Wecon LX3V-EY Series User manual

WECON
LX3V-EY
MODULES
Wecon Technology Co.Ltd.,
SITE: http://www.we-con.com.cn/en
Technical Support: [e-mail]
Skype: fcwkkj
Phone: [phone]

LX3V-EY Extension module
1. Naming rule
Naming rule of LX3V I/O output extension module:
LX3V - 16 E Y
① ② ③ ④ ⑤
①Wecon series programming logic controller
②Extension output point
③Extension module
④Extension output (Y)
⑤T: transistor ; R:relay
2. External dimensions
Weight:Approx 0.3kg (0.661bs) Dimensions:mm (inches)
①Extension cable and connector
②Power LED:Light when connect to 24V
③State LED:Light when normal condition
④Module name
⑤Analog signal output terminal
⑥Extension module interface
⑦DIN rail mounting slot
⑧DIN rail hook
⑨Mounting holes(φ4.5)
2.1 Using crimp terminations

3.Output Specification
Item
Relay output
Transistor output
Mode
LX3V-16EYR
LX3V-16EYT
Output circuit
Power supply
Less than AC25V or DC30V
DC5V ~ 30V
Circuit insulation
Mechanical
Photo-coupling
LED
LED ON when relay is energized
LED on when Photo-coupling is driven
Load
Resistance
2A/ one point
0.5A/ one point
inductance
8A/ two point COM
0.8A/ two point
Lamp
8A/ eight point COM
1.6A/ eight point
Leakage current
-----
0.1mA/DC30V
Minimum load
DC5V 2mA reference value
-----
OFF->ON
About 10ms
Less than 0.2ms
ON->OFF
