Weed Razers 580110 User manual

Product Contents................ 2
Assembly Instructions . . . . . . . . . . .3-4
Operating Instructions ............ 4
Blade Sharpening Instructions .....5-6
Safety Instructions............... 7
Replacement Parts .............. 8
Product Warranty................ 8
Table of Contents:
Item 580110
Product Manual

www.weedrazers.com
Important Information:
2
Please read these instructions thoroughly before use. Failure to follow instructions
may result in equipment damage or failure, losses, injury or death.
WARNING:
To reduce the risk of injury:
•The Weed Razer is designed for cutting submerged, partially emergent,
or emergent aquatic vegetation from underwater. Any other use is strictly
prohibited. Before using the Weed Razer, please read this manual carefully to
understand the proper use of the unit.
•The Weed Razer blade(s) are razor sharp. The blade covers should be on while
assembling the tool and when tool is not in use. Failing to comply can result in
severe lacerations, dismemberment, and even death.
SAFETY FIRST:
Instructions containing a warning within this manual are marked with a symbol.
Keep out of reach of children.
Do not use with children in immediate area.
IMPORTANT: Jenlis, Inc®is not responsible for equipment damage or failure,
losses, injury or death resulting from failure to follow safety
precautions, misuse or abuse of equipment.
C
L
DGI
A
B
F
E
K
H
J
PART QTY
A Handle 1
B Angled Handle 1
C Blades 2
D Support Bracket 2
E Handle Connector 1
F Weed Deector 2
PART QTY
G Nylon Spacer 2
H 1.5" Bolt & T-Nut 1 ea.
I 1.5" Bolt, Nut, Washer 1 ea.
J 1.2" Bolt, Nut, Washer 5 ea.
K Rope 25' 1
L Blade Sharpener 1
PRODUCT CONTENTS:

www.weedrazers.com 3
Notes:
Assembly & Instructions
Tools Required:
• #3 Phillips Screwdriver • 7/16” Wrench
Step 1
Insert 4 of the 1.2” Bolts (J) into the four outermost
holes of one of the triangular Support Brackets (D)
making sure to slide the bolts through the domed
side, then place the bracket on a flat work surface
with the screw heads down. Place a Nylon Spacer
(G) on each of the bolts at the base of the triangular
bracket.
Step 2
Place each Blade (C) onto the Support Bracket (D)
so that each blade edge faces outward and the
holes seat over the two bolts at the narrow end
of the triangular bracket. Next, seat the second
triangular Support Bracket (D) over the assembly
with the domed side facing up and place a washer
and nut on each of the four bolts—be sure to
simply hand tighten at this time.
Step 3
Slide the blade covers back about 2” to make
room for the handle. Take the two halves of the
Weed Deflector (F) and snap together at the pins
molded into each piece. Slip the Weed Deflector
(F) onto the Angled Handle (B) at the end with
two holes making sure that the hole in the Weed
Deflector aligns with the second hole from the end,
then slide the Angle Handle (B) into the Support
Bracket (D) so that the holes align. At this time, the
blade covers can be slid back into place for safety
and will ride up over the Weed Deflector slightly.

www.weedrazers.com
4
Step 4
Next insert a 1.2” bolt (J) into the hole at the base
of the Support Bracket and a 1.5” bolt (I) through
the hole with the Weed Deflector (F), then secure
each with a washer and nut. Tip the assembly
upright and tighten all fasteners securely using a
Phillips screwdriver and 7/16” wrench.
Step 5
Handle Assembly—Press the spring-loaded
buttons on one end of the Handle Connector (E),
slide into the open end of the Handle (B) and turn
until the buttons snap into the holes in the handle.
Repeat this process for the second half of the
handle.
Step 1
Throw the Weed Razer out and over area to be
cleared. If you are on a dock, tie the rope to a post
so you don’t throw too far.
Step 2
Let the Weed Razer sink.
Step 3
Pull back in using short, hard, jerking motions.
Repeat as many times as needed to clear your
weeds.
Assembly & Instructions (con’t)
Operating Instructions

www.weedrazers.com 5
Step 1
Always wear cut resistant gloves when handling
the Weed Razer.
Step 2
Stand the assembled Weed Razer up and grip the
handle in one hand, or rest the handle of the Weed
Razer against a wall or building.
Step 3
Kneel or sit in front of the Weed Razer in a stable
position (Figure 1). Do not sharpen while standing
or leaning over the cutting edge.
Step 4
Grip the handle of the Sharpener (L) so that the
guard is between your hand and the blade surface.
Step 5 To remove burs from the blade surface,
use the inserts on either side of the tool (1).
Step 6
To sharpen BOTH SIDES of the blade at once, use
the carbide insert (3) with two pointed tips that
form a V. Run the sharpener down the cutting edge
in four to six strokes using less pressure as the
edge gets sharper.
Notes:
Blade Sharpening Instructions
Fig. 1
1
2
3
4
WARNING

www.weedrazers.com
6
Notes:
Blade Sharpening Instructions (con’t)
Step 7
To sharpen ONE SIDE of the blade only, use the
insert (2) with one pointed carbide tip and one
rounded metal guide. Press the inside edge of the
carbide insert against the edge of the blade you
want to sharpen. Run the carbide over the entire
edge four to six times with consistent pressure.
Repeat this process for the other side of the blade.
NOTE: We recommend using the process in
STEP 6 for greater consistency in sharpening.
Step 8
In the end of the sharpener’s handle (4), you will
find a screw-in felt pad and oil for lubricating
the blades. We encourage you to use the Weed
Razer Sharpening Tool for all of your sharpening
needs. When you are sharpening other tools that
may rust or corrode, add a few drops of oil to the
lubricating pad and apply to each blade after every
sharpening.

www.weedrazers.com 7
Notes:
Safety Instructions
1. Always wear cut resistant gloves when
handling the Weed Razer, especially during
and after removal of the blade covers.
2. The Weed Razer is to be operated by hand
only. Do not pull the Weed Razer behind a
boat or any other machine driven equipment.
Doing so will void the warranty and damage
your Weed Razer.
3. Do not use with children in immediate area.
4. Do not use the Weed Razer when humans
and/or animals are present within 100 feet
from the launch point.
5. Do not place or use near electrical wires or
cords.
6. Never touch the sharp edges of the blades
with bare hands at any time.
7. Leave blade covers on the cutting edges
when not in use.
8. Check all bolts, connections, and rope before
use.
9. Avoid areas with underwater structures.
10. When not in use, store in a safe location out
of the reach of children.
NOTE: Failing to comply can result in severe
lacerations, dismemberment, and even death.
Do not pull behind a boat
Do not pull behind a vehicle
or any mechanical device
Do not use when humans or animals are within
100 feet from the launch point
WARNING

8View other great products on-line at www.weedrazers.com V1
Replacement Parts
ONE YEAR MANUFACTURER’S WARRANTY:
1-Year Manufacturer’s Warranty – Jenlis, Inc. warrants this product to be free from
defects in workmanship and materials, under normal, non-commercial use and conditions,
for a period of (1) one year from the original invoice date. Warranty Limitations – Damage
resulting from use in commercial environment, misuse, abuse, negligence, and/or accidents.
The manufacturer agrees, at its option during the warranty period, to repair any defect in
material or workmanship, or to furnish a repaired or refurbished product without charge. All
warranty claims must be sent to Jenlis, at the customer’s expense. Return shipping will be
pre-paid. All returns must be pre-approved. Please visit www.weedrazer.com/warranty for
an RMA number prior to returning product. Returns without RMA’s will be refused.
Replacement parts can be found online at www.weedrazers.com
