WEIGH RIGHT PMB-801C User manual

INSTRUCTION MANUAL
MODEL PMB-801C
Serial No. 2019-0048
Mikes Popcorn
Manufacturer: WEIGH RIGHT AUTOMATIC SCALE CO.
612A Mills Rd.
Joliet, IL 60433
PH: 815-726-4626
FAX: [phone]prinyre
www.weighright.com
This manual serves as a guideline for operation, maintenance, troubleshooting, and parts replacement.
Any questions regarding this information should be directed to;
Customer Service 815-726-4626, Monday-Friday 8:00 am to 4:30 pm, Central Time.

Page 2
WHY USE THE MANUAL? ............................................................................................. 5
PAY ATTENTION TO THIS! ..................................................................................................... 5
USER NOTES ............................................................................................................................... 5
SAFETY INFORMATION .......................................................................................................... 5
SERVICE INFORMATION ........................................................................................................ 5
WHEN YOU CALL ...................................................................................................................... 5
GETTING STARTED ...................................................................................................... 6
MACHINE REQUIREMENTS ................................................................................................... 6
UNPACKING AND SETTING UP.................................................................................... 7
MODEL IQ UNCRATING INSTRUCTIONS ........................................................................... 7
MODEL IQ SAFETY INSTRUCTIONS ............................................................................ 8
INSTALLATION .............................................................................................................. 8
MACHINE POSITIONING ......................................................................................................... 8
ADJUSTING HEIGHT ................................................................................................................ 9
CONNECTION OF AIR AND POWER .................................................................................... 9
IQ ASSEMBLY INSTRUCTIONS .................................................................................. 10
GENERAL DESCRIPTION ........................................................................................... 11
OPERATION ................................................................................................................. 11
CONTROLS .................................................................................................................. 12
“Start/Stop Screen” .................................................................................................................... 12
“Settings” ..................................................................................................................................... 13
“Set Weights” .............................................................................................................................. 14
“Speed Adjustments” .................................................................................................................. 15

Page 3
“Timer Adjustments” ................................................................................................................. 16
“Pieces Screen” ............................................................................................................................ 17
“Recipe” ....................................................................................................................................... 18
“Password request page” ........................................................................................................... 19
“To save a new job” .................................................................................................................... 19
“Calibration” ............................................................................................................................... 21
“History Screen” ......................................................................................................................... 22
LEVEL CONTROL ........................................................................................................ 23
IQ NET WEIGH FILLER MAINTENANCE .................................................................... 23
TROUBLE SHOOTING INSTRUCTIONS ..................................................................... 24
CUSTOMER SERVICE SCHEDULE ............................................................................ 25
TERMS & CONDITIONS ......................................................................................................... 25
LIVING EXPENSES: ................................................................................................................. 27
TRAVELING EXPENSES: ....................................................................................................... 27
LOAD CELL TROUBLE-SHOOTING ........................................................................... 28
FILTER / REGULATOR / LUBRICATOR ...................................................................... 29
WARNING: IF YOUR UNIT HAS A PLASTIC BOWL ....................................................... 29
IMPORTANT INSTALLATION INSTRUCTIONS FOR FILTERS ................................... 29
IMPORTANT MAINTENANCE INSTRUCTIONS FOR FILTERS ................................... 30
INDICATOR TROUBLESHOOTING GUIDE ................................................................. 31
FTO1 SERVICE INSTRUCTIONS ................................................................................ 32
INTRODUCTION....................................................................................................................... 32
THEORY OF OPERATION ..................................................................................................... 33
LONG TERM STORAGE ......................................................................................................... 33
INSTALLATION ........................................................................................................................ 34

Page 4
OPERATION .............................................................................................................................. 35
MAINTENANCE ........................................................................................................................ 35
TROUBLE SHOOTING ............................................................................................................ 36
SPRING REPLACEMENT ....................................................................................................... 37
AIR GAP ...................................................................................................................................... 37
CHECKING FEEDER CURRENT .......................................................................................... 37
STROKE GAUGE ...................................................................................................................... 38
VIBRATORY FEEDER CONTROL BOARD ................................................................. 39

Page 5
WHY USE THE MANUAL?
Reading this manual and applying the information it contains is the best way to
become familiar with the Weigh Right Model IQ. Many answers to the questions we
receive from new customers can be found in this manual.
PAY ATTENTION TO THIS!
When important information about the machine and the operation of the machine
is presented, it will be printed in bold text with a special graphic symbol, called an icon,
on the page edge to draw your attention. Take special notice of these notes and
warnings when they appear. An explanation of each kind follows:
USER NOTES
Note icons like the one shown here at the edge of the page are used to point out tips
and suggestions for operating your new machine at it's peak performance.
SAFETY INFORMATION
The caution sign icon appearing in the margin alerts you to a SAFETY CAUTION on
the subject it accompanies and will appear in RED. A safety caution affects the
machine and the operator. A full explanation of the safety caution accompanies the
caution sign icon when it is used.
SERVICE INFORMATION
Information on the maintenance and repair of your machine can be found in this
manual.
WHEN YOU CALL
When it becomes necessary to contact Weigh Right, please be prepared to provide our
service representative with your machine model and serial number.
2019-0048

Page 6
GETTING STARTED
MACHINE REQUIREMENTS
The following are the minimum requirements for installing the machine.
POWER: 12O VAC 60 Hz 15 AMP grounded service.
DO NOT OPERATE THIS MACHINE WITHOUT A PROPER GROUND.
DANGEROUS CONDITIONS WILL EXIST WITH OUT PROPER GROUNDING.
ALL GUARANTEES ARE VOID IF THE MACHINE IS USED
WITH AN UNGROUNDED CONNECTION!
AIR: 2 CFM @ 80 PSI unlubricated, unless machine is equipped with a mini Air
compressor
CONNECT THE MACHINE TO AN AIR SUPPLY WITH A GOOD FILTRATION
AND CONDENSATION REMOVAL SYSTEM.
ENVIRONMENT: 50º F (10º C) to 100º F (38º C)
DO NOT OPERATE THIS MACHINE IN AN EXPLOSIVE ATMOSPHERE.
DO NOT SUBJECT THE MACHINE TO WET OR CORROSIVE ENVIRONMENTS.
KEEP ALL FLAMMABLE AND CAUSTIC SUBSTANCES AWAY FROM THE
MACHINE AT ALL TIMES.

Page 7
UNPACKING AND SETTING UP
MODEL IQ UNCRATING INSTRUCTIONS
A) Check crate(s) for visible damage.
Call Weigh Right if shipping damage is evident.
B) Carefully uncrate machine, Note that one side of the crate may be attached with
wood screws for easy disassembly and re crating if necessary.
C) Remove all separately packaged boxes and open to check contents against packing
list.
D) Carefully remove braces making sure load cell cables are not damaged or stretched.
DO NOT CONNECT AIR OR POWER UNTIL THE MACHINE
HAS BEEN PROPERLY UNPACKED AND INSPECTED!
The machine is shipped on a pallet. Locate the box marked FOOTSWITCH and
remove the straps holding the box to the machine pallet. Open the box and remove the
footswitch assembly and set it aside for now. Lift the machine from the pallet at set it on
the ground.
Remove the wrapping from the outside of the machine. Examine the exterior of the
machine for any visible shipping damage. Remove the remaining packing materials
from the machine and inspect the machine for any damaged, missing or loose
hardware.
IF THERE IS ANY DAMAGE, CONTACT THE DELIVERING CARRIER
IMMEDIATELY AND FILE A CLAIM.

Page 8
MODEL IQ SAFETY INSTRUCTIONS
1) Never open control panel while power source is connected. Product safety labels
must remain highly visible on the equipment. Establish a regular schedule to check
visibility. Should safety labels require replacement, contact Weigh Right ASC for an
additional supply, free of charge.
2) Disconnect and lock out the power supply before performing any maintenance or
operation adjustments.
3) DO NOT make any alterations to the controls without first contacting the Weigh
Right ASC Engineering Dept. Un-authorized alterations will void the warranty.
Weigh Right ASC will not assume responsibility for damage that may occur due to
unauthorized alterations to the controls.
4) DO NOT dis-assemble to clean when power source is connected.
5) DO NOT put hands or fingers near conveyor when power source is connected.
6) DO NOT remove guards while machine is connected to power supply.
7) DO NOT remove hoppers while machine is connected to power supply.
Control Panel cover must be closed and secured while power source is
connected
INSTALLATION
Machine installation is accomplished in two steps: Positioning of the Machine in Work
Area and Connection of Air and Power. Follow these steps and the machine will be
ready for loading of your product, adjustment and operation.
MACHINE POSITIONING
The machine should be placed so that it can be accessed easily from all four sides. The
top of the machine has a supply hopper for loading of the product; therefore do not
block the top of the machine. The height of the machine, which can be adjusted with
threaded leveling feet, is usually determined by the method by which the bags are filled.
Manual filling will require the machine to be set at a comfortable height for the operator.
Automatic filling processes because of the way they operate usually require the
machine to be set at a pre-engineered height, based on conveyors and other pieces of
equipment.

Page 9
ADJUSTING HEIGHT
Height adjustment of the machine is accomplished by loosening (but not removing) the
four leveling feet on either side of the main machine chassis. Move the machine to the
desired height and tighten the lock nuts. Make sure it is level before tightening the bolts
all the way.
THE MACHINE IS TOP HEAVY! DO NOT LOOSEN THE LEVELING FEET UNTIL
PROVISIONS HAVE BEEN MADE TO SUPPORT THE MACHINE WHEN IT IS OFF
OF THE GROUND. MAKE SURE A 1” MINIMUM OF THREAD IS LEFT IN THE
THREADED FRAME POST.
CONNECTION OF AIR AND POWER
Most IQ 1E(s) machines come with an Air Compressor mounted to the frame. If not, the
main air filter regulator assembly is attached to the right rear corner of the machine and
has a
¼”
NPT port for the plumbing of the air supply. Connection can be made with
either a quick connect nipple or hard plumbed with a hose fitting.
THE AIR SUPPLY TO THE MACHINE IS FITTED WITH A SUPPLY CUTOFF
DEVICE. IN THE EVENT OF AN EMERGENCY SITUATION THIS DEVICE WILL BE
NECESSARY TO DISCONNECT THE MACHINE FROM THE MAIN AIR SUPPLY.
The machine comes equipped with a standard 3-prong male 120-volt line cord. Uncoil
the cord and straighten it out. On the front left corner of the machine, locate the
EMERGENCY STOP switch. Make sure the switch is depressed, which is the off
position. Plug the cord into an acceptable outlet as outlined in set up section on power
requirements.
If a footswitch is supplied, the assembly may be equipped with a 4-pin cable.
Locate the receptacle, align the pins and push the plug into the receptacle.

Page 10
IQ ASSEMBLY INSTRUCTIONS
1. Install (4) leveling feet or casters to machine lower base. Frame should be level
when in final position.
THE MACHINE IS TOP HEAVY! DO NOT LOOSEN THE LEVELING FEET UNTIL
PROVISIONS HAVE BEEN MADE TO SUPPORT THE MACHINE WHEN IT IS OFF
OF THE GROUND. MAKE SURE A 1” MINIMUM OF THREAD IS LEFT IN THE
THREADED FRAME POST.
2. Install weigh buckets onto load cell mounting platform. NOTE: Lower bucket
through rectangular hole in frame, place studs in slot then slip down into “key hole”
notch. (see drawing below)
3. Install machine discharge hopper using hardware provided. (This requires 2 or more
persons.)
4. Re-tighten all electrical terminals and connections after shipping; check for loose
nuts and bolts on machine.
5. Connect air and power; Check scale with 5.00 lb. test weight provided. If scale is
not accurate, follow the calibration procedure as listed in the indicator
instructions. (If scale is oz.; 5 lb. = 80 oz., if scale is grams; 5 lb. = 2268 grams)

Page 11
General Description
The Weigh Right IQ series is an automatic packaging machine that fills by weight and
dispenses your product into containers or bags.
The product is fed automatically into a weigh bucket by a vibratory feed system. When the
desired preset target weight is attained, a gate or feeder stops the feeding of the product and
the weigh bucket dumps the material into the container when a dump signal is received by
footswitch or conveyor sensor.
The vibratory feed system features multi speed controls for fast bulk feeding and slow dribble
feeding for a fast and accurate fill.
The electronic weigh scale indicates the weight at any time during the filling process through a
digital readout.
The IQ Series features solid state electronic controls for speed, accuracy, and reliability.
Operation
Open hopper flow gates to desired opening for unrestricted product flow.
1. The machine is ready to start feeding product when the supply hopper is full.
2. Rotate (clockwise) the red E-Stop button so it will “pop out”.
3. Press “Start”. Next press the “Hopper Vibr” button to turn on the Supply Hopper Vibrator
(this is optional and not required to run the machine).
4. Press the “Settings” button and enter the desired weight and Fast Rate/Slow Rate fill
speeds. (See the Control section for pictures/explanations of function keys)
5. Adjusting the speeds also changes the filling speed. This range is from 0 -100%. This
unit is equipped with a Fast Rate and Slow Rate sequence. The Fast Rate setting should
always be higher than the Slow Rate setting. This assures the most accurate filling.
6. Note: The machine is factory tested with Typical Settings saved as Job 1. Use
these as an example for “startup” settings and modify them as it suits your
product. Insure the Vibrator Pan has an even flow of product (½” to ¾” deep is
typical) and Fast/Slow Rates at 80/20 (again, these are typical rates). Timers are
then adjusted to obtain a fast and accurate fill of the desired weight.
7. If auto-adjust mode is turned “ON”, run the product through about 50 fill/dump
cycles so the machine may “learn” the correct settings for your product.
8. Before beginning production, press the “zero” key to zero the scale. This also must be
done when the machine is in the “Stop” mode INSURE NO PRODUCT IS IN THE
BUCKET WHEN THIS BUTTON IS PRESSED!
9. Pressing the “Start Scale” starts the filling process.
10. Allow for several dump cycles to complete before adjusting any settings, as product
must fill the trays evenly to achieve proper weights.

Page 12
CONTROLS
“Start/Stop Screen”
This Button displays this Screen
Start/Stop Scale – Starts/Stops the machine
Cycles per Minute - Displays the Containers per
minute. This value is averaged over time.
Last Weight - Displays the last fill weight of each
bucket dumped.
OZ – By selecting this button you can set what value
to measure and display (lbs., oz., kg, g.) Machine
must also be in “Stop” mode to change value
Live Weight - Displays the current live weight of
each bucket. (Large Display at top of screen).
Settings - Sets speed rates for feeders and timer
values.
Auto Cycle - The machine will simulate a foot pedal
press every X seconds as programmed in the Auto
Cycle (Settings Screen).
Recipes - Recalls stored jobs
Manual Dump - Manually dumps the weigh bucket.
(Press and Hold button). Note: Air compressor has
to be turned on for this to function
#of dumps - Allows user to set multiple dump cycle
with each foot switch input
Air Compressor - Used to turn on/off air supply.
Hopper Vibr. - Turns Supply Hopper Vibrator
on/off.
Gate – Notepad for Supply Hopper Gate setting.
(Performs no function, other than to annotate gate
opening.)
Batch Count – Allows user to set a number of
dumps to occur automatically and stop. Also
shows how many have occurred.
Re-zero Count - Allows user to set frequency of the
automatic re-zero function. Also shows how many
have occurred.
Zero Scale - Allows user to instantly re-zero scale.
INSURE NO PRODUCT IS IN THE BUCKET
WHEN THIS BUTTON IS PRESSED!
Current Recipe – Displays the Job number and
description of the job in memory.
Help – Displays Help screens that offer
explanations for the function of each button.
Note1: Some functions are not accessible unless
machine is in “Stop” mode.
Note2: All buttons have color. White background(s)
are for display only.

Page 13
“Settings”
This Screen is displayed when the “Settings” button is pressed
Select any of the 3 yellow buttons on the left side to adjust the settings.
Calibrate Load Cell – Used to Calibrate Load Cell span using a test weight.
This is usually not necessary unless the Load Cell is replaced or the indicator has lost battery
backup of parameters.
This area is also password protected. The password is 4321.
Dump History – Displays the last 20 dump weights

Page 14
“Set Weights”
This Screen is displayed when the “Set Weights” button is pressed
Target Weight – Desired final weight
Bulk Percentage- The percentage of product run in bulk mode (Fast Rate) before the feeders start to run
slower.
Free Fall Amount- The amount of product in the air that has not been measured yet. The filler will stop
short to account for the freefall amount.
Number of Dumps – For large amounts, multiple dumps my. be required to achieve desired weight
Back – Returns you to Previous Screen
Home – Returns you to Main Operators Screen
To change any value, press the yellow portion of the appropriate button, enter in the new value, and press
“ENT” to accept that value.
Note: All These Values will be saved when a recipe (job number) is assigned

Page 15
“Speed Adjustments”
This Screen is displayed when the “Speed Adjustments” button is pressed
Fast rate - The Speed range is 0-100%. Increasing the number speeds up the vibrator.
Slow rate - The Speed range is 0-100%. Increasing the number speeds up the vibrator.
Main Tray
– Controls the rates of the Main tray. These values have to be set manually.
Note: The Fast Rate should always be Higher than the value of the Slow Rate.
Back – Returns you to Previous Screen
Home – Returns you to Main Operators Screen
To change any value, press the yellow portion of the appropriate button, enter in the new value, and press
“ENT” to accept that value.
Note: All These Values will be saved when a recipe (job number) is assigned

Page 16
“Timer Adjustments”
This Screen is displayed when the “Timer” button is pressed
Dribble Pulse Time – Time allowed for dribble to “burst” to achieve final weight. Typical is .25 seconds
Settle Time – Time before scale takes final weight measurement. Typical is .5 seconds
Dump Time - Time for the weigh bucket to remain open. Typical is 1.00 seconds
Auto Cycle – Sets time delay to simulate a foot pedal press. The machine will wait for X seconds to send
a signal to dump product.
Drop Delay - Delay to allow product to fall in Discharge Hopper before sending signal to external
equipment (such as a conveyor, bagger, etc.). Typical is 0.50 seconds
Back – Returns you to Previous Screen
Home – Returns you to Main Operators Screen
To change any value, press the yellow portion of the appropriate button, enter in the new value, and press
“ENT” to accept that value.
Note: All These Values will be saved when a recipe (job number) is assigned

Page 17
“Pieces Screen”
The “Set Piece Weight” button is displayed only when “count” mode has been selected on the
Units Screen
When the Unit “count” on the Main Screen is selected, the Piece Weight button will then
display in the “Save Job” Screen.
Select “Set Piece Weight” to obtain the Piece Weight Screen
Select a number of pieces for a good averaged weight, 20 to 50 for small pieces (ex:
#10 washers), 10 to 20 for large pieces (ex: ¾” washers). Note: More pieces will
produce a more accurate count, but make sure your count is exact!
Press “Zero Scale”, and then place pieces in the bucket.
Press “Calculate”, this will then display a calculated Per Piece Weight. You may
perform this as many times as you desire, but when the back button is pressed, the last
value displayed will be stored in memory.

Page 18
“Recipe”
This Screen is displayed when the “Recipe” button is pressed. This Screen is not password
protected.
This screen allows for quick operator recall of previously saved Jobs.
1 to 50 buttons – Are available and are used to select the Job Number to recall and display
jobs saved.
To recall a job, press the displayed number (ex: 01) and the machine will then return you to the
Main Screen with the job number selected.
To view other Jobs, press the “>” button to scroll to the next 5 Jobs listed
Current Recipe, displays the current job in memory
If you do not want to select a job, press the “Exit” button at any time to return to the Main
Screen.

Page 19
“Password request page”
Enter a password when requested. Press the yellow portion of the number and a keypad will
display for entry. Type in the password and press “ENT”. Password is 4321

Page 20
“To save a new job”
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
To save your CURRENT SETTINGS;
1. Select the Recipe button on the Main Screen
2. Select the “Save Recipe” button
3. Select the Job number that you want the Job stored in
4. The “Password” screen will appear. Enter the password assigned.
The password is 4321
5. The “Recipe Entry” screen will then appear. Select the yellow portion of the description
button so you can change the title of the job.
6. An entry screen will appear, type in the name of the job, then press “ENT”. You will then
be returned to the “Recipe Entry” screen. Press “Yes” to save the job
7. Press “Exit” to return to the Main Screen
