WERTHEIM PETS W1000 User manual

High Performance
Bagged Vacuum Cleaner
User Manual
PETS W1000

1
PETS W1000
INTRODUCTION
Congratulations on the purchase of your new Wertheim vacuum
cleaner. There are many useful features built into your cleaner and
we recommend that you carefully read this instruction manual so
that you may take best advantage of them.
Due to our program of continuous product improvement and
innovation, sometimes the product you buy may dier slightly
from the one shown on this product carton/manual.
Handle
Hose
Telescopic Tube
On/O Button
Speed Control Dial
Cable Rewind Button
Hose Inlet
Carry Handle
Combination Floor Tool
Crevice Tool
Dusting Brush
Upholstery Tool
Hand Turbo Brush
1
2
3
4
5
6
7
8
9
10
11
12
13
1
2
3
45
6
Features
Specications
7
8
11
12
13
10
9
Wattage: 1800W
Dust Capacity: 2L
Noise Level: <77dBa
Telescopic Tube: Chrome
Power Cable Length: 5m
Hose Length: 1.5m
Net Weight: 7.2kg

32
PETS W1000
Precautionary measures:
1. Do not operate the vacuum cleaner too close to heaters, radiators,
and other hot surfaces.
2. Before inserting the plug into the wall, make sure your hand is dry.
3. Before turning on the vacuum cleaner, remove any large or sharp
objects from the oor or cleaning surface in order to prevent
damage to the lter.
4. When you want to pull the plug from the wall, do not pull the power
cable, gently pull the plug from the power socket.
5. Do not use vacuum cleaner to pick up water or liquids.
If the air inlet, oor head or telescopic wand are blocked, you should switch o
the cleaner straight away and remove from mains power. First clear the blocked
substance before attempting to start the vacuum cleaner again.
BEFORE YOU BEGIN
The cleaner must be operated in accordance with these instructions
and used only for domestic household cleaning to remove DRY dirt and
dust from household carpets, ooring and fabrics. This cleaner is not t to
be used as an industrial cleaner, and is not designed for the collection
of vitreous building material including particle board, construction
products and similar products such as wood/bres, cement, llers, bre
glass etc or excessive or frequent sand. The infrequent pick-up of these
materials in these circumstances may be harmful to your cleaner and
may void the manufacturer’s warranty.
Please read these instructions thoroughly
This will ensure you obtain full benet from your new cleaner.
Keep this instruction manual in a handy place for future reference.
To reduce the risk of re, electric shock, or injury:
1. Do not leave the appliance connected to the mains power
supply when not in use. Disconnect from any power supply before
performing any maintenance duties.
2. To reduce the risk of electric shock, do not use outdoors or on
wet surfaces.
3. This appliance must not be used as a toy. Do not allow children to
use the appliance unattended.
4. Use only as described in this instruction manual. Do not use for any
other purpose except those outlined in this instruction manual.
5. If the power cable or plug appears damaged, do not use. If the
vacuum cleaner is not working correctly, has been dropped,
damaged, left outdoors, or dropped into water, please contact
Customer Care: 1800 815 270 or email [e-mail]
6. Do not pull or carry the appliance by the power cable, use the power
cable as a handle, or pull the power cable around sharp edges or
corners. Avoid running the appliance over the power cable.
7. Keep the appliance away from heated surfaces.
8. Unplug the appliance by grasping and pulling the plug from the
wall. Do not unplug the machine by pulling on the power cable.
9. Do not handle the appliance and/or power cable with wet hands.
10. Always ensure that all openings and entry points on the appliance
are clear from objects or any blockages before commencing use.
Removal of dust, lint, hair and dirt from all openings and entry points
will help improve airow on the appliance.
SAFETY INSTRUCTIONS

54
PETS W1000
11. Keep hair, loose clothing, ngers and all body parts away from
openings and entry points on the appliance.
12. Ensure the appliance is switched o before unplugging.
13. Use extra care when cleaning on stairs.
14. Do not use the appliance to pick up ammable items or
combustible liquids (i.e. petrol, hot ashes, cigarettes, matches or
anything burning) or use in areas where such substances and items
may be present.
15. Hold the plug when rewinding onto cord reel. To prevent accidental
injury do not allow the plug to whip when rewinding.
16. Ensure the appliance is disconnected from the mains power supply
before connecting the hose to the unit.
17. Do not use the appliance without dust bag and/or lter in place.
18. If the power cable is damaged, do not use and contact
Customer Care: 1800 815 270 in order to avoid a hazard.
19. Do not extend the power cable beyond the red mark.
20. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
21. If using an extension cord please make sure that it is of an approved
type and that it is fully extended. Failure to do so could cause your
cleaner to overheat and damage it.
SAFETY INSTRUCTIONS CONT’D INSTRUCTIONS FOR USE
Before using, unwind a sucient length of cable and insert the plug into
the power socket. A yellow mark on the power cable shows the ideal
cable length. Do not extend the cable beyond the red mark.
1. Connect the hose to the cleaner
at the hose inlet.
2. Insert the telescopic tube into the
combination oor head.
3. Fit the other end of the
telescopic tube to the handle.

76
PETS W1000
Assembling Your Cleaner
The cleaner should be switched o and disconnected from the mains
power supply before you start to assemble.
1. Do not extend the power cable
beyond the yellow mark.
2. Press the On/O button to switch
the appliance on.
3. Rotate the speed control dial to
adjust the suction of the vacuum.
INSTRUCTIONS FOR USE (cont’d)
Combination
Floor Tool
Ideal for daily
cleaning on carpets
and hard oors.
Mini Hand Turbo Brush
Ideal for picking up pet hair on upholstery.
Note: The mini hand turbo brush adaptor
must be used to t the rod to the accessory.
1. Insert the smaller end of the adaptor into
the end of the mini hand turbo brush.
2. Insert the larger end of the adaptor into the
end of the telescopic wand.
3. The mini hand turbo tool is now ready to be used with the vacuum.
Note: By unlocking the side release buttons, the external bristles can be
rotated to face upwards allowing a closer clean as required.
Safety Precautions:
1. Keep hair, hands and feet away from rotating brush while the mini
hand turbo brush is running.
2. Remember the mini hand turbo brush will operate whenever it is
connected to a running vacuum. If children are present, make sure
to turn the vacuum system o when leaving the mini hand turbo
brush unit unattended.
3. Do not attempt to service or unclog the mini hand turbo brush while
the unit is running.
Cleaning on carpet Cleaning on hard oors

98
PETS W1000
Accessories
1. Crevice tool is used for radiators, crevices, corners, baseboards
and between cushions.
2. Dusting brush is used for the furniture, venation, blinds, book, lamp
shades and shelves.
3. The upholstery brush is used for cleaning furniture and upholstery.
Crevice tool Dusting brush Upholstery brush
INSTRUCTIONS FOR USE (cont’d) MAINTENANCE
WARNING: ENSURE THE CLEANER IS NOT CONNECTED
TO THE MAINS POWER SUPPLY WHEN PERFORMING ANY
MAINTENANCE PROCEDURES.
Step 1: Unlock the neck on the mini hand turbo brush by twisting
anti-clockwise.
Step 2: Push the release buttons on the side of the mini hand
turbo brush down to unlock the external bristles. Rotate this bristle
attachment upwards.
Step 3: Remove the clear cover.
Mini Hand Turbo Brush
Step 4: Remove any dirt or hair
from the roller brush.
Step 5: Replace the clear cover.

1110
PETS W1000
1. Pull the dust bag and lter supporter upward and remove the lter.
2. Rinse the lter in lukewarm water and dry the lter completely
before retting to the cleaner.
3. Place the lter back into the appliance.
5. Open the cover for the HEPA lter by the tabs at the rear of
the appliance.
6. Pull HEPA out and replace with a clean or new lter and replace
cover. Filters should be replaced at least once a year or when
they become visibly dirty.
Filter Maintenance
The HEPA lter should be replaced when clogged or at least once a
year. Do not use cleaner without the lters tted as it will cause damage
to the cleaner.
MAINTENANCE (cont’d)
This dust bag has a unique sealing system locking in the dust, making disposal
easier, and ensuring no allergens are returned to the room.
1. Open the front cover and rotate the bag support to the correct position.
Remove dust bag.
2. Replace the dust bag when it is full with a new dust bag.
3. Close the cover by pressing down until it is locked.
Mini Hand Turbo Brush (cont’d)
Changing the Dust Bag
Step 6: Lock the neck on the mini hand
turbo brush by twisting clockwise.
Step 7: Rotate the external bristles down
and lock the side release buttons by
pushing upwards.

1312
PETS W1000
Filter Set - Inlet and HEPA Exhaust 32200838
Dust Bag 4pk 33400174
Hose Assembly 31220375
Rod, telescopic 31300417
Bag Holder 33101192
Motor 33300667
TROUBLESHOOTING
Service problems that appear to be major can often be solved easily. You
can be your own troubleshooter by reviewing this guide. All other servicing
should be done by an authorised service agent or qualied technician.
SPARE PARTS
Problem Remedy
The cleaner will not
turn on.
Check that the power cable is inserted securely;
remove from the power supply and then reinsert into
the power supply. Check that the on/o button is in
the“ON” position.
The vacuum
performance is
deteriorating.
Check the appliance to ensure there are no blockages.
Clear any blockages that may be found. Check that
the motor inlet lter sponge is not dusty; frequently clean
or replace the motor inlet lter and air outlet HEPA lter.
The cleaner makes
an abnormal sound
when switched on.
Turn o the cleaner immediately.
Check the appliance to ensure there are no
blockages. Clear any blockages that may be found.
This warranty on your cleaner commences
from the original date of purchase and is not
transferable; please retain your original proof of
purchase for any warranty claims. This warranty
is valid only in the country where the cleaner
is purchased.
The cleaner must be operated in accordance
with these instructions and used only for domestic
household cleaning to remove DRY dirt and dust
from household carpets, ooring and fabrics.
This cleaner is not t to be used as an industrial
cleaner, and is not designed for the collection
of vitreous building material including particle
board, construction products and similar products
such as wood/bres, cement, llers, bre glass
etc or excessive or frequent sand. The infrequent
pick-up of these materials in these circumstances
may be harmful to your cleaner and may void the
manufacturer’s warranty.
Accessories and consumables including dust
bags and lters, unless defective in manufacture,
are not subject to this warranty. In order to prolong
the life of accessories and consumables, regular
care and maintenance is recommended.
When properly used and cared for, your
cleaner will render excellent service; refer to the
instruction manual for further details, as misuse
or failure to follow the instructions makes this
warranty void.
In the event of service or advise being needed,
please contact International Cleaning
Solutions Pty. Ltd. Level 1, Building 2, Brandon
Business Park, 530 Springvale Road, Glen
Waverley Victoria 3150, AUS: 1800 815 270,
NZ: [phone], Monday – Friday, 9am-5pm
EST. Email: [email protected]
The decision to repair or replace the cleaner is
at the sole discretion of International Cleaning
Solutions Pty Ltd.
International Cleaning Solutions Pty Ltd is
unable to accept responsibility under this
warranty for any repair work not carried out by
an authorised International Cleaning Solutions
Service Agent or from the use of non-genuine
parts. If any part is no longer available or
manufactured, International Cleaning Solutions
Pty Ltd will replace it with a genuine functional
replacement part. This warranty does not apply
to the cost of replacing any parts of the product
due to normal wear and tear, alterations,
improper installation, physical abuse, misuse or
accidental damage. Any transportation costs
involved in the repair of defective parts shall be
borne by the claimant.
If proof of purchase cannot be provided at the
time of a warranty claim or service, any work
carried out on the cleaner is chargeable. The
repair or replacement of the cleaner under this
warranty does not extend the original period
of warranty.
The benets conferred by this warranty are
in addition to all other rights and remedies
in respect of the product as outlined under
the Trade Practises Act and other State and
Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund for
a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.”
SAVE TIME, REGISTER WARRANTY ONLINE!
www.wertheim.net.au and www.wertheim.co.nz

14
International Cleaning Solutions Pty. Ltd.
ACN 119 462 798
Level 1, Building 2, Brandon Business Park
530 Springvale Road,
Glen Waverley, Victoria 3150
www.wertheim.net.au
www.wertheim.co.nz
[e-mail]
V1 02/15
