USER’S MANUAL

Important safety
Product description
Exercise session
Usage environment
Product Maintenance
2
3
4
5
6

2
Warning: Before beginning this or any exercise program, please consult your physi-
cian. This is especially important for persons over the age of 35 or persons with
pre-existing health issues. Read all instructions before using the device.
It is the responsibility of the owner to ensure that all users of the vibration exercise machine
are adequately informed of all warnings and precautions.
Use the Vibration Exercise Machine only as mentioned in the manual.
Place the vibration exercise machine on a level surface, with at least 8 feet of clearance
behind it. Do not place the deviceon any surface that blocks air openings. To protect the floor
or carpet from damage, place a mat under the power trainer plus.
Keep the device indoors, away from moisture and dust. Do not put the device in a garage,
covered patio or near water.
Do not operate the device where aerosol products are used or where oxygen is being
administered.
Keep children under the age of 12 and pets away from the device at all times.
The device should not be used by persons weighing above 120 kg.
Never allow more than 1 person on the device at a time.
Keep the power cord and surge suppresoraway from heated surfaces.
Never leave the device unattended while it is running. Always remove/unplug the power
cordwhen the device is not in use.
Do not attempt to move or adjust the device until it is properly assembled.
Inspect and Tighten all partsof the device regularly. Wrong usage could influence the stability
of the device.For example: the post is made to support you during an exercise to keep you in
balance. One should NOT PUSH the post fro stretching or use the post to create more tension.
Never insert or drop an object into any opening.
DANGER: Always unplug the power cord immediately after use, before cleaning the device
and before performing the maintenace and adjustment procedures described in this
manual. Never remove the motor hood unlessinstructed to do so by an authorized service
representative.Servicing other than the procedures mentioned in this manual should be
performed by an authorized service representative only.
This device is intented for in-house use only. Do not use the vibration exercise machine in
any commercial, rental or institutional setting.
Please keep this manula in a safe place for reference
WARNING: To reduce the risk of burns, fire, electric shock or injury to persons, read the following
important precautions and information before operating the fitness vibration
machine.
IMPORTANT SAFETY INSTRUCTION
2.
1.
3.
4.
1.
5.
6.
7.
9.
8.
10.
11.
12.
13.
14.
15.

Power switch
Time -
Speed -
Magnetic massager
Vibrating Platform(Antiskid pedal)
LED screen
Power Plug
Power switch
Warming label
FeetBase
Cover
Walking mode
Jogging mode
start
Speed +
Time +
Speed -
Speed shortcuts:
Switch gear to 20、50、
80 level
mode button: You can choose
the most comfortable frequency
according to different gear
Running mode
3
1.Name & Components
2.Console
3.Remote Control

4
The Exercise Vibration Machine uses your own body to create an effective full-body
workout that targets your muscle size and tone, your balance, and also your endurance
without taking too much of your time or energy. This device works best in stress taking
positions like squats. You stand on top of the machine, which allows powerful vibrations
to pass through your body from the machine. These vibrations cause your muscles to
rapidly move, forcing them to work harder to keep your body balanced, and this effort
leads to an intense workout that you can feel all over. For the best results, you should
always carry out your workout using the positions shown, but the device will also double
up as a massager for when you are not working out. You can carry out multiple
positions one after another for an effective full-body workout.
Stand on the plate with
your feet positioned so
their width apart is in
like with your shoulders.
This will give you a
comfortable balance
and ensure that the
vibrations pass through
your whole body to
provide muscle tone.
Whole body
exercise posture Stretch your legs as
wide as your shoulders
when squatting and
bend your knees down
to 90 degrees if you
can and hold the
position. This is great
for your legs and your
core muscles too.
Squat Posture
Position your hands in
line with your shoulders.
If you wish to exercise
the muscles more,
bend your elbows to 90
degrees and hold this
position.
Press Up posture
Put your lower legs as
shown on the plate with
your hands supporting
behind you on the floor.
For a deeper exercise,
raise your buttocks off
the floor and press
down on your calves.
Lower Legs posture
Position your legs wide
apart, bend down at the
waist and put your
hands on the plate.
Bend your elbows for a
deeper exercise.
Waist bend posture
Put one foot on the
footpad and on the
machine and the other
off of the machine on the
floor. For a deeper
exercise, lunge forward,
placing more body
weight on the plate.
Single Foot posture
Sit with your buttocks
on the Exercise
Vibration Machine. Sit
comfortably, keeping
your back straight.
Sitting Posture 1
Rest your legs on the
Exercise Vibration
Machine whilst sitting on a
chair. This is a great way
to ease tension and can
help to support circulation
in the legs.
Sitting posture 2

• Do NOT use the Machine in an excessively humid or dusty environment as it may result in
malfunction or electric shock.
• Do NOT expose the machine to heaters,stoves or direct sunlight
• Place and use the machine on an even,non-slip floor.Keep the product away from the
pets and children.The machine is designed for home use and not for commercial purpose.
Please stop using it if the following cases happen
• You should stop using the machine immediately when the following cases happen,
and turn the power off, pulled the power line out from the outlet. Splash water or
other liquid on products or remote control.
• Relevant parts are damaged or the inside occurs abnormal sound.
• Feel abnormal body or local pain during use the product, and power outages suddenly.
• Thunder and lightning occur.
Phenomena Common reasons Methods
Unable to start work
Power plug didn't connect well Connect the power plug
power switch do not turn on Turn on the power switch
and the indicator lights up.
Fuse was burned out for Excessive
current abruptly
change a fuse of the same
model
Machine noise like
pinging and dada.
It is normal operaon sound not for
machinery breakdown.
Don't need to deal with
The remote control
doesn't work
It has a dead baery
Replace the baery
The control distance is too far
The effecve infrared sensing
range is 2.5m
Stop working when
using
Default working me is over Operate again in the interval of
10min
Unable to operate
normally
Maybe execute commands too oen
turn offthe power and restart
If the breakdown has not been solved after the above methods, please contact the
manufacturer or local dealers, and do not disassemble and maintain by yourself.
5

Product placement and storage
Environment factors can strongly affact the product physically and mechanically.
Do not expose the machine to direct sunlight or in places with extreme heat in order
to avoid the machine cracked or the color faded.
Please cover it with a dust cover and disconnect the power plug from the electrical
outlet ifthe machine is not to be used for a long time.
Do not use benzene thinner and corrosive and volatile detergent such as alcohol and
gasolineto clean the machine.This may result in the paint faded or cause the interior
structure corrosive and cracked. Don't spilled the liquid into the body inside in case
of power short circuit.
Please wipe the remote control with dry cloth. Wet cloth may result in malfunction.
Product Name: Vibration Exercise Machine
Rated Voltage: 220V-240V/50Hz
Rated Power: 200W
Suggested Usage Time: 15mintues
Max.Loading: 120KGS
Technical Specification
