Wersi SONIC OAX500LS User manual

OAX1 - OAX500 - OAX600 - OAX700
OAX800 –OAX900 - PERGAMON OAX1000
Operating Manual
Brand Owner and Development

Imprint & User Content
2Operating Manual
Imprint & User Content
Operating Manual for
Keyboard OAX1
Orgel OAX500LS
OAX600, OAX600LS
OAX700, OAX700LS
OAX800LS
OAX900
PERGAMON OAX1000
Software version on release:
V2.91
Date: 10. February 2023
OAX Ideas and Design: Ulrich Wildhack
OAX Programming: Ulrich Wildhack, Part time: Torsten Reichold, Tom Kolorz, Dennis Noppeney
Copyright © 2023 by
MUSIC STORE professional GmbH
Istanbulstraße 22-26
51103 Cologne
Germany
E-Mail: [email protected]
Website: www.wersi.net
All rights reserved.
We reserve the right to make technical changes to the hardware and software of the OAX instruments
without prior notice. We do not guarantee that all the properties described in this manual will be consistent
with those of an OAX instrument currently delivered.
Reproduction, translation, microfilming as well as storage and processing in electronic systems is not
permitted without our express consent and violates the copyright law.

OAX-System 3
User Content
Imprint & User Content................................................................................................................ 2
1Safety instructions...................................................................................................... 8
2Legal notices...............................................................................................................9
3First commissioning.................................................................................................. 10
3.1 Connections.........................................................................................................................10
General connections behind the cover flap...................................................................................10
Additional connections OAX500 - OAX600.....................................................................................11
Additional connections OAX700.....................................................................................................11
Additional connections OAX800 –OAX900 - OAX1000..................................................................11
3.2 Connect...............................................................................................................................12
3.3 Switching on and off ............................................................................................................13
Turn On...........................................................................................................................................13
Switch off........................................................................................................................................13
Switch off/restart (reset)................................................................................................................13
3.4 Connections/controls at the front ........................................................................................14
Headphone.....................................................................................................................................14
Pitch Bend and Modulation Controller ..........................................................................................14
USB-Connecters..............................................................................................................................14
DVD/Blu-ray-Drive (not OAX1) .......................................................................................................15
3.5 Remote control for LED-light control in music desk (not OAX1) ............................................16
4Overview of the control panels................................................................................. 17
4.1 Tempo/Data Wheel and Transposer.....................................................................................17
4.2 Select sounds via the control panel buttons..........................................................................18
Subcategories for each sound button............................................................................................20
Favorites for each sound button....................................................................................................20
Own mapping for each sound button ............................................................................................21
4.3 Selecting the Drawbars Live and Drawbars Presets ..............................................................21
Switching between the different organ models.............................................................................22
Your favorites of all organ types on the mapping..........................................................................23
Selecting self-saved drawbar sounds via the mapping ..................................................................24
Create your own mapping for the live drawbars ...........................................................................24
4.4 Select Total Presets..............................................................................................................25
4.5 Switch on or off the sounds on the manuals .........................................................................25
OAX1 –OAX500 - OAX600 - OAX700..............................................................................................25
OAX800 –OAX900..........................................................................................................................26
PERGAMON OAX1000 ....................................................................................................................26
4.6 Global Manual Controls .......................................................................................................27
Global Manual Controls for OAX1 - OAX500 - OAX600 - OAX700..................................................27
Global Manual Controls for OAX800 - OAX900 - OAX1000............................................................28
4.6.2.1 Preset Edit.................................................................................................................................29
4.6.2.2 Manual Edit...............................................................................................................................29
Description of the General Global Manual Controls......................................................................32
4.6.3.1 WERSIChord..............................................................................................................................32
4.6.3.2 LM-Hold (OAX1 –OAX500 –OAX600 –OAX700) .....................................................................32
4.6.3.3 Fast operation Reverb...............................................................................................................33
4.6.3.4 Fast operation Chorus...............................................................................................................35
4.6.3.5 Fast operation Delay.................................................................................................................36

Imprint & User Content
4Operating Manual
4.7 Accompaniments Styles .......................................................................................................37
Subcategories for each Accompaniment button ...........................................................................38
Favorites for each Accompaniment button ...................................................................................39
Own mapping for each Accompaniment button ...........................................................................39
4.8 Accompaniments MIDI and AUDIO.......................................................................................40
ACC Controls OAX1 - OAX500 - OAX600 - OAX700 ........................................................................40
ACC Controls OAX800 - OAX900 - OAX1000 ..................................................................................41
Sound To Styles (only OAX1 - OAX500 - OAX600 - OAX700)..........................................................41
4.9 Effect-Sounds ......................................................................................................................42
4.10 User panel Accompaniment Controls....................................................................................43
4.11 User panel General Volume, Microphone and Light ..............................................................45
OAX1...............................................................................................................................................45
OAX500 ..........................................................................................................................................45
OAX600 –OAX700..........................................................................................................................46
OAX800 –OAX900 - OAX1000........................................................................................................46
OAX800UP - OAX1000UP ...............................................................................................................47
4.12 Control manual volumes ......................................................................................................47
Volume of sounds on manuals for OAX1 - OAX500 - OAX600 - OAX700.......................................48
Volume of the sounds on the manuals for OAX800 -OAX1000 .....................................................48
Volume of the sounds on the manuals for OAX1000 ....................................................................48
Volume of Styles, MIDI-Sequences and Multimedia-Files.............................................................49
4.13 Pitch- and Modulation .........................................................................................................49
Wheels for OAX1 - OAX500 - OAX600 - OAX700 - OAX800 –PERGAMON OAX1000 ....................49
Wheels for OAX1000UP .................................................................................................................49
5Live organ –Live Accordion –Church Organ...............................................................50
5.1 The WERSI OX7....................................................................................................................50
Main page OX7...............................................................................................................................50
Additional setting options..............................................................................................................53
5.2 The WERSI VB3 ....................................................................................................................55
Main page VB3...............................................................................................................................55
VB3 Rotor-Settings.........................................................................................................................58
5.3 Legendary FARFISA Compact Organ......................................................................................60
Main page of the FARFISA Compact ..............................................................................................60
Advanced settings for the FARFISA Compact.................................................................................61
Standard controller of the FARFISA organ.....................................................................................63
5.4 Your favorites of all organ types on the mapping..................................................................64
5.5 Saving your own drawbar settings........................................................................................65
Saving your own drawbar sounds..................................................................................................65
Selecting self-saved drawbar tones via the mapping ....................................................................65
Selecting Live Drawbar sounds via the sound list..........................................................................66
5.6 Live Organ or Mini Organ in Profi Display..............................................................................67
Die Mini Displays............................................................................................................................67
Show Live organ.............................................................................................................................68
Factory presets as a demonstration...............................................................................................68
5.7 The Live Controls OX7 and VB3.............................................................................................69
The Live Controls OAX1 - OAX500 - OAX600 - OAX700..................................................................69
The Live Controls OAX800 –OAX900 - OAX1000...........................................................................70
5.8 Accordion LIVE operation.....................................................................................................71

OAX-System 5
5.9 Silbermann Church Organ ....................................................................................................75
Historical Information ....................................................................................................................75
Quickly select the Silbermann organ via the Total Presets............................................................76
How can you make music with the Silbermann organ?.................................................................77
5.9.3.1 Historical View 1 .......................................................................................................................79
5.9.3.2 Modern view 2..........................................................................................................................80
5.9.3.3 Church acoustics.......................................................................................................................80
Register the manuals on your organ ..............................................................................................81
Possibilities of the standard and sound controller.........................................................................82
Save registrations in a Total Preset................................................................................................83
6The simple EASY display or the PROFI display ........................................................... 84
7The EASY-Display...................................................................................................... 85
7.1 Overview upper, lower and pedal ........................................................................................86
The OAX1000 with three manuals..................................................................................................86
7.2 The EASY Manual Controller.................................................................................................87
7.3 The accompaniment in the EASY Mode ................................................................................90
Styles Settings.................................................................................................................................90
7.3.1.1 Chord recognition.....................................................................................................................90
7.3.1.2 Style Volumes ...........................................................................................................................92
Settings for MIDI sequences...........................................................................................................93
7.4 Play Styles, MIDI-Sequences or Multimedia-Files directly from the USB stick.........................95
7.5 Import styles from USB stick ................................................................................................96
7.6 Import MIDI-Sequences or Multimedia-Files from the USB stick............................................97
8The PROFI-Display .................................................................................................... 98
8.1 Easy split point for the lower manual (two-manual models)................................................100
Instructions for using the Easy Split .............................................................................................100
Set Easy Split.................................................................................................................................101
8.2 Keyboard split point only for OAX1 keyboard .....................................................................103
8.3 Up to 16 sounds in PROFI mode ......................................................................................... 104
8.4 Profi Manual Controls........................................................................................................ 108
The Standard Controls..................................................................................................................111
The Sound Controls ......................................................................................................................112
Dynamic, expression pedal, volume, and modulation curves......................................................113
8.4.3.1 Select dynamic, expression pedal, volume, or modulation preset.........................................115
8.4.3.2 Recreate dynamic, expression pedal, volume, and modulation curves.................................116
8.4.3.3 Save your own newly-changed curve.....................................................................................118
Further adjustment options .........................................................................................................118
Special Settings for the Live Organ Models..................................................................................119
8.5 Profi ACC-Controls .............................................................................................................120
Styles Settings...............................................................................................................................120
8.5.1.1 Range of chord recognition ....................................................................................................121
8.5.1.2 Chord recognition...................................................................................................................122
8.5.1.3 Style Volumes .........................................................................................................................123
8.5.1.4 More ACC Settings (Styles and MIDI-Sequences)...................................................................124
Settings for MIDI-Sequences........................................................................................................126
8.5.2.1 Settings Karaoke .....................................................................................................................128
Settings for Multimedia-Files .......................................................................................................129

Imprint & User Content
6Operating Manual
8.6 Settings .............................................................................................................................130
8.7 Volume control in PROFI mode...........................................................................................132
8.8 WERSIChord ......................................................................................................................133
8.9 Sound list ..........................................................................................................................133
General notes on the sound list...................................................................................................133
Load sound onto a selector..........................................................................................................134
Finding sounds .............................................................................................................................135
Import of new sounds..................................................................................................................136
8.10 Accompaniment List ..........................................................................................................137
The 16 main groups......................................................................................................................137
The subgroups..............................................................................................................................138
Load ACC to play via the list.........................................................................................................138
The list of accompaniments.........................................................................................................139
Find Styles, MIDI-Sequences or Multimedia-Files........................................................................140
Importing your own accompaniments.........................................................................................141
Sort your own accompaniments..................................................................................................143
8.10.7.1 Sort your own accompaniments on the eight USER subgroups ........................................143
Assign your own styles to the 12 style groups or change the existing assignment.....................145
Rename accompaniments............................................................................................................145
Exporting accompaniments .........................................................................................................145
8.11 Effects ...............................................................................................................................146
Set an effect preset as default or global......................................................................................147
General operation of effect programming ..................................................................................147
Set and save your own effects presets ........................................................................................148
8.11.3.1 The Reverb 1 and Reverb 2 programs................................................................................149
8.11.3.2 The Chorus .........................................................................................................................150
8.11.3.3 The delay............................................................................................................................151
8.12 CD-Player (not OAX1).........................................................................................................152
8.13 Audio Recorder..................................................................................................................153
9Select and save TOTAL PRESETS...............................................................................155
9.1 Overview Total Presets ......................................................................................................155
Select Total Presets via Bank Names ...........................................................................................155
Select Total Presets via List..........................................................................................................157
Save your own Total Presets........................................................................................................158
Save sheets in Total Preset ..........................................................................................................161
Total Preset Live-Settings.............................................................................................................163
9.2 The Music Archive..............................................................................................................164
Open and close the music archive ...............................................................................................164
Choosing a title.............................................................................................................................165
Find specific titles.........................................................................................................................166
Creating favorites.........................................................................................................................168
Add your own songs to the music archive...................................................................................169
Edit your own Total Presets in the Music Archive. ......................................................................170
10 Changing mapping for sounds and accompaniment .................................................171
10.1 Create or edit your own mapping .......................................................................................171
Map a Sound or Accompaniment ................................................................................................172
Delete individual mapping ...........................................................................................................173
Swap mapping places...................................................................................................................174
Delete Mapping for a button .......................................................................................................174

OAX-System 7
10.2 Create your own mapping for the live drawbars .................................................................175
10.3 Delete or freeze Favorites .................................................................................................. 178
Freeze favorites............................................................................................................................178
Delete favorites for a button........................................................................................................179
10.4 Global mapping an favorite settings ................................................................................... 180
Direct select and mapping selection ............................................................................................180
Delete all favorites .......................................................................................................................182
Delete all your own mappings......................................................................................................183
10.5 Special Settings for the Live Organ Models ......................................................................... 184
Select start mapping.....................................................................................................................184
Mapping selection........................................................................................................................185
11 Sound To Style (STS) ............................................................................................... 188
11.1 Using STS-Presets...............................................................................................................188
Using STS-Presets without Easy-Split ...........................................................................................188
Play STS-Presets with Easy-Split...................................................................................................188
11.2 User-STS Presets................................................................................................................ 190
User-STS Presets for own Accompaniments ................................................................................190
Own STS Preset for Factory-Styles ...............................................................................................190
Save USER-STS Presets .................................................................................................................191
Changing already saved USER-STS presets...................................................................................192
Deleting USER-STS Presets ...........................................................................................................192
Exporting and importing accompaniments with USER-STS presets.............................................193
12 Activations ............................................................................................................. 194

Safety instructions
8Operating Manual
1Safety instructions
If possible, read the entire operating manual - or at least these instructions and the chapter: "First
commissioning" - before putting the instrument into operation.
For your own safety, be sure to follow the basic precautions described below to avoid the risk of serious
injury or even fatal accidents, electric shocks, short circuits, damage, fire or other hazards.
These precautions include the following points, but they do not constitute a complete list or a final list.
Power supply
1. Use only the correct power supply required for the instrument.
2. Check the power supply with all connectors and the power cord at regular intervals for damage and
contamination.
3. Never place the power supply cables near strong heat sources such as heat eras or the like, do not
bend it excessively, do not place heavy objects on it and do not place it in places where you can step
on it, stumble over it and over it could roll.
4. Always pull the power cord on the plug and never on the cable from the socket to avoid damage.
5. If possible, do not connect the instrument to multiple sockets if other high-performance devices,
such as lighting systems, are already running over it.
6. During prolonged absence or thunderstorms, disconnect the power cord from the power outlet to
avoid damage caused by, for example, surges.
Installation site - Danger from water - Cleaning
Place the instrument in a stable place.
Avoid setting-up locations near strong heat sources or places that are subject to a sharp change in
temperature or humidity.
Ensure that the instrument on its back always has flawless ventilation.
Never place the instrument in close proximity to powerful radios such as fluorescent tubes,
televisions, mobile phones and others to avoid radiation that causes noise and degradation of sound
quality in your instrument can.
Do not place open flames (candles) or drinks on the instrument.
If electrically conductive objects or a liquid enter your instrument, immediately turn off
the instrument and unplug the power plug!
Do not return the instrument to operation until it has been inspected by a qualified WERSI customer service
technician. Never try to open the instrument yourself and make repairs or technical changes yourself.
Never put your instrument into operation immediately if you have just brought it from an unheated
environment (e.g. car) into a warm room. Wait until the instrument reaches room temperature to
avoid electrical damage from condensation and creep currents.
To clean your instrument, use only a soft cloth, at most slightly moistened, and not chemical
detergents or cleaning cloths.

OAX-System 9
2Legal notices
Software Copyrights
Their instrument comes from the latest generation of the WERSI-OAX series. The central control of all
functions is carried out and controlled by a PC system equipped with the Microsoft WINDOWS® 10 operating
system. The instrument is used to supply various PC programs that are copyrighted by either the
manufacturer or other companies. You will only receive these programs with the right to use them
exclusively on your instrument. The operation on other PC systems or instruments, the copying of the
programs (except for security purposes) as well as the transfer to third parties is expressly prohibited,
constitutes a violation of copyright and is therefore punishable. The license terms for the WINDOWS®
operating system can be found in the original documentation of Microsoft®.
Music Copyrights
Please also observe the copyright provisions for the public reproduction of protected music. This applies both
to the pieces of music you play yourself and to pieces of music that you play either from an audio CD or as an
MP3 or MIDI file through your instrument.
Warranty and notes on the operating system and hardware
Within the scope of the statutory provisions, the manufacturer assumes the warranty for instruments in
the unchanged hardware and software equipment supplied by the manufacturer.
The hardware used is controlled by the SystemCode and is calculated from all components used in
your instrument. The System Code is a distinctive fingerprint of your instrument. If components
(boards, RAM, processor ....) are replaced in your instrument, the System Code changes- This will
cause activations to be lost and the instrument will no longer be usable.
We expressly point out that in the event of malfunctions that have arisen:
by installing additional software programs that have not been supplied or expressly authorized by
WERSI and released for use and are therefore not compatible with or not used for the operating
system due to, for example, the current version of WINDOWS® programmed so-called "drivers"
by installing components that do not work optimally with the WERSI-OAX system
by installing replacement and auxiliary components not supplied by WERSI
warranty claim expires.
Therefore, before planning to install or install "foreign" software or hardware,
be sure to contact WERSI first.
In addition, it is extremely important for your instrument to function correctly that the entire WERSI folder,
including its subfolders, and the WINDOWS folder are not modified on the hard drive. No files and folders
may be deleted, moved and no other files stored in it (except for official software updates).
In case of malfunctions after interventions in the WINDOWS file system, only a modified
WERSI/WINDOWS version may be reinstalled!
Since in this case your self-created data is deleted, you always ensure a data backup –at appropriate
intervals or after larger storages!

First commissioning
10 Operating Manual
3First commissioning
3.1 Connections
General connections behind the cover flap
The connectors of the instrument can be found behind a flap on the back of the instrument. Use the two
handles on the right and left sides of the back to open. There you will find the following connections:
3 x DIN connectors (5-pin) connectors for MIDI 1 IN/THRU/OUT
3 x DIN connectors (5-pin) connectors for MIDI 2 IN/THRU/OUT
MIDI over USB (The OAX1 and OAX500 instruments do not have a "MIDI Over USB" port)
2 x mono outputs LINE OUTPUT 1 with LEFT (left channel) + RIGHT (right channel)
2 x mono outputs LINE OUTPUT 2 with LEFT (left channel) + RIGHT (right channel)
Connection of threshold via Sub-D jack with two side foot switches (is already wired)
Connection 17-button pedal via Sub-D jack (is already wired)
OAX 1 –OAX500
1 x asymmetrical microphone input via 6.35 mm jack
2 x asymmetrical mono inputs LINE INPUT 1 with LEFT (left channel) + RIGHT (right channel) via 6.35
mm jack
