USING THE SMOKER .............................................26
CLEANING THE SMOKER .........................................26
RoTISSERIE bURNER IGNITIoN & USAGE ...............27
ROTISSERIE BURNER IGNITION....................................27
TO EXTINGUISH .................................................27
ROTISSERIE BURNER MANUAL IGNITION............................28
TO EXTINGUISH .................................................28
IMPORTANT SAFEGUARDS ........................................29
OPERATING THE ROTISSERIE .....................................29
ROTISSERIE COOKING ...........................................30
ROTISSERIE MOTOR STORAGE ....................................30
ROTISSERIE SPIT STORAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
TRoUbLESHooTING .................................31
SIDE bURNER TRoUbLESHooTING ....................31
SEAR STATIoN® TRoUbLESHooTING ...................32
RoTISSERIE TRoUbLESHooTING ......................32
GRILL oUT™ HANDLE LIGHT TRoUbLESHooTING .......32
mAINTENANcE .....................................33
CLEANING......................................................33
WEBER®SPIDER/INSECT SCREENS ................................33
BURNER TUBE CLEANING ........................................33
REPLACING MAIN BURNERS ......................................34
SIDE BURNER MAINTENANCE .....................................35
ANNUAL MAINTENANCE ..........................................36

4
8
9
11
12
13
16
25
27
28
29
30
31
32
33
41
42
43
44
46
55
56
57
26
7
14
48
60
59
47
45
34
35
36
37
38
39
40
17
18
19
20
21
22
24
49
51
50
53
54
52
62
61
10
2
3
4
5
6
1SUMMIT_470_LP_US_012011
23
15
58
EXPLoDED VIEW

WWW.WEbER.com®5
1. Shroud Hardware
2. Shroud
3. Thermometer
4. Thermometer Bezel
5. Handle
6. Grill Out™ Handle Light
7. Rotisserie Motor
8. Rotisserie Bracket
9. Warming Rack
10. Cooking Grate
11. Flavorizer®Bar
12. Burner Tube
13. Side Table
14. Left Tool Holder
15. Control Panel Wiring Harness
16. Manifold
1 7. Control Panel
18. Small Knob Bezel
19. Small Knob
20. Large Knob
21. Large Knob Bezel
22. Sear Station®Knob
23. Battery Housing
24. Water Baffle / Heat Shield
25. Disposable Drip Pan
26. Slide Out Grease Tray
2 7. Catch Pan
28. Catch Pan Holder
29. Left Door
30. Door Handle
31. Right Door
32. Left Frame Panel
33. Bottom Panel
34. IR Burner Cover
35. Infrared Burner
36. IR Burner Box
3 7. IR Burner Igniter Wire
38. Thermocouple
39. IR Burner Hose
40. Rotisserie Spit Assembly
41. Smoker Box
42. Smoker Bar
43. Smoker Burner
44. Sear Station®Burner
45. Side Burner
46. Cookbox
4 7. Bulkhead
48. Manifold Hose
49. Side Burner Lid
50. Side Burner Table
51. Hose / Regulator
52. Right Tool Holder
53. Side Burner Hose
54. Frame Support
55. Back Panel
56. Right Frame Panel
5 7. Tank Scale
58. LED Tank Scale Assembly
59. Tank Glide
60. Matchstick Holder
61. Caster
62. Locking Caster
EXPLoDED VIEW LIST

6
WARRANTY
Weber-Stephen Products LLC (Weber) hereby warrants to the ORIGINAL PURCHASER of this
Weber®gas grill that it will be free of defects in material and workmanship from the date of purchase
as follows:
Aluminum castings: 25 years (2 years on paint; excludes fading)
Stainless steel shroud: 25 years
Porcelain-enameled shroud: 25 years
Stainless steel burner tubes: 10 years
Stainless steel cooking grates: 5 years no rust through or burn through
Stainless steel Flavorizer®bars: 5 years no rust through or burn through
Porcelain-enameled cast-iron cooking grates: 5 years no rust through or burn through
Porcelain-enameled cooking grates: 3 years no rust through or burn through
Porcelain-enameled Flavorizer®bars: 2 years no rust through or burn through
Infrared rotisserie burner: 2 years
All remaining parts: 2 years
when assembled and operated in accordance with the printed instructions accompanying it. Weber
may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN YOUR
SALES SLIP OR INVOICE.
This Limited Warranty shall be limited to the repair or replacement of parts that prove defective under
normal use and service and which on examination shall indicate, to Weber’s satisfaction, they are
defective. Before returning any parts, contact the Customer Service Representative in your area
using the contact information on our website. If Weber confirms the defect and approves the claim,
Weber will elect to replace such parts without charge. If you are required to return defective parts,
transportation charges must be prepaid. Weber will return parts to the purchaser, freight or postage
prepaid.
This Limited Warranty does not cover any failures or operating difficulties due to accident, abuse,
misuse, alteration, misapplication, vandalism, improper installation or improper maintenance or
service, or failure to perform normal and routine maintenance, including but not limited to damage
caused by insects within the burner tubes, as set out in this owner’s manual.
Deterioration or damage due to severe weather conditions such as hail, hurricanes, earthquakes
or tornadoes, discoloration due to exposure to chemicals either directly or in the atmosphere, is not
covered by this Limited Warranty.
There are no other express warrants except as set forth herein and any applicable implied warranties
of merchantability and fitness are limited in duration to the period of coverage of this express written
Limited Warranty. Some regions do not allow limitation on how long an implied warranty lasts, so this
limitation may not apply to you.
Weber is not liable for any special, indirect or consequential damages. Some regions do not allow the
exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not
apply to you.
Weber does not authorize any person or company to assume for it any other obligation or liability in
connection with the sale, installation, use, removal, return, or replacement of its equipment; and no
such representations are binding on Weber.
This Warranty applies only to products sold at retail.
WEBER-STEPHEN PRODUCTS LLC
Customer Service Center
1890 Roselle Road, Suite 308
Schaumburg, IL 60195
USA
For replacement parts call:
1-800-446-1071
Visit www.weber.com®, select your country of origin, and register your grill today. ◆

WWW.WEbER.com®7
Your Weber®gas barbecue is a portable outdoor cooking appliance. With the Weber®
gas barbecue you can grill, barbecue, roast and bake with results that are difficult to
duplicate with indoor kitchen appliances.The closed lid and Flavorizer®bars produce
that “outdoor” flavor in the food.
The Weber®gas barbecue is portable so you can easily change its location in your yard
or on your patio. Portability means you can take your Weber®gas barbecue with, if you
move.
Liquid Propane (LP) gas supply is easy to use and gives you more cooking control than
charcoal fuel.
• Theseinstructionswillgiveyoutheminimumrequirementsforassemblingyour
Weber®gas barbecue. Please read the instructions carefully before using your
Weber®gas barbecue. Improper assembly can be dangerous.
• Notforusebychildren.
• Iftherearelocalcodesthatapplytoportablegasgrills,youwillhavetoconformto
them. Installation must conform with local codes or, in the absence of local codes,
with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and
Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code,
B149.2, or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and
CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
• ThepressureregulatorsuppliedwiththeWeber®gas barbecue must be used.This
regulator is set for 11 inches of water column (pressure).
• ThisWeber®gas barbecue is designed for use with liquid propane (LP) gas only. Do
not use with natural (piped in city) gas.The valves, orifices, hose and regulator are for
LP gas only.
• Donotusewithcharcoalfuel.
• Checkthattheareaunderthecontrolpanelandtheslideoutgreasetrayarefree
from debris that might obstruct the flow of combustion or ventilation air.
• TheareasaroundtheLPcylindermustbefreeandclearfromdebris.
• Replacementpressureregulatorsandhoseassembliesmustbethosespecifiedby
Weber-Stephen Products LLC. ◆
CANADIAN INSTALLATION
These instructions, while generally acceptable, do not necessarily comply with the
Canadian Installation codes, particularly with piping above and below ground. In
Canada the installation of this appliance must comply with local codes and/or Standard
CSA-B149.2 (Propane Storage and Handling Code). ◆
OPERATING
mWARNING: Only use this barbecue outdoors in a well-
ventilated area. Do not use in a garage, building, breezeway
or any other enclosed area.
mWARNING: Keep ventilation openings for cylinder enclosure
free and clear from debris.
mWARNING: Your Weber®gas barbecue shall not be used
under overhead combustible construction.
mWARNING: Your Weber®gas barbecue is not intended to be
installed in or on recreational vehicles and/or boats.
mWARNING: Do not use the barbecue within 24 inches of
combustible materials.
mWARNING: The entire cookbox gets hot when in use. Do not
leave unattended.
mWARNING: Keep electrical supply cord and the fuel supply
hose away from heated surfaces.
mWARNING: Keep the cooking area clear of flammable vapors
and liquids such as gasoline, alcohol, etc., and combustible
materials.
mWARNING: Never store an extra (spare) LP cylinder under or
near the Weber®gas barbecue.
mWARNING: The LP cylinder used with your barbecue must
be with a listed OPD (Overfilling Prevention Device) and
a QCC1 or Type 1 (CGA810) cylinder connection. The
cylinder connection must be compatible with the barbecue
connection. ◆
STORAGE AND/OR NONUSE
• ThegasmustbeturnedoffattheliquidpropanecylinderwhentheWeber®gas
barbecue is not in use.
• WhentheWeber®gas barbecue is stored indoors, the gas supply must be
DISCONNECTED and the LP cylinder stored outdoors in a well-ventilated space.
• LPcylindermustbestoredoutdoorsinawell-ventilatedareaoutofreachofchildren.
Disconnected LP cylinder must not be stored in a building, garage or any other
enclosed area.
• WhentheLPcylinderisnotdisconnectedfromtheWeber®gas barbecue, the
appliance and LP tank must be kept outdoors in a well-ventilated space.
• TheWeber®gas barbecue should be checked for gas leaks and any obstructions
in the burner tubes before using. (Refer to “MAINTENANCE/ANNUAL
MAINTENANCE”).
• Checkthattheareasunderthecontrolpanelandthedriptrayarefreefromdebris
that might obstruct the flow of combustion or ventilation air.
• TheSpider/Insectscreensshouldalsobecheckedforanyobstructions.(Referto
“MAINTENANCE/ANNUAL MAINTENANCE”). ◆
GENERAL INSTRUcTIoNS

8
GAS INSTRUcTIoNS
SAFE HANDLING TIPS FOR LIQUID PROPANE GAS CYLINDERS
• LiquidPropane(LP)gasisapetroleumproductasaregasolineandnaturalgas.LP
gas is a gas at regular temperatures and pressures. Under moderate pressure, inside
a cylinder, LP gas is a liquid. As the pressure is released, the liquid readily vaporizes
and becomes gas.
• LPgashasanodorsimilartonaturalgas.Youshouldbeawareofthisodor.
• LPgasisheavierthanair.LeakingLPgasmaycollectinlowareasandprevent
dispersion.
• Tofill,taketheLPcylindertoagaspropanedealer,orlookup“gas-propane”inthe
phone book for other sources of LP gas.
mWARNING: We recommend that your LP cylinder be filled
at an authorized LP gas dealer, by a qualified attendant,
who fills the tank by weight. IMPROPER FILLING IS
DANGEROUS.
• AirmustberemovedfromanewLPcylinderbeforetheinitialfilling.YourLPdealeris
equipped to do this.
• TheLPcylindermustbeinstalled,transported,andstoredinanuprightposition.LP
cylinders should not be dropped or handled roughly.
• NeverstoreortransporttheLPcylinderwheretemperaturescanreach125°F(toohot
to hold by hand — for example: do not leave the LP cylinder in a car on a hot day).
Note: A refill will last about 18-20 hours of cooking time at normal use.The fuel scale,a
feature on some of our grills, will indicate the propane supply so you can refill before
running out.You do not have to run out before you refill.
• Treat“empty”LPcylinderswiththesamecareaswhenfull.EvenwhentheLPtank
is empty of liquid there still may be gas pressure in the cylinder. Always close the
cylinder valve before disconnecting.
mCAUTION: Place dust cap on cylinder valve outlet whenever
the cylinder is not in use. Only install the type of dust cap
on the cylinder valve outlet that is provided with the cylinder
valve. Other types of caps or plugs may result in leakage of
propane.
• DonotuseadamagedLPcylinder.DentedorrustyLPcylindersorLPcylinders
with a damaged valve may be hazardous and should be replaced with a new one
immediately.
• ThejointwherethehoseconnectstotheLPcylindermustbeleaktestedeachtime
the LP cylinder is reconnected. For example, test each time the LP cylinder is refilled.
• Besuretheregulatorismountedwiththesmallventholepointeddownwardsothatit
will not collect water. This vent should be free of dirt, grease, bugs etc.
• ThegasconnectionssuppliedwithyourWeber®gas appliance have been designed
and tested to meet 100% CSA and ANSI requirements.
mWARNING: Replacement LP tanks must match the regulator
connection supplied with this Weber®gas appliance.
Liquid Propane Cylinder Requirements
• ChecktobesurecylindershaveaD.O.T.certification(1), and date tested (2) is within
five years of use.Your LP gas supplier can do this for you.
• AllLPtanksupplysystemsmustincludeacollartoprotectthecylindervalve.
• TheLPcylindermustbea20-lb.sizeapproximately18¼incheshigh,12¼inchesin
diameter.
• ThecylindermustbeconstructedandmarkedinaccordancewiththeSpecifications
for LP - Gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the
National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes or
Transportation of Dangerous Goods; and Commission, as applicable.
Canadian Liquid Propane Cylinder Requirements
Note:Your retailer can help you match a replacement tank to your barbecue.
• TheLPcylindermustbeconstructedandmarkedinaccordancewiththe
specifications for LP gas cylinders, T.C. ◆

WWW.WEbER.com®9
GAS INSTRUcTIoNS
1
234
5
1
2345
TYPE 1 coNNEcTIVE coUPLING
1Type 1 Valve
2Hand Wheel
3External Thread
4Thermally Sensitive Nut
5Propane Regulator
The Liquid Propane Cylinder
All Weber®liquid propane gas grill regulators are equipped with a UL-Listed tank
connection as per the latest edition of ANSI Z21.58. This will require a liquid propane
tank that is similarly equipped with a Type 1 connection in the tank valve. This Type 1
coupling allows you to make a fast and totally safe hookup between your gas grill and
your liquid propane tank. It eliminates the chance of leaks due to a POL fitting that is
not properly tightened. Gas will not flow from the tank unless the Type 1 coupling is fully
engaged into the coupling.
mWARNING: Make sure that the LP cylinder valve is closed.
Close by turning valve clockwise.
mDANGER
Do not use an open flame to check for gas leaks. Be sure
there are no sparks or open flames in the area while you
check for leaks. Sparks or flames will result in a fire or
explosion which can cause serious bodily injury or death,
and damage to property.
IMPORTANT LP CYLINDER INFORMATION
mDANGER
NEVER store a spare LP cylinder under or near Weber®gas
appliances. NEVER fill the tank beyond 80% full. Failure to
follow these statements exactly may result in a fire causing
death or serious injury.
Weber®gas appliances are equipped for a cylinder supply system designed for vapor
withdrawal.
mWARNING: Only use Weber®gas appliances outdoors in
a well-ventilated area. Do not use in a garage, building,
breezeway or any other enclosed area.
The proper filling methods for the filling of your cylinder are by weight or volume, as
described in NFPA 58. Please make sure your filling station fills your LP cylinder by
weight or volume. Ask your filling station to read purging and filling instructions on the LP
cylinder before attempting to fill. ◆
LEAK CHECK PREPARATION
Check That All Burner Valves Are Off
Valves are shipped in the OFF position, but you should check to be sure that they are
turned off. Check by pushing down and turning clockwise. If they do not turn, they are off.
If they do turn, continue turning them clockwise until they stop, then they are off.

10
A) Locate hose retention clip (1) on regulator hose. Secure into slot (2) on underside of
tank scale.
mWARNING: The hose must be secured to the tank scale
with the Hose Retention Clip. Failure to do so could cause
damage to the hose resulting in a fire or explosion which
can cause serious bodily injury or death, and damage to
property.
Some LP tanks have differing top collar assembles. (The top collar is the metal
protective ring around the valve.) One series of tanks mount with the valve facing front
(3). The other tanks mount with the valve facing away from the fuel scale (4). Weber
recommends the use of cylinder manufacturer’s Manchester and Worthington, with a
47.6 lb water capacity. Other cylinders may be acceptable for use with the appliance
provided they are compatible with the appliance retention means (see illustrations).
The LP cylinder is installed inside the base cabinet, on the tank scale (right side).
B) Open base cabinet doors.
C) Loosen cylinder lock wing nut. Swing cylinder lock up (5).
D) Turn the LP cylinder so the opening of the valve is either to the front or side of the
Weber®gas barbecue.
E) Lift tank up into position on the tank scale (6).
F) Swing the cylinder lock down.Tighten the wing nut.
Connect The Hose To The Cylinder
A) Remove the plastic dust cover from the valve.
B) Screw the regulator coupling onto the tank valve, clockwise, or to the right. Hand-
tighten only (7).
Note:This connection tightens clockwise and will not allow gas to flow unless the
connection is tight.The connection requires tightening by hand only.
mWARNING: Do not use a wrench to tighten the connection.
Using a wrench could damage the regulator coupling and
could cause a leak.
GAS INSTRUcTIoNS
6
1
2
3 4
5 5
7
