WEIBANG WBSC457LC User manual

WBSC457LC
SOD CUTTER
Operator's manual
(Original instruction)
DO NOT operates this equipment until you have read and understood all enclosed Operator’s
Manual.
READ ALL the sections in this manual PRIOR to attempting to service, maintain or operate this
equipment!
775 Glenn Ave, Wheeling, IL 60090
Copyright WEIBANG US 2018
All rights reserved

Content
1 Pre-operation note------------------------------------------------------------------------1
2 Safety precautions------------------------------------------------------------------------2
3 Assembly-------------------------------------------------------------------------------------8
3.1 Unpacking instructions----------------------------------------------------------8
3.2 How to set up your sod cutter------------------------------------------------9
4 Features and controls r-----------------------------------------------------------------9
5 Transporting the sod cutter----------------------------------------------------------11
6 Pre-operation procedures------------------------------------------------------------12
7 Operation procedures------------------------------------------------------------------13
7.1 Starting and stopping the engine------------------------------------------13
7.2 Operating the machine to cutting sod------------------------------------14
7.3 Notes during operation--------------------------------------------------------16
8 Service and adjustment---------------------------------------------------------------17
8.1 Engine-------------------------------------------------------------------------------17
8.2 Sod cutter--------------------------------------------------------------------------17
9 Storage -------------------------------------------------------------------------------------18
10 Maintenance procedures------------------------------------------------------------19
10.1 Inspection schedule----------------------------------------------------------19
10.2 Preventative maintenance procedures---------------------------------20
10.3 General service procedures-----------------------------------------------21
10.3.1 General safety procedures-----------------------------------------21
10.3.2 Pre-maintenance-------------------------------------------------------22
10.3.3 Maintenance Contents-----------------------------------------------22
11 Trouble shooting-----------------------------------------------------------------------26
12 Warranty ---------------------------------------------------------------------------------28
DANGER: Do not operate the engine in an enclosed area. Engine exhaust
contains carbon monoxide, a deadly gas that is odorless, colorless and tasteless.
Always run engine outdoors and make sure there is adequate ventilation.
DO NOT operates this equipment until you have read and understood all the enclosed Operator’s
Manual.
READ ALL the sections in this manual PRIOR to attempting to service, maintain or operate this
equipment!

1
Following security identity is to remind you always pay attention to safety during operation:
Danger:
Show immediate serious results of injury or death.
Warning:
Show unsafe actions or conditions may cause serious injury, death or damage to major
equipment.
Caution:
Show unsafe action or conditions may cause injury or property damage.
Any modification unauthorized by manufacturer is prohibited. These modifications
will change the performance and reliability of this machine or cause safety hazards to
operators, and lead to the failure of warranty.
Thank you for your purchase of the WEIBANG sod cutter. This sod cutter has been designed
and manufactured to our highest quality demands for durability and performance.
WEIBANG Garden Machine Company Limited is committed to offering durable products and
quality after-market service. The WEIBANG sod cutter is warranted to be free from
manufacturer’s defects in material and workmanship for a period of one (1) year from the date of
purchase (except used for commercial purpose or hire and rental applications). This warranty will
be void if the machine has not been operated and maintained in the manner prescribed in this
Operator’s Manual. Any machine malfunctions, and/or warranty claims that arise from the
misinterpretation or the misunderstanding of the instructions and cautions discussed in this
booklet will not be eligible for warranty protection.
In order for the sod cutter to perform at its optimum capabilities, the operator must read this
manual thoroughly before using this unit. This Operator’s Manual contains important product
operation procedures, safety precautions, maintenance and troubleshooting tips as well as other
advisories. Please keep this manual nearby when operating the lift as a reference should any
questions arise.
WBSC457LC
Sod Cutter is a professional garden machine with high efficiency used for sod
transplant, which can separates the entire sod away from the planting soil from the bottom of
roots, and form a sod belt with uniform width and uniform thickness, meanwhile retain a certain
length of roots. The sod belt can be transplanted to landscaping jobsite to form the desired turf
vegetation landscape quickly. The sod thickness can be adjusted by change cutting depth
according to different varieties of sod to reduce the damage to grass roots, and the sod
transplanted is easy to survival.
The machine should not be used for any other purpose than that stated above. The
inappropriate use of any machine can cause serious damage and/or bodily harm to the
environment and operator. It is imperative that the operator of this equipment be responsible for
the operational environment of the sod cutter. Please read, understand and follow all instructions
that are provided in this manual. Please be prepared and well-informed for all specific
requirements precautions and work hazards that may and/or do exist at the jobsite.
Powered by a 7 HP LONCIN engine, the WBSC457LC is a powerful unit. A heat-treatment
hardened high-strength alloy steel blade equipped is very durable and cutting sod easily. Failure
to maintain the sod cutter in a proper manner will lead to decreased productivity of the tool and
hazards to the operator and bystanders. Inspect you jobsite for any debris such as rocks, wiring,
string or and other items that can become hazardous during work. Identify and mark all fixed

2
objects to be avoided during work, such as sprinkler heads, water valves, buried cables, or
clothes line anchors etc. Do not use the machine if it has been modified or improperly
maintained.
All jobsites are different. Please ensure that when using the WEIBANG sod cutter, all local
bylaws and codes are followed. All operators and mechanics of this machine should be trained in
general machine use and safety.
Every care and effort has been made to ascertain the accuracy and completeness of
procedures described in this document to ensure your enjoyment and satisfaction. If you have
any questions or concerns, please contact the WEIBANG’S local dealer or WEIBANG’s exclusive
national distributor.
Specifications
Model WBSC457LC
Power LONCIN G200F 4.1kW 6hp
Cutting depth(Max.) 1.8 inches 4.5 cm
Cutting width 18 inches 45cm
Cutting speed 0.9-1.1m/s
machine size LxWxH 69x29.5x37.4 inches 175x75x95cm
Net weight 387 Pound 176 Kg
Gross weitht 440 Pound 200 Kg
SAFETY REGULATIONS
1. This machine may only be operated by responsible persons, who are trained and familiar with
the operating instructions. Before starting to use this machine, read, under stand and follow all
instructions that are provided in this manual.
2． Before operating power rake, ensure that it is structurally and mechanically safe by checking
the following:
a. Are all engine controls and the clutch action functioning within acceptable tolerances?
b.Are all nuts and bolts in good working condition? Tight and keep all guards and deflectors
in place and in good working condition.
3. Before using the sod cutter on proposed jobsite, perform the following environmental checks:
a. Inspect the entire work area for unexpected buried hazards, such as boulders,
foundations, and fencing.
b. Clean work area of any litter or debris, such as wire, boards, rocks, or any other potential
hazards.

3
c. Know and mark the location of any and all buried utility lines or sprinkler systems. If in
doubt, always check with your local utilities provider for survey information and
assistance.
d. Check for ventilation in area. Do not operate the sod cutter or run the engine in
unventilated areas. Engine exhaust contains carbon monoxide, a deadly gas that is
odorless, colorless, and tasteless.
ALWAYS OPERATE CHIPPER/SHREDDER OUTDOORS!!
4 Always wear proper safety clothing and equipment for the job. These can and should include
eye and ear protection, gloves, dust mask and any other items that are appropriate for the job and
jobsite requirements.
●Never wear any jewelry, neck ties, or other loose or hanging items that can be caught on
any part of the machine.
●Tie back or remove any loose hair, clothing and any other potential hazards and
obstructions. Keep all hands, loose clothing, hair, jewelry and all other personal parts and
belongings away from moving parts of the machine.
●Avoid coming in contact with the muffler and other engine parts after the engine is started
and the time immediately after the machine is turned off. Machine and engine
temperatures may exceed 150°F or 66℃. Machine must be allowed to cool before
touching it or attempting to perform any maintenance!
●Do not tamper with the engine governor settings on the machine; the governor controls
the maximum safe operating speed and protects the engine and all moving parts from
damage caused by dangerously high speeds.
●Do not transport or move machine while the engine or machine is running.
5. For the safety of others and that of the operator, observe the following precautions:
●While the machine is in use, keep observers and bystanders at least 35 feet away from
the sod cutter and its immediate working environment.
●Stop operations or if anyone or anything (i.e.: humans, animals, etc.) approaches from the
front or the sides while the machine is in operation.
●If the cutting mechanism strikes any foreign object or if the machine should start making
an unusual noise or vibration, immediately shut off the engine and allow the machine to
stop. Disconnect the spark plug wire from the spark plug and take the following steps:
i. Inspect for damage.
ii. Replace or repair damaged parts.
iii. Check for and tighten any loose parts.
●Stop work and turn off the sod cutter if chipping jams the machine or causes it to labor
unnecessarily. Inspect the machine for any possible causes.

4
●Before attempting to clear any jams in the unit, inspecting or servicing any part of the
machine, stop the engine and remove the sparkplug wire, and make sure that all moving
parts have come to a complete stop.
●Never leave machine unattended. Shut off the engine whenever you leave the work area.
●This machine only used for cutting sod and should not be used for any other purpose.
The inappropriate use of any machine can cause serious damage and/or bodily harm to
the environment and operator.
●DO NOT, under any circumstances, operate machine if any of the following conditions
are applicable:
i. Any impairment (i.e.: medical conditions, medicinal side-effects, alcohol, drugs etc.) of
the operator.
ii. The operator has not read or understood the operator’s manual for this machine.
iii. The operator does not clearly understand the operations of the machine.
iv. The machine is in need of repair
v. The operator is inappropriately attired to operate the machine.
6. Take care of children. Tragic accidents can occur if the operator is not alert to the presence of
children. Children are often attracted to the chipper/shredder and to the operation activity. Never
assume that children will remain where you last saw them.
a. Keep children out of the working area and under the watchful care of a responsible adult.
b. Be alert and turn machine off if children enter the area.
c. Never allow children to operate the cod cutter.
Warning: Do not carry children or any other persons sitting on the machine.
7. Use extra care in handling fuels. They are flammable and vapours are explosive.
●Use only an approved container.
●Never remove fuel cap or add fuel with the engine running. Allow engine to cool before
refueling.
●Do not smoke.
●Never refuel the machine indoors.
●Never store the machine or fuel container inside where there is an open flame, such as a
water heater.
●If fuel is spilled, do not attempt to start the engine, but move the machine away from the area
of spillage before starting.
●Always replace and securely tighten fuel cap after refueling.
SAVE THESE INSTRUCTIONS!!
Special safety precautions
1. Do not remove any safety guard and other security protection facilities.
2. Do not start the machine until the gear selecting lever is set in neutral.
3. For safety reasons, when the machine is self propelled for transporting, make sure the blade
is disengaged and lift up.

5
4. Never leave machine unattended. Shut off the engine and shift the ignition switch to “OFF”
whenever you leave the work area.
5. For engaging blade or selecting gears, reduce the throttle and pull the clutch
handle slowly until the transmission is semi-engaged to avoid damaging
gears.
6. Do not engage the blade until the transmission is in neutral, FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH.
7. The cutting work should be carried in low gear, fail to do so will damage the machine and
affect cutting effect.
● DO NOT cutting sod when the machine is in high speed gear.
● DO NOT use this machine at any other circumstances except lawn.
● THIS MACHINE IS NOT DESIGNED FOR USE ON SLOPES OF MORE THAN 20% GRADE.
IF MACHINE IS USED ON EXTREME SLOPS, THE MACHINE MAY BECOME
UNBALANCED TO THE POINT OF PRESENTING THE DANGER OF ROLLING OVER.
● Keep all hands or feet and all other personal parts away from moving parts of the machine.
● Do not run this machine in unventilated areas.
● Do not manually drive the machine until the gear is disengaged.
● Do not attempt to perform any repairs, service, or diagnostics, or to transport or move the
machine until it comes to a complete stop. Disconnect cable from the sparkplug and place
where it cannot come in contact with plug.
● Do not run this machine until all guards and deflectors in place and in good working condition.
● The sod cutter is a heavy unit. DO NOT ATTEMPT TO MANUALLY LIFT ALONE!
● Do not select gears until the machine stops moving.
● After gear selecting, accelerate the throttle slowly
● Do not put down or lift up the blade until the driving system is disengaged.
Regular maintenance and parts replacement are important steps to extending the life of your
equipment and enjoying its optimum performance. When performing or conducting any
maintenance or repairs, always check that your working surroundings are safe and well-ventilated
and that the technician is familiar and comfortable with all aspects of the machine and required
procedures.
This guide aims to serve as a representational guide to the WBSC409H. Any other uses or
application beyond the scope of this document are strictly prohibited. While every attempt has
been made to maintain its accuracy，WEIBANG reserves the right to update and modify the
equipment without prior notification. Prior to undertaking to perform any maintenance or repair
procedures, please contact our Technical Support Hotline for clarification and to acquire
appropriate parts.
To order spare parts, please provide the following information:
1. Machine Make
2. Model Number
3. Machine Serial Number

6
4. Quantity Required of Each Part
5. Part Numbers
6. Part Descriptions.
1Contents List
Prior to setting up the WBSC409H Professional sod cutter, check that the following items are
enclosed:
Item Quantity Check if enclosed
WBSC457LC Sod cutter 1 ____Yes ____No
WBSC457LC Handle bar with clutch handle
1 ____Yes____No
WBSC457LC Sod cutter Operator’s manual 1 ____Yes____No
Engine Operator’s manual 1 ____Yes ____No
If any of these items are missing, please contact local dealer and ask for the Service Department
at once.
DO NOT ATTEMPT ASSEMBLY OR OPERATION WITHOUT ANY OF THESE LISTED PARTS!
All WEIBANG parts are guaranteed by a thirty (30) day warranty against any manufacturer’s
defects in workmanship and material. Consult Warranty page in the Operator’s Manual for further
details on our Warranty Policy.
2 Information on Safety Decals
Below are the decals available for re-ordering to facilitate maintenance. All decals are
available for replacement except that with the serial number of the unit for each number serves as
an unique identifier for warranty and support purposes.
If you have any questions, please do not hesitate to contact your local dealer for further
assistance.
Warning
●Do not shift gears or engage blade when the machine is running with high speed.
●Shift gears or engage blade until the engine is running with idle speed and the power is
semi-engaged to avoid damaging the gearbox.
Caution
The engine exhaust from this production contains chemicals know to the state of California to
cause cancer, birth defects, or other reproductive harm. Engine produces carbon monoxide which
Is an odorless deadly poison. DO NOT OPERATE IN AN ENCLOSED AREA.
READ ALL the sections in this manual PRIOR to attempting to service, maintain or operate this
equipment.
DO NOT operate this equipment until you have read and understood all the enclosed Operator’s
Manual.

7
Qty Required=1PCS
PART No.XYJLP070
OPERATOR:
Qty Required=1PCS
PARTNo. L0106040Z
FUEL TANK:
Qty Required=2PCS
PARTNo. L0106080Z
SERVICE:
Qty Required=1PCS
PARTNo. L0203000
WARNING:

8
Carefully read these instructions and this manual in its entirety, before you attempt to operate
your new shredders.
IMPORTANT: THIS SOD CUTTER IS DELIVERED WITHOUT OIL OR PETROL IN THE
ENGINE.
Your new sod cutter has been pre-assembled at the factory, with the exception of those parts left
unassembled for shipping purposes. All parts such as nuts, washers, bolts, etc. necessary to
complete the assembly have been attached on the machine. To assure safe and proper operation
of your sod cutter all parts and hardware you assemble must be tightened securely. Use the
correct tools needed to assure proper tightening.
I UNPACKING INSTRUCTIONS
WARNING
To prevent personal injury or property damage, do not attempt to start the engine until all
assembly steps are complete and you have read and understand the safety controls and
operating instructions in this manual.
INTRODUCTION
Please carefully follow these assembly steps to properly prepare your machine for use. We
recommend that you read this Section in it’s entirely before beginning assembly.
NOTE: All references to left, right, front and rear of the machine are determined by standing
behind the handlebars and facing the direction of forward travel.
INSPECTION AFTER DELIVERY
When unpacking the machine, inspect for shipping damage or missing parts, if you find any
damage, or if parts are missing, notify the WEIBANG Dealer who sold you the machine.
TOOLS/MATERIALS NEEDED:
Active Wrench / Motor Oil / Tire Gauge
1. UNPACKING STEPS
•Cut plastic banding. To open the box, remove top plywood panel firstly,
•Remove the handle bar with belt clutch handle.
•Remove all around wall panel.
•Remove the angle iron securing machine to wood pallet.
•Move the machine from the wood pallet.
•Check the box thoroughly and remove additional loose parts included with sod cutter.
•Remove all packing materials.
● The WBSC409H is a HEAVY machine. The net weight is 387 lbs/176kgs. DO NOT ATTEMPT
TO MANUALLY LIFT ALONE! It is recommended extremely using a crane to lift the unit.
If there is no crane for lifting, make sure that four people lifting the machine
are capable of lifting at least 100 lbs/45.36kgs individually!! NEVER ATTEMPT
TO LIFT THE MACHINE WITH ONLY ONE or TWO PERSON!!

9
II HOW TO SET UP YOUR SOD CUTTER
CAUTION: Wear protective gloves during operation of setting up your sod cutter.
1) Remove the temporary bracket, and then install the components of handle-bar & rod, and then
connect the screw end of clutch cable to the belt clutch handle according to installing drawing.
2) Make sure the handle bar have been connected to the machine correctly and all bolts have
been tightened securely.
3) Check the tensional spring to ensure the clutch
cable connected correctly. The cable travel should
be 1.9-2.54cm and the cable is easy to reset.
4) Check and make sure the engine has enough oil in
5) Refer to engine operator's manual for further details
Machine Overview
The following is a list of important control and operation mechanisms with which the operator
must be familiar PRIOR to using this machine . Failure to do so may result in severe injury
and/or fatality to the operator and others and may lead to reduced machine life or damage to this
machine.
Ｇｅａｒ ｂｏｘ
Ｔｅｎｐｏｒａｒｙ ｂｒａｃｋｅｔ Ｈａｎｄｌｅ ｂａｒ
ｓｐａｃｅｒ
Ｒｏｄ
Ｐａｒｔｓ ｒｅｌａｔｉｏｎｓｈｉｐ Ａｓｓｅｍｂｌｅｄ
Ｎｙｌｏｎ
Ｂｅｌｔ ｔｅｎｓｉｏｎｅｄ ｐｏｓｉｔｉｏｎ Ｂｅｌｔ ｒｅｌｅａｓｅｄ ｐｏｓｉｔｉｏｎ
Ｃａｂｌｅ ｓｈｅａｔｈ
２－３ｃｍ
Ｃａｂｌｅ ｂｒａｃｋｅｔ
Ｐｉｎ
Ｎｙｌｏｎ ｓｐａｃｅｒ
Ｃｏｔｔｅｒ ｐｉｎ
Ｃｌｕｔｃｈ ｃａｂｌｅ ｈｅａｄ
Ｓｐｒｉｎｇ ｏｐｅｎｅｄ
Ｔｅｎｓｉｏｎａｌ ａｒｍ
crankcase.
of running an engine.
Ｎｕｔ
Ｕ ａｄａｐｔｅｒ
Ｐｉｎ ｋｉｔｓ
Ｃｏｎｎｅｃｔｉｎｇ ｒｏｄ
Ｃｏｎｎｅｃｔｉｎｇ ｒｏｄ
Ｕ ａｄａｐｔｅｒ
Ｐａｒｔｓ ｒｅｌａｔｉｏｎｓｈｉｐ
Ｃｈｅｃｋ ｔｅｎｓｉｏｎａｌ ｓｐｒｉｎｇ

10
1. Bumper, Used for protecting the engine and the towing the machine.
2. Blade-controlling handle，used for controlling cutting depth and blade angle.
3. Upper locking lever,
used together with blade controlling handle for setting different cutting depth.
4. Lower locking lever, used together with blade controlling handle for adjusting the blade
cutting angle.
5. Gear-selecting lever, used for selecting gears to change driving speed.
6. Blade-engaging lever, used for control the running and stopping of the blade, which include a
locking lever and a shifting lever.
7. Handle bar, used for controlling the direction of machine's travelling.
8. Throttle-controlling lever, used for stopping or accelerating the machine.
9. Belt- clutch handle，for engaging or disengaging the gearbox with engine.
10. Oil gauge, used for observing oil quality and liquid level.
12. Travelling wheel, intalled on driving wheel, used for short distance (less than 1000m) transferr- one jobsite to
ing from another. Remove the wheel before cutting sod.
13. Starting knob, used for recoil starting the engine.
Engine lubrication oil
For oil type, viscosity and capacity please refer to engine manual.
Lubrication oil for engine gear box
For gear oil type, viscosity and capacity please refer to engine manual.
Lubrication oil for transmission system
1. If transmission box need maintenance, please contact your local dealer.
2. The transmission system uses vehicles gear oil, which can be observed by vision through an
oil level gauge on transmission case. The oil should be replaced after first 500 working hours
and every1000 hours later. Adding oil in time when the liquid level is below the window of oil
gauge.
3. Greasing all zerks every 10 hours
Bumper
Startingknob
Bladecontrolinghandle
Throttlecontrollinglever
Handlebar
Belt-clutchlever
Oilgauge
Upperlockinglever
Gearselectinglever
Crank
Lowerlockinglever
Bladeengaginglever
Drivingwheel
Blade
11. Driving wheel, for pressing lawn and selpropelling.

11
CAUTION: Do not transport or move machine while the engine or machine is running.
Stop the engine and remove the sparkplug wire, and make sure that all moving parts have
come to a complete stop. Prevent fuel spillage, gasoline is flammable and vapors are
explosive.
● The machine is equipped with 14-inch 6PR inflatable tires with ball bearings, which make the
machine can self propelled easily for short distance. Do not manually drive the machine until
the gear is disengaged. Do not tow the machine for transportation.
● The WBSC409H is a HEAVY machine. The net weight is 387lbs/176kgs. It is recommended
extremely using a crane to lift the unit.
If there is no crane for lifting, make sure that four people lifting the machine
are capable of lifting at least 100 lbs/45.36kgs individually!! NEVER ATTEMPT
TO LIFT THE MACHINE WITH ONLY ONE or TWO PERSON!!
● Working with partners, lift the unit to the transportation vehicle. ALWAYS use safe lifting
techniques to avoid back or muscle injury! Consult your local health and safety organization
for tips and best practices for moving heavy machinery.
● Use a heavy-duty trailer or truck to transport the machine. Block wheels and securely fasten
the machine to the trailer or truck with straps, chains, cable, or ropes. Be sure that the trailer
or truck has all necessary lighting and marking as required by law.
● Secure a trailer with a safety chain.
Transferring the machine with special wheels
For short distance (less than 1000m) transferring from one jobsite to another, tip up the machine
to install two 14-inch wheels onto drive wheel spindles, and then insert two check pins into hub
holes to lock them.
It is extremely recommended to use a heavy-duty trailer or truck to transport the machine
for long distance.

12
Before using the WEIBANG WBSC457LC Professional
Sod cutter, please perform the following
procedures for the personal and property safety of the operator and jobsite and for optimal
performance.
1). Before operating the sod cutter ensure that it is structurally and mechanically safe by checking
the following:
a. Perform a detailed visual inspection on the machine with particular attention to the following:
i. Are there any loose, worn or damaged parts? If so, DO NOT ATTEMPT TO OPERATE THE
MACHINE. Make note of required parts, and contact your local dealer for replacement parts
and further assistance to service the unit PRIOR to any further use.
ii. Is the machine, particularly the blade part, clean and free of debris? Small rocks and other
foreign objects can jam machine and cause the unit to malfunction, leading to serious injury
to the operator and property damage on the jobsite.
iii. Are there any cracks or damage on the engine? Consult with the engine manufacturer's
manual for guidelines and instructions on service. DO NOT ATTEMPT TO OPERATE THE
MACHINE until engine is refurbished to engine factory standards.
iv. Is the blade part disengaged in the traveling state (i.e: raised from the working surface)?
Ensure that the blade is securely raised away from the working surface until arrival at
jobsite. Moving the sod cutter with the blade in the lowered working position can damage
the unit and jobsite.
b. Inspect the handle for the following:
i. Is the handle properly and securely attached to the machine?
ii. Is the handle set in the correct operating position?
c. Consult the “Recommended Maintenance Schedule” section of this manual and verify that:
i. The wheels, zerks and carriage are lubricated and in good condition.
ii. The blade part is clean and not in need or replacement. Consult the “Maintenance and
Service” section of this manual for guidelines and instructions on when and how to change
the blade.
iii. The drive belt is in good condition and set to the appropriate tension. Consult the
“Maintenance and Service” section of this manual for guidelines and instructions on taking
care of the belt.
2). Before operating the sod cutter, perform the following environmental checks:
a. Is the ground where the sod cutter will be operating level and solid? If it is a slope of more
than 20% grade, please refer to “cutting sod on Inclined Surfaces” under the “Operation
Procedures” section of this manual.
b. Has the sod been cleared of debris such as string, wire, rocks, metal and other materials?
Such items could cause malfunction or damage to the sod cutter that could also be
potentially hazardous to the machine and operator.
c. Are all obstructions such as sprinkler lines, electrical boxes, fences etc. clearly marked?
If any of the above checks fail, please take necessary steps to maintain or repair the unit
before operating it in any environment.
CAUTION: Always wear proper safety clothing and equipment for the job. These can and
should include eye and ear protection, gloves, dust mask and any other items that are
appropriate for the job and jobsite requirements

13
WARNING: Before operating the machine, be sure to read all safety, controls and operating
instructions in this Owner’s Manual and on decals located on machine.
Server personal injury or property damage could result if this instruction is not followed.
Before starting the machine
1. Read and understood all the sections in this manual.
2. Make sure the oil is the grade recommended by engine manufacturer. (Refer to engine
operator’s manual）
3. Make sure the gear selecting lever is in neutral position before starting the machine.
4. Make sure the blade is disengaged and set in upper position for traveling before starting the
machine.
7.1 STARTING AND STOPPING THE ENGINE
DANGER: Do not operate the engine in an enclosed area. Engine exhaust contains carbon
monoxide, a deadly gas that is odorless, colorless and tasteless. Always run engine
outdoors and make sure there is adequate ventilation.
To start the engine
1) Move the machine to a level area.
2) Move the engine chock control lever to choke setting to start a cold engine.
WARNING:
To avoid injury, look behind you to be sure there are no obstacles before pulling recoil
starter rope.
3) To start engine using recoil starter:
A: Stand on left side (as viewed from behind handlebars) of machine.
B: Grasp starter rope handle and pull slowly until rope pulls slightly harder. Let rope rewind
slowly. Then pull rope with a rapid, full arm stroke. Let rope return slowly.
C: when engine starts, operate in fast throttle setting (move throttle from choke setting to fast
setting slowly to engage the blades).
CAUTION: When you pull the engine starter knob to start the engine, please stop the
operation and check the causes in case the engine fails to start in 30 second after repeated
starting operation. See trouble shooting.
To stop the engine
1. Move throttle from fast setting to slow position.( Whenever possible, gradually reduce engine
speed before stopping engine.)
2. Move the throttle control all the way to stop position.

14
See sod cutter instruction manual for starting, procedure and additional safety instructions before
using the machine.
7.2 OPERATION THE MACHINE TO CUTTING SOD
1. Start the engine when the gear box is in neutral.
2. Turn the throttle lever to accelerate the engine till it runs smoothly (idle speed).
3. Lift the handle bar, and then pull the blade-controlling handle back to lower the blade.
4. Pull the belt clutch handle back slowly until the belt is semi engaged, and then turn the
Blade-engaging lever to engage the blade.
5. Pull the belt clutch handle back slowly until the belt is semi engaged, and then shift the gear
selecting lever to engage slow speed gears (rapid speed is only for travelling.)
6. Lift the handle bar, pull the belt clutch handle back to full travel, and then turn the throttle to
biggest. Now the machine starts self driving and cutting the sod.
7. Press the handle bar to make the blade cutting into the sod for short distance (about 1m)
8. Disengage the belt clutch by pushing the belt clutch handle forward to stop the machine. Lift
the edge of sod cut to check the depth.
9. For adjusting the cutting depth, turn down the throttle and release the belt clutch handle to stop
the moving, and then disengage the gear selecting lever and blade engaging lever.

15
10. After adjustment, repeat steps 4-6, and then continue cutting sod. Hold the handle bar firmly
to avoid shaking.
11. For turning the machine during traveling, hold the handle bar firmly and lift it until rear wheels
raise from the ground.
12. Stopping cutting sod,
●Lift up the handle bar during cutting operation, until the blade moves to sod surface;
●Shift the gear selecting lever to neutral to disengage the driving wheels;
●Shift the blade lever to disengaging position to stop the blade.
●
Lift the High-adjustment and turn the Blade-c
ontrolling handle to raise blade from working
surface.
WARNNING: DO NOT CUTTING THE SOD WHEN THE MACHINE IS SET IN HIGH SPEED
GEARS.
9.1. Adjusting blade angle: Turn and release
controling lever to desired blade angle,
9.2. Adjusting cutting depth:
Adjust blade angle
Blade controling lever
Lower locking lever
Lossen
Tight
1) For precise adjustment, set blade angle and keep the solt "A" in vertical direction.
2) Turn star knob to release the locating block.
3) Turn and release upper locking lever.
4) Turn the blade controling lever according to the graduated scale, till to your desired
5) Slide the locating block along slot "B" to contact the blade controling lever, and then
The locating block is used to indicate different cutting depth and lock frequently used
position, If you need to change your machine from transportating state to last time operat-
ting state, you only need turning the blade controling lever to contact the locating block
and then relock upper locking lever.
cutting depth, and then relock upper locking lever.
lower locking lever, and then turn blade
then relock lower locking lever.
Ｓｈａｌｌｏｗ Ｕｐｐｅｒ ｌｏｃｋｉｎｇ ｌｅｖｅｒ
A
B
Star Knob
Deep
Blade controling lever
Locating block
Lossen
Tight
relock star type knob.

16
7.3 Notes during operation
1. Start the machine when the gear shifting lever is set in neutral.
2. To select gears successfully, slowly accelerate the throttle and meanwhile swing the selecting
lever gently to engage gears completely.
3. Set the gear selecting lever in neutral before stopping the machine.
4. Soil conditions will influence cutting depth. If the cutting movement is from hard soil to soft soil
or damp places, the cutting depth should be re-adjusted.
5. Do not cutting sod during U-turn. Stop cutting sod before u-turn.
6. Watering or not before cutting?
●Usually the sod needs not watering before cutting. But it needs watering appropriately in
some especial circumstances (such as very tight clay).
●A simple way can determine whether the sod needs watering before cutting. Use a shovel,
weeding tools, or other test tools to test the soil's stiffness.
●If the testing tool can be inserted into the soil 5-8cm with a small force, the lawn need not
watering, otherwise, the lawn need watering the day before cutting sod, to allow soil
having sufficient time to absorb water.
●Before cutting, use tool to re-test the watering effect and make lawn drying to reduce the
resistance of soil.
CUTTING SOD ON SLOPES
WARNING: THIS MACHINE IS NOT DESIGNED FOR USE ON INCLINES OF MORE THAN
20% GRADE.
Cutting sod on inclines will cause the centre of gravity of the unit to shift to the downward side of
the machine. The following conditions may occur as a result:
i. Greater effort and physical exertion may be required to maneuver and control the balance
of the machine.
ii. Uneven cutting results from the shift in gravity leading to downhill blade working at a lower
cutting depth than the uphill blade which are working at a higher setting.
IF MACHINE IS USED ON EXTREME INCLINES, THE MACHINE MAY BECOME
UNBALANCED TO THE POINT OF PRESENTING THE DANGER OF ROLLING OVER.
Disengage blade from ground only when machine is on a flat surface.
NEVER DISENGAGE BLADE WHEN TRAVELLING UP OR DOWN INCLINES.
2. Consider the following tips for cutting on inclines:
a. Move machine down hills rather than across hills on the hill for greater control and even
cutting. (See above for explanation and Diag.1 below for diagram).The angle of sod cutter
like such that it is 20° to the slope.
b. Try to avoid U-turn on slopes.
Warning: For selecting gears, push the belt clutch handle to front to disengage the gear
box and stop machine’s moving,

17
Before any service and adjustments:
1. Make sure the blade and all moving parts have stopped completely.
2. Disconnect cable from the sparkplug and place where it cannot come in contact with
plug.
CAUTION
●Any modifications unauthorized by manufacturers to the machine will lead to the failure of
warranty.
●Do not operate the machine until read and understand all enclosed operator’s manual.
CAUTION
WEIBANG parts have been designed and manufactured to the highest quality demands for
durability and performance of a commercial operation. Always use original spare parts with the
logo "WEIBANG" to ensure maximum performance, reliability and service life from your
WEIBANG machine.
8.1 ENGINE
ENGINE SPEED
Your engine speed has been preset at the factory. Do not attempt to increase the engine speed,
as this may result in personal injury. If you believe that the engine is running too fast or too slow,
take your sod cutter to an authorized service centre for repair and adjustment.
THROTTLE CONTROL
If it becomes necessary to adjust or replace the throttle control, see the adjustment section of
your engine manual.
CARBURETOR
The carburetor has been preset at the factory and adjustment should not be necessary. However,
minor adjustment may be required to compensate for differences in fuel, temperature, altitude or
load.
●The air filter must be assembled to the carburetor when running engine.
●Best carburetor adjustment is obtained when fuel tank is ¼ full.
●For further information, please see the Adjustment section of your engine manual for further
instruction.
Contact your nearest authorized engine service department or your local dealer to
maintenance engine and consulting warranty issues.
In case any engine failure during the warranty period, the machine should be sent to
authorized engine service department for checking but not disassembled by customers, otherwise
it will lead to the warranty invalid.
8.2 SOD CUTTER
● For easier access to cleaning the sod cutter, the machine may be tipped on its engine guard
for NO MORE THAN 2 MINUTES. Engine damage may result from gasoline flowing into the
crankshaft due to prolonged tipping. Refer to the engine operator's manual and maintenance
instructions.
● The sod cutter can be tilted forward in 30 seconds，by lifting up the handle bar. Engine
damage may result from gasoline flowing into the engine's cylinder due to prolonged tipping.
Refer to the engine operator's manual and maintenance instructions.

18
When sod cutter is to be stored for a period of time, clean it thoroughly, remove all dirt, grease,
leaves, etc. Store the sod cutter in a clean and dry place.
1. Clean the entire sod cutter (See "CLEANING" in the customer Responsibilities section of this
manual)
2. Lubricate as shown in the Customer Responsibilities section of this manual.
3. Be sure that all nuts, bolts, screws and pins are securely fastened. Inspect moving parts for
damage, breakage and wear. Replace if necessary.
4. Touch up all rusted or chipped paint surfaces; sand lightly before painting.
5. Apply some grease or anti-rust paint on the blade surface will inhibit rusting.
6. Store the machine out of children’s access and in a covered or indoor storage area for
increased protection and longevity. Ensure that the area in which the machine will be stored is
well-ventilated and free of any potential fire hazards such as open flames, gas appliances,
furnaces, water heaters, and other appliances.
7. Store unit in transport position (see “Transporting the WBSC457LC” in “Operation Procedures”
section)
FUEL SYSTEM
IMPORTANT: DURING STORAGE, IT IS IMPORTANT TO PREVENT GUM DEPOSITS FROM
FORMING ON ESSENTIAL SYSTEM PARTS, SUCH AS THE CARBURETTOR, FUEL FILTER,
FUEL HOSE OR FUEL TANK. EXPERIENCE ALSO INDICATES THAT ALCOHOL BLENDED
FUELS, ALSO CALLED GASOHOL, OR THE USE OF ETHANOL OR METHANOL, CAN
ATTRACT MOISTURE WHICH LEADS TO SEPARATION AND THE FORMATION OF ACIDS
DURING STORAGE. ACIDS CAN DAMAGE THE FUEL SYSTEM OF AN ENGINE WHILE IN
STORAGE.
●Drain the fuel tank.
● Start the engine and let it run until the fuel lines and carburetor are empty and dispose of it in a
safe, responsible manner.
● Never use engine or carburetor cleaning products in the fuel tank, as permanent damage may
occur.
● Refill the fuel tank with fresh fuel at the start of next season.
NOTE: Fuel stabilizers are an acceptable alternative for minimizing the formation of fuel
gum deposits during storage. Add stabilizing agents to the petrol in fuel tank or storage
container. Always observe the mixing ratio found on stabilizer container. Run the engine
for at least 10 minutes after adding a stabilized fuel, to allow the stabilizer to reach the
carburetor. Do not drain the gas tank and carburetor if using stabilizer.
Drain oil (while engine is warm) and replace with clean engine oil (see "ENGINE" in the
CUSTOMER RESPONSIBILITIES section of this manual).
CYLINDER
●Remove the sparkplug.
● Pour (29 ml) oil through the sparkplug hole into the engine cylinder.
● Pull the starter handle slowly a few times to distribute the oil.
● Replace with new sparkplug.
