Weh TSF4 User manual

WEH®- We Engineer Hightech
Type TSF4
Operating instructions ⋅Betriebsanleitung Date: 11/21
WEH®Filter for use in a gaseous media stream and for installation
in gas mixing plants
WEH®Filter für den Einsatz in einem gasförmigen Medienstrom
und zum Einbau in Gasmischanlagen

Die deutsche Version ist das Original.
Hersteller: WEH GmbH Verbindungstechnik - im Nachfolgenden „WEH“ genannt.
The German version is the original.
Manufacturer: WEH GmbH Precision Connectors – hereinafter referred to as “WEH”.
LANGUAGES
TYPE TSF4 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
WEH®Filter for use in a gaseous media stream and for installation in gas
mixing plants
TYP TSF4 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 26
WEH®Filter für den Einsatz in einem gasförmigen Medienstrom und zum
Einbau in Gasmischanlagen
AE
DE

CONTENTS
1. INTRODUCTION 6
1.1 For your guidance 6
1.2 General information 7
1.3 Warranty and liability 7
1.4 General safety instructions 8
1.5 Definition of qualified personnel 9
2. INTENDED USE 9
3. PRODUCT OVERVIEW / PRODUCT DESCRIPTION 10
4. TECHNICAL DATA 11
5. STORAGE 12
5.1 Safety instructions for proper storage 12
5.2 Storage 13
Type TSF4
WEH®Filter for use in a gaseous media stream and for installation
in gas mixing plants
MD-10012-L51-R1.1.0-03
Page 4
Operating instructions
AE

The German version is the original.
Manufacturer: WEH GmbH Precision Connectors - hereafter referred to as 'WEH'.
6. REQUIRED TOOLS 14
7. INSTALLATION 15
7.1 Safety instructions for installation 15
7.2 Installing the filter 16
8. COMMISSIONING 16
9. INSPECTION | MAINTENANCE 17
9.1 Safety instructions for inspection and maintenance 17
9.2 Note on the cleaning interval of the wire filter insert 18
9.3 Overview of minimum intervals for inspection and maintenance 19
9.4 Maintenance 19
10. DISPOSAL 25
11. ACCESSORIES | SPARE PARTS 25
MD-10012-L51-R1.1.0-03 Page 5
Operating instructions AE

1. INTRODUCTION
Dear Customer,
thank you for deciding to use our products.
The WEH®TSF4 Filter is designed to filter dirt particles from the gas flow.
Observe and follow all instructions and warnings in these operating instructions�
Non-observance may result in personal injury and/or property damage�
1�1 For your guidance
The markings and symbols contained in these operating instructions have the following
meanings:
- Items are indicated by a dash
ÎCalls for action are indicated by an arrow
Figures
The illustrations and/or images used in these operating instructions are particularly provided
for illustrative purposes only and may differ in some details from the actual product. For
binding information, please refer to your individual orders.
Abbreviations
For explanation of abbreviations and definitions of terms see Technical Appendix of the
corresponding catalog or www.weh.com
Definition of signal words
Caution: A section marked with 'Caution' warns you about hazards that could result in a
slight, usually reversible personal injury if you do not comply with this instruction.
Attention: Sections marked ‘Attention’ warn you of situations that could lead to property
damage and disruptions in operation if you do not comply with the instruction.
Note: Sections marked ‘Note’ indicate that malfunctions in operation may occur if you
do not comply with the instruction.
Please note: Sections marked with ‘Please note’ provide you with additional information
for smooth operation.
MD-10012-L51-R1.1.0-03
Page 6
Operating instructions
AE

1�2 General information
ÎFirst read these operating instructions to avoid misuse and resulting damage.
- In these operating instructions you will find all the necessary information and instruc-
tions for the WEH®Product.
ÎThen check the contents of your delivery. Each delivery must contain:
- a delivery note
- an original WEH Test report (not applicable to spare parts)
- WEH operating instructions
ÎIf any documents are missing, please contact WEH or your responsible distributor.
1�3 Warranty and liability
- Our General Terms and Conditions apply.
ÎRead these operating instructions and safety instructions carefully and follow the
information contained therein.
- The information in these operating instructions reflects to the state of knowledge at
the time of printing. Failure to comply may void the warranty. Any side agreements to
these operating instructions require the written approval of the Head of the Quality
Department at WEH.
- Violation of these operating instructions result in the lapse of all warranty claims.
WEH will accept no liability for consequential damage, in particular damage due to
personal injury and/or other legal interests.
Caution: WEH®Products may only be repaired by WEH.
ÎContact WEH or the responsible distributor if the WEH®Product requires mainte-
nance. Special maintenance work that may be performed by the operator is described
in these operating instructions and is specially marked.
ÎOnly use original WEH®Spare parts. These are exactly suited to the intended appli-
cation and subject to strict quality controls.
- You are responsible for the correct operation of the replacement or repair. WEH is not
responsible for the performance or any damage and/or losses arising from it. WEH
assumes no guarantee, warranty, product liability or other liability for any replace-
ment or repair of the WEH®Product performed by you or a third party. If you or a
third party does not have the necessary skills and qualification for proper perfor-
mance, you must refrain from performing replacement or repair. Otherwise, there is a
particular risk of endangering yourself and third parties.
MD-10012-L51-R1.1.0-03 Page 7
Operating instructions AE

1�4 General safety instructions
ÎAlways comply with all applicable local, national and international requirements,
stipulations, decrees, laws, standards, provisions, directives, norms, regulations,
prohibitions and instructions as well as all applicable industrial, quality and technical
standards. In particular, make sure that you and all users comply with the applicable
requirements related to occupational health and safety as well as product safety
requirements and that all required permissions, certificates and approvals have been
obtained.
ÎThese operating instructions should be provided to anyone responsible for the instal-
lation, operation and maintenance of this WEH®Product.
ÎContact WEH before using the WEH®Product if the instructions in these operating
instructions are unclear in any way.
ÎTake appropriate safety measures if operating conditions exist that could endanger
the user.
ÎIn case of any damage that may affect the proper functioning of the WEH®Product, do
not use the WEH®Product until the situation has been clarified. Disassembly of the
WEH®Product may only be performed by WEH.
ÎComply with the assembly data indicated in these operating instructions. Tightening
with higher torques/assembly turns can result in damage or even fractures when the
system is pressurized.
ÎDo not use any auxiliary materials or cleaning agents other than those indicated in
these operating instructions. Using other auxiliary materials or cleaning agents may
cause damage to the WEH®Product or to downstream components.
ÎKeep the WEH®Product free of oil and grease when using oxygen.
Caution: If you do not comply with this, there is a rist of fire.
ÎDo not operate the WEH®Product in an environment where ammonia vapors may be
present.
- WEH is not responsible for damage caused by external forces or other external
influences.
- It is assumed that only transport and storage facilities suitable for the storage of the
WEH®Product are used.
MD-10012-L51-R1.1.0-03
Page 8
Operating instructions
AE

1�5 Definition of qualified personnel
- Qualified personnel, as defined by these instructions, are persons who, based on
their professional training, their knowledge (including the relevant standards and
regulations), experience and manual skills, can independently assess and properly
perform assigned work tasks (in conjunction with WEH®Products) and can thus
independently recognize and prevent potential dangers at an early stage.
2. INTENDED USE
- The WEH®TSF4 Filter is exclusively designed to filter dirt particles from the gas flow.
ÎAlways ensure that the WEH®Product is used only within the range of its intended use.
Please note in particular the technical data of the WEH®Product in Chapter 4 as well
as the marking on the WEH®Product itself.
- This WEH® Product has been specially developed for your application and require-
ments that you specified when placing your order. The filter only works properly
together with your ports or medium and may only be attached to this ports, or may
only be operated using this medium. Operation with a mixture of media can lead to
damages due to residue or contamination, particularly in combination with oxygen. For
this reason, make sure that the necessary framework conditions (e.g. cleanliness) are
met for operation with the respective medium.
ÎFor the medium oxygen, use only the filter provided by WEH for this purpose according
to Chapter 3 .
- This WEH®Product is generally classified as pressure accessory in accordance
with Article 2 (5) of the Pressure Equipment Directive 2014/68/EU and is consid-
ered to be similar to piping. This WEH®Product may not be used as safety acces-
sory. Furthermore, it is pointed out, that this WEH®Product is designed and placed
on the market in accordance with the requirements of Article 4 (3) of the Pressure
Equipment Directive 2014/68/EU. The assessment with regard to a different classi-
fication can, however, be made on request.
Caution: Any use beyond the scope of application is considered as unintended use
and may result in personal injury and/or property damage.
MD-10012-L51-R1.1.0-03 Page 9
Operating instructions AE

3. PRODUCT OVERVIEW / PRODUCT DESCRIPTION
Product Overview
Series Medium Pressure range (PS) Part no�
Inert gases* Oxygen 420 bar
TSF4
X X C1-82292-X01
X X C1-125920-X01
X X C1-92654-X01
*Inert gases are all noble gases and nitrogen. Other gases which are also considered inert under certain circumstances
(e.g. CO2, sulfur hexaflouride) must not be operated with the filter without consulting WEH.
Product description
Pos� Description
1 Outlet housing
2 Inlet housing
3 Wire filter insert (inside)
B2
3B1
1
2
Definition of ports
B1 Media inlet
B2 Media outlet
MD-10012-L51-R1.1.0-03
Page 10
Operating instructions
AE

4. TECHNICAL DATA
Please note: Depending on the application, the technical data of your WEH®Product
may differ from these operating instructions. Please therefore observe the marking on
the WEH®Product itself.
Characteristics Basic version
Nominal bore (DN) 12 mm
Max. allowable operat-
ing pressure PS 420 bar
Medium Inert gases or oxygen (according to Chapter 3)
Temperature range -20 °C to +85 °C
-10°C to +60°C (O2)
Part materials Brass and stainless steel or Monel® (O2)
Sealing materials Housing seal in EPDM (C1-82292-X01 and C1-92654-X01)
Housing seal in FKM (C1-125920-X01)
Design Incl. unscrewable wire filter insert (40 micron)
Conformity/
/Approval/
Approvals
Type approval for suitability against adiabatic compression avail-
able
Other designs on request
MD-10012-L51-R1.1.0-03 Page 11
Operating instructions AE

5. STORAGE
5�1 Safety instructions for proper storage
ÎMake sure that you always comply with these following safety instructions and
storage time.
Attention: Improper storage of the WEH®Product can significantly reduce the maxi-
mum service life.
ÎProtect the WEH®Product against damage, contamination, inappropriate storage
and excessive temperature fluctuations.
ÎStore the WEH®Product, the accessories and spare parts in the original packaging
until they are used for the first time and during periods when they are not being used.
ÎStore the WEH®Product within a temperature range of 0 °C up to +25 °C. Storage
temperatures outside this range may affect the service life of the WEH®Product.
ÎDo not store the WEH®Product in the vicinity of heat sources. Avoid humidity and
condensation. The ideal relative air humidity for storage is under 60%.
ÎDo not store the WEH®Product together in the same space with solvents, chemicals,
acids, fuels or disinfectants.
ÎProtect the WEH®Product against light, in particular direct sunlight, oxygen, ozone,
heat, UV radiation, and other negative environmental influences. The service life of
parts made of elastomer or plastic may be substantially reduced by such environ-
mental factors.
ÎDo not stack WEH®Products. For storage and retrieval, follow the first-in-first-out
(FIFO) principle.
ÎDo not store the WEH®Product in an environment where ammonia vapors may be
present.
MD-10012-L51-R1.1.0-03
Page 12
Operating instructions
AE

5�2 Storage
ÎFollow the safety instructions in Chapter 5.1 and observe the following storage
times. The appropriate storage period applies from the date of delivery (i.e. the date
of invoicing or goods issue date as recorded by WEH or its distributor). If the
WEH®Product is installed in a complete system, the storage time depends on the
component with the shortest storage time.
Up to 3 years
ÎBefore use, check the surfaces of the seals for cracks.
Attention: Any elastomer seals with fine cracks on the surface must
be replaced.
Note: If you should have any doubts about the aging state of the
stored WEH® Product, please contact WEH.
Attention: Before commissioning, check the WEH® Product for leak
tightness. On this topic, see Chapter 7. Installation on page 15.
> 3 years - Before use, all elastomer seals must be replaced.
ÎFor this, send the WEH®Product to WEH for maintenance.
MD-10012-L51-R1.1.0-03 Page 13
Operating instructions AE

6. REQUIRED TOOLS
Part no� Description Installation Maintenance &
Lubrication
-- Suitable open-ended wrench
(suitable for the relevant wrench sizes) X
-- Calibrated torque wrench
(suitable for the corresponding torque) X
-- Suitable open-ended wrench insert (suitable for the relevant wrench sizes and torque
wrench) X
Suitable roller fork wrench insert
(suitable for the relevant wrench sizes and torque
wrench) X
Ratchet adapter switchable
(suitable for the torque wrench and the hexagonal
insert) X
Hexagonal insert A/F6
(suitable for the relevant ratchet adapter) X
-- Vice X
-- Allen key A/F6 X
-- Rolling fork wrench X
E99-4 WEH®Lubricant for inert gases X
E99-10 WEH®Lubricant for oxygen X
E99-9 WEH®Degreasing spray X
E34-120513 WEH®Assembly tool X
E34-120514 WEH®Assembly tool X
W136538 WEH®O-ring picker set*X
*The WEH® O-ring picker is manufactured from plastic and has to be considered as a
consumable product.
MD-10012-L51-R1.1.0-03
Page 14
Operating instructions
AE

7. INSTALLATION
7�1 Safety instructions for installation
ÎCheck the information provided in these operating instructions and the label on the
WEH® Product. The information must conform to your application.
ÎOnly connect the WEH®Product to faultless connections.
ÎCheck the WEH®Product for transport damages, contamination and other damage. If
you should detect anything wrong with the WEH®Product, it may no longer be used.
Replace the WEH®Product or send it to WEH for maintenance.
ÎRemove transport securing devices (such as protection caps) before installing the
WEH®Product. Transport securing devices serve the purpose of protecting the
product and connection ports during transport and storage. The transport securing
devices are not, for example, designed to withstand pressure or to be used as plugs.
ÎEnsure that the system is depressurized. Installation must only be effected in
depressurized condition.
ÎAvoid using excessively short media lines and narrow bending radii. Lateral forces
may cause leakages or damage to components and make it more difficult to attach
the WEH®Connector properly.
ÎThe WEH®Product is mounted between two pipe ends.
Attention: Observe the direction of the flow – the flow direction is marked on the
product.
ÎSelect the operating pressure so that any pressure peaks that occur do not exceed
the maximum permissible operating pressure of the products.
ÎProtect valves and pipelines used at temperatures above 50°C with insulation or
mark them with a warning sign.
ÎDo not vent flammable, toxic, corrosive or other hazardous materials into a room.
- Inert gases vented into a room can be hazardous to health.
Ensure that there is adequate ventilation.
- Oxygen vented into a room endangers health and can cause property damage if it
accumulates in the room air. Oxygen has an oxidizing effect and can lead to increased
combustion processes if the air content is increased!
Ensure that there is adequate ventilation.
- Secure the system outlets when pressurizing the system for the first time so that
no medium can escape uncontrolled!
MD-10012-L51-R1.1.0-03 Page 15
Operating instructions AE

ÎBefore installation, check if the counterparts are designed to withstand the assembly
data (see Chapter 7.2 Installing the filter) that WEH determined for this WEH®Product.
Note: The indicated assembly data (tightening torques, assembly turns etc.) are values
that apply only to the components delivered by WEH.
7�2 Installing the filter
Please note: Subsequent mentions of descriptions and position numbers refer to
Chapter 3. Product overview / product description on page 10.
ÎUnscrew the protection caps from the ports.
ÎWhen mounting the filter, hold against the wrench flats with an open-ended wrench.
ÎInstall the filter into your system at ports ‘B1’ and ‘B2’. Place the ports of the media
line straight and screw them on pressure-tight without tilting.
Attention: Please note the flow direction marked.
Tightening torque 60 Nm +10% (UNF 1 3/8“-12 male thread)
8. COMMISSIONING
- Before commissioning, check the WEH®Product for leak tightness.
ÎApply the operating pressure slowly to the WEH®Product slowly.
ÎUse a foaming leak detection agent to check the WEH®Product and connection to the
product for leak tightness. The test points must be sealed tight without any bubbles.
Caution: Observe the technical data in Chapter 4 and all appropriate technical stan-
dards and applicable legal requirements.
Attention: Do not use a leak detection spray that contains ammonia, since this could
cause
corrosion of the product.
MD-10012-L51-R1.1.0-03
Page 16
Operating instructions
AE

9. INSPECTION | MAINTENANCE
Please note: Subsequent mentions of descriptions and position numbers refer to
Chapter 3. Product overview / product description on page 10.
Attention: If damage to the WEH®Product, restrictions to its functionality or leaks are
found, the WEH®Product must be sent to WEH for maintenance.
9�1 Safety instructions for inspection and maintenance
- The WEH®Product must be depressurized and dismantled for maintenance work.
ÎCheck the WEH®Product for leakage after maintenance work. Please refer to Chapter
7. Installation on page 15.
- For inspection purposes, it is not necessary for the WEH®Product to be dismantled,
but it must be depressurized.
ÎOnly use original WEH®Spare parts. These are exactly suited to the intended applica-
tion and subject to strict quality controls.
ÎDo not damage sealing surfaces or sealing components.
ÎBefore reassembling; check the components, threads and, if present, the sealing
surfaces for damage and contamination. Should you find any damage, replace the
WEH®Product or send it to WEH for maintenance. Stop using the WEH®Product
immediately.
ÎAssemble the WEH®Spare parts absolutely free of oil, grease and dust.
ÎBefore each reassembly, clean the WEH®Product and the corresponding
components by blowing off with oil-free compressed air and remove any adhering
dirt using a damp, soft and lint-free cloth.
Do not use solvents. Use only clean water as cleaning agent.
Attention: Only use oil-free compressed air to blow off the dirt.
Note: Make sure that no cleaning agent enters the gas channel.
ÎObserve the specified tightening torques during maintenance.
ÎClean the wire filter insert (Pos. 3) using only commercially available neutral cleaning
agents and detergents. Please also note:
- Because the main body of the filter is made of brass, the cleaning agent must not
contain ammonia.
- No aggressive substances may be used that could attack the materials in the filter.
- The cleaning agent must leave no residue on the wire mesh filter as this would compro-
mise the flow rate of the medium when the device is put back into operation.
MD-10012-L51-R1.1.0-03 Page 17
Operating instructions AE

ÎAttention: During maintenance or when handling components for oxygen devices,
observe the following points:
- Keep your hands free of oil and grease
- Keep your hands and face free of creams and other cosmetic products
- Wear clean work clothing
- Clean all tools and the workplace from contamination, especially grease. All
auxiliaries must be oxygen clean.
- Thoroughly degrease all surfaces in contact with the media using WEH®Degreasing
spray and a lint-free cloth. Before reassembly, all residues of the spray that have not
yet evaporated must be removed.
Caution: Be sure to comply with the above regulations of oxygen products. If you do
not comply with this, there is a risk of oxygen burnout. If you are unable to comply
with these regulations, refrain from maintenance and send the filter to WEH for
maintenance.
9�2 Note on the cleaning interval of the wire filter insert
- The service life of the wire filter insert (Pos. 3) is primarily dictated by the conditions
of the overall system. Filter inspections should therefore be carried out as occasion
demands.
Any irregularities in the system that may have caused contamination of any kind
will similarly warrant inspection of the filter. Lower flow rates may be indicative of a
contaminated filter.
Depending on the degree of contamination, it may be necessary for the operator to
set a suitable maintenance schedule independently.
To replace the filter, observe the Chapter 9.4.1 Replacing the wire filter insert (Pos. 3)
on page 20.
MD-10012-L51-R1.1.0-03
Page 18
Operating instructions
AE

9�3 Overview of minimum intervals for inspection and maintenance
No� Inspection
Initial
(before com-
missioning for
the 1st time)
After each
maintenance
No� 3
1 Check exterior for damage and dirt X
2Check filter and media line for leakage
(see Chapter 7. Installation)X X
No� Maintenance When required, see Chapter 9.2
3Replace wire filter insert (see Chapter 9.4.1 Replac-
ing the wire filter insert (Pos. 3))X
Note: For component arrangement see Chapter 3. Product overview / product description
on page 10.
ÎIf your application requires, set shorter intervals thanindicated above. A significant
shortening of the minimum intervals is particularly necessary if abnormalities are
found during the inspections.
9�4 Maintenance
Please note: Subsequent mentions of descriptions and position numbers refer to Chap-
ter 3. Product overview / product description on page 10.
ÎIf you detect any leaks or malfunction, replace the WEH®Product or send it to WEH
for maintenance. Stop using the product immediately.
MD-10012-L51-R1.1.0-03 Page 19
Operating instructions AE

The following maintenance work may be carried out by the operator:
9�4�1 Replacing the wire filter insert (Pos� 3)
ÎUnscrew the filter from your system.
ÎClamp the filter at the
wrench flat of the
outlet housing (Pos. 1) in a
vice.
ÎUnscrew the
inlet housing (Pos. 2)
out off the
outlet housing (Pos. 1) using
a rolling fork wrench.
ÎUnscrew the
wire filter insert (Pos. 3)
using the hexagonal allen key
A/F6 and remove it from the
outlet housing (Pos. 1).
ÎRemove the O-ring and the
back-up ring with the
WEH®O-ring picker.
MD-10012-L51-R1.1.0-03
Page 20
Operating instructions
AE
