Wenger Select Lab User manual

Assembly Instructions
Select Lab Adjustable Height
Workstation
Visit the Music Lab Workstations web page at www.wengercorp.com.
Mobile version is shown.
Also available without casters.
Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Workstation Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Basic Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mobile Version Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Non-Mobile Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Optional Rackmount Shelf Assembly . . . . . . . . . . . . . . . . . . . . . . 23
Note: Please read and understand these instructions before starting the assembly.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2018 Printed in USA 2018-07 Part #225D098-02
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: [phone] • wengercorp.com

2
Important User Information
General
Copyright © 2018 by Wenger Corporation
All rights reserved. No part of the contents of this manual may be reproduced, copied, or transmitted in any form
or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information
storage and retrieval systems without the written permission of the publisher, unless it is for the purchaser’s
personal use.
Printed and bound in the United States of America.
The information in this manual is subject to change without notice and does not represent a commitment on the
part of Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may
appear in these instructions.
In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct,
indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions.
The manufacturer reserves the right to change this product at any time.
The information in this document is not intended to cover all possible conditions and situations that might occur.
The end user must exercise caution and common sense when assembling or installing Wenger Corporation
products. If any questions or problems arise, call the Wenger Corporation at (800) 4WENGER (493-6437)
or [phone] worldwide.
Manufacturer
The Select Lab Adjustable Height Workstation is manufactured by:
Wenger Corporation
555 Park Drive
Owatonna, MN 55060
(800) 4WENGER (493-6437) • [phone]
wengercorp.com
Intended Use
· This product is intended for indoor use in normal ambient temperature and humidity conditions —
it must not be exposed to prolonged outside weather conditions.
· This product is intended to be assembled and used only as described in these instructions.
Warranty
This product is guaranteed free of defects in materials and workmanship for ten full years from date
of shipment. A full warranty statement is available upon request.
Optional power strips, digital locks and other electronic equipment are covered by the
individual manufacturer’s warranty.

3
Required Tools
· Phillips Head Screwdriver
· Rubber or Plastic Mallet
· 3/8” Open-End Wrench or Socket
· Drill
· Side Cutter or Scissors
· 5/32” Hex Insert Bit (supplied)
· 1-3/4” Caster Wrench (supplied)
Safety Precautions
Make sure anyone
assembling the Select
Lab Workstation has read
and understands these
instructions.
!CAUTION
Failure to comply with
Warnings and Cautions in
this document can result
in damage to property or
serious injury.
Throughoutthismanualyoumayndcautionsandwarningswhicharedenedasfollows:
• WARNING means that failure to follow the instruction may result in serious injury or death.
• CAUTION means that failure to follow the instruction may result in serious injury or damage
to property.
Read all of these safety instructions before assembling the Select Lab Adjustable Height Workstation.
!CAUTION
To avoid damage and injury,
more than one person is
needed for assembly.
!CAUTION

4
Hardware Parts List
*Quantities may vary, extras can be discarded.
250A508._
7 x 50mm
Particle Board Screw
(color matched paint)
1
X003583
2-3/8” Grommet
X003706
2” 5-Knuckle
Hinge
X000045
#8 x 5/8”
Pan Head Screw
X002540
8 x 25mm
Wood Dowel
5
2
3
4
100A444
Corner
Bracket
6
X003074
Flush Mount
Handle
X000824
#8-18 x 3/8”
Sheet Metal Screw
X003600
Wiring Clamp
X001503
#10-16 x 3/4”
Sheet Metal Screw
7
8
9
X002971
1/4-20 x 1/2”
Carriage Bolt
11
X003110
1/4-20
Wing Nut
X001442
1/4 x 47/64”
Flat Washer
X001484
1-1/2” Plug
100A534
1-3/4” Caster Wrench
12 13
14 16
X000482
#8 x 5/8
Sheet Metal Screw
(used only on mobile version)
17
X003736
3.75 Dia x 2.50
Clevis Pin
225D234
Door Stop
Bracket
X003456
Push-In
Bumper
15
18
X003738
#6 x 3/4”
Flat Head Screw
20
X001162
#8 x 1-1/4”
Sheet Metal Screw
(used only on mobile version)
X001962
5/32” Hex
Insert Bit
X003751
8-32
Hex Nut
X002998
4” Nylon Tie
26
21 22
27
X003743
1/4-20 x 0.708”
Machine Screw
25
250A508
7 x 50mm
Particle Board Screw
(black paint)
28
10
19
250A515._
1/4-20
Cap Nut
(color matched paint)
23
250A515
1/4-20
Cap Nut
(black paint)
24

5
Workstation Components
Item Description Item Description
29 Shelf Wiring Panel 39 Standard Swivel Caster
30 Front Wiring Panel 40 Adjustable Keyboard Bracket
31 Back Panel 41 Bottom Fixed Shelf
32 Left Side Panel 42 Wiring Access Door
33 Right Side Panel 43 Sti󰀨ener
34 Desktop 44 Pullout Panel
35 Left Side Support Weldment 45 Headphone Mount
36 Right Side Support Weldment 46 Plain Channel*
37 Mobile Leg Tube 47 Non-Mobile Leg Tube*
38 Swivel Caster with Brake
31
33
35
32
34
37
39
41
38
40
42
44
45
*Used on
Non-Mobile Versions
Only
29 30 36
43
47
46

6
Basic Assembly
1. Connect the Shelf Wiring Panel (29) and Front Wiring Panel (30)
together using six Wood Dowels (5) and
veBlack 7 x 50mm Particle Board Screws (28).
2. Attach the Shelf Wiring Panel to the Back Panel (31)
usingveWoodDowels(5)and
four 7 x 50mm Particle Board Screws (1).
Shelf Wiring
Panel
(29)
Back Panel
(31)
Front Wiring
Panel
(30)
Wood Dowel
(5)
Black
7 x 50mm
Particle Board Screw
(28)
Wood Dowel
(5)
7 x 50mm
Particle Board Screw
(1)
The following assembly procedure shows the Mobile Version of the Adjustable
Height Workstation, the procedure is the same for the Non-Mobile Version unless
otherwise noted.

7
Basic Assembly (continued)
3. Attach four Wiring Clamps (9) to the Back Panel using four
#10-16 x 3/4” Sheet Metal Screws (10).
4. Attach two sets of 5-Knuckle Hinges (3) to the Back Panel using two
#6 x 3/4” Flat Head Screws (20).
Only one set of hinges will be attached if an optional Rackmount Shelf Accessory
will be installed.
Be sure that the screws are seated ush with the hinges.
Wiring Clamp
(9)
#10-16 x 3/4”
Sheet Metal Screw
(10)
This set of hinges will not be attached
if a Rackmount Accessory will be
installed.
5-Knuckle
Hinge
(3)
#6 x 3/4”
Flat Head Screw
(20)

8
Basic Assembly (continued)
5. Insert eight color matched 1/4-20 Cap Nuts (23) into the outside surface
of both the Left Side Panel (32) and Right Side Panel (33).
The outside of the Side Panels do not have dowel holes.
6. With the top facing up (the side without dowel holes), attach two sets of Door Stop Brackets (18)
to the back side of the Desktop (34) using two #8 x 5/8” Sheet Metal Screws (17) in each.
Only one set of brackets will be attached if anoptional Rackmount Shelf Accessory
will be installed.
7. Push/pull a Push-In Bumper (19) into each Door Stop Bracket.
Use two Bumpers where there will be adjoining Wiring Access Doors
Trimo󰀨theexcesstailsusingasidecutterorscissors.
Door Stop
Bracket
(18)
Push-In Bumper
(19)
#8 x 5/8”
Sheet Metal
Screw
(17)
Desktop
(34)
This set of brackets will not be
attached if a Rackmount Accessory will
be installed.
Color Matched
1/4-20
Cap Nuts
(23)
Dowel holes are in the
inside of the Side Panels.
Left
Side Panel
(32)
Right
Side Panel
(33)
Dowel holes face down.

9
8. Attach the Front Wiring Panel and Back Panel Assembly to the Right Side Panel (33)
usingthreeWoodDowels(5)andve7x50mmParticleBoardScrews(1).
Leave the Particle Board Screws loose until after Step #9.
9. Use more than one person to attach the Desktop to the Front Wiring Panel and
Right Side Panel using seven Wood Dowels (5) and three 7 x 50mm Particle Board Screws (1).
10. Tighten the Particle Board Screws installed in Step #8.
Basic Assembly (continued)
Desktop
Wood Dowel
(5)
7 x 50mm
Particle Board Screw
(1)
Tighten the
Particle Board Screws.
Right Side
Panel
(33)
Wood Dowel
(5)
7 x 50mm
Particle Board Screw
(1)
These two screws may need to
be removed to complete Step #9.
To avoid damage and injury,
more than one person is
needed for assembly.
!CAUTION

10
11. Attach the Left Side Panel to the Desktop, Back Panel and Front Wiring Panel using
six Wood Dowels (5) and eight 7 x 50mm Particle Board Screws (1).
12. Attach the Left and Right Side Support Weldments
to the Back Panel using
three #8 x 5/8” Sheet Metal Screws (17)
in each.
Left
Side Panel
(32)
Wood Dowel
(5)
7 x 50mm
Particle Board Screw
(1)
Basic Assembly (continued)
Left Side
Support Weldment
Right Side
Support Weldment
#8 x 5/8”
Sheet Metal Screw
(17)

11
1. Attach the Left Side Support Weldment (35) and
the Right Side Support Weldment (36) to the
Back Panel using three
#8 x 5/8” Sheet Metal Screws (17) in each.
2. Attach the Left and Right Side Support Weldments
to the bottoms of the Side Panels Back Panel
using four #8 x 1-1/4” Sheet Metal Screws (26)
in each.
3. Attach both Side Support Weldments
to each Side Panel using
one #8 x 5/8” Sheet Metal Screw (17).
Mobile Version Assembly
Left Side
Support Weldment
(35)
Right Side
Support Weldment
(36)
#8 x 5/8”
Sheet Metal Screw
(17)
The following assembly procedure shows how to assemble the Mobile Version
of the Adjustable Height Workstation.
For Non-Mobile Version Assembly, go to page 14.
#8 x 5/8”
Sheet Metal Screw
(17)
#8 x 1-1/4”
Sheet Metal Screw
(26)

12
Mobile Version Assembly (continued)
4. Attach the Left and Right Side Support Weldments
to the Nut Inserts in the Side Panels using
eight 1/4-20 x 0.708” Machine Screws (25)
in each.
5. Attach six Wiring Clamps (9) to the
Back Panel using six
#10-16 x 3/4” Sheet Metal Screws (10).
6. Using a mallet, tap 1-1/4” Plug (14) into the open end of
all four Mobile Leg Tubes (37).
1/4-20 x 0.708
Machine Screw
(25)
#10-16 x 3/4”
Sheet Metal Screw
(10)
Wiring Clamp
(9)
1-1/2” Plug
(14)
Mobile
Leg Tube
(37)

13
Mobile Version Assembly (continued)
7. Insert one Adjustable Leg Assembly with the Plug end
at the top through the bottom of all four of the
Side Support Weldment slots.
8. Attach the two Swivel Casters with Brakes to
the front of the Workstation and two
Standard Swivel Casters to the
Fixed Tubes using the supplied
Caster Wrench (16).
9. Set the height of the Adjustable Leg Tubes with a
3.75 Dia x 2.50 Clevis Pin (15). and skip ahead to “Final Assembly” on Page 16.
Adjustable
Leg Assembly
Standard Swivel
Caster
(39)
Swivel Caster
with Brake
(38)
3.75 Dia x 2.50
Clevis Pin
(15)

14
1. Attach six Wiring Clamps (9) to the
Back Panel using six
#10-16 x 3/4” Sheet Metal Screws (10).
2. Attach two Plain Channels (46) to the
Nut Inserts in both Side Panels using
four 1/4-20 x 0.708” Machine Screws (25)
in each.
Non-Mobile Version Assembly
The following assembly procedure shows how to assemble the Non-Mobile Version
of the Adjustable Height Workstation.
For Mobile Version Assembly, go to page 11.
Plain Channel
(46)
1/4-20 x 0.708”
Machine Screw
(25)
#10-16 x 3/4”
Sheet Metal Screw
(10)
Wiring Clamp
(9)

15
Non-Mobile Version Assembly (continued)
3. Using a mallet, tap a 1-1/4” Plug (14) into both open ends
of all four Mobile Leg Tubes (47).
4. Insert one Adjustable Leg Assembly with the Plug end
at the top through the bottom of all four of the
Plain Channel slots.
5. Set the height of the Adjustable Leg Tubes with a
3.75 Dia x 2.50 Clevis Pin (15). and skip ahead to “Final Assembly” on Page 16.
1-1/2” Plug
(14)
Non-Mobile
Leg Tube
(47)
Adjustable
Leg Assembly
3.75 Dia x 2.50
Clevis Pin
(15)

16
Final Assembly
1. Attach seven Corner Brackets (6) to the Desktop,
Side Panels and Front Wiring Panel using
#8 x 5/8” Pan Head Screws (4) in each.
2. Attach two Adjustable Keyboard Brackets (40)
tothebottomoftheDesktopusingve
#10-16 x 3/4” Sheet Metal Screws (10)
in each.
#8 x 5/8”
Pan Head Screw
(4)
Corner
Bracket
(6)
#10-16 x 3/4”
Sheet Metal Screw
(10) Adjustable
Keyboard
Bracket
(40)
The following assembly procedure shows the Mobile Version of the Adjustable
Height Workstation, the procedure is the same for the Non-Mobile Version unless
otherwise noted.

17
Final Assembly (continued)
3. This step is for the Mobile Version Only, does not apply to the Non-Mobile Version:
Insert four Black 1/4-20 Cap Nuts (24) into pilot holes in the the top of the
Bottom Fixed Shelf (41).
4. Tip the Assembly onto the Legs.
Bottom
Fixed Shelf
(41)
Black
1/4-20
Cap Nut
(24)

18
Final Assembly (continued)
5. Attach the Bottom Fixed Shelf (41).
Mobile Version Instruction (Non-Mobile Version on the following page):
a. Keep the narrower side of the Bottom Shelf at the same side as the Keyboard Brackets
(this leaves room for a computer tower on the wider side of the shelf).
b. WiththeCapNutsfacingup,tiptheShelftotontothebottomlipsofthe
Side Support Weldments.
c. Attach the Shelf to the Side and Back Panels using two Wood Dowels (5)
at the back and eleven 7 x 50mm Particle Board Screws (1).
d. Attach the Shelf to the Side Support Weldments on each side using
two 1/4-20 x 0.708” Machine Screws (25) into the previously installed Cap Nuts.
1/4-20
Cap Nut
1/4-20 x 0.708”
Machine Screw
(25)
Bottom Fixed
Shelf
(41)
Wood Dowel
(5)
7 x 50mm
Particle Board Screw
(1)
Bottom
Lip
1/4-20
Cap Nut
Narrower side
Wider side

19
Final Assembly (continued)
5. Attach the Bottom Fixed Shelf (41).
Non-Mobile Version Instruction (Mobile Version on the previous page):
a. Tip the Assembly onto the Back Panel.
b. Keep the narrower side of the Bottom Shelf
at the same side as the Keyboard Brackets
(this leaves room for a computer
tower on the wider side of the shelf).
c. TiptheShelftotoverthePlainChannels.
d. Attach the Shelf to the Side and
Back Panels using two
Wood Dowels (5) at the back and
six 7 x 50mm Particle Board Screws (1).
e. Tip the Assembly onto the Legs.
f. Attach the Shelf to the Back Panel on
each side using three
7 x 50mm Particle Board Screws (1)
into each Side Panel.
Bottom Fixed
Shelf
(41)
Wood Dowel
(5)
7 x 50mm
Particle Board Screw
(1)
Narrower side
Wider side
7 x 50mm
Particle Board Screw
(1)

20
6. Attach the Flush Mount Handle (7) to the longer Wiring Access Door (42)
using two #8-18 x 3/8” Sheet Metal Screws (8).
7. Attach a Wiring Access Door to each set of Hinges in the Back Panel using
two #6 x 3/4” Flat Head Screws (20).
Be sure that the screws are seated ush with the hinges.
Final Assembly (continued)
Flush Mount
Handle
(7)
5-Knuckle
Hinge
(3)
#8-18 x 3/8”
Sheet Metal Screw
(8)
Wiring Access
Door
(42)
#6 x 3/4”
Flat Head Screw
(20)
Wiring Access
Door
(42)
