Weizhen WZ-VC-4 Installation manual

LCD VISUAL CHART OPERATION MANUAL

Sitting type installation
Notice: Installations are not the same with different kind of structure .
Sitting type-I:
Fixed with screws, Process installation with following steps
Take out instrument and bottom case from package, take put screws from
accessory bag.
2、Put instrument on desk or flat surface and install bottom case to instrument.
3、Fix screws onto pillars( attention: Fix screw with appropriate force to ensure
parts just been fixed. Excessive force will damage instrument)
4、After plugging in the power apd U disc, instrument is ready for visual test.
Sittingtype-11 :
1、Take out instrument and bottom case from package
2、Put instrument on desk or flat surface.
3、Put pillars(on instrument) into holes on basement case.
4、Ensure male slot being plugged into and fixed with femaleo.
5、After plugging in power and U disc. instrument is ready for visual test.
Installation guide for hanging-type instrument.
Process installation with following steps for all kinds. of hanging-type
instrument:
1、Take out instrument and hanger parts from package. Hanger usually has
been installed with mstrument.
2、Select appropriate area and use hanger plate to mark fixing holes on the
wall;
3、Drill four fixing holes and fix hanger plate with bolts.
4、Hang instrument on the wall.
5、After plugging in power and U disc, instrument is ready for visual test.
Installation guide
- 01 - - 02 -
LCD Chart System
English user’s manual
Dear users:
Thanks for using this LCD chart system chart produced by our company. We
hope that our product will dedicate you a convenient life and new feeling.
With the advanced convenient life and new feeling.With the advanced
numerical processing technology 、multifunctional and perfect (accurate)
optotype , This inteligent vision chart is your best choice of optometr y
instrument.
*If there are any differences between the pictures/signs/symbols used in this
manual and the actual product, please take the. actual product as the standard.
* Please comply with the cautions/notices listed in this manual.
Product Series
Product types are still increasing.
Type Display 3D
Polarization
3D
Screen Max.R .P. Red/
Green
Dot Pitch
WZ-VC-1
WZ-VC-2
WZ-VC-3
WZ-VC-4
21.5"
19"
21.5"
19"
21.5"
1680x1050
1440x900
1680x1050
1440x900
1920x1080
0. 282mm
0. 284mm
0. 282mm
0. 284mm
0.2475mm
√
√
√
√
√
√
√
√
√
√ √

- 03 -
１． Ｄｅｌｉｃａｔｅ ｄｅｓｉｇｎ ｈｉｇｈ ， ｄｅｆｉｎｉｔｉｏｎ ｄｉｓｐｌａｙ： Ｔｈｉｓ ｉｎｓｔｒｕｍｅｎｔ ｉｓ ｄｅｓｉｇｎｅｄ ｗｉｔｈ ｐｒｏｆｅｓｓｉｏｎａｌ ｖｉｄｅｏ
ａｎｄ ａｕｄｉｏ ｍｕｌｔｉｍｅｄｉａ ｐｒｏｃｅｓｓｉｎｇ ｔｅｃｈｎｏｌｏｇｙ， ｗｉｔｈ ｒａｐｉｄ ｒｅｓｐｏｎｓｅ ａｎｄ ｃｏｎｖｅｎｉｅｎｔ ｏｐｅｒａｔｉｏｎ．
２． Ｗｉｔｈ Ｐｒｏｔｅｃｔｉｎｇ ｆｕｎｃｔｉｏｎ ｔｏ ｅｎｓｕｒｅ ｌｏｎｇ ｌｉｆｅｓｐａｎ ｏｆ ｔｈｅ ｓｃｒｅｅｎ；
３． Ｃｏｍｐａｔｉｂｌｅ ｗｉｔｈ ｍｕｌｔｉｆｏｌｄ ｔｙｐｅｓ ｏｆ ｖｉｄｅｏ ａｎｄ ａｕｄｉｏ ｆｉｌｅｓ
４． Ａｃｃｕｒａｔｅ ａｎｄ ｅｘａｃｔ， ｅｆｆｅｃｔｉｖｅ ｄｉｓｔａｎｃｅ ｉｓ ２－７ｍ， ｃａｎ ｂｅ ａｄｊｕｓｔ ｔｏ ｔｈｅ ｍｉｎｉｍｕｍ
ｄｉｓｔａｎｃｅ（ｌｍ） ｆｏｒ ｃｒｏｗｄｅｄ ａｒｅａ．
５．Ｗｉｔｈ ｔｈｅ ｍａｘｉｍｕｍ ３ ｌｉｎｅｓ ａｎｄ ８ ｒｏｗｓ ｏｆ ｏｐｔｏｔｙｐｅｓ ｓｈｏｗｉｎｇ ｏｎ ｓｃｒｅｅｎ， ｃｏｎｖｅｎｉｅｎｔ ｆｏｒ ｔｅｓｔ．
６． Ｎｕｍｅｒｏｕｓ ｏｐｔｉｏｎ ｏｆ ｏｐｔｏｔｙｐｅｓ： ｉｎｔｅｒｎａｔｉｏｎａｌ Ｃ ｏｐｔｏｔｙｐｅｓ， Ｅ ｏｐｔｏｔｙｐｅｓ， ｌｅｔｔｅｒ ｏｐｔｏｔｙｐｅｓ ｃｈｉｌｄｒｅｎ
ｏｐｔｏｔｙｐｅｓ 、ｎｕｍｅｒｉｃ ｏｐｔｏｔｙｐｅｓ 、ａｓｔｉｇｍａｔｉｃ ｏｐｔｏｔｙｐｅｓ 、ｃｒｏｓｓ ｏｐｔｏｔｙｐｅｓ 、ｂｉｎ．ｏｃｕｌａｒ ｂａｌａｎｃｅ
ｏｐｔｏｔｙｐｅｓ 、ｃｏｌｏｒ ｂｌｉｎｄｎｅｓｓ ｏｐｔｏｔｙｐｅｓ， ａｎｄ ｓｏ ｏｎ ．
７． Ｃｏｎｖｅｎｉｅｎｔ ａｎｄ ｑｕｉｃｋ ｉｎｓｔａｌｌａｔｉｏｎ： ｓｉｍｐｌｙ ｈａｎｇ ｏｒ ｐｌａｃｅ ｏｎ ｓｏｌｉｄ ｓｕｒｆａｃｅ， ｅａｓｙ ｔｏ ｍａｉｎｔｅｎａｎｃｅ．
８． ＬＣＤ ｓｃｒｅｅｎ ｗｉｔｈ ｔｈｅ ｍｉｎｉｍｕｍ（０．２６４ｍｍ／０．２８２ｍｍ／０．２８４ｍｍ） ｏｆ ｄｏｔ ｐｉｔｃｈ ａｎｄ ｈｉｇｈ ｒｅｓｏｌｕｔｉｏｎ，
ｖｉｖｉｄ ｔｏ ｄｉｓｐｌａｙ ｐｔｏｔｙｐｅｓ．
９． Ｐｏｗｅｒｆｕｌ ｅｘｔｅｎｄｅｄ ｆｕｎｃｔｉｏｎ： ｉｎｓｔｒｕｍｅｎｔ ｃａｎ ｂｅ ｕｓｅｄ ａｓ ａ ｃｏｍｐｕｔｅｒ ｄｉｓｐｌａｙ， ｏｒ ａｓ ａ ｍｕｌｔｉｍｅｄｉａ
ｐｌａｙｅｒ
１０． Ａｌｌｏｗｓ ｔｏ ｃｏｎｎｅｃｔ ｗｉｔｈ ＶＧＡ／Ｓ－ＶＩＤＥＯ／ＡＶ／ＴＶ ｓｉｇｎａｌ．
１１． ３Ｄ－ｔｙｐｅ ｉｎｓｔｒｕｍｅｎｔ ｉｓ ｄｅｓｉｇｎｅｄ ｗｉｔｈ ｓｔｅｒｅｏ ｐｏｌａｒｉｚａｔｉｏｎ ｓｐｅｃｉａｌｌｙ ｕｓｅｄ ｆｏｒ ｅｘａｍｉｎｅ ｏｆ ｓｔｅｒｅｏ
ｖｉｓｉｏｎ ａｎｄ ｂｉｎｏｃｕｌａｒ ｂａｌａｎｃｅ
Ｎｏｔｉｃｅ ａｂｏｕｔ ＬＣＤ ｓｃｒｅｅｎ
ＬＣＤ．ｓｃｒｅｅｎ ｉｓ ｐｒｏｄｕｃｅｄ ｗｉｔｈ ｈｉ－ｔｅｃｈ ９９． ９％ ｏｒ ｈｉｇｈｅｒ ｅｆｆｅｃｔｉｖｅ ｐｉｘｅｌｓ． Ｐｏｓｓｉｂｌｅ ａｐｐｅａｒａｎｃｅ ｏｆ ａ
ｆｅｗ ｂｌａｃｋ ｏｒ ｃｏｌｏｒ ｄｏｔｓ ｏｎ ｔｈｅ ｓｃｒｅｅｎ ｉｓ ｎｏｒｍａｌ ｐｈｅｎｏｍｅｎａ； ｔｈｅｓｅ ｄｏｔｓ ｗｉｌｌ ｎｏｔ ａｆｆｅｃｔ ｔｈｅ ｎｏｒｍａｌ
ｓｃｒｅｅｎ ｐｅｒｆｏｒｍａｎｃｅ．
Ｎｏｔｉｃｅ ａｂｏｕｔ ｂａｃｋｇｒｏｕｎｄ ｌｉｇｈｔ
ＬＥＤ ｌｉｇｈｔ ｉｓ ｕｓｅｄ ａｓ ｔｈｅ ｂａｃｋｇｒｏｕｎｄ ｌｉｇｈｔ， ｉｆ ｓｃｒｅｅｎ ｂｅｃｏｍｅｓ ｆａｄｅ、ｆｌｉｃｋｅｒｉｎｇ
ｏｒ ｓｔｏｐｓ ｓｈｏｗｉｎｇ ｔｈｅ ｉｍａｇｅ， ｉｔ ｍｅａｎｓ ｔｈａｔ ｔｈｅ ＬＣＤ ｓｃｒｅｅｎ ｉｓ ａｇｅｄ ａｎｄ ｓｈｏｕｌｄ ｂｅ ｒｅｐｌａｃｅｄ．
Ｎｏｔｉｃｅ ａｂｏｕｔ ｄｉｓｃａｒｄｉｎｇ
ＬＣＤ ｓｃｒｅｅｎ ａｎｄ ｂａｃｋｇｒｏｕｎｄ ｌｉｇｈｔ ｃｏｎｔａｉｎｓ ａ ｓｍａｌｌ ｑｕａｎｔｉｔｙ ｏｆ ｍｅｒｃｕｒｙ， ｐｌｅａｓｅ ｔｒｅａｔ ｔｈｅ ｗａｓ ＬＣＤ
ｓｃｒｅｅｎ Ｃｏｍｐｌｉａｎｃｅ ｗｉｔｈ ｔｈｅ ｌｏｃａｌ ｌａｗ． ，
Ｓｅｒｖｉｃｅ ｃｏｎｄｉｔｉｏｎ
Characteristic
Notice of characteristic
Working tempetature : 5℃---35℃
Working humidity: 20%RH-80%
Atmospheric pressure: 86KPa--106KPa
Parameter
Items
Technical parameter
Parameter
Max. remote-controlling distance >8m
Imperial fraction, or decimal
Electrical source
Rated power
Standby power
Screen resolution ratio
Dot pitch
Screen ratio
Screen type
Screen size
Visible angle
Color
Visible size
Max. Brightness
Max.contrast ratio
Signal response time
Overal,l size(mm)
Weight
Effective distance
Record of vision test result
Emote-controlIing distance
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
(Adjustable)(Adjustable)(Adjustable)
- 04 -
Dimension

- 05 -
Structure and function
Signal receive point
Power lamp
Panel adjusting key
Hanger fixing holes
Hanger fixing screw
Bottom case
Hanger accessory
Remote Controller
Power line
To receive control signal
Indication of power state
Used set parameters
Used to fix instrument on wall
Used to fix hanger
Used to support instrument for sitting type instrument
For hanger fixing
Used to control. instrument
Used to supply power with adapter
Connection with peripheral equipment
This instrument can be connected with other peripheral equipments, please refer to followin
pictures for connection
- 06 -
Ｆｕｎｃｔｉｏｎ ｓｗｉｔｃｈ
Ｐｏｗｅｒ ｂｕｔｔｏｎ
Ｂｉｎｏｃｕｌａｒ ｂａｌａｎｃｅ Ｒｅｄ ａｎｄ ｇｒｅｅｎ ｃｏｌｏｒ
ｂａｌａｎｃｅ
Ｃｈｉｌｄｒｅｎ ｏｐｔｏｔｙｐｅｓ
Ｎｕｍｅｒｉｃ ｏｐｔｏｔｙｐｅｓ
Ｉｅｔｔｅｒ ｏｐｔｏｔｙｐｅｓ
Ｃ ｏｐｔｏｔｙｐｅｓ
Ｅ ｏｐｔｏｔｙｐｅｓ
Ｐａｒａｍｅｔｅｒ ｓｅｔｔｉｎｇ
Ｅｙｅｂａｌｌ ａｎａｌｙｓｉｓ ｄｉｓｐｌａｙ
ｉｎｖｅｒｔｅｄ ｏｐｔｏｔｙｐｅｓ
Ｂａｃｋｌｉｇｈｔ ｆｕｎｃｔｉｏｎ Ａｓｔｉｇｍａｔｉｃ ｏｐｔｏｔｙｐｅ
Ｃｏｎｔｒａｓｔ ｓｅｎｓｉｔｉｖｉｔｙ
Ａｍｂｌｙｏｐｉａ ｔｒａｉｎｉｎｇ Ａｕｔｏｍａｔｉｃ ｏｐｅｒａｔｉｏｎ
Ｉｉｎｅ ｄｉｓｐｌａｙ Ｓｉｇｎａｌ ｄｉｓｐｌａｙ
Ｉｉｓｔ ｄｉｓｐｌａｙ Ｒｅｓｕｍｅ ｄｉｓｐｌａｙ
Ｂｒｏｗｓｉｎｇ
Ｒｅｄ ａｎｄ ｇｒｅｅｎ ｃｏｌｏｒ
ｄｉｓｐｌａｙ
01
02
03
04
05
06
07
08
09
Main instrument
Controller
Controller battery
Hanger
hanger fixing screws
power line
User’s manual
Warranty card
Certification
1
1
2
1
4
1
1
1
1
NotesQuantityItems Name
Packing list
Ｓｉｇｎａｌ ｌｉｇｈｔ
ｓｉｇｎａｌ ｒｅｃｅｉｖｅ ｐｏｉｎｔ ｍａｉｎ ｂｏｄｙ
ｐａｎｅｌ ａｄｊｕｓｔｉｎｇ ｋｅｙ ｂｏｔｔｏｍ ｃａｓｅ ｂａｓｅ ｃｏｎｎｅｃｔｉｏｎ
ｐｏｗｅｒ ｌｉｎｅ
ｐｏｗｅｒ ｓｏｃｋｅｔ ｈａｎｇｅｒ ｆｉｘｉｎｇ ｈｏｌｅｓ
ｈａｎｇｅｒ ｆｉｘｉｎｇ ｓｃｒｅｗｓ
ｈａｎｇｅｒ ａｃｃｅｓｓｏｒｙ
ｒｅｍｏｔｅ ｃｏｎｔｒｏｌｌｅｒ

- 07-
Ｍａｎｕｌ ｏｆ ｒｅｍｏｔｅ ｃｏｎｔｒｏｌｌｅｒ
１． Ｏｐｔｏｔｙｐｅｓ ｃｈｏｏｓｉｎｇ
Ｐｒｅｓｓ ｃｏｒｒｅｓｐｏｎｄｉｎｇ ｂｕｔｔｏｎ ｏｎ ｔｈｅ ｃｏｎｔｒｏｌｌｅｒ ｔｏ ｃｈｏｏｓｅ ｄｉｆｆｅｒｅｎｔ ｏｐｔｏｔｙｐｅｓ
２． Ｆｕｃｔｉｏｎ ｃｈｏｏｓｉｎｇ
１． Ｌｉｎｅ ｄｉｓｐｌａｙ ： ｄｉｓｐｌａｙ ａｓ ｌｉｎｅｓ
２． Ｌｉｓｔ ｄｉｓｐｌａｙ： ｄｉｓｐｌａｙ ａｓ ｌｉｓｔ
３． Ｓｉｇｎａｌ ｄｉｓｐｌａｙ： ｄｉｓｐｌａｙ ａｓ ａ ｓｉｇｎａｌ
４． Ｒｅｄ ａｎｄ ｇｒｅｅｎ ｃｏｌｏｒ ｄｉｓｐｌａｙ： ｄｉｓｐｌａｙ ａｓ ｒｅｄ ａｎｄ ｇｒｅｅｎ ｃｏｌｏｒ
５． Ｆｕｌｌ ｓｃｒｅｅｎ ｄｉｓｐｌａｙ： ｄｉｓｐｌａｙ ａｓ ｆｕｌｌ ｓｃｒｅｅｎ
３． Ｗｏｒｋｉｎｇ ｐａｒａｍｅｔｅｒ ｃｈｅｃｋｉｎｇ
Ｉｎ ｓｐｉｔｅ ｏｆ ａｎｙ ｃｏｎｄｉｔｉｏｎ， ｐｒｅｓｓ ｔｈｅ ｐａｒａｍｅｔｅｒ ｓｅｔｔｉｎｇ ｂｕｔｔｏｎ， ｕ ｃａｎ ｃｈｅｃｋ ｔｈｅ ｗｏｒｋｉｎｇ
ｐａｒａｍｅｔｅｒ， ｃｏｎｔａｉｎｓ ｌｉｇｈｔｎｅｓｓ， ｃｏｎｔｒａｓｔ ｒａｔｉｏ， Ｒ． Ｇ． Ｂ． Ｎｕｍｂｅｒ ， ｌａｎｇｕａｇｅ， ｗｏｒｋｉｎｇ ｍｏｄｅ，
ｅｆｆｅｃｔｉｖｅ ｄｉｓｔａｎｃｅ， ａｕｔｏｍａｔｉｃ ｏｐｅｒａｔｉｏｎ ｔｉｍｅ， ｓｃｒｅｅｎ ｓａｖｅｒ ｐａｒａｍｅｔｅｒ
４． Ｗｏｒｋｉｎｇ ｐａｒａｍｅｔｅｒ ａｄｊｕｓｔｍｅｎｔ
Ｉｎ ｓｐｉｔｅ ｏｆ ａｎｙ ｃｏｎｄｉｔｉｏｎ， ｐｒｅｓｓ ｔｈｅ ｐａｒａｍｅｔｅｒ ｓｅｔｔｉｎｇ ｂｕｔｔｏｎ， ｕｓｅ ｕｐ ａｎｄ ｄｏｗｎ ｂｕｔｔｏｎ
ｔｏ ｃｈｏｏｓｅ ｔｈｅ ｐａｒａｍｅｔｅｒ ｕ ｗａｎｔ ｔｏ ａｄｊｕｓｔ， ｔｈｅｎ ｕｓｅ ｌｅｆｔ ａｎｄ ｒｉｇｈｔ ｂｕｔｔｏｎ ｔｏ ａｄｊｕｓｔ ｔｈｅ
ｐａｒａｍｅｔｅｒ
５． ａｕｔｏｍａｔｉｃ ｏｐｅｒａｔｉｏｎ
Ｉｎ ｓｐｉｔｅ ｏｆ ａｎｙ ｃｏｎｄｉｔｉｏｎ， ｐｒｅｓｓ Ａｕｔｏ ｂｕｔｔｏｎ， ｔｈｅ ｏｐｔｏｔｙｐｅｓ ｗｉｌｌ ａｕｔｏｍａｔｉｃ ｃｙｃｌｅ ｄｉｓｐｌａｙ．
Ｐｒｅｓｓ ａｎｙ ｏｔｈｅｒ ｂｕｔｔｏｎ， ｔｈｅ ａｕｔｏｍａｔｉｃ ｄｉｓｐｌａｙ ｗｉｌｌ ｓｔｏｐ
６． Ｏｎ／ｏｆｆ ｂｕｔｔｏｎ
Ｕｓｅ ｔｈｉｓ ｂｕｔｔｏｎ ｔｏ ｔｕｒｎ ｏｎ ａｎｄ ｏｆｆ ｔｈｅ ｄｉｓｐｌａｙ
７． Ｏｐｔｏｔｙｐｅｓ ｂｒｏｗｓｉｎｇ
Ｉｎ ｓｐｉｔｅ ｏｆ ａｎｙ ｃｏｎｄｉｔｉｏｎ， ｐｒｅｓｓ ｕｐ ａｎｄ ｄｏｗｎ ｂｕｔｔｏｎ ｔｏ ｂｒｏｗｓｅ ｏｐｔｏｔｙｐｅｓ
８． ｉｎｉｔｉａｌ ｓｅｔｔｉｎｇ ｒｅｓｕｍｅ
Ｉｎ ｓｐｉｔｅ ｏｆ ａｎｙ ｃｏｎｄｉｔｉｏｎ， ｐｒｅｓｓ ｔｈｅ ｐａｒａｍｅｔｅｒ ｓｅｔｔｉｎｇ ｂｕｔｔｏｎ， ｕｓｅ ｄｏｗｎ ｂｕｔｔｏｎ ｔｏ ｃｈｏｏｓｅ
ｒｅｓｕｍｉｎｇ， ｔｈｅｎ ｐｒｅｓｓ ｒｉｇｈｔ ｂｕｔｔｏｎ， ｉｔ ｗｉｌｌ ｂｅ ｒｅｓｕｍｅ ｔｏ ｉｎｉｔｉａｌ ｓｅｔｔｉｎｇ
９． ｃｏｎｖｅｒｔ ｔｏ ｍｅｄｉａ ｐｌａｙｅｒ ｍｏｄｅ
Ｉｎ ｓｐｉｔｅ ｏｆ ａｎｙ ｃｏｎｄｉｔｉｏｎ， ｐｒｅｓｓ ２ｎｄｆ ｂｕｔｔｏｎ， ｗｏｒｋｉｎｇ ｃｏｎｄｉｔｉｏｎ ｗｉｌｌ ｂｅ ｃｏｎｖｅｒｔ ｔｏ ｍｅｄｉａ
ｐｌａｙｅｒ ｍｏｄｅ
１０． ｃｏｎｖｅｒｔ ｔｏ ＴＶ ｍｏｄｅ
Ｃｏｎｖｅｒｔ ｔｏ ｍｅｄｉａ ｐｌａｙｅｒ ｍｏｄｅ ｆｉｒｓｔ， ｔｈｅｎ ｉｔ ｃａｎ ｃｏｎｖｅｒｔ ｔｏ ＴＶ ｍｏｄｅ
１１． Ｃｏｎｖｅｒｔ ｔｏ ｃｏｍｐｕｔｅｒ ｍｏｄｅ
Ｃｏｎｖｅｒｔ ｔｏ ｍｅｄｉａ ｐｌａｙｅｒ ｍｏｄｅ ｆｉｒｓｔ， ｔｈｅｎ ｉｔ ｃａｎ ｃｏｎｖｅｒｔ ｔｏ ｃｏｍｐｕｔｅｒ ｍｏｄｅ
Ａｔｔｅｎｔｉｏｎ！
Ｕｎｄｅｒ ＬＣＤ ｖｉｅｗ ｃｈａｒｔ ｍｏｄｅ， ｔｈｅ ｓｏｕｒｃｅ ｂｕｔｔｏｎ ｉｓ ｕｓｅｌｅｓｓ
- 08 -
Ｔｒｏｕｂｌｅｓｈｏｏｔｉｎｇ
Ｃｏｍｍｏｎ ｆａｕｌｔｓ ａｎｄ ｒｅｐａｉｒ ｍｅｔｈｏｄｓ ａｒｅ ｌｉｓｔｅｄ ａｓ ｆｏｌｌｏｗ，
１、Ｕｎａｂｌｅ ｔｏ ｓｔａｒｔ： Ｉｎｄｉｃａｔｏｒ ｌｉｇｈｔｓ ｏｎ ｉｎｓｔｒｕｍｅｎｔ ａｎｄ ａｄａｐｔｅｒ ａｒｅ ａｌｌ
ｆｌａｓｈｉｎｇ ｓｉｍｕｌｔａｎｅｏｕｓｌｙ．
Ｆａｉｌｕｒｅ ｄｉａｇｎｏｓｉｓ ：ａｄａｐｔｅｒ ｄａｍａｇｅｄ Ｓｏｌｕｔｉｏｎ： ｒｅｐｌａｃｅ ａｄａｐｔｅｒ ｗｉｔｈ
ｎｅｗ ｏｎｅ．
２、Ｕｎａｂｌｅ ｔｏ ｃｏｎｔｒｏｌ ： Ｉｎｓｔｒｕｍｅｎｔ ｓｔａｒｔｓ ｓｕｃｃｅｓｓｆｕｌｌｙ ，ａｎｄ ｃａｎ ｂｅ
ｏｐｅｒａｔｅｄ ｂｙ ｐａｎｅｌ ｋｅｙｓ ， ｂｕｔ ｃａｎ′ｔ ｂｅ ｏｐｅｒａｔｅｄ ｂｙ ｃｏｎｔｒｏｌｌｅｒ．
Ｆａｉｌｕｒｅ ｄｉａｇｎｏｓｉｓ： ｃｏｎｔｒｏｌｌｅｒ ｄａｍａｇｅｄ ｏｒ ｂａｔｔｅｒｉｅｓ ｅｘｈａｕｓｔｅｄ．
Ｓｏｌｕｔｉｏｎ： ｒｅｐｌａｃｅ ｃｏｎｔｒｏｌｌｅｒ ｏｒ ｂａｔｔｅｒｉｅｓ；
３、Ｕｎａｂｌｅ ｔｏ ｔｅｓｔ： Ｉｎｓｔｒｕｍｅｎｔ ｓｔａｒｔｓ ｓｕｃｃｅｓｓｆｕｌｌｙ ａｎｄ ｃａｎ ｂｅ
ｏｐｅｒａｔｅｄ ｏｎｌｙ ｂｙ ｃｏｎｔｒｏｌｌｅｒ“ｓｅｔｕｐ”ｏｒ “ｒｅｄ／ｇｒｅｅｎ” ｋｅｙｓ， ｂｕｔ ｃａｎ′ｔ
ｐｒｏｃｅｓｓ ｖｉｓｕａｌ ｔｓｔ．
Ｆａｉｌｕｒｅ ｄｉａｇｎｏｓｉｓ： Ｓｏｆｔｗａｒｅ ｓｅｔｕｐ ｐｒｏｂｌｅｍ．
Ｓｏｌｕｔｉｏｎ：Ｓｏｆｔｗａｒｅ ｐ．ｅｅｄｓ ｔｏ ｈｅ ｕｐｄａｔｅｄ，ｐｌｅａｓｅ ｃｏｎｔａｃｔ ｔｈｅ ｓｅｌｌｅｒｏ
４、Ｉｎｓｔｒｕｍｅｎｔ ｉｎｄｉｃａｔｏｒ ｌｉｇｈｔ ｏｆｆ： Ａｄａｐｔｅｒ ｉｎｄｉｃａｔｏｒ ｌｉｇｈｔ ｉｓ ｏｎ； ｂｕｔ
ｉｎｓｔｒｕｍｅｎｔ ｌｉｇｈｔｓ ｏｆｆ．
Ｆａｉｌｕｒｅ ｄｉａｇｎｏｓｉｓ： ｓｈｏｒｔ ｃｉｒｃｕｉｔ ｏｆ ｐｏｗｅｒ ｌｉｎｅ．
Ｓｏｌｕｔｉｏｎ： ｏｐｅｎ ｉｎｓｔｒｕｍｅｎｔ， ｃｏｖｅｒ ｔｏ ｆｉｎｄ ｂｒｏｋｅｎ ｏｒ ｌｏｏｓｅ ｗｉｒｅｓ ｉｎｓｉｄｅ．
Ｉｆｐｒｏｂｌｅｍ ｓｔｉｌｌ ｃａｎ′ｔ ｂｅ ｒｅｓｏｌｖｅｄ， ｐｌｅａｓｅ ｃｏｎｎｅｃｔ ｗｉｔｈ ｓｅｌｌｅｒ．
