Weldability Sif SifLITE Revenge FXADF700 Series User manual
AUTO DARKENING
WELDING HELMET
Please read this manual carefully before using
User’s Manual
SifLITE Revenge FXADF700
Approved
www.weldability-sif.com
Peters House, The Orbital Centre
Icknield Way, Letchworth Garden City
Hertfordshire SG6 1ET
Tel. +44 (0) 845 130 7757
Technical specications
Helmet structural graph
Revenge series
ADF guide
FXADF700CART
Technical support
For further product information and technical support
please contact your local dealer
lIf there is any quality problem within 12 months of purchase,manufactur-
ers will provide free repair or replacement services.
lDamage as a result of improper use, or claims made after the warranty
period may be subject to charges.
Product guarantee
Colour
Red FXADF700A
Blue FXADF700B
Yellow FXADF700C
®
LITE
Abstract
Solar energy auto-darkening welding helmet is a set of spectral ltering
technology, photoelectric inductive control technology, liquid crystal
light control technology in one high-tech products. Auto darkening lter
(ADF) works with the photoelectric induction principle, which makes the
liquid crystal change from the bright state into a dark state in receiving
the arc light, and automatic back to dark state when welding is nished.
thereby protecting the user’s eyes and face skin from the arc, splash
and infrared / ultraviolet radiation.
1. BEFORE WELDING
lPlease check if the protective lm is been removed from the internal and
external screen.
lPlease check if the power is sufcient before using.
lPlease check if the lter display is normal.
lPlease check whether the protect lms are complete, solar cell is damaged
or blocked by dust, especially check whether the arc sensor is polluted.
lPlease check all operating parts are worn off or damaged. If any scratched
or broken parts, should be replaced immediately. So as not to incur any
personal injury.
lPlease check light tightness before each using.
lAccording to the machine type and welding current to choose the right
shade number.
Product features
lBy the lithium/alkaline battery and solar battery power supply, without
replacement, long service life of 5000 hours, 15-20 minutes with automatic
closing function, low voltage indication.
lIn the internal or external control knob, can be realized on the shading
9-13, sensitivity and delay time control, welding / grinding functions can be
selected.
l Photoelectric sensor technology, high-quality dual LCD and lter, which
provide the welder a clear eld of view and effective protection, ultraviolet ray
protection grade up to DIN16.
lTwo arc sensing probe, constantly sense arc induction in using, that enable
the lter switch time reach 1/25000s from light to dark state, so as to protect
the eyes from arc damage.
lFilter bright state grade is DIN4, it takes 0.1-1.0s by preset from dark state
to a bright state when arc disappear.
lNormal operation temperature is from minus 5 degrees to 55 degrees .
broad scope of application, such as manual arc welding, gas shielded arc
welding, argon arc welding and plasma cutting.
lPortable and balanced design, fully adjustable headgear, provides
comfortable wearing and relieves fatigue.
lProducts meets the safety and technical standard of EN379,
ANSI Z87.1, CSAZ94.3
Operation guide
2. SHADE NUMBER SELECTION
lShade number can be manually set from 9-13., adjusting knob is outside/
inside the mask, by rotating the adjusting knob to set the proper shading
number.
lAdjust the helmet to the correct shade for the welding process by referring
to Table 1.
3. DELAY TIME
Delay time,it’s for the helmet to switch back from full dark to full light.
according to the welding current and power length,by the “ DELAY” knob fast
or slow.
lChoose the minimum, the delay time is set in 0.1-0.25s, suitable for spot
welding, short welding or seam welding work.
lChoosing the maximum, the delay time is set in 0.85-1.0s. suitable for high
current welding or prevent eye fatigue from the arc.
lChoosing the medium, suitable for the majority of indoor and outdoor
welding operation.
4. SENSITIVITY
According to the welding process and the ambient light, through the
regulation of “ SENSITIVITY” knob for setting, default sensitivity is at the
lowest state
lChoose the Min, suitable for high current welding or in bright light
environment in welding, or from other sources interference environment. l
Choose the Max, suitable for low current welding or in low light environment
in welding, especially low current argon arc welding.
lMid-range selection, suitable for most in indoor and outdoor welding
5. WELDING / GRINDING SET
During the cutting or grinding, need to put the knob to the “Grind” position.
Note: some products without this feature, see the technical parameter table.
6. TEST
lSet the shading number at any place of 9-13, press the TEST button,
check whether the LCD change from light to dark, and automatic return to
bright state.
lFor the lter without self-test function, pis set the shading to any place
between 9-13 before use, then use the ordinary incandescent light source
more than 40W near to the arc sensor of lter, check whether the LCD
becomes dark, and automatically returned to the bright state after removing
the light source.
7. HEADBAND ADJUSTMENT
lHeadband size can be manually adjusted to t different people to wear.
Press the rotary gear moderately and adjust the tightness to feel comfortable.
The rotating gear has self-locking function, rotating forcibly is prohibited in
order to avoid damaging the gear.
lThere are positioning holes on the side of the helmet , through adjusting
the xed plate in lateral hole location, can change the angle
of sight, adjusting the angle of view
lBy adjusting the screw tightness, can change the face mask on angle, also
it can be turned up or down. The ideal angle in welding is eyes and joints
connected by straight line perpendicular to the lter.
8. BATTERY REPLACEMENT
lPart ADF use 2 pieces of 3V lithium battery, or 2 piecesAAA alkaline battery
as a backup power supply, part ADF use non-changeable battery. Note: waste
battery shall dump in accordance to local government laws and regulations
lters should be in accordance with the electronic waste material processing.
lThe battery can be used continuously for 5000 hours in normal condition.
The low voltage lamp doesn’t work when the power is sufcient and battery is
required to be replaced when the low voltage lamp is on.
Note: some products have no alarm function of low voltage.
9. MAINTENANCE
lPlease use tissues, lens paper or clean soft cotton cleaning the lter.
lPlease use neutral detergent to clean welding helmet shell and sweat bands.
lRegularly replace of external and internal protection plate, sweat bands.
lDo not use corrosive solvent or gasoline to dilute detergent.
10. ATTENTION
lThe auto-darkening welding helmet is not suitable to laser welding and
oxygen acetylene welding.
l Do not put weld cap and lter near heat or damp place.
lDo not remove the lter from the welding cap or open the lter box without
authorization.
lBefore operation, please conrm the welding or grinding function selection
is correct.
lThe protective plate must be installed to protect the lter away from damage.
lDo not make any amend or replacement of weld cap or ADF without
authorization.
lStop using immediately if the lter can’t change to dark and contact the dealer.
lDo not use alcohol, petrol or thinner to clean ller, do not immerse it in water.
lOperation temperature:-5’C - + 55 ‘C ( 23 ‘-131’ F, F) the reaction ofADF will
be slow down if the ambient temperature is too low. But ii does not affect the
protective performance.
lReplace protective lms immediately if it’s broken or scratched. Since it may
affect view and seriously reduce the protective performance.
lReplace protector immediately if it’s broken or scratched. Do not use hard
objects to contact lter lens surface, in order to prevent damage to the lter
lClean lter surface, sensors and solar cells regularly.
lHelmet can not prevent serious impact, explosive or corrosive liquid damage.
Note: serious personal injury will be incurred if users do not follow the above-
mentioned attentions
11. TROUBLSHOOTING
This manual suits for next models
